Planet Wireless Access Point w/Bridge WAP-1963A User manual

11Mbps Wireless Access Point w/Bridge
WAP-1963A
User s Manual

2
Copyright
Copyright 2004 by PLANET Technology Corp. All rightsreserved. No part of this publication may
be reproduced, transmitted, transcribed, stored in aretrieval system, or translated into any language or
computerlanguage,in any formorby any means, electronic, mechanical,magnetic, optical, chemical,
manual orotherwise, without the prior written permission of PLANET.
PLANETmakes no representations or warranties,either expressed orimplied,with respectto the
contentshereofand specifically disclaims any warranties,merchantability orfitness forany particular
purpose. Any software described in this manual is sold or licensed "as is". Should the programs prove
defective following their purchase,the buyer (and not PLANET,itsdistributor,or itsdealer)assumes
the entire cost of all necessary servicing, repair,and any incidental or consequential damages resulting
from any defect in the software. Further,PLANETreserves the right to revise this publication and to
make changes from time to time in the contentshereof without obligation tonotify any person of such
revision or changes.
All brand and product names mentioned in this manual aretrademarks and/or registered trademarks of
their respective holders.
Federal Communication Commission Interference Statement
This equipment has been tested and found tocomply with the limitsfor aClass Bdigital device,
pursuant to Part 15 of FCC Rules. These limitsare designed to provide reasonable protection against
harmful interference in aresidential installation. This equipment generates, uses, and can radiateradio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However,there is no guarantee that interference will not occur in
aparticular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correctthe interference by one or more of the following measures:
1. Reorientor relocate the receiving antenna.
2. Increase the separation between the equipmentand receiver.
3. Connect the equipment intoan outleton acircuit differentfrom thatto which the receiver is
connected.
4. Consult the dealer or an experienced radio technician forhelp.
FCC Caution
Toassurecontinued compliance. (example-use only shielded interface cables when connecting to
computeror peripheral devices). Any changes or modifications not expressly approved by the party
responsible for compliance could void the user s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the Following two
conditions:( 1 ) This device may not cause harmful interference, and ( 2 ) this Device mustaccept any
interference received, including interference thatmay cause undesired operation.

3
Federal Communication Commission (FCC) Radiation Exposure
Statement
This equipment complies with FCC radiation exposure set forth for an uncontrolled environment. In
order to avoid the possibility ofexceeding the FCC radio frequency exposure limits, human proximity to
the antenna shall not be less than 20 cm (8 inches) during normal operation.
R&TTE Compliance Statement
This equipmentcomplies with all the requirementsof DIRECTIVE 1999/5/CE OF THE EUROPEAN
PARLIAMENTAND THE COUNCILOF 9March 1999 on radio equipment and telecommunication
terminal Equipment and the mutual recognition of theirconformity (R&TTE)
The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal
Equipmentand Satellite EarthStation Equipment) As of April 8,2000.
Safety
This equipment is designed with the utmost carefor the safety of those who install and use it. However,
special attention must be paid to the dangersof electric shock and static electricity when working with
electrical equipment. All guidelines of this and of the computer manufacture must therefore be allowed
at all times to ensure the safe use of the equipment.
EU Countries Not Intended for Use
The ETSI version ofthis device is intended forhome and office use in Austria Belgium,Denmark,
Finland, France (with Frequency channel restrictions). Germany,Greece, Ireland, Italy,
Luxembourg .The Netherlands, Portugal, Spain, Sweden and United Kingdom.
The ETSIversion of this device is also authorized foruse in EFTAmember states Iceland,
Liechtenstein, Norway and Switzerland.
Potential restrictive use
France: Only channels 10,11,12 and 13
Revision
User s Manual for PLANET Wireless Access Point w/Bridge
Model: WAP-1963A
Rev: 1.0 (November,2003)
Part No. EM-WAP1963A

