Playcore ultra site 993-R6 User manual

Model # 993-R6
1/25/2017 Page 1 of 11

1675 Locust Street
Red Bud, IL 62278
Phone: [phone]
Fax: [phone]
WARRANTY & TERMS
WARRANTY: 5 Year Limited Warranty on Thermoplastic coated elements. Ultra Play guarantees all items for one full year to be
free of defects in workmanship or materials when installed and maintained properly. We agree to repair or replace, any items
determined to be defective. Items specifically not covered by this warranty include vandalism, man made or natural disasters, lack of
maintenance, normal weathering or wear and tear due to public abuse.
Damages or loss in transit is the responsibility of the carrier, whether visible or concealed. It is the responsibility of the recipient to
assure that the order is received complete. Before signing the delivery receipt, inspect the shipment immediately and completely. Note
any damages or shortages on the bill of lading. Damage reports must be filed within 5 days. Ultra Play is NOT responsible for
damages or loss in transit. Title to all goods passes to the customer at the time of shipment. Ultra Play will assist in filing claims if the
freight arrangements were made by Ultra Play at your request.
CANCELLATIONS AND RETURNS: Cancellations are only accepted with approval of Ultra Play. No merchandise shall be returned
without a Return Goods Authorization number which is issued by customer service. Any authorized merchandise must be carefully
packed and received in saleable condition. A restocking charge of up to 25% will be applied to all returned goods when the error is not
the fault of Ultra Play. All returns must be shipped freight prepaid.
1/25/2017 Page 2 of 11

Owners and installers please note these safety warnings and make use of this checklist on a regular basis.•
Follow installation instructions when erecting equipment.•
Ground surfaces around equipment should be restored as needed. Concrete footings should never be exposed. Surface depth•should comply with ASTM and CPSC specifications.
Check for and repair damage caused by wear or vandalism, a major factor in injury causing situations.•
All protruding bolts should be covered or cut off and finished smooth. Sharp edges on pipes should be capped or removed. Check•for bent, broken, or severely worn pipe, and replace.
All equipment should be free of rust and repainted whenever necessary to deter rusting.•
We provide our customers with layout sheets and installation instructions. Please keep on file the specifications sheet that contains•the listing of every part used.
Never add components not intended for use with this product.•
Regular maintenance is necessary in this and all park and recreational equipment to insure the safety of the user.•
Note: Proper maintenance of equipment requires regular tightening of all bolts, nuts, and setscrews.•
Note: Regular checking of all parts, castings, etc. should be made. If a part is broken or worn, it should be replaced immediately.•
Check to be sure all fittings are tight and that bars and pipes do not move.•
Replace all worn S-hooks. S-hooks must be completely closed. Failure to close S-hooks can result in serious injury to the user.• NEVER reuse S-hooks.
Test for free movement of swing hanger and other moving attached parts.•
Check for worn chains and replace them.•
A soft resilient surface should be placed under all swings extending at least twice the height of the top rail both front and back.•
SAFETY WARNINGS & EQUIPMENT INSPECTION
1/25/2017 Page 3 of 11

800-45-ULTRA www.ultra-site.com
HARDWARE
5/16" x 3-1/2"
Carriage Bolt
5/16" x 2-1/4"
Carriage Bolt
5/16" Hex Nut
5/16" Washer
1/25/2017 Page 4 of 11

800-45-ULTRA www.ultra-site.com
1/2" Wrench 1/2" Socket Wrench Tape Measure Level
TOOLS REQUIRED
1/25/2017 Page 5 of 11

800-45-ULTRA www.ultra-site.com
ULTRA SITE PRODUCT SPECIFICATIONS
Seat: 3x4 planks are made from a minimum of 96% post-consumer or post-industrial recycled plastic. Contains UV stabilizers to
prevent fading.
Frame: Seat support is fabricated from 3/16” angle.
Planters: 2x4 planks are made from a minimum of 96% post-consumer or post-industrial recycled plastic. Contains UV stabilizers to
prevent fading.
Frame: 7 gauge. formed steel plate. Bottom plate is 10 gauge. steel.
Frame Coating: TGIC electrostatic powder coated application oven cured, or hot dipped galvanized after fabrication.
Hardware: All fasteners are zinc coated.
Dimensions: 6’ bench without back. Seat height is 17”. Seat width is 15 ½”. Planters are 27” square x 18”tall.
993-R6
BACKLESS BENCH with THREE PLANTERS
Liner(Not Included - Sold Separately)
Part number: 01-05-0212
Dimensions: 21-11/16" Diameter x 17" Tall
1/25/2017 Page 6 of 11

ITEM NO. PartNo DESCRIPTION QTY
1 P-01-01-0243 planter bench attachment angle 4
2
BRN72-3x4-PB,
CDR72-3x4PB,
GRN72-3x4-PB,
or GRY72-3x4-
PB
3 x 4 Recycled Planter Bench Plank (6') 8
3 P-01-04-0118 952 recycled center angle 2
4 P-01-01-0248 6' Recycled Planter Bench Angle (71 1/2") 4
5
BRN18-2x4-PL,
CDR18-2x4-PL,
GRN18-2x4-PL,
or GRY18-2x4-
PL
2 x 4 Brown Recycled Planter Plank (18"), 2 X 4 Cedar
Recycled Planter Plank (18"), 2 x 4 Green Recycled
Planter Plank (18"), or 2 x 4 Grey Recycled Planter
Plank (18") 72
6 01-05-0090 TR Sq. Planter/Receptacle bottom ring assembly 3
7 01-05-0089 TR Sq. Planter/Receptacle L bracket assembly 3
8 33-06-0006 5/16" x 2 1/4" Carriage Bolt (Zinc) 144
9 33-02-0001 5/16" Zinc Plated Washer 168
10 33-01-0001 5/16" Hex Nut (Zinc) 168
11 33-06-0023 5/16" x 3-1/2" Carriage Bolt (Zinc) 24
11
2
5
9
10
6 4
3
8
1
7
800-45-ULTRA www.ultra-site.com
COMPONENTS
1/25/2017 Page 7 of 11

800-45-ULTRA www.ultra-site.com
STEP 1
7
10
9
5
8
Attach the 18" Recycled Planks to the Bottom Ring Assembly and the L Bracket Assembly using
specified hardware for each Planter. Be sure to leave 2 adjacent sides unbolted on 1 of the
Planters (as shown above) and 1 side unbolted for the other 2 Planters to attach the benches.
6
1/25/2017 Page 8 of 11

4
3
1
2
11
10
9
Attach the 6' Recycled Planks to the Bench Attachment Angles and
the 952 Center Angle and attach the 952 Bench Angles as shown
using specified hardware.
800-45-ULTRA www.ultra-site.com
STEP 2
1/25/2017 Page 9 of 11

800-45-ULTRA www.ultra-site.com
STEP 3
Attach the assembled Benches to the Planters using specified hardware.
8
910
1/25/2017 Page 10 of 11

18"
125 7/8"
26 3/4"
72"
26 3/4"
90°
26 3/4" 72" 26 3/4"
15 1/2"
800-45-ULTRA www.ultra-site.com
OVERALL DIMENSIONS
1/25/2017 Page 11 of 11
