Samson FOUNDATION 3730-5 Service manual

Series 3730
Electropneumatic Positioner
Type 3730-5
with FOUNDATION™ fieldbus communication
FF Device Rev 2
Mounting and
Operating Instructions
EB 8384-5 EN (1300-1619)
Firmware version 1.55
Edition July 2012
Fig. 1 · Type 3730-5

Contents Page
1 Important safety instructions . . . . . . . . . . . . . . . . . . . . . . 8
2 Article code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3 Design and principle of operation . . . . . . . . . . . . . . . . . . . 11
3.1 Application type. . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.2 Additional equipment . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.3 Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.3.1 Configuration using TROVIS-VIEW software . . . . . . . . . . . . . . 14
3.3.2 Configuration using the NI-FBUS™ Configurator . . . . . . . . . . . . 14
3.4 Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4 Attachment to the control valve – Mounting parts and accessories . . . 18
4.1 Direct attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.1.1 Type 3277-5 Actuator . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.1.2 Type 3277 Actuator . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.2 Attachment according to IEC 60534-6 . . . . . . . . . . . . . . . . . 24
4.3 Attachment to Type 3510 Micro-flow Valve. . . . . . . . . . . . . . . 26
4.4 Attachment to rotary actuators . . . . . . . . . . . . . . . . . . . . . 28
4.4.1 Heavy-duty version . . . . . . . . . . . . . . . . . . . . . . . . . . 30
4.5 Reversing amplifier for double-acting actuators . . . . . . . . . . . . . 32
4.5.1 Reversing amplifier (1079-1118 or 1079-1119) . . . . . . . . . . . . 32
4.6 Attaching an external position sensor. . . . . . . . . . . . . . . . . . 34
4.6.1 Mounting the position sensor with direct attachment. . . . . . . . . . . 34
4.6.2 Mounting the position sensor with attachment according to IEC 60534-6 36
4.6.3 Mounting the position sensor to Type 3510 Micro-flow Valve . . . . . . 37
4.6.4 Mounting the position sensor to rotary actuators . . . . . . . . . . . . 38
4.7 Attaching positioners with stainless steel housings. . . . . . . . . . . . 39
4.8 Air purging function for single-acting actuators . . . . . . . . . . . . . 39
4.9 Mounting parts and accessories . . . . . . . . . . . . . . . . . . . . 41
5 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
5.1 Pneumatic connections . . . . . . . . . . . . . . . . . . . . . . . . . 44
5.1.1 Signal pressure gauges . . . . . . . . . . . . . . . . . . . . . . . . 44
5.1.2 Supply pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
5.1.3 Signal pressure (output) . . . . . . . . . . . . . . . . . . . . . . . . 45
5.2 Electrical connections . . . . . . . . . . . . . . . . . . . . . . . . . 45
5.2.1 Establishing communication . . . . . . . . . . . . . . . . . . . . . . 48
6 Operator controls and readings . . . . . . . . . . . . . . . . . . . . 50
7 Start-up – Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . 52
2EB 8384-5 EN
Contents