4
TABLE OF CONTENTS
Chapter 1 Introduction1
1.1 Package Contents1
1.2 SystemRequirements1
1.3 Features2
1.4 Specification 2
Chapter 2 Hardware Installation3
2.1 Hardware Connection 3
Chapter 3 Configuration 4
3.1 Home5
3.2 Wireless Setting 6
3.2.1 APmode 6
3.2.2 Station-Ad Hoc mode 8
3.2.3 Station-Infrastructure mode 10
3.2.4 APBridge –Point to Point Mode 11
3.2.5 APBridge –Point to Multi-Point Mode 12
3.2.6 APBridge –WDS Mode 13
3.3 Wireless Advance Settings15
3.4 Security17
3.4.1 WEP 17
3.4.2 802.1x 18
3.4.3 802.1x WEPstatic key 20
3.4.4 WPApre-shared key 22
3.4.5 WPARADIUS 23
3.5 RADIUS Server24
3.6 MAC Filtering 26
3.7 SystemUtility27
3.8 Configuration Tool29
3.9 Upgrade 31
3.10 Reset 32
Chapter 4 Application 33

5
4.1 Enterprise or Campus Users33
4.2 Wireless ISP 33
4.3 LAN to LAN or LAN to Multi-LAN34
Chapter 5 Troubleshooting 35

1
Chapter 1 Introduction
Thank you for purchasing WAP-1963A.The WAP-1963Ais an access pointforIEEE 802.11b 2.4GHz
wireless network. You can use this access point to build up awireless LAN, any wireless LANstation can
join the wireless network. It has support the most security functions such as WPA, 802.1X authentication,
64/128-bitWEP(Wired EquivalentPrivacy) Encryption and MAC address filter o consolidate the wireless
network security; you can prevent unauthorized wireless stations from accessing yourwireless network.
WAP-1963Aalso offers a RADIUS-based access control, for the enterprise manage requirement.
WithitsBridge and Station modes,thatit can provide more elasticity for userscreate their Wireless
Network. Connected to you LAN, it is able to access the network via Access Point or join to asmall
wireless network without Access Points. It sdataratesupport11, 5.5, 2and 1Mbps. Maximize network
efficiency while minimizing your network investment and maintenance costs.
This productprovides easy to use userinterface and allows usersto configuring from web browser.Also
it integrates DHCP server to provide multiple wireless and wired usersto get an IP address automatically.
Withthe versatile offeatures, this productis the best choice for you to integrate your wireless and wired
network seamlessly.
1.1 Package Contents
Make sure that you have the following items:
• One WAP-1963A
• One AC Power Adapter
• One User s Manual CD
• One Quick Installation Guide
• One External Antenna
Note:
If any of the above items are missing, contact your supplier as soon as
possible.
1.2 System Requirements
Before installation, please check the following requirementswith your equipment.
• Pentium Based (And Above) IBM-Compatible PC System
• CD-ROMdrive
• Windows 98/ME/2000/XP/Server2003 Operating System with TCP/IP protocol

2
1.3 Features
l Compliant with the IEEE 802.11b (DSSS) 2.4GHz specification
l High data rate 11, 5.5, 2 and 1Mbps network speed, Auto rate fallback
l Seamlessly integrate wireless and wired EthernetLAN networks
l 64/128-bitWEP Encryption and MAC Filter to protect the wireless data transmissions
l SupportsWireless AP / Bridge / Station mode
l WPA, 802.1Xauthentication
l MAC Address Filter
l Built-in DHCP server supportsauto IP addresses assignment
l Web-based configuration
l Wireless connection without the hassles and cost ofcabling
1.4 Specification
Standard IEEE 802.11b Compliant
Signal Type DSSS (Direct Sequence Spread Spectrum)
Modulation QPSK / BPSK / CCK
Port One 10/100BASE-TX
Antenna One Dipole Antenna
Data Encryption
64 bit / 128 bit WEPencryption
Frequency 2.4GHz - 2.4835GHz
Channel 11 Channels (US/ Canada, FCC)
13 Channels (Europe, ETSI)
14 Channels (Japan, TELEC)
Data Rate Up to 11Mbps(with automatic scale back)
Range Coverage
(In Open Environment)
11M448 feet = 140m
5.5M640 feet = 200m
2M864 feet = 270m
1M1100 feet = 340m
LED Indicators PWR, WLAN, LAN
Power Requirement 12V DC, 0.5A
Temperature Operating :0 ~ 55 degree C
Storage: -20 ~ 70 degree C
Humidity Operating: 10 ~ 90%
Storage: 10 ~ 90% Non-Condensing
Dimensions 160 x87 x28 mm
Output Power 18dBm
Antenna Gain 2dBi
Antenna Connector Reversed Polarity SMAMale

