Collins Youldon SDM09H User manual

Product Manual
SDM09H-Hosereel
Issue 2 –April’20
Hosereels –Hydraulic Rewind
Installation and Maintenance Manual
(Technical Manual No SDM09H)

Product Manual
SDM09H-Hosereel Page 1
Issue 2 –April’20
Index
Page
Section
1.0 Introduction
1.1 Scope of this manual 2
1.2 Description 4
1.3 Inspection 5
2.0 Installation
2.1 Installing the hosereel 6
2.2 Connecting the hose 6
2.3 Installing the hydraulic motor 7
2.4 Handwheel friction brake 9
2.5 Installing ancillary devices 9
3.0 Operation
3.1 Deploying the hose 12
3.2 Rewinding the hose - with the manual rewind handle 12
3.3 Rewinding the hose - with the hydraulic rewind motor 13
3.4 Operating ancillary devices 13
4.0 Maintenance
4.1 Weekly maintenance 14
4.2 Monthly maintenance 14
4.3 Bi-annual maintenance 14
4.4 Corrective maintenance 15
4.5 Swingjoint / fluid path assemblies 15
4.6 Problem solving 19
Appendices
1 Layout of hosereel with hydraulic rewind motor 20
2 ¾” and 1” fluid path layouts 21
3 ¾”, 1” and 1¼” swingjoint assemblies 22
4 1½” Swingjoint / fluid path assemblies 23
5 2” Swingjoint / fluid path assemblies 24
Figures
1 Typical hydraulic motor rewind hosereel
2 Lifting the hosereel
3 Hydraulic motor
4 Valve port connection
5 Typical hydraulic system schematic
6 Friction brake
7 Fixed roller guides
8 Hinged roller guides
9 Earth continuity device
10 Swing out platform
11 Typical swingjoint / fluid path assembly (1½” and 2”)
Tables
1 Problem solving

Product Manual
SDM09H-Hosereel Page 2
Issue 2 –April’20
1.0 INTRODUCTION
1.1 Scope of this manual
WARNING
WARNINGS ARE GIVEN WHERE FAILURE TO OBSERVE THE INSTRUCTION COULD
RESULT IN INJURY TO PERSONNEL.
CAUTION
Cautions are given where failure to observe the instruction could result in damage to
the equipment or associated equipment.
This manual provides the end-user of Collins Youldon hosereels with full details of the equipment, its
installation, use, maintenance and basic repair / spares information. It must be stressed that proper
installation and regular maintenance of the equipment provide the key to long and trouble-free use.
In the unlikely event of any operational problems or for the supply of spare parts and any technical or
usage queries please call our Sales Office on 01480 832200 and they will be pleased to help.
As soon as you take delivery of a hosereel, please complete the boxes below. This will enable us to
respond quickly to any enquiry.
A The serial number and model number of the reel from the plate on the cross stay at the front of the
hosereel.
B The nominal width of the hosereel drum
(measured between the drum disks)
C The diameter of the drum disks
D Method of rewind
E Internal diameter of the fluid path
F Date of purchase
Collins Youldon has a policy of continual product improvement, and reserves the right to modify the design, or
materials used, at any time in the future.
203mm 305mm 406mm 457mm
508mm 610mm 711mm 813mm
432mm 482mm 508mm 584mm 736mm
19mm 25mm 32mm 38mm 51mm
¾” 1” 1¼” 1½” 2”
Hydraulic

Product Manual
SDM09H-Hosereel Page 3
Issue 2 –April’20
10
11
1 Drum 2 Drive gears and chain
3 Centre shaft inlet / swingjoint connection 4 Frame
5 Hydraulic motor 6 Hose roller guides (if fitted)
7 Serial number plate
10 Swingjoint 11 Flexible connection
Figure 1 –Typical hydraulic motor rewind hosereel
(for more part details refer to Appendix 1)