7.1 Defining the valve closed position . . . . . . . . . . . . . . . . . . . 52
7.2 Setting the volume restriction Q . . . . . . . . . . . . . . . . . . . . 53
7.3 Adapting the display. . . . . . . . . . . . . . . . . . . . . . . . . . 53
7.4 Limiting the signal pressure. . . . . . . . . . . . . . . . . . . . . . . 54
7.5 Checking the operating range of the positioner . . . . . . . . . . . . . 54
7.6 Initialization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
7.6.1 MAX – Initialization based on maximum range . . . . . . . . . . . . . 57
7.6.2 NOM – Initialization based on nominal range . . . . . . . . . . . . . 58
7.6.3 MAN – Initialization based on a manually selected range . . . . . . . . 59
7.6.4 SUb substitute calibration . . . . . . . . . . . . . . . . . . . . . . . 60
7.7 Zero calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
7.8 Selecting the application type . . . . . . . . . . . . . . . . . . . . . 64
7.9 Reset to default values . . . . . . . . . . . . . . . . . . . . . . . . . 64
8 Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
8.1 Enabling and selecting parameters . . . . . . . . . . . . . . . . . . 65
8.2 Operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
8.2.1 Automatic and manual modes . . . . . . . . . . . . . . . . . . . . . 66
8.2.2 SAFE – Fail-safe position. . . . . . . . . . . . . . . . . . . . . . . . 67
8.3 Malfunction/maintenance alarm . . . . . . . . . . . . . . . . . . . . 67
8.3.1 Confirming error messages . . . . . . . . . . . . . . . . . . . . . . 68
9 Adjusting the limit switch . . . . . . . . . . . . . . . . . . . . . . . 69
9.1 Retrofitting an inductive limit switch. . . . . . . . . . . . . . . . . . . 71
10 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
11 Servicing explosion-protected devices . . . . . . . . . . . . . . . . . 72
12 Firmware update (serial interface) . . . . . . . . . . . . . . . . . . . 72
13 Maintenance, calibration and work on equipment . . . . . . . . . . . 73
14 Code list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
14.1 Decimal values of the modes in the FOUNDATION™ fieldbus blocks
(Code 48) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
14.2 Decimal values of the states in the FOUNDATION™ fieldbus blocks
(Code 48) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
15 Dimensions in mm. . . . . . . . . . . . . . . . . . . . . . . . . . . 98
15.1 Fixing levels according to VDI/VDE 3845 (September 2010) . . . . . 100
16 Valve characteristic selection . . . . . . . . . . . . . . . . . . . . . 101
Test certificates. . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
EB 8384-5 EN 3
Contents

4EB 8384-5 EN
DANGER!
indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING!
indicates a hazardous situation which, if not
avoided, could result in death or serious inju-
ry.
NOTICE
indicates a property damage message.
Note: Supplementary explanations,
information and tips
Definitions of the signal words used in these instructions

Revisions of the positioner firmware compared to the previous version – Control R
Control R 1.43 R 1.44
Internal revisions
R 1.45
Internal revisions
R 1.46
Internal revisions
R 1.52
Application type The user determines in the positioner whether the valve is to oper-
ate as a control valve or an open/close (on/off valve) (see section
3.1)
Diagnosis All EXPERTplus diagnostic functions are available without having
to activate them in the positioner (see EB 8389 EN on
EXPERTplus Valve Diagnostics).
Additional function blocks – 2x DO (Discrete Output)
– 1x IS (Input Selector)
– 1x MAI (Multiple Analog Input)
– 1x MAO (Multiple Analog Output)
Refer to Configuration Manual KH 8384-5 EN
New functions In the DO Function Block (Discrete Output), the following new
functions are implemented:
– Discrete analysis of on/off valves
– Start partial stroke test (PST)
– Start and reset the data logger
– Reset diagnosis
– Stop diagnosis
– Move to fail-safe position
– Lock local operation
Refer to Configuration Manual KH 8384-5 EN
Action on fault detection If the AO Transducer Block is in Out of Service mode and the
condensed state changes to 'Maintenance alarm', the following
actions can be started:
– Hold last value
– Move valve to fail-safe position
– Move to a predefined fault state value
Refer to Configuration Manual KH 8384-5 EN
EB 8384-5 EN 5
Revisions of the positioner firmware

Revisions of the positioner firmware compared to the previous version – Control R
Codes 48 extended The following subitems have been added to Code 48:
h0: Activation/deactivation reference test
h1: Reference test completed (YES/No)
h3: Automatic reset of diagnosis after this time
h4: Remaining time until diagnosis time
See section 14.
R 1.54 and R 1.55
Internal revisions
Revisions to the communication firmware are listed in the Configuration Manual
KH 8384-5 EN.
6EB 8384-5 EN
Revisions of the positioner firmware