3
Chapter 2 Hardware Installation
Before you proceed with the installation, it is necessary that you have enough information about the
WAP-1963A.
2.1 Hardware Connection
12V DC
LAN RESETANT
+
1. Locate an optimum location for the WAP-1963A. Thebestplace foryourWAP-1963Ais
usually at the center of your wireless network, with line ofsight to all of your mobile stations.
2. Assemble the antennas to WAP-1963A. Try to place them to a position thatcan bestcover your
wireless network. The antenna sposition will enhance the receiving sensitivity.
3. Connect RJ-45 cableto WAP-1963A. Connect this WAP-1963Atoyour LAN switch/hub or a
single PC.
4. Plug in power adapter and connect to power source.After power on, WAP-1963Awill start to
work.
Note: ONLYuse the power adapter supplied with the WAP-
1963A.Otherwise, the product may
be damaged.
If you want to reset your WAP-
1963Ato default settings, press the Reset button 5second.
And then wait for 10 seconds for WAP-1963Arestart.

4
Chapter 3 Configuration
Web configuration provides auser-friendly graphical user interface (web pages)to manage your
WAP-1963A. An AP with an assigned IPaddress (e.g. http://192.168.0.1)will allowyou via web browser
(e.g., MS Internet Explorer or Netscape) to monitor and configure.
1. Open your web browser.
2. Enter WAP-1963AIPaddress (default IPaddress is http://192.168.0.1)into the address field of the
web browser. Please also make sure your PC s IP address is in the same IPrange of WAP-1963A.
3. AUser Name and Password dialog boxwill appear.Please enter your User Name and Password here.
DefaultUser Name and Password is “admin”.Click “OK”.
4. Then you will see the WAP-1963Ainformation in the web page as the picture in section 3.1.

5
3.1 Home
On this screen,you can see the general information ofthe Access Pointincluding Alias Name,
Firmware Version,SSID,Channel Number,Security,Number ofAssociated Clients,IP Address,MAC
Address, etc.

6
3.2 Wireless Setting
In this option, you can set the Mode, Alias Name, ESSID and Work Channel to this Access Point.
There are sixoperating modes available in WAP-1963A: AP,Station-Ad hoc, Station-Infrastructure, AP
Bridge-Point toPoint, AP Bridge-Point toMulti-Point, and APBridge-WDS. When configuration finished,
please click “Apply”to save.
3.2.1APmode
This mode is setto WAP-1963Aby default.Itserved as atransparentMedia Access Control (MAC)
bridge between wired and wireless network.
Parameters Description
Alias Name The alias name of this access point.
ESSID The ESSID (up to 31 printable ASCII characters) is the unique name identified in a
WLAN. The ID prevents the unintentional merging of two co-located WLANs.
Please make sure thatthe ESSID ofall stations
in the same WLANnetwork are the

7
same. The default ESSID is “default”.
Channel Number Select the appropriate channel from the list provided to correspond with your
network settings. Channels differ from country to country.
Channel 1-11 (North America)
Channel 1-14 (Japan)
Channel 1-13 (Europe)
Associated Clients Click “ShowActive Clients”button, then a “Active Wireless Client Table”
will pop up
as below.You can see the status ofall active wireless stations that are connecting
to the access point.
“Active Wireless ClientTable”records the status ofall active wireless stations that areconnecting to
the access point.You can lookup the MAC Address, Number ofTransmitted Packets,Number of
Received Packets and Encryption Status of each active wireless clientin this table.
Parameters Description
MAC Address MAC address of this active wireless station.
TxPacket The number of transmitted packets that are sent out from this active wireless
station.
RxPacket The number of received packets that are received by this active wireless station.
TXRate The transmission rate in Mbps.
Power Saving Shows if the wireless client is in Power Saving mode.
Expired Time
The time in second beforedissociation. If the wireless keeps idle long than the
expired time,this access point will dissociate
it.The wireless clientstation has to
associate again when it become active.

8
Refresh Refresh the “Active Wireless Client Table”.
Close Close “Active Wireless Client Table”window.
3.2.2Station-Ad Hoc mode
Served as a wireless station (Ad-hoc).Connected to a PC or a small LAN, this station along with
other wireless stations can establish a small wireless network without Access Points.
Parameters Description
Alias Name The alias name of this access point.
ESSID The ESSID (up to 31 printable ASCII characters)
is the unique name identified in a
WLAN. Please set it as the WLANsESSID that
you want to join. In default, the
ESSID is “default”.
Channel Number Select the appropriatechannel from the list provided to
correspond with your
network settings.
Site Survey After WAP-
1963Aapply to this mode, this button will appear for user tofind out the
devices that it can connect to. When you press the button, the
dialog boxwill

9
appear as below.You can select the APyou want to connect and press “Connect”
button to connect. Ifyou don
thave find the APyou want to connect,please press
“Refresh”to rescan.