Product Manual
SDM09H-Hosereel Page 4
Issue 2 –April’20
1.2 Description
1.2.1 The basic hosereel consists of a centrally positioned drum assembly supported by two bearings on the
frame of the hosereel, see figure 1.
1.2.2 Hosereels with hydraulic rewind motors are fitted with a sprocket and chain drive to the drum
assembly. Additionally, the hose may be rewound manually with a cranked handle or by the hydraulic
motor. The emergency crank rewind shaft, operates a crown wheel and pinion set at 90 degrees or 26
degrees to the hosereel front.
1.2.3 The main frame of the hosereel is made up of two end plates joined by two tie plates. The swingjoint
and gooseneck assembly are positioned at one end of the hosereel. The rewind mechanism may be
at either end of the drum assembly. The gooseneck, depending on the size of the fluid path, may be
an integral part of the centre shaft or use separate castings.
1.2.4 This manual describes hydraulic rewind Collins Youldon hosereels. Other types of hosereel include:
electric motor rewind, air motor rewind, manual rewind, and the HR30 series of catherine reels with
various power rewind options. There is a separate manual for each type.
1.2.5 All hosereels are supplied powder painted in a range of standard colours, or in grey primer epoxy
powder coat finish for painting to individual customer requirements. Alternatively, they can be
galvanised or supplied in stainless steel.
1.2.6 Collins Youldon inspect and test all parts of the hosereel fluid path before despatch.

Product Manual
SDM09H-Hosereel Page 5
Issue 2 –April’20
1.3 Inspection
1.3.1 Remove all packaging materials and inspect the hosereel on receipt. If there is any damage,
please notify your supplier and the carrier in writing within 3 days, stating the serial number of the
hosereel and your order number.
1.3.2 If the hosereel is received undamaged, packaging materials may be disposed of in accordance
with local Environmental Health and Safety regulations.
1.3.3 The total weight of the hosereel requires more than one person to lift or move it and in some
installations lifting equipment may be required. Lifting instructions are given below.
WARNING
THE CENTRE OF GRAVITY IS NOT QUITE CENTRAL TO THE HOSEREEL AND MUST
BE DETERMINED BEFORE LIFTING. WE RECOMMEND THAT A MINIMUM OF TWO
PERSONS ASSIST DURING THE MOVEMENT OR INSTALLATION OF THE
HOSEREEL.
CAUTIONS
1 The centre of gravity is not central to the hosereel; we recommend that a minimum
of two persons assist during the movement or installation.
2 The hosereel must only be lifted by the drum (as shown below), or by the frame.
Figure 2 –Lifting the hosereel

Product Manual
SDM09H-Hosereel Page 6
Issue 2 –April’20
2.0 INSTALLATION
CAUTIONS
1 Care must be taken to avoid distortion of the frame when fitted.
2 Care must be taken not to exert undue force on the swingjoint when the inlet connection
is made.
3 The inlet connection to the hosereel must be through a flexible hose.
4 Care must be taken to protect the gears, bearings and chains from dirt and water.
5 The maximum working pressure marked on the serial number label must not be
exceeded.
6 The minimum bend radius of the hose must be compatible with the diameter of the drum
of the hosereel. The drum diameter should be twice the minimum bend radius.
7 If the installation is such that transmission parts are exposed, then additional guarding
may be required.
2.1 Installing the hosereel
2.1.1 Bolt the hosereel frame onto a flat, firm surface. A distorted frame will affect the mesh of the rewind
gears. We recommend the use of four flexible mounting pads to minimise distortion. Where a hosereel
is supplied without a frame it is essential that the mounting is square and the rewind gears are
correctly aligned.
2.1.2 Fully engage the manual rewind handle to make sure that there is sufficient space around the hosereel
for rotation of the handle. It may be necessary to use the manual rewind handle if the power rewind
fails for any reason.
2.1.3 The inlet connection to the swingjoint must be through a flexible hose. Make sure that the hose is
flexible enough to avoid strain or twisting and does not exert any side load on the swingjoint.
2.1.4 External swingjoints are loosely fitted to the hosereel for transport purposes. These must be removed
and refitted using thread sealant.
2.1.5 To protect the gears, bearings and chains from dirt and water, install vehicle mounted hosereels in a
cabinet wherever possible.
2.1.6 Allow sufficient space around the hosereel so that it can be easily serviced and maintained.
2.2 Connecting the hose
2.2.1 When using the hosereel for hose with an inside diameter of 38mm (1½”) or 50mm (2"), the gooseneck
should be removed. Fit the hose to the gooseneck and then refit the gooseneck to the hosereel. When
refitting the gooseneck, ensure that the seal is correctly positioned in the groove in the centre spindle,
section 4.4.4.
2.2.2 If the hose is too close to the drum at the gooseneck connection point, the drum may be dished locally
with a hide mallet. No harm will be done and the hose should then be a snug fit with a smooth profile
around the drum.