Note concerning these Mounting and Operating Instructions
These instructions EB 8384-5 EN describe the mounting, start up and on-site operation of the
Type 3730-5 Positioner.
You can find additional information on the enclosed CD-ROM (CD 8384-5) or on the Internet
at http://www.samson.de.
The CD-ROM (CD 8384-5) contains further information on the Type 3730-5 Positioner:
4[Documentation]
–KH 8384-5 EN: Configuration Manual for Type 3730-5 Electropneumatic
Positioner, configuration and operation over FOUNDATION™fieldbus
–T 8384-5 EN: Data Sheet for Type 3730-5 Electropneumatic Positioner
–EB 8389 EN: Instructions for Series 373x Positioners; EXPERTplus Valve Diagnostics
–T 8389 EN: Data Sheet for EXPERT/EXPERT+Valve Diagnostics
–T 6661 EN: Data Sheet for TROVIS-VIEW software
4[Approvals]
– PTB/ATEX – NEPSI
– CSA – GOST
– FM – STCC
– IECEx – JIS
– CERTUSP/INMETRO – CCoE
4[Declarations of Conformity]
4[Integrations]
– Enhanced Electronic Device Description (DD)
– 375/475 Field Communicator
– Emerson AMS™/DeltaV™
– Yokogawa PRM – Device Viewer
4[TROVIS-VIEW (demo version)]
The HTML-based CD-ROM allows you to easily find any required information using a web
browser.
The PDF documents can be read using Acrobat Reader software.
EB 8384-5 EN 7
Note concerning these Mounting and Operating Instructions

1 Important safety instructions
For your own safety, follow these instructions concerning the mounting, start-up and opera-
tion of the positioner:
4The positioner is to be mounted, started up or operated only by trained and
experienced personnel familiar with the product.
According to these Mounting and Operating Instructions, trained personnel refers to
individuals who are able to judge the work they are assigned to and recognize
possible dangers due to their specialized training, their knowledge and experience as
well as their knowledge of the applicable standards.
4Explosion-protected versions of this positioner may only be operated by personnel
who have undergone special training or instructions or who are authorized to work
on explosion-protected devices in hazardous areas. Refer to section 11.
4Any hazards that could be caused by the process medium, the operating pressure, the
signal pressure or by moving parts of the control valve are to be prevented by means
of the appropriate measures.
4If inadmissible motions or forces are produced in the actuator as a result of the supply
pressure, the supply pressure must be restricted by means of a suitable supply
pressure reducing station.
To avoid damage to any equipment, the following also applies:
4Do not operate the positioner with the back of the positioner/vent opening facing
upwards.
The vent opening must not be sealed when the positioner is installed on site.
4Proper shipping and appropriate storage are assumed.
4Do not ground electric welding equipment near to the positioner.
8EB 8384-5 EN
Important safety instructions
Vent opening

Note: The device with a CE marking fulfills the requirements of the Directives 94/9/EC
(ATEX) and 89/336/EEC (EMC).
The Declaration of Conformity is included on the CD-ROM (CD 8384-5).
EB 8384-5 EN 9
Important safety instructions

2 Article code
Positioner Type 3730-5 xxx0x0xx0x00x0xx
With LCD and autotune, FOUNDATION™ fieldbus
Explosion protection
Without 0
ATEX: II 2G Ex ia IIC T6; II 2D Ex tb IIIC T 80°C IP 66 1
FM/CSA:
Class I, Zone 0 AEx ia IIC; Class I, II, III, Div.1, Groups A–G;
ClassI,Div.2,GroupsA–D; ClassII,Div.2,GroupsF,G/
Ex ia IIC T6; Class I , II, Div.1, Groups A–G;
Ex nA II T6; Ex nL IIC T6; Class I, II, Div.2, Groups A–G; Class II, Div.1, Groups E–D
3
ATEX: II 3G Ex nA II T6, II 3G Ex ic IIC T6, II 3D tc IIIC T 80°C IP 66 8
Additional equipment
Inductive limit switch Without
SJ2-SN
SJ2-S1N
0
1
2
Solenoid valve Without
With, 24 V DC
0
4
External position sensor Without
With 0
0
10 0
Binary input Without
Floating contact 0
0
1
Diagnostics
EXPERTplus 4
Housing material
Aluminum (standard) 0
Stainless steel 1.4581 0 1
Special applications
None 0
Positioner compatible with paint 1
Vent connection with ¼-18 NPT thread, back of housing sealed 0 0 0 0 2
Special version
None 000
NEPSI: Ex ia IIC T6 1 0 0 9
NEPSI: Ex nA II T6; Ex nL IIC T6 8 0 1 0
IECEx: Ex ia IIC T6 1 0 1 2
GOST: 0Ex ia IIC T8 X 1 0 1 4
10 EB 8384-5 EN
Article code

