Plantronics GAMECOM X95 - QUICK START GUIDES User manual

Pair/Connect
button
LED
Power
button
CONNECT
GameCom®X95™:
1. Place batteries in headset.
2. Connect the wireless adapter to the Xbox.
3. Press the Power button for 2 seconds to turn the
headset on. The headset and the adapter should
connect immediately (see LED status on reverse).
If you cannot hear anything through your headset,
try adjusting the volume up or restarting the
game or application.
If headset is still not paired
(see LED status on reverse)
you can manually pair your
headset and adapter.
From powered off state,
press the Power button
for 6 seconds until LED
begins to flash rapidly.
Release the button; headset
is now in pairing mode.
On wireless adapter: press the Pair/Connect button
on the wireless adapter for 6 seconds until the LED
flashes rapidly. Release button; headset and adapter
should now be paired.
TROUBLESHOOT
HEADSET
STATUS/CONDITION LED STATUS OR ACTION
Paired/connected LED solid blue flash
Pairing LED rapid blue flash
Not connected LED slow blue flash
Pairing fails If pairing mode times out, LED
changes from rapid flash to
headset power off
Power off 2 second button press,
LED gets bright then turns off
Power on Press the Power button for
2 seconds, LED comes on to
appropriate status
Low battery LED triple blue flashes
Auto shut down Headset shuts down after
defined period of time with no
signal from wireless adapter
WIRELESS ADAPTER
Paired LED solid blue flash
Pairing LED rapid blue flash
LED slow blue flash
Pairing fails If pairing mode times out,
LED goes into “not connected”
state
Patents US D589492; Brazil DI68056010; China ZL200830349586.8;
EM 001053631-0001; Taiwan D132123; and Patent Pending
84246-01 (09.10) Rev B AM 84247-01