Product Manual
SDM09H-Hosereel Page 7
Issue 2 –April’20
SHAFT Ø16mm
7640.OH.M ADAN AMM.32.P
(DANFOSS OMM 32)
FOR ALL HOSEREELS
2.3 Installing the hydraulic motor
WARNINGS
1 A COMPETENT TECHNICIAN MUST CARRY OUT THIS DESIGN AND INSTALLATION.
2 THE PRESSURE RELIEF VALVE SETS THE MAXIMUM REWIND POWER OF THE
HOSEREEL. THIS LEVEL MUST BE SET LOW ENOUGH TO PROTECT THE
OPERATOR.
2.3.1 All hydraulic rewind hosereels must be connected to a suitable hydraulic control system. In the Collins
Youldon hydraulic control system there are three main components. These are a changeover valve, a
flow control valve and a three position control lever with pressure relief valve. The function of these
components are described below and figure 5 shows a suggested layout for the complete system.
(i) Changeover valve –directs hydraulic power either to the hosereel or cargo pump.
(ii) Flow control valve –enables the maximum rewind speed to be pre-set during installation by
adjustment of the flow of hydraulic oil to the motor.
(iii) Combined three-position control lever and pressure relief valve –controls the operation of the
reel. The control positions and their functions are:
Position 2 –allows the reel to freewheel when the hose is being deployed but without over-
running. Note: The handwheel friction brake provides additional friction braking, see section
2.4.
Position 0 –locks the reel so that the hose is discouraged from shaking loose during transit.
Position 1 –energises the hydraulic motor and rewinds the hose. The lever will detent into
positions 0 and 2. There is a spring return from position 1 to position 0.
Pressure relief valve –sets the maximum rewind power of the hosereel, and must be set during
installation to give a safe maximum rewind torque
Figure 3 –Hydraulic motor

Product Manual
SDM09H-Hosereel Page 8
Issue 2 –April’20
B
A
P
PR
P
EX
P
T
P1 T1
T4
B
A
P
T
1
0
2
P
OPERATING LEVER
PRESSURE RELIEF VALVE ADJUSTMENT
P/P1 - USE EITHER FOR INLET
SUPPLY FROM DIVERTER. BLANK OFF OTHER
COLOUR - RED
T1 - USE FOR RETURN TO TANK
BLANK OFF T4 & T
COLOUR - BLUE
B - USE FOR FEED TO MOTOR
A - BLANK OFF
COLOUR - GREEN
SPRING
DETENT
Amendment No. 24 (07.12.06)
Key: A output
B output
EX excess –return to tank
P supply
PR regulated output Figure 4 - Valve Port connection
Refer to figure 4 above for port connection information
Key A Hydraulic supply
B Lever operated changeover valve –open type spool which will not “dead end” supply.
C Adjustable flow control valve –excess returned to tank.
D Combined 3 position control lever and pressure relief valve.
E Hosereel hydraulic motor.
Figure 5 - Typical hydraulic system schematic
E
BA
CD
at typically 80 bar
Nominal 6 L/Min.
'X' L/Min. (40 kgf/cm )
Nominal 40 bar
Hydraulic Driven Cargo Pump
2
Hydraulic Fluid Reservoir
(X-6) L/Min.