3 Design and principle of
operation
The electropneumatic positioner is attached
to pneumatic control valves. It is used to as-
sign the valve stem position (controlled vari-
able x) to the control signal (reference vari-
able w). The input signal received from a
control system is compared to the travel or
rotational angle of the control valve, and a
pneumatic signal pressure (output variable
y) is produced.
The positioner consists of a travel sensor sys-
tem proportional to resistance, an analog
i/p converter with a downstream booster
and the electronics unit with microcontroller.
When a deviation occurs, the actuator is
pressurized or vented. If required, the
changes in the signal pressure can be
slowed down by a connectable Q restriction.
The signal pressure supplied to the actuator
can be limited by software or on site to 1.4,
2.4 or 3.7 bar.
A constant air stream to the atmosphere is
created by the flow regulator (9) with a
fixed set point. The air stream is used to
purge the inside of the case as well as to op-
timize the air capacity booster. The i/p
module (6) is supplied with a constant up-
stream pressure by the pressure regulator
(8) to make it independent of the supply air
pressure.
EB 8384-5 EN 11
Design and principle of operation
Fig. 2 · Functional diagram
w
x
Q
%
S
mm
GG
PD
Serial
Interface
16
15
BE2
BE1
11
2
4
13
20
17 18
19
24V DC
5
3
12
6
7
8
10
1
14
9
x
y
1 Control valve
2 Travel sensor
3 PD controller
4 A/D converter
5 Microcontroller
6 i/p converter
7 Air capacity booster
8 Pressure regulator
9 Flow regulator
10 Volume restriction
11* Inductive limit switch
12* Solenoid valve
13 IEC 61158-2
interface module
14 Binary input, passive
15* Binary input, active
16 Display
17* Solenoid valve control
18* Galvanic isolation
19 D/A converter
20 Communication interface
* Optional
FOUNDATION
fieldbus
IEC 61158-2

The positioner communicates and is pow-
ered using IEC 61158-2 transmission tech-
nology conforming to FOUNDATION™
fieldbus specification.
As a standard feature, the positioner comes
with a binary input for DC voltage signals to
signalize process information over the
FOUNDATION™fieldbus.
The extended EXPERTplus diagnostics are in-
tegrated into the positioner. They provide in-
formation on the positioner and generates
diagnostic and status messages, which allow
faults to be pinpointed quickly.
The positioner is suitable for the following
types of attachment using the corresponding
accessories:
4Direct attachment to SAMSON
Type 3277 Actuator: Section 4.1
4Attachment to actuators acc. to
IEC 60534-6 (NAMUR): Section 4.2
4Attachment to Type 3510 Micro-flow
Valve: Section 4.3
4Attachment to rotary actuators acc. to
VDI/VDE 3845: Section 4.4
3.1 Application type
Two application types for the valve are
available: Control valve and Open/Close
(on/off) valve. The manual mode
(MAN) and the automatic mode (AUTO)
can be selected with both application types.
Depending on the application type that has
been selected, the positioner behaves differ-
ently in the automatic mode (AUTO) :
Control over FOUNDATION™ fieldbus is
performed over the AO Function Block (con-
trol valve) and over the DO1 Function Block
(on/off valve). The application type can be
entered in the Resource Block over the
SELECT_DO_1 parameter (see Configura-
tion Manual KH 8384-5 EN) or at the
positioner using Code 49 - h0. See section
14.
Note:
–
Depending on the application type, cer-
tain diagnostic functions cannot be per-
formed or analyzed. Refer to
EB 8389 EN on EXPERTplus valve diag-
nostics.
–
In manual mode, an on/off valve can be
moved past 100 % of the nominal range
(with the closed position for ATO) or be-
low 0 % of the nominal range (with the
closed position for ATC). See section 7.1
for the valve closed position.
3.2 Additional equipment
Solenoid valve
If the operating voltage for the solenoid
valve (12) fails, the supply pressure for the
i/p module is vented to the atmosphere. The
12 EB 8384-5 EN
Design and principle of operation
Control valve Open/close valve
AUTO The positioner
follows the reference
variable
continuously.
The valve position
(current position)
appears in % on the
display.
Discrete analysis
of the reference
variable.
The valve position
(current position)
in % and O/C
(Open/Close) ap-
pear in alternating
sequence on the
display.
MAN The positioner follows the reference
variable given over local operation.