10
3.2.3Station-Infrastructure mode
Served as a wireless station (infrastructure).Connected to a PC or a small LAN, itallows the PC or
small LAN able to access the wireless network via Access Point.
Parameters Description
Alias Name The alias name of this access point.
ESSID The ESSID (up to 31 printable ASCII characters) is the unique name identified in a
WLAN.Please setit as the AP s ESSID that you want to connect to. In default, the
ESSID is “default”.
Site Survey After WAP-
1963Aapply to this mode, this button will appear for user tofind out the
devices that it can connect to. When you press the button, the
dialog boxwill
appearas picture in section 3.1.2.2.

11
3.2.4APBridge –Point to PointMode
This mode can use to connect to another Bridge Mode WAP-1963Athat the MAC Address is entered in
the setting. It can work as a bridge to connect two LANs in distantplace.
Parameters Description
Channel Number Select the appropriate
channel from the list provided tocorrespond with your
network settings.
MAC Address Please enter the MAC Address of the WAP-1963Athatyou want to connect to.
Set Security
Set aWEPKey toprotect your wireless connection. Itis support 64/128bit Key to
the WEPfunction. Ifyou want to change WAP-
1963Ato otheroperatemode,
please disable this function before change operating mode. Please make sure the
WEPKey have set to another WAP-1963Ais the same.

12
3.2.5APBridge –Point to Multi-Point Mode
This mode can use to connect to other Bridge Mode WAP-1963Athat the MAC Address is entered in the
setting. It can work as a bridge to connect max7 LANs in distant place.
Parameters Description
Channel Number Select the appropriate channel from the list provided to correspond with your
network settings.
MAC Address 1~6 Please enter the MAC Address of the other WAP-1963Athatyou want to connect
to.
Set Security Set aWEPK
ey toprotect your wireless connection. Itis support 64/128bit Key to
the WEPfunction. Ifyou want to change WAP-
1963Ato otheroperatemode,
please disable this function before change operating mode. Please make sure the
WEPKey have set to others are the same.

13
3.2.6APBridge –WDS Mode
In this mode, WAP-1963Awill be a repeater between twoAPmode WAP-1963A, that can extend the
connect distance. When it works in this mode, it will also be an access point.
Parameters Description
Alias Name The alias name of this access point.
ESSID The ESSID (up to 31 printable ASCII characters) is the unique name identified in a
WLAN. The ID prevents the unintentional merging of two co-located WLANs.
Please make sure thatthe ESSID ofall stations in the same WL
ANnetwork are the
same. The default ESSID is “default”.
Channel Number Select the appropriate channel from the list provided to correspond with your
network settings.
Associated Clients When you press the “ShowActive Clients”button, you can see adia
log box to show
you the clients that connect tothis WAP-1963A. Please refer to the section 3.1.2.1
to knowthe detail of the dialog box.

14
MAC Address 1~6 Please enter the MAC Address of the other WAP-1963Athatyou want to connect
to.
Set Security Set
aWEP Key to protect yourwireless connection. It has support 64/128bitKey to
the WEPfunction. Ifyou want to change WAP-
1963Ato otheroperatemode,
please disable this function before change operating mode. Please make sure the
devices that connect to this WAP-1963Ahave work with the same WEP Key.

15
3.3 Wireless Advance Settings
You can set advanced parameters of this WAP-1963A. The parametersinclude Authentication Type,
Fragment Threshold, RTS Threshold, Beacon Interval,DataRate, Preamble Type, and Broadcast
ESSID. You should not change these parametersunless you knowwhat effect the changes will have
on WAP-1963A. When configuration finished, please click “Apply”to save the settings.
Parameters Description
Authentication Type There are twoauthentication types: “Open System”and “Shared Key”
.When you
select “Open System”
,wireless stations can associate with this access point
without WEP encryption. When you select “Shared Key”
,you should also setup
WEPkey in the “Encryption”page and wire
less stations should use WEP
encryption in the authentication phase to associatewith this access point. If you
select “Both”
,the wireless client can associate with this access point by using
any one of these two authentication types.