Product Manual
SDM09H-Hosereel Page 9
Issue 2 –April’20
90° RH HANDWIND
7700.0R.A
LH ANGLED
7705.0L.A 7705.0R.A
RH ANGLED
12 TEETH
26° REWIND
7700.0L.A
90° LH HANDWIND
SWING COVER
SIDEWAYS TO
GAIN ACCESS
TO REWIND
SHAFT
2.4 Handwheel Friction Brake
2.4.1 This brake is fitted to most hosereels as standard.
2.4.2 Rotating the handwheel clockwise will increase the strength of the brake. The brake should be
partially released when deploying the hose, whilst still providing sufficient friction to prevent overrun of
the drum. To rewind the hose the brake should be released further. When the hose is stored the
brake should be fully tightened to ensure that the drum cannot rotate during transit.
Figure 6 –Friction brake
2.5 Installing ancillary devices
Additional equipment may have been supplied with the hosereel. This may include but not be limited to the
following:
2.5.1 Fixed 4 way roller guides
These are designed to reduce hose wear. Make sure that the hose will run smoothly off the hosereel drum
and between the rollers.
Figure 7 –Fixed roller guides
4 - WAY TOP
FIXED
ROLLER
GUIDES
4 - WAY FRONT
FIXED
ROLLER
GUIDES

Product Manual
SDM09H-Hosereel Page 10
Issue 2 –April’20
2.5.2 Hinged roller guides
These are designed to reduce damage to cabinet door seals and bodywork. Where indicated they are
supplied as a separate kit item with full installation instructions.
PLAN VIEW
Figure 8 –Hinged roller guides
2.5.3 Inverted mounting kit
If the hosereel is to be mounted upside down an inverted mounting kit must be factory-fitted. The
installation must be adequate for the weight of the hosereel and hose.
Collins Youldon hosereels are not designed for mounting on a vertical surface.
2.5.4 Earth continuity device
Where an earth continuity device is fitted to the hosereel the installer must provide a continuity path as
appropriate.
Figure 9 –Earth continuity device
BACK FOR STORAGE
ROLLERS HINGED
OUT FOR DEPLOYMENT
ROLLERS HINGED
ROLLER GUIDES
TOP TILT OUT ROLLER GUIDE KIT FRONT HINGE OUT
OUT FOR DEPLOYMENT
ROLLERS HINGED
BACK FOR STORAGE
ROLLERS HINGED
4.7mm PLASTIC BEARING.
FRAME.

Product Manual
SDM09H-Hosereel Page 11
Issue 2 –April’20
2.5.5 Swing out platforms
The installer must provide rigid mounting points for the bearings. Support will also be required under the
end of the platform when it is in the “parked” position.
Figure 10 –Swing out platform
2.5.6 Remote Rewind
If the hosereel is supplied with remote rewind adequate guarding must be fitted to all moving parts and the
rewind mechanism must be correctly aligned.
PLAN VIEW
4 HOLES Ø14.3mm [9/16"]
114mm
SEE DETAIL OF
MOUNTING PAD [1 1/2"]
114mm
[1 1/2"]

