PLUS+QUIP EQP-061 User manual

PlusQuip EQP-061
Tool
Getting Started
Guide

INTRODUCTION
Please read this information carefully before using your new PlusQuip EQP-061 tool
Thank you for purchasing your PlusQuip EQP-061 tool. We at PlusQuip believe that you will
have many years of successful business as a result of your investment and it is our aim to
ensure that you will remain as up-to-date as possible.
Always ensure you have the latest version of software and vehicle data that is available. Follow
the instructions for Software Update procedure.
Please refer to this manual when using the tool and don't hesitate to contact your distributor if
you experience any difficulty with it.
Safety Information
Always wear eye protection when handling batteries.
Keep batteries away from children.
No smoking, avoid open flames or creating sparks near batteries.
Explosion hazard. Batteries emit an explosive mixture of hydrogen and
oxygen during and after charging.
Corrosive hazard. Wear protective equipment to shield eyes, hands, and
clothing
Product Details:
Modern battery management systems used in today’s vehicles require their systems to be
reconfigured each time a battery is fitted, the EQP-061 tool allows you to reconfigure the stored
battery data on these modern vehicles.
The EQP-061 tool allows you to enter the new battery information quickly and simply, it can also
display the current battery’s details. In addition, the EQP-061 can be used to initiate a diesel
particulate filter regeneration.
Regeneration must be undertaken on a level concrete surface.
Regeneration must be undertaken externally and must not use exhaust extraction
instead.
oMust be undertaken away from combustible materials.
Regeneration will generate high levels of heat and noise whilst being undertaken, you will
need to:
oEnsure adequate levels of fuel are available and regeneration must not be started
if the fuel light is on.
oEssential that the level of engine oil is checked to ensure sufficient is available.
oEnsure that timing belts have been replaced in line with the manufacturer’s service
levels.
Regeneration cannot repair worn or damaged components.
Regeneration can take between 5 –60 minutes dependent on the manufacturer.

Features:
Replacement of vehicle batteries
Display of battery condition
Display of battery replacement history
Regenerates Diesel Particulate Filters
Resets EOLYS Additive Lights
ID Fault Codes
Filter Replacement Function
Static Regeneration
Numerous Systems Covered
Supports Vehicles from 2000 on
USB Connector
LCD Display
Multi-Functional
Keypad
16 Pin J1962
Diagnostic plug

PlusQuip EQP-061 tool Navigation:
Arrows control the
cursor around the
screen
OK Button confirms
the selected option
Mini USB connector is
used when updating the
tool via a PC
ESC Button cancels an
operation or returns
from a menu

USER INTERFACE:
Navigation buttons
The arrow keys are used to navigate through the
menus.
The OK button is used to confirm a selection.
The ESC button is used to go back to the previous
screen.
The mini USB connector is used to connect to a PC to allow
you to update the PlusQuip EQP-061 tool with additional
software.
The J1962 connector needs to be connected to the vehicle’s
OBD socket in order to get power and make communications
with the particular vehicle.

Menu & Icons
Main Menu
Diagnostic / Vehicle Selection Icon –Select this to go into Vehicle
Specific Serial Diagnostics
System Setup Icon –Select this to configure the
various settings of the PlusQuip EQP-061 Tool
Diagnostic / ECU Selection Icon –Select this to go into ECU Specific Serial
Diagnostics
Information Icon –Select this to display
software and hardware version information

System Setup Menu
Clock Icon –Select this to view the date and
time of the PlusQuip EQP-061 Tool
Garage Information Icon –Select this to display
your user details. This is changed through the
PC Suite
Test Icon –Select this to carry out hardware
tests on the PlusQuip EQP-061 Tool if
requested by Technical Support
Volume Icon –Select this to turn the sounder
ON or OFF
‘Back’ Icon – Select this to return to the
previous menu
Language Selection –Select this icon to
change the language used by the PlusQuip
EQP-061 Tool.

Additional Icons used (depending on Software purchased)
Erase Diagnostic Trouble Codes –Select this to clear the Diagnostic
Trouble Codes on the vehicle you are currently diagnosing.
Live Data –Select this to display Live Data (Components) for the
vehicle you are currently diagnosing.
Actuator –Select this to run actuators for the vehicle you are
currently diagnosing.
Service –Select this to access service related functions only.
Service functions are also accessible under the vehicle selection
option.
Micro Filter - Heating, air conditioning or automatic air conditioning: replace
micro filter/carbon canister this is important because micro filters trap 80% of
the pollen and traffic fumes before it gets into the cabin, helps keep drivers and
passengers alert and helps demist windows quickly even on a rainy winter's
day.
Diagnostic Trouble Codes –Select this to read the Diagnostic
Trouble Codes on the vehicle you are currently diagnosing.
Statutory Inspection - (where relevant) - Statutory inspection for
vehicles 3 years and older

Fuel Filter - Diesel filter is changed. This filter is important to the general
efficiency of diesel engines. As the fuel passes through this filter, unwanted
particles and residue will become trapped, so that the fuel is passing to the
engine is 'clean'. Therefore, this filter has to be replaced when indicated to
ensure that your engine is running at optimum performance.
Vehicle Inspect –General inspection of the vehicle.
Emissions Test –This is part of the statutory test that tests the emissions fall
within the limits required.
Engine Oil - The engine oil and oil filter are changed because keeping the oil at
the right level and clean is vital to the protection and longevity of the life of
movable engine parts. Also, if you do a lot of short journeys, your oil filter will be
more susceptible to blockages caused by the condensation of water in the oil.
Spark Plugs - Spark plugs are replaced. When it comes to fuel efficiently, spark
plugs are one of the most critical parts of a petrol/gasoline car's engine. Defective
spark plugs can result in worsening emissions and increased fuel consumption,
and can even result in misfires if not replaced. Replacing these worn spark plugs
will improve the performance of the engine.
Rear Brake Pads - Brake pads are changed, and the brake caliper cavities are
cleaned. Failure to get your brake pads matched correctly will result in a brake
imbalance front to rear on your vehicle, and if the calipers are cleaned, any
squeaking in the brakes should be diminished.
Brake discs:- Surface and thickness - the importance of having a safe level of
thickness in your brake discs is paramount to your driving safety; if necessary,
the brake discs will be replaced.
Brake Fluid - Brake fluid is changed. The problem with brake fluid is that it
absorbs moisture from the air quickly. This is important because the amount of
moisture in your brake fluid affects your vehicle's performance.