positioner can no longer operate and the
control valve moves to the fail-safe position
determined by the actuator, independent of
the reference variable.
NOTICE
In manual mode (MAN), the manual set
point is also reset to 0 %. A different manual
set point must be entered again (Code 1).
Inductive limit switch
The rotary shaft of the positioner carries an
adjustable tag which actuates the installed
proximity switch.
External position sensor
In this version, only the sensor is mounted to
the control valve. The positioner is located
separately from the valve.
The connection of x and y signals to the
valve is established by cable and piping for
air (only without inductive limit switch).
Binary inputs
Binary input BE1 (14):
The positioner has an binary input for DC
voltage signals as standard, which allows
process information to be exchanged over
the FOUNDATION™fieldbus network.
Binary input BE2 (15):
This binary input is optional. It is an active
input which connects a floating contact
which is powered by the positioner. The
switching state of the binary input can be in-
dicated over the FOUNDATION™fieldbus
network.
Note: The binary inputs are configured in
the DI Function Blocks (see Configuration
Manual KH 8384-5 EN).
3.3 Communication
The positioner is completely controlled over
the digital signal transmission implemented
according to FOUNDATION™ fieldbus spec-
ification.
Data are transmitted as bit-synchronous
current modulation at a rate of 31.25 kbit/s
over twisted-pair cables conforming to
IEC 61158-2.
Note: In the case, complex functions are
started in the positioner, which require a
long calculation time or lead to a large
quantity of data being stored in the volatile
memory of the positioner, the alert “busy” is
issued over DD.
This alert is not a fault alarm and can sim-
ply be confirmed.
The Configuration Manual KH 8384-5 EN
contains a description on how to configure
and operate the positioner over
FOUNDATION™ fieldbus.
EB 8384-5 EN 13
Design and principle of operation

3.3.1 Configuration using
TROVIS-VIEW software
The positioner can be configured using
TROVIS-VIEW Configuration and Operator
Interface software.
The positioner is equipped with an addi-
tional digital SERIAL INTERFACE to connect
the RS-232 or USB port of the computer to
the positioner over an adapter cable.
The TROVIS-VIEW software enables the user
to easily set parameters in the positioner
and view process parameters online.
Note: The TROVIS-VIEW software is a com-
mon operator interface for various smart
SAMSON devices. The software together
with a device-specific module allow the con-
figuration and parameterization of the de-
vice.
The device-specific module for Type 3730-5
can be downloaded free of charge from the
SAMSON website (Services > Software >
TROVIS-VIEW).
Additional information on TROVIS-VIEW
(e.g. system requirements) can found on the
SAMSON website and in the Data Sheet
T 6661 EN.
3.3.2 Configuration using the
NI-FBUS™ Configurator
The NI-FBUS™ Configurator from National
Instruments can also be used to configure
the positioner. For this purpose, an interface
card must be installed in a computer to con-
nect it to the FOUNDATION™ fieldbus.
The integrated function blocks are linked us-
ing the NI-FBUS™ Configurator.
14 EB 8384-5 EN
Design and principle of operation