Product Manual
SDM09H-Hosereel Page 12
Issue 2 –April’20
3.0 OPERATION
WARNINGS 1 ALL PERSONS ARE TO COMPLY WITH THE INSTALLERS INSTRUCTIONS
AND ANY LOCAL LEGISLATION OR HEALTH AND SAFETY REQUIREMENTS.
2 MAKE SURE ALL GUARDS ARE CORRECTLY FITTED BEFORE PROCEEDING.
3.1 Deploying the hose
3.1.1 Make sure that the manual rewind handle is removed and the brake is correctly set, see section
2.4. If roller guides are fitted please refer to section 3.4.
3.1.2 The operator should pull the hose from the hosereel with a smooth even movement.
3.1.3 Hosereels with hydraulic motor rewind will rotate by free-wheeling the motor, provided the piping
arrangement is correct and the controls set to the appropriate position.
3.1.4 Motors should not be used to deploy the hose.
3.2 Rewinding the hose –with the manual rewind handle
WARNINGS
1 IF A HOSE ROLLER GUIDE IS FITTED, TAKE CARE NOT TO TRAP HANDS
BETWEEN THE HOSE AND THE ROLLERS.
2 BEFORE COMMENCING THE REWIND OPERATION, MAKE SURE THAT ALL
OTHER PERSONS ARE STANDING AWAY FROM THE HOSEREEL AND THE
HOSE.
CAUTIONS
1 Ensure that there are no tools or other loose objects near the hose or
hosereel.
2 When manually rewinding, if the hose snags or the rewind seizes do not force
the handle to turn, this may cause the teeth on the gears to jump, become
damaged, or distort the frame.
3 When rewinding the hose do not drag the nozzle along the ground.
3.2.1 Return the nozzle to a position adjacent to the hosereel.
3.2.2 Swing open the handwind cover and fit the manual rewind handle to the slotted drive shaft on the
front of the hosereel.
3.2.3 Check that the brake is correctly set to allow free rotation of the drum, section 2.4.
3.2.4 Check the direction of rotation and turn the rewind handle, using gloved hands to guide the hose
evenly across the drum of the hosereel.
3.2.5 When all the hose has been rewound onto the drum, set the brake to prevent the hosereel from
turning.
3.2.6 Finally, ensure that the nozzle and rewind handle are stored safely and the handwind cover is
swung closed.

Product Manual
SDM09H-Hosereel Page 13
Issue 2 –April’20
3.3Rewinding the hose –with the hydraulic rewind motor
3.3.1 Observe the warnings and cautions under 3.2 above.
3.3.2 Return the nozzle to a position adjacent to the hosereel.
3.3.3 Make sure the manual rewind handle is not fitted and the brake is correctly set see section 2.4.
3.3.4 Operate the controls as directed by the installer of the hydraulic system and commence rewind of
the hose.
3.3.5 Allowing the hose to run freely between gloved hands, guide it evenly across the drum of the
hosereel.
3.3.6 When the hose is almost completely rewound, reduce the speed of rewind until all the hose has
been rewound onto the drum.
3.3.7 When all the hose has been rewound onto the drum, set the brake to prevent the hosereel drum
turning.
3.3.8 Finally, ensure that the nozzle is stored safely.
3.4 Operating ancillary devices
3.4.1 Fixed 4 way roller guides
The hose should be fed smoothly between the roller guides when deploying and rewinding. Care
must be taken not to trap hands between the rollers.
3.4.2 Hinged roller guides
Before deploying the hose, the roller guide(s) should be swung into the open position. After use,
and when the hose has been fully rewound, the rollers must be returned to the parked position
3.4.3 Top tilt out roller guides
3.4.3.1 To deploy the rollers first operate the latches at each end before pulling forward the rollers. In the
case of inverted hosereels a pull wire is provided to operate both levers simultaneously. Ensure the
levers return to the latched position before deploying the hose.
3.3.4.2 After rewinding of the hose return the rollers to the “parked” position by unlatching both levers prior
to pushing the rollers back. Ensure the levers return to the latched position.
CAUTION
Do not push the rollers to the parked position without first operating the levers, this may
cause irreparable damage.
3.4.4 Swing out platforms
The spring bolt should be released and the platform opened to the required position, securing with
the appropriate spring bolt. After use the platform should be returned to the “parked” position and
secured with the spring bolt. Dependant upon the installation there may be additional instructions
which should be followed.

