Planet IGS-5227X-4P2T User manual

Industrial IP67-rated 4-Port 10/100/1000T 802.3at PoE
+ 2-Port 10/100/1000T Managed Ethernet Switch
IGS-5227X-4P2T
Quick Installation Guide

Table of Contents
1. Package Contents ....................................................................................... 3
2. M12 X-coded Connector Pin Assignment ....................................................... 4
3. M12 (8-pin, X-coded Male) to RJ45 (8-pin) Straight-through UTP Cabling ........ 5
4. Connecting M12 Cable to the Industrial Managed PoE+ Switch ....................... 6
5. M23 DC Power Cable Pin Assignment ........................................................... 8
6. Requirements ............................................................................................. 9
7. Starting Web Management .........................................................................10
7.1 Logging in to the Industrial Managed PoE+ Switch ................................11
 7.2 SavingConguration...........................................................................13
8. RecoveringBacktoDefaultConguration.....................................................14
9. Customer Support .....................................................................................15

3
1. Package Contents
Thank you for purchasing PLANET Industrial IP67-rated 4-Port 10/100/1000T
802.3at PoE + 2-Port 10/100/1000T Managed Ethernet Switch.
“Industrial Managed PoE+ Switch” mentioned in this Quick Installation Guide
refers to the above model.
Open the box of the Industrial Managed PoE+ Switch and carefully unpack it. The
box should contain the following items:
Item/Model IGS-5227X-4P2T
The Industrial Managed PoE+ Switch 1
Quick Installation Guide 1
Waterproof/dustproof Power Cap 1
Waterproof/dustproof M12 Caps 6
2m 8-pin X-coded M12-to-RJ45 UTP Cable 1
DIN-rail Kit 
Wall-mount Kit 
If any item is found missing or damaged, please contact your local reseller for
replacement.

4
2. M12 X-coded Connector Pin Assignment
The Industrial Managed PoE+ Switch front panel provides six 10/100/1000BASE-T
Ethernet ports in the form of M12 8-pin X-coded female connector. These ports
are designed for Ethernet equipment connection through Cat5/5e UTP cables. The
M12 8-pin X-coded input interface pinout is shown below:
Pin Con
1DA+
2DA
5
8
3DB+
6
7
DD+
DD
DC
DB4
DC+
6
3
7
2
4
5
1
8
8-pin M12 X-coded Female 10/100/1000T Connector Pin Assignment

5
3. M12 (8-pin, X-coded Male) to RJ45 (8-pin)
Straight-through UTP Cabling
M12 X-coded Male
Connector Pin No.
MDI
1000BASE-T Signal ID T568B Color RJ45 Connector
Pin No
1BI_DA+ white/orange 1
2BI_DA- orange 2
3BI_DB+ white/green 3
4BI_DB- green 6
5BI_DD+ white/brown 7
6BI_DD- brown 8
7BI_DC- White/blue 5
8BI_DC+ blue 4
Note
As each Ethernet port of the Industrial Managed PoE+ Switch is
running in auto negotiation mode, make sure the Ethernet ports of
the corresponding Ethernet devices are also running in auto nego-
tiation mode; otherwise, the Ethernet performance will be poor.

6
4. Connecting M12 Cable to the Industrial Managed
PoE+ Switch
Step 1: Turn counterclockwise to remove the waterproof caps of an M12
connector and M23 power input.
Step 2: Insert the M12 UTP male connector into the M12 female Gigabit Ethernet
port of the Industrial Managed PoE+ Switch.
Step 3: Turn clockwise to tighten the connection to the M12 connector.

7
Step 4: Insert the M23 power female connector into the M23 male port of the
power input.
Note
The box doesn’t contain the M23 5-pin A-coded female
connector power cable.
Step 5: Turn clockwise to tighten the connection to the M23 power connector.
Caution
To have the waterproof effect, connectors must be totally tight-
ened, otherwise, it would invalidate your warranty.
Note
Before connecting the DC power cord, please check whether your
local DC power source is stable.

8
5. M23 DC Power Cable Pin Assignment
The front panel of the Industrial Managed PoE+ Switch provides one M23 DC
power 5-pin male connector for DC power input. Please use the power cable with
the M23 DC power 5-pin female connector from the Industrial Managed PoE+
Switch package for DC power input. The M23 DC power cable pin assignment is
shown below:
Note
1. The box doesn’t contain the M23 5-pin A-coded female
connector power cable.
2. Please contact your local reseller to purchase CB-M23F5F-120
from PLANET.
V1−
V1+
V2−
V2+
CB-M23F5F-120 M23 DC power cable pin assignment and wiring code
V1−
V1+
V2−
V2+
V1 positive (+) pin = white cable
V1 negative (-) pin = brown cable
V2 positive (+) pin = black cable
V2 negative (-) pin = yellow cable
Note
A. Make sure you connect the correct power pin to your DC power
source.
1. The wire gauge for the power cable should be in the range of
12 ~ 24 AWG
2. The DC power input range is 12 ~ 56V DC.
B. There are two methods to install the Industrial Managed PoE+
Switch – DIN-rail mounting and wall-mount plate mounting. For
more detailed information, please refer to the user’s manual.

