Playcore ultra site 238U-R6 User manual

Model # 238U-R6
11/7/2013 Page 1 of 10

1675 Locust Street
Red Bud, IL 62278
Phone: [phone]
Fax: [phone]
WARRANTY & TERMS
WARRANTY: 5 Year Limited Warranty on Thermoplastic coated elements. Ultra Play guarantees all items for one full year to be
free of defects in workmanship or materials when installed and maintained properly. We agree to repair or replace, any items
determined to be defective. Items specifically not covered by this warranty include vandalism, man made or natural disasters, lack of
maintenance, normal weathering or wear and tear due to public abuse.
Damages or loss in transit is the responsibility of the carrier, whether visible or concealed. It is the responsibility of the recipient to
assure that the order is received complete. Before signing the delivery receipt, inspect the shipment immediately and completely. Note
any damages or shortages on the bill of lading. Damage reports must be filed within 10 days. Ultra Play is NOT responsible for
damages or loss in transit. Title to all goods passes to the customer at the time of shipment. Ultra Play will assist in filing claims if the
freight arrangements were made by Ultra Play at your request.
CANCELLATIONS AND RETURNS: Cancellations are only accepted with approval of Ultra Play. No merchandise shall be returned
without a Return Goods Authorization number which is issued by customer service. Any authorized merchandise must be carefully
packed and received in saleable condition. A restocking charge of up to 25% will be applied to all returned goods when the error is not
the fault of Ultra Play. All returns must be shipped freight prepaid.
11/7/2013 Page 2 of 10

Owners and installers please note these safety warnings and make use of this checklist on a regular basis.•
Follow installation instructions when erecting equipment.•
Ground surfaces around equipment should be restored as needed. Concrete footings should never be exposed. Surface depth•should comply with ASTM and CPSC specifications.
Check for and repair damage caused by wear or vandalism, a major factor in injury causing situations.•
All protruding bolts should be covered or cut off and finished smooth. Sharp edges on pipes should be capped or removed. Check•for bent, broken, or severly worn pipe, and replace.
All equipment should be free of rust and repainted whenever necessary to deter rusting.•
We provide our customers with layout sheets and installation instructions. Please keep on file the specifications sheet that contains•the listing of every part used.
Never add components not intended for use with this product.•
Regular maintenance is necessary in this and all park and recreational equipment to insure the safety of the user.•
Note: Proper maintenance of equipment requires regular tightening of all bolts, nuts, and setscrews.•
Note: Regular checking of all parts, castings, etc. should be made. If a part is broken or worn, it shoud be replaced immediatly.•
Check to be sure all fittings are tight and that bars and pipes do not move.•
Replace all worn S-hooks. S-hooks must be completely closed. Failure to close S-hooks can result in serious injury to the user.• NEVER reuse S-hooks.
Test for free movement of swing hanger and other moving attached parts.•
Check for worn chains and replace them.•
A soft resilient surface should be placed under all swings extending at least twice the height of the top rail both front and back.•
SAFETY WARNINGS & EQUIPMENT INSPECTION
11/7/2013 Page 3 of 10

5/16" Washer
5/16" Hex Nut
3/8" x 1-3/4"
Carriage Bolt
3/8" Washer
5/16" x 2-1/4"
Carriage Bolt
800-45-ULTRA www.ultra-site.com
HARDWARE
3/8" Hex Nut
3/8" x 1-1/4"
Carriage Bolt
11/7/2013 Page 4 of 10

800-45-ULTRA www.ultra-site.com
1/2" & 9/16"
Wrench 1/2" & 9/16" Socket Wrench Tape Measure Level
TOOLS REQUIRED
11/7/2013 Page 5 of 10

800-45-ULTRA www.ultra-site.com
ULTRA SITE PRODUCT SPECIFICATIONS
238U-R6
6’ PORTABLE UTILITY TABLE WALK-THROUGH DESIGN
Top: Minimum of 96% commingled post-consumer or post-industrial recycled plastic. With a maximum of 4% due to various additives
including color and UV stabilization to obtain desirable properties.
Frame: 2-3/8” O.D. x 12 gauge pre-galvanized structural steel tubing. One 1 1/2" x 3/4" x 1/8" center channel shall be mechanically
attached to the bottom side of tabletop to prevent warping of wood and to attach cross braces, thus providing over all strength and
rigidity. Cross braces 1 5/16” O.D. x 15 gauge pre-galvanized structural steel tubing. Brace attachment points 1-1/2”x1-1/2”x3/16” steel
angle. All tabletop brackets shall be precision punched and fabricated from 2" x 2" x 7 gauge formed angle. All electrically MIG welded.
Frame Coating: Hot dipped galvanized or Electrostatic powder coated application oven cured.
Hardware: Hardware shall be hot-dipped galvanized.
Dimensions: 6’ portable utility table. Top is 28” wide x 72” long and is 30” high.
11/7/2013 Page 6 of 10

800-45-ULTRA www.ultra-site.com
COMPONENTS
10
1
2
5
3
8
6
94
7
ITEM NO. PartNo DESCRIPTION QTY
1BRN72-2x10-T,
CDR72-2x10-T,
GRN 72-2x10-T, or
GRY72-2x10-T
2 x 10 Brown Recycled Table Plank (6'), 2 x
10 Ceder Recycled Table Plank (6'), 2 x 10
Green Recycled Table Plank (6'), or 2 x 10
Gray Recycled Table Plank (6') 3
2 V238U 238 Utility Frame 2
3 33-02-0007 5/16" Flat Washer (SS) 18
4 33-02-0002 3/8" Zinc Plated Washer 3
5 33-06-0006 5/16" x 2 1/4" Carriage Bolt (Zinc) 18
6 33-06-0005 3/8" x 1 3/4" Carriage Bolt (Zinc) 1
7 33-06-0032 3/8" x 1-1/4" Carrige Bolt (Zinc) 2
8 33-01-0001 5/16" Hex Nut (Zinc) 18
9 33-01-0002 3/8" Hex Nut (Zinc) 3
10 01-04-0027 center c channel 1
11 01-04-0165 6' Wood Brace 2
12 01-04-0168 recycled 6' plank stiffener strip 6
1
12
Stiffener strips are inserted into the
Recycled Planks during production.
11/7/2013 Page 7 of 10

Attach the 238U Legs and Center C Channel to the 6' Recycled Table Plank as shown using specified hardware.
Note that the 3/8" x 1-3/4" Carriage Bolt is sandwiched between the C Channel and the middle Table Plank.
3
6
10
2
1
5
8
800-45-ULTRA www.ultra-site.com
STEP 1
11/7/2013 Page 8 of 10

800-45-ULTRA www.ultra-site.com
STEP 2
9
7
4
11
Attach the 6' Braces to the C Channel and 238U Legs as shown using specified hardware.
11/7/2013 Page 9 of 10

30"
800-45-ULTRA www.ultra-site.com
OVERALL DIMENSIONS
72"
28"