3.4 Technical data
EB 8384-5 EN 15
Design and principle of operation
Type 3730-5 Positioner (technical data in test certificates additionally apply for explosion-protected devices)
Rated travel,
adjustable
Direct attachment to Type 3277: 3.6 to 30 mm
Attachment acc. to IEC 60534-6: 3.6 to 200 mm
Attachment to rotary actuators (VDI/VDE 3845): 24° to 100°
Travel range,
adjustable
Adjustable within the initialized travel/angle of rotation;
travel can be restricted to 15at the maximum
Bus connection
Fieldbus interface acc. to IEC 61158-2 bus-powered
Physical Layer Class: 113 (without explosion protection) und 111 (with ex. protection)
Field device acc. to FM 3610 Entity, FISCO and FNICO
Communication
Fieldbus
Data transmission as per FOUNDATION™ fieldbus specification,
Communication Profile Class: 31 PS, 32 L;
Interoperability tested according to Interoperability Test System (ITK 5.2) Revision 4.6
Local Over SAMSON SSP interface and serial interface adapter
Software requirements
(SSP) SAMSON TROVIS-VIEW with database module 3730-5
Permissible operating
voltage
9 to 32 V DC, power supply over bus line
The limits in the test certificate additionally apply for explosion-protected devices
Max. operating current 15 mA
Add. current in case of fault 0 mA
Supply air
Supply pressure from 1.4 to 7 bar (20 to 105 psi),
Air quality acc. to ISO 8573-1 Edition 2001: Max. particle size and density: Class 4
Oil content: Class 3; Moisture and water: Class 3; Pressure dew point: At least 10 K
beneath the lowest ambient temperature to be expected
Signal pressure (output) 0 bar up to supply pressure,
limitable to 1.4/2.4/3.7 bar ±0.2 bar via software
Characteristic
Linear/equal percentage/reverse equal percentage · User-defined (over operating
software and communication) · Butterfly valve linear/equal percentage · Rotary plug
valve linear/equal percentage · Segmented ball valve linear/equal percentage
Deviation from terminal-based conformity £1 %
Hysteresis £0.3 %
Sensitivity £0.1 %
Direction of action Reversible
Air consumption Independent from supply pressure approx. 110 ln/h
Air output capacity
Actuator pressurized
Actuator vented
At Dp = 6 bar: 8.5 mn
3/h, at Dp = 1.4 bar: 3.0 mn 3/h KVmax (20 °C) = 0.09
at Dp = 6 bar: 14.0 mn
3/h, at Dp = 1.4 bar: 4.5 mn 3/h KVmax (20 °C) = 0.15

16 EB 8384-5 EN
Design and principle of operation
Type 3730-5 Positioner (technical data in test certificates additionally apply for explosion-protected devices)
Permissible ambient
temperature
–20 to +80 °C for all versions
–45 to +80 °C with metal cable gland
–25 to +80 °C with inductive limit switch (SJ2-S1N) and metal cable gland
The limits in test certificate additionally apply for explosion-protected devices.
Influences
Temperature £0.15 %/10 K
Supply air None
Vibration £0.25 % up to 2000 Hz and 4 g acc. to IEC 770
Electromagnetic
compatibility
Complying with requirements of EN 61000-6-2, EN 61000-6-3, EN 61326-1 and
NAMUR Recommendation NE 21
Explosion
protection
ATEX
FM
CSA
NEPSI
IECEx
GOST
Type 3730-51: II 2G Ex ia IIC T6, II 2D Ex tb IIIC T 80 °C IP 66
Type 3730-58: II 3G Ex nA IIC T6, II 3G Ex ic IIC T6, II 3D Ex tc IIIC T 80 °C IP 66
Type 3730-53: Class I, Zone 0 AEx ia IIC; Class I, II, III, Div.1, Groups A–G;
Class I, Div.2, Groups A–D; Class II, Div.2, Groups F, G
Type 3730-53: Ex ia IIC T6; Class I, II, Div.1, Groups A–G;
Ex nA II T6; Ex nL IIC T6; Class I, II, Div.2, Groups A–G; Class II, Div.1,
Groups E–D
Type 3730-51xx0x0xx0x00x009: Ex ia IIC T6
Type 3730-58xx0x0xx0x00x010: Ex nA II T6; Ex nL IIC T6
Type 3730-51xx0x0xx0x00x012: Ex ia IIC T6
Type 3730-51xx0x0xx0x00x014: 0Ex ia IIC T8 X
Electrical connection One M20 x 1.5 cable gland, for 6 to 12 mm clamping range · Second additional
threaded M20 x 1.5 hole · Screw terminals for 0.2 to 2.5 mm² wire cross-section
Degree of protection IP 66/NEMA 4X
Implementation in
safety-related systems in
compliance with
IEC 61508/SIL
Probability of failure on demand of safety functions PFD < 2.8 x 10–7 for a confidence
level of 95 %.
The safe failure fraction (SFF) according to Table A1 in IEC 61508-2 is greater or
equal to 0.99.
The valves are therefore suitable for implementation in safety-related systems with a
hardware fault tolerance of 1 or 2 up to and including SIL 4.
Binary input BE1
Input 0 to 30 V DC reverse polarity protection, static destruction limit 40 V,
current consumption 3.5 mA at 24 V, galvanically isolated
Signal Signal “1” at Ue > 5 V · Signal “0” at Ue < 3 V
Materials
Housing Die-cast aluminum EN AC-AlSi12(Fe) (EN AC-44300) acc. to DIN EN 1706;
chromated and powder paint coated · Special version: stainless steel 1.4581
External parts Stainless steel 1.4571 and 1.4301
Cable gland Nickel-plated brass, M20x1.5
Weight Approx. 1 kg