Product Manual
SDM09H-Hosereel Page 14
Issue 2 –April’20
4.0 MAINTENANCE
WARNINGS
1 BEFORE PROCEEDING, ISOLATE THE HYDRAULIC POWER SUPPLY TO THE
HOSEREEL.
2 A HOSE THAT LEAKS COULD CAUSE INJURY TO THE OPERATOR.
3 SPECIAL CARE IS REQUIRED WHEN CARRYING OUT MAINTENANCE OR REPAIR
WORK ON INVERTED HOSEREELS.
CAUTIONS
1 A weak hose could swell under pressure and could cause damage to the drum.
2Where there is surface contamination of the hose and reel i.e. road traffic grime, or
frequent hosing down, the reel may need to be greased more frequently than
suggested.
4.1 Weekly maintenance
4.1.1 Check the hydraulic oil level in the reservoir and top up as required.
4.2 Monthly maintenance
4.2.1 Grease the drum bearings and the spindle of the rewind mechanism through the grease nipples.
4.2.2 Lubricate the drive chain sparingly.
4.2.3 Release the brake and check the reel for easy rotation.
4.2.4 Check the hose for damage and deterioration. Look for any swelling under pressure.
4.2.5 If fitted, check that the earth continuity device is functioning correctly, section 2.6.4.
4.3 Bi annual maintenance
4.3.1 Check that all fasteners are tight.
4.3.2 Check for excessive free movement between the bearings on the frame. If necessary adjust the
position of the support bearing at the opposite end of the drum to the rewind assembly.
4.3.3 Remove the plastic guard and check the alignment of the handwind gear pinion and crown wheel. If
adjustment is required, re-position the handwind spindle bracket and lubricate the gear teeth with
grease. Make sure the nyloc nuts are tightened to at least 53Nm [40lb ft ] and refit the guard.
4.3.4 Check the tension of the drive chain(s) over one complete revolution of the drum. Allow 13mm total
side movement of chain at the midway position. Adjust as required by moving the rewind motor
mounting plate. Lubricate the chain with a suitable lubricant.
4.3.5 Examine the hydraulic pipe work for any damage or leaks. Repair any fault found.
4.3.6 Check the control valves for leaks. Repair or replace faulty valves.

Product Manual
SDM09H-Hosereel Page 15
Issue 2 –April’20
4.4 Corrective Maintenance
4.4.1 Removing or replacing the hydraulic rewind motor
4.4.2.1 To remove the motor, first loosen the 4 x M10 nuts and bolts holding the motor bracket to the frame.
This will allow the chain to be removed by sliding the motor assembly to one side.
4.4.2.2 Remove the 4 fixings and remove the assembly from the frame.
4.4.2.3 Remove the sprocket from the shaft by loosening the 2 grub screws and pulling the sprocket of the
end of the shaft. If the sprocket is tight a bearing extractor may be required. DO NOT use a hammer to
knock the sprocket off as this will cause irreparable damage.
4.4.2.4 To refit any parts above follow the reverse order. Allow 13mm total movement of the chain at the
midway position.
4.5 Swingjoint / Fluid Path Assemblies
Collins Youldon hosereels have two basic type of swingjoint / fluid path assembly. ¾”, 1” and 1 ¼” swingjoints
are external to the hosereel, see appendix 4 for more detail. These swingjoints can be replaced or serviced
without removing the delivery hose from the reel.
1½” and 2” fluid paths are formed from several cast items, see figure 12 and appendices 3 and 4. The inlet and
seals of these assemblies can be easily replaced without removing the delivery hose from the reel, however
replacement of the spindle and/or shaft will require removal of the drum from the frame.
Leaking product may be due to a worn inlet seal or component. The inlet seal may need occasional
replacement but if the hosereel frame is twisted this will lead to irregular wear of swingjoint components.
Before replacing worn parts ensure that the frame alignment is correct, see Installation section 2.1.1 and
contact our Sales Department for advice.
4.5.1 Replacing swingjoint seals ¾”, 1” and 1 ¼” hosereels
Equipment A pair of external circlip pliers and 2 new seals.
4.5.1.1 Drain the hose and if necessary remove the inlet hose..
4.5.1.2 Remove the circlip and washer from the end of the stem and pull off the sleeve.
4.5.1.3 Remove the seals inside the sleeve, as you pick the seals out take care not to scratch the bottom of
the groove where the seals fits.
4.5.1.4 Wipe all the parts clean, fit new seals into the grooves, put the sleeve back on the stem.
4.5.1.5 Refit the washer and circlip. Replace the inlet hose if it was removed at 4.5.1.1.
4.5.2 Replacing the swingjoint -¾”, 1”, 1 ½” LPG and 1 ½” high pressure hosereels
4.5.2.1 Disconnect the flexible hose from the swingjoint.
4.5.2.2 Disconnect the swingjoint from the hosereel.
4.5.2.3 Fit the new swingjoint to the hosereel using an appropriate thread sealant.
4.5.2.4 Reconnect the flexible hose to the swingjoint and check for leaks.
4.5.3 Replacing Inlet ‘O’ ring or Chevron seal in 1 ½” and 2” swingjoints