9
6. Requirements
zWorkstations running Windows XP/2003/2008/2012/Vista/7/8/10, MAC OS X or
later, Linux, UNIX, or other platforms are compatible with TCP/IP protocols.
zEthernet Port Connection
Workstations are installed with Ethernet NIC (Network Interface Card)
Network cables -- Use standard network (UTP) cables with RJ45 connectors.
The above PC is installed with Web browser.
Note
It is recommended to use Internet Explorer 8.0 or above to access
the Industrial Managed PoE+ Switch. If the Web interface of the
Industrial Managed PoE+ Switch is not accessible, please turn off
the anti-virus software or firewall and then try it again.

10
7. Starting Web Management
The following shows how to start up the Web Management of the Industrial
Managed PoE+ Switch. Note the Industrial Managed PoE+ Switch is congured
through an Ethernet connection. Please make sure the manager PC must be set to
the same IP subnet address.
For example, the default IP address of the Industrial Managed PoE+ Switch is
192.168.0.100, then the manager PC should be set to 192.168.0.x (where x
is a number between 1 and 254, except 100), and the default subnet mask is
255.255.255.0.
IP Address:
192.168.0.x
IP Address:
192.168.0.100
IGS-5227X-4P2T
RJ45/UTP Cable
Figure 7-1: IP Management Diagram

11
7.1 Logging in to the Industrial Managed PoE+ Switch
1. Use Internet Explorer 8.0 or above for Web browser and enter IP address
https://192.168.0.100 (the factory-default IP address) to access the Web
interface.
2. When the following dialog box appears, please enter the default user name
“admin” and password “admin” (or the password you have changed before) as
shown in Figure 7-2.
Default IP Address: 192.168.0.100
Default Username: admin
Default Password: admin
Figure 7-2: Web Login Screen
3. After entering the password, the main screen appears as shown in Figure 7-3.
Figure 7-3: Web Main Screen of Industrial Managed PoE+ Switch

12
The Switch Menu on the top of the Web page lets you access all the commands
and statistics the Industrial Managed PoE+ Switch provides. The Switch Menu
always contains one or more buttons, such as “System”, “Switching”, “QoS”,
“Security”, “PoE”, “Ring”, “ONVIF” and “Maintenance”.
Figure 7-4: Switch Menu
Figure 7-5: Switch Sub-menu
Figure 7-6: Switch Sub-menu

13
Now, you can use the Web management interface to continue the Switch
management. Please refer to the user manual for more.
Note
If you are not familiar with Switch functions or the related param-
eter, press “Help icon” anytime on the Web page to get the help
description.
7.2 SavingConguration
To save all applied changes and set the current conguration as a startup
conguration on the Web user interface, the startup-conguration le will be
loaded automatically across a system reboot.
1. Click the Save icon on the top Switch Menu bar.
2. Press the “Save Conguration” button.
3. Or the other way to save the setting is to Click Maintenance, Switch Mainte-
nance, Save Startup Cong.
Figure 7-7: Save Cong -- Maintenance

14
8.RecoveringBacktoDefaultConguration
IP address has been changed or admin password has been forgotten –
Note
Follow all the recovering back to default configuration steps as
shown in the example.
1.Power o the Industrial Managed PoE+ Switch and remove all the existing
connections.
2. Use the straight RJ45 cable to connect to port 1 and port 2 in the loop topology
as shown below:
3. Power on the Industrial Managed PoE+ Switch and 6 LNK/ACT LEDs will be lit.
4. Resetting Industrial Managed PoE+ Switch to the factory default is done when 6
LNK/ACT LEDs are lit again.
5. Remove the RJ45 cable from port 1 and port 2.
6.Reset the Industrial Managed PoE+ Switch to Factory Default conguration. The
Industrial Managed PoE+ Switch will then reboot and load the default settings as
shown below:
Default Username: admin
Default Password: admin
Default IP Address: 192.168.0.100
Default Subnet Mask: 255.255.255.0

15
9. Customer Support
Thank you for purchasing PLANET products. You can browse our online FAQ
resourceandUser’sManualonPLANETWebsitersttocheckif itcouldsolveyour
issue. If you need more support information, please contact PLANET switch support
team.
PLANET online FAQs:
https://www.planet.com.tw/en/support/faq
Switch support team mail address:
[email protected]
IGS-5227X-4P2T User’s Manual:
http://www.planet.com.tw/en/support/download.php?type1=22153&model=&type=3
(Please select your switch model name from the drop-down menu of Product
Models.)
Copyright © PLANET Technology Corp. 2021
Contents are subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp.
All other trademarks belong to their respective owners.