EB 8384-5 EN 17
Design and principle of operation
Options for Type 3730-5
Binary input BE2 for floating contact
Switching input R < 100 W, contact loadability 100 mA, static destruction limit 20 V / 5.8 mA,
galvanically isolated
Solenoid valve Approval acc. to IEC 61508/SIL
Input
24 V DC, reverse polarity protection, static destruction limit 40 V
Current consumption I = U5.7V
3840
-
W(corresponding to 4.8 mA at 24 V/114 mW)
Signal "0" no pick-up £15 V
Signal "1" safe pick-up >19 V
Service life >5 x 106switching cycles
KVcoefficient 0.15
Implementation in
safety-related systems in
compliance with
IEC 61508/SIL
Same as positioner pneumatics
Inductive limit switch For connection to switching amplifier acc. to EN 60947-5-6
SJ2-SN proximity switch NAMUR NC contact
SJ2-S1N proximity switch NAMUR NO contact
External position sensor
Travel Same as positioner
Cable 10 m with M12x1 connector, designed for continuous flexing, flame retardant acc. to
VDE 0472, resistant to oils, lubricants, coolants as well as other corrosive media
Perm. ambient temperature –60 to +105 °C
Vibration immunity Up to 10 g in the range between 10 and 2000 Hz
Degree of protection IP 67

4 Attachment to the control
valve – Mounting parts and
accessories
WARNING!
Mount the positioner, keeping the following
sequence:
1. Remove protective film from pneumatic
connections.
2. Mount the positioner on the control
valve
3. Connect the supply air
4. Connect the electrical power
5. Perform the start-up settings
The positioner is suitable for the following
types of attachment:
4Direct attachment to SAMSON
Type 3277 Actuator
4Attachment to actuators according to
IEC 60534-6 (NAMUR)
4Attachment to Type 3510 Micro-flow
Valve
4Attachment to rotary actuators
NOTICE
Attach the positioner to the control valve,
observing the following instructions to avoid
damaging the positioner.
–
Use only the mounting parts/accessories
listed in the Tables 1 to 5 (pages 41 to
43) to mount the positioner. Observe the
type of attachment!
–
Observe the assignment between lever
and pin position (see travel tables on
page 19)!
Lever and pin position
The positioner is adapted to the actuator
and to the rated travel by the lever on the
back of the positioner and the pin inserted
into the lever.
The travel tables on page 19 show the maxi-
mum adjustment range at the positioner. The
travel that can be implemented at the valve
is additionally restricted by the selected
fail-safe position and the required compres-
sion of the actuator springs.
The positioner is standard equipped with the
lever M(pin position 35).
Note: If the standard mounted lever M (pin
position 35) is replaced, the newly mounted
lever must be moved once all the way as far
as it will go in both directions to adapt it to
the internal measuring lever.
18 EB 8384-5 EN
Attachment to the control valve – Mounting parts and accessories
Fig. 3 · Lever M with pin position 35