Product Manual
SDM09H-Hosereel Page 16
Issue 2 –April’20
Equipment: 13mm A/F spanner and a new seal (check type is correct for your model of hosereel).
4.5.3.1 Drain the delivery hose and remove the inlet hose from the hosereel inlet.
4.5.3.2 Remove the 3 bolts and shakeproof washers securing the inlet and pull off the inlet to expose the
seal.
4.5.3.3 Remove the old seal from the end of the spindle, taking care not to scratch any of the sealing faces.
4.5.3.4 Wipe all parts clean and fit the new seal. O ring seals locate into the groove on the spindle, chevron
seals locate in the inlet.
4.5.3.5 Apply a little grease to the mating parts of the seal and carefully push the inlet back into position,
locate with the 3 bolts previously removed, taking care not to damage the seal.
4.5.3.6 Refit 3 bolts and tighten firmly, reconnect the hose to the inlet using an appropriate thread sealant
and check for leaks.
NOTE:
If leakage still occurs after replacement of the seals it is possible that other components of the
swingjoint are worn and may need replacement. Please identify your hosereel, see section 1.1 and
contact our Sales department for further assistance.
Figure 12 –Typical swingjoint / fluid path assembly (1½“ and 2”)
Key to parts
1 Spindle
2 Gooseneck
3 Bearing housing
4 Inlet
5 Shaft
6 Chevron seal (or o ring –see appendix 4 and 5)
1
3
4
2
5
6

Product Manual
SDM09H-Hosereel Page 17
Issue 2 –April’20
4.5.4 Replacing the gooseneck &/or seal in 1 ½” and 2” swingjoints
Equipment: 17mm A/F spanner, suitable tools for removing and re-fitting the delivery hose, thread
sealant and 1 new seal (check type is correct for your model of hosereel).
4.5.4.1 Drain the delivery hose and fully unwind it from the drum. Remove the two bolts and shakeproof
washers which secure the gooseneck (still attached to the delivery hose), noting the orientation of
the gooseneck for future use.
4.5.4.2 If replacing the gooseneck remove it from the delivery hose taking care not to damage/crush the
gooseneck when removing the hose. Connect the delivery hose to the new gooseneck using suitable
tools and thread sealant as required. Take care not to damage/crush the gooseneck when fitting the
hose.
4.5.4.3 Remove the seal from inside the groove, taking care not to scratch the bottom of the ‘O’ ring groove.
4.5.4.4 Wipe all parts clean, fit new seal into groove and refit gooseneck holding down with the two bolts
removed at 4.5.4.1 and check for any leaks from the fluid path.
4.5.5 Replacing the inlet of 1 ½” and 2” swingjoints
4.5.5.1 Drain the delivery hose and remove the inlet hose from the hosereel inlet.
4.5.5.2 Remove the 3 bolts and shakeproof washers securing the inlet and pull off the inlet to expose the seal.
Wipe all parts clean and if required fit a new seal into the inlet.
4.5.5.3 Apply a little grease to the mating parts of the seal and carefully push the inlet back into position,
locate with the 3 bolts previously removed, taking care not to damage the seal.
4.5.5.4 Refit 3 bolts and tighten firmly, reconnect the hose to the inlet and check for leaks.
4.5.6 Replacing the bearing housing of 1 ½” and 2” swingjoints
Equipment 2 x 13mm A/F spanners. 17mm A/F spanner. Flat bladed screwdriver. Suitable equipment to
lift/support the hosereel drum. Suitable tools for removing and refitting the inlet hose. Thread
sealant.
4.5.6.1 Drain the delivery hose and, if the hosereel has a rewind motor, isolate the power supply.
4.5.6.2 To reduce the weight of the drum to be supported during bearing replacement, unwind the delivery
hose fully from the drum.
4.5.6.3 If the hosereel has power rewind, remove the chain guard.
4.5.6.4 Slacken the chain fully by loosening the 4 bolts on the drive unit mounting flange and moving the
drive unit towards the centre of the frame.
4.5.6.5 Support the drum, using appropriate equipment and remove the 3 bolts and shakeproof washers
securing the inlet to the bearing housing, and remove the inlet.
4.5.6.6 Remove the 2 bolts and shakeproof washers which connect the two halves of the bearing housing
and lift off the top of the bearing housing.
4.5.6.7 At the opposite end of the drum, remove the bolts securing the bearing to the top of the hosereel
frame, lift the hosereel drum away from the frame assembly and set aside carefully to avoid
damage to the end disks.

