PMK MSA 100 User manual

3D Probe-Positioners
Instruction Manual

2
Assembly 3D Probe-Positioners
The 3D Probe Positioner is delivered in three single components: Base [A], positioner [B] and probe holder [C].
Screw the positioner [B] to the base [A] and tighten it with a combination wrench (width across flats 7 mm).
The base is available in four different variants: Steel base, vacuum base, table clamp or magnet foot.
Finally screw the probe holder [C] to the other side of the positioner and thighten it with a combination wrench
(width across flats 7 mm), too.
Clamping the Probe
Release the holder tensioning knob [E] and clamp the probe into the probe holder [C], as shown in the figure.
To fix the probe turn the holder tensioning knob [E] contrary until the probe is fixed.
Three different sizes of opening ports are available at the probe holder, which can be used for different probe
dimensions.
[A] [B] [C]

3
Maintenance and General Notes
Basically the 3D Probe Positioner is maintanance-free. However if the device is exposed to pollution, regular
cleaning is necessary.
Remove dust and dirt from the joints.
For cleaning purposes use standard cleaning agents commercially available (don`t use any lyes or acids!).
Apply a little amount of lubricant to the screws and joints.
[D]
[E]
Handling 3D Probe-Positioners
The 3D Probe Positioner can be operated easily.
Hold the 3D Probe Positioner and loosen the central tensioning knob [D] until the 3D Probe Positioner can be
moved. Bring the 3D Probe Positioner into the desired position and fix the device by turning the central
tensioning knob [D] contrary. With the spring tip of PMK probes you can set precisely the contact to the
measuring point.
Attention: Do not release the tensioning knob [D] completely, since otherwise the 3D Probe Positioner
collapses in itself and could damage your measuring setup!

Manufacturer
PMK GmbH
Mess- und Kommunikationstechnik
Königsteiner Straße 98
D-65812 Bad Soden, Germany Internet: www.pmk.de
Phone: [phone] - 930 E-Mail: [email protected]
Fax: [phone] - 939
Warranty
PMK GmbH warrants this oscilloscope accessory for normal use and operation within specifications for a peri-
od of two (2) years from date of shipment and will repair or replace any defective product which was not dama-
ged by negligence, misuse, improper installation, accident or unauthorized repair or modification by the buyer.
This warranty is applicable only to defects due to material or workmanship. PMK GmbH disclaim any other
implied warranties of merchantability or fitness for a particular purpose. PMK GmbH will not be liable for any
indirect, special, incidental, or consequential damages (including damages for loss of profits, loss of business,
loss of use or data, interruption of business and the like), even if PMK GmbH has been advised of
the possibility of such damages arising from any defect or error in this manual or product.
Copyright © 2015 PMK GmbH All rights reserved.
Information in this publication supersedes that in all previously published material. Specifications are subject to
change without notice.
A93-350-00X Revision G - September 2015
PMK 3D Scope-Probe Positioner
Order-No. Type Description
893-350-001 MSA 100 PMK Probe-Positioner with steel base, span width 200 mm (HAL512)
893-350-002 MSB 40 PMK Probe-Positioner with table clamp, span width 200 mm (HAL512)
893-350-003 MSC 85 PMK Probe-Positioner with vacuum clamp, span width 200 mm (HAL512)
893-350-004 MSM 130 PMK Probe-Positioner with magnet foot, span width 130 mm (HAL512)
893-350-005 MSM 200 PMK Probe-Positioner with magnet foot, span width 200 mm (HAL512)
893-350-006 MSU 1500 PMK Probe-Positioner with steel base, span width 200 mm (UNIHOLD)
Accessories and Spares for 3D Probe-Positioners
Order-No. Typ Description
893-100-001 STS 100 1200g heavy steel base, ø 100 mm, Positioner collet M6
893-100-002 TIK 40 Table clamp with a clamping range up to 40 mm for table edges and
pipes, 2 collets M6
893-100-003 VAS 85 Vacuum cup M8 incl. 1 x adapter to M6, ø 85 mm
893-100-004 TM 170 Magnet food 170 N M6 ø 30 mm
893-100-005 TM 300 Magnet food 300 N M8 incl. 1 x adapter to M6, ø 30 mm
893-200-130 STV 130 PMK 3D Probe Positioner, span length 130 mm, both sided M6
893-200-200 STV 200 PMK 3D Probe Positioner, span length 200 mm, both sided M6
893-050-000 HAL 512 Holder for PMK probes and other probing devices with ø 5-12 mm,M6
893-000-M86 GAD M86 Screw adapter M8/M6 SW 13 mm
893-090-000 UNIHOLD PMK universal Probe Holder "Uniholder" for PMK Probes and other
Readings recorders with ø 1.5-17 mm, M6