EB 8384-5 EN 19
Attachment to the control valve – Mounting parts and accessories
Travel tables
Note: The lever Mis included in the scope of delivery.
Levers S,L,XL for attachment according to IEC 60534-6 (NAMUR) are available as acces-
sories (see Table 3 on page 42).
Direct attachment to Type 3277-5 and Type 3277 Actuators
Actuator size Rated travel Adjustment range at positioner Required
lever
Assigned
pin position
[cm²] [mm] Min. Travel Max.
120 7.5 5.0 to 25.0 M 25
120/240/350 15 7.0 to 35.0 M 35
355/700 30 10.0 to 50.0 M 50
Attachment according to IEC 60534-6 (NAMUR)
SAMSON valves/Type 3271 Actuator Other valves/actuators
Required
lever
Assigned
pin position
Actuator size Rated travel
[cm²] [mm] min. Travel max.
60 and 120 with
Type 3510 Valve 7.5 3.6 to 18.0 S 17
120 7.5 5.0 to 25.0 M 25
120/240/350 15 7.0 to 35.0 M 35
700 7.5
700 15 and 30 10.0 to 50.0 M 50
1000/1400/2800 30 14.0 to 70.0 L 70
1000/1400/2800 60 20.0 to 100.0 L 100
1400/2800 120 40.0 to 200.0 XL 200
Attachment to rotary actuators according to VDI/VDE 3845
Rotary actuators Required
lever
Assigned
pin position
Min. Opening angle Max.
24 to 100° M 90°

4.1 Direct attachment
4.1.1 Type 3277-5 Actuator
Refer to Table 1 on page 41 for the required
mounting parts as well as the accessories
with their order numbers.
Note the travel table on page 19!
Actuator with 120 cm²
Depending on the type of positioner attach-
ment, the signal pressure is routed either left
or right of the yoke through a bore to the
actuator diaphragm. Depending on the
fail-safe action of the actuator "Actuator
stem extends" or "Actuator stem retracts"
(valve closes or opens upon supply air
failure), the switchover plate (9) must first be
attached to the actuator yoke. Align the
switchover plate with the corresponding
symbol for left or right attachment according
to the marking (view looking onto the
switchover plate).
1. Mount connecting plate (6) or pressure
gauge bracket (7) with pressure gauges
onto the positioner, making sure both
seal rings (6.1) are seated properly.
2. Remove vent plug (4) on the back of the
positioner and close the signal pressure
output "Output 38" on the connecting
plate (6) or on the pressure gauge
bracket (7) with the stopper (5) included
in the accessories.
3. Place follower clamp (3) on the actuator
stem, align and screw tight so that the
mounting screw is located in the groove
of the actuator stem.
4. Mount cover plate (10) with narrow side
of the cut-out opening (Fig. 4, left) point-
ing towards the signal pressure connec-
tion. Make sure that the bonded gasket
(14) points towards the actuator yoke.
5. 15 mm travel: Keep the follower pin (2)
at lever M(1) on the back of the
positioner in the pin position 35 (deliv-
ered state).
7.5 mm travel: Remove the follower pin
(2) from the pin position 35, reposition it
in the bore for pin position 25 and
screw tight.
6. Insert formed seal (15) in the groove of
the positioner casing.
7. Place positioner on the cover plate (10)
in such a manner that the follower pin
(2) rests on the top of the follower clamp
(3). Adjust the lever (1) correspondingly
and open the positioner cover to hold
the positioner shaft in position at the cap
or the switch (Fig. 20).
The lever (1) must rest on the follower
clamp with spring force.
Mount the positioner on the cover plate
(10) using the two fixing screws. During
the installation make sure that the seal
ring (10.1) is inserted in the bore of the
cover plate.
8. Mount cover (11) on the other side.
Make sure that the vent plug points
downwards when the control valve is in-
stalled to allow any condensed water
that collects to drain off.
20 EB 8384-5 EN
Attachment to the control valve – Mounting parts and accessories