Product Manual
SDM09H-Hosereel Page 18
Issue 2 –April’20
4.5.6.8 Remove the nuts and shakeproof washers, which secure the bottom half of the bearing housing to
the top of the hosereel frame. Remove the old part and replace with the new component. Refit the
nuts and shakeproof washers and tighten.
4.5.6.9 Lower the drum into place, at the opposite end of the drum, refit the bolts securing the bearing to
the top of the hosereel frame, and tighten. Fit the new bearing housing top, refitting and tightening
the two bolts and shakeproof washers.
4.5.6.10 Refer to section 4.5.3 regarding replacement of the inlet seal (and the two types of seal that may
be fitted).
4.5.6.11 Apply a little grease to the mating parts of the seal and put the inlet in position, locating with the 3
bolts and shakeproof washers. If the spindle has the ‘O’ ring type seal, take care not to damage
the ‘O;’ ring when positioning the inlet.
4.5.6.12 Tighten the 3 bolts evenly until secure and reconnect the inlet hose to the inlet using thread sealant
as required.
4.5.6.13 If the hosereel has a chain drive, re-tension the chain by moving the motor mounting plate until
there is 13mm total side movement of the chain at the mid-point in its tightened position. Check the
tension of the chain over one complete revolution of the drum. Once this has been achieved,
tighten the 4-drive unit fixing bolts.
4.5.6.14 Refit the chain guard.
4.5.6.15 Check the reel turns freely when the hose is pulled out. If necessary, adjust the brake as described
in section 2.4.
4.5.6.16 Fit the rewind handle (or re-connect the rewind power supply) and check that the rewind operation
works correctly, ensuring the gears are correctly meshed and running smoothly and check for any
leaks in the fluid path.

Product Manual
SDM09H-Hosereel Page 19
Issue 2 –April’20
4.6 PROBLEM SOLVING
Table 1 - Problem solving
Problem
Possible fault
Corrective action
a. Drum does not rotate
easily.
The handwind brake is engaged.
The drum bearings are not
lubricated.
The drive chains are too tight.
The frame was twisted when
mounted.
Rewind gears are not meshed
correctly.
Release handwind brake.
Apply grease to grease nipples.
Loosen the tension so that there is
13mm sideways movement. Check that
the sprockets are correctly aligned.
Loosen mounting bolts, place packing
piece under one corner of the frame and
retighten bolts.
Contact Collins Youldon for advice.
b. Rewind is weak
Hydraulic set pressure too low
Check setting of controls see ‘c’ below
c. Hydraulic drive not
rewinding
No hydraulic fluid flow
Faulty motor
A competent technician should check:-
Hydraulic drive control lever is in correct
position.
Pressure relief valve is set correctly
That there is hydraulic fluid in the
system
Flow control valve is working
Changeover valve is working
Replace the motor, section 4.4.2
d. Product leakage
Leaks from swingjoint.
Make sure seals are not worn, replace
as per section 4.5
Swingjoint defective, replace part or
whole assembly as necessary, see
section 4.5
