Baltic Mobile Shower Commode Chair
PHS1300 
AssemblyandOperationManual

Removecontentsfrompackageandarrangethemonaflatsurfaceforeasyassembly.
TheCaspianincludesthefollowingparts:
A)Mainchairframe E)Footrest
B)TwoarmrestsF)Largerearwheels
C)SeatframeG)BoltandKnobset(4boltsx4knobs)
D)PaddedseatH)Pailwithlid




B
C
D
E
G
A
F
H


PHONE:888.550.2410EMAIL:[e-mail]www.platinumhealthllc.com
Step1.Placechairframe(A)onfloor(Figure1.a).Toavoidunnecessarymovementduringassembly,
pressthefrontbrakesonthewheelstolockthetwocasters(Figure1.b).

Figure1.aFigure1.b

Step2.TheBalticisdesignedforsimpleattachmentofthelargerearwheels(F).TheBalticwheelsattach
totheframeoftheBalticbytakingthewheelandpushingthewheelaxlethroughtheholeontheBaltic
frame(Figure2.a&2.b).PressinonthewheelreleaseleverontheBalticframeandpushthewheelaxle
throughtheBalticframeuntilincomesthroughtheothersideoftheframe(Figure2.c).Releasethe
buttonandtightentheknobtosecurethewheel(Figure2.d).Theknobmustbetightenedbeforeuse.
 
Figure2.aFigure2.b
 
Figure2.cFigure2.d


PHONE:888.550.2410EMAIL:[e-mail]www.platinumhealthllc.com
Step3.Takeseatframe(C)andplaceitintotheblackinsertsonthechairframe.Thepaddedseat(D)
maybeonorofftheseatframeatthispoint.Ifthepaddedseatisnotontheseatframe,itmaybe
installedbysnappingitonthetopofseatframe.
  
Figure3.aFigure3.b

Step4.Installaboltandknobset(G)byinsertingaboltthroughtheholeoftheblackplasticinsertof
seatframeandtightenwithaknob.Repeatonother3insertsofframe.

Figure4.aFigure4.b

Step5.Attachthearmrest(B) tothesideofthechairframe.Placetheboltthroughthearmrestintothe
framethrougheach upperandlowerholesandtightentheknob.Repeatontheoppositeside.
   
Figure5.aFigure5.bFigure5.c



PHONE:888.550.2410EMAIL:[e-mail]www.platinumhealthllc.com
Step6.Insertfootrestintothesupportbarontheinsidebaseofthechairframebyslidingthespring
loadedgoldbuttonintotheblackinsertuntilitclicksinplace.Repeatonoppositeside.Thefootrestwill
beabletofoldupanddown.NOTE:Alwaysensureeachgoldbuttonisproperlylockedinplace.
  
Figure6.aFigure6.bFigure6.c


Step7.Removethepaillidandslidepailundertherearentryofseatframe.
 
Figure7

TheBalticMobileShowerCommodeChairisnowreadyforuseinastandardorwalkinshower.





PHONE:888.550.2410EMAIL:[e-mail]www.platinumhealthllc.com
InstructionsonhowtotransferauserintotheCaspianshowerchair

PlacingtheuserintheBalticshowerchair:
1. BringtheBalticshowerchairasclosetotheuseraspossibleandlockthecasters.Forlateral
transfers,raiseanarmrestforeasieraccesstotheseat.
2. AssisttheuserintotheBalticbygentlyplacingthemontotheseat.Besurebotharmrestsarelevel
forusersafetyandcomfort.
3. Bringthechestsafetybeltaroundthefrontoftheuserandfastenforaddedsecurity.Thecasters
cannowbeunlockedfortransportintoashowerroomordesignatedbatharea.
RemovingtheuserfromtheBalticshowerchair:
1. MakesurethecastersarelockedbeforeassistingauseroutoftheBalticshowerchair.Raiseone
armrest,shouldyouperformalateraltransfer.Instructtheusertoplacetheirfootonthefloor.
Unbucklethecheststrap.
2. GentlyassisttheuseroutoftheBalticshowerchairtothedesiredlocation.StoretheBaltictoits
designatedstorageareaandlockthecastersduringstorage.

CleaningInstructions:
TheBalticshowerchairisverydurableandeasytoclean.Theshowerseatcanbedisinfectedbyspraying
itwithanystandardnon‐abrasivehospitalgradehardsurfacedisinfectant.Gentlywipethedisinfectant
intothesurfaceusingasofttowelorclothandletsitfor10minutes.Thenrinsetheshowerseattomake
surealldisinfectanthasbeenremoved.




PHONE:888.550.2410EMAIL:[e-mail]www.platinumhealthllc.com
IMPORTANTSAFETYINFORMATION

READALLSAFETYINFORMATIONBEFOREUSING

Itistheuser’sresponsibilitytoensuretheappropriatenessofthisdevicefortheuserinquestionbefore
using.
‐NEVERusethisdevicewithindividualswhoareseverelymentally,cognitively,physicallyorvision
compromised.
‐ALWAYSattachsafetybeltandadjusttoasnugfitarounduser’ships.
‐NEVERleaveacompromiseduserunattended.
‐ALWAYSensurethatthelegsareproperlyadjustedtoensurethatthebenchislevelsidetosideand
fronttoback.
‐NEVERexceedthemaximumweightcapacityof330lbs.
NOTE:Failuretofollowtheabovenotedsafetyinstructionscanleadtosevereinjuries.






