PMT AS7.P001.101 User manual

TrimLine Vehicle Dock with Flex Lock
For Panasonic FZ-G1 Toughpad Tablet Computers
User Guide
www.precisionmounts.com
Description
Part Number
PMT Standard G1 Vehicle
Dock with Flex Lock
AS7.P001.101
PMT Standard G1 DPT Vehicle Dock with Flex Lock
AS7.P001.105
PMT Extended G1 Vehicle Dock with Flex Lock
AS7.P001.201
PMT Extended G1 DPT
Vehicle Dock with Flex Lock
AS7.P001.205
Note: Extended docks accommodate extended batteries and hand straps

Description of Parts and Layout
Lock
Docking Connector
RF pass thru
connectors
(optional)
Docking
Guide Plate
Top Clamp Locating Pin
Mounting Plate
attachment holes
(4) 2 each side
Front View
Note: Pictures used are of a standard dual pass thru (DPT) vehicle dock, however
processes and info relate to all PMT FZ-G1 vehicle docks
Alignment
Guide (2)
Grounding Pin (2)

Description of Parts and Layout
Top Clamp
Flex Lock Lever
Mounting Plate
attachment
holes (4) 2 each
side
Rear View
Note: Pictures used are of a standard dual pass thru (DPT) vehicle dock, however
processes and info relate to all PMT FZ-G1 vehicle docks

Description of Parts Continued
Power
16v dc
Ethernet
USB 3.0
USB 3.0
HDMI
VGA
Serial
Internal/External Antenna Switch
-Switch should be towards the outboard
side of the dock when using external (RF
pass-though) antennas
Rear View
WWAN (cellular data)
(optional)
-SMA style connector*
*TNC adapters available
WLAN (WIFI or
GPS)
(optional)
-SMA style
connector*

Inserting the Tablet
Step 1:
Ensure the dock is unlocked
To unlock insert key and rotate to the
horizontal (unlocked) position and
remove the key
Step 3:
Insert the tablet bottom edge first
ensuring proper alignment with
connector and alignment pins, then
push top of tablet back into the dock
Step 2:
Pull the Flex Lock Lever towards the
outside of the dock
The Top Clamp will spring up to the
open position to allow easy tablet
docking

Inserting the Tablet
Step 4:
Push the Top Clamp down until it clicks.
The Flex Lock lever will auto-engage
and the tablet is now secure in the dock
and ready for use
Step 5:
For added theft deterrence you may
now insert the key and rotate to
vertical (locked) position, then remove
the key

Removing the Tablet from Docking Station
Step 1:
Ensure the dock is unlocked
To unlock insert key and to the
horizontal (unlocked) position
and remove the key
Step 2:
Pull the Flex Lock Lever towards the
outside of the dock
The Top Clamp will spring up to the
open position to allow easy tablet
removal
Step 3:
Tilt the top of the computer out and
past the Top Clamp, then remove from
the dock.
The dock can now be left as is making
re-docking of the tablet even easier

Wiring/Cable Management
Tie Strap
Tie Strap
Connect all cables securely to dock
connections, and use tie straps to
secure cables to the built-in slots on
the mounting/interface plate.
PMT VESA 75mm x 75mm
mounting/interface plate
Wiring Tip:
PMT does not recommend relying on a
cigarette socket adaptor for powering
vehicle docks. We recommend hard wiring
using a good clean ground direct from the
vehicle battery (-) post, and (+) supply from
a fused 12v location also directly from the
vehicle battery. All Peripherals connecting
to the docking station should get power
and ground from the same location as the
dock.
Visit www.precisionmounts.com/installation-instructions.html for a copy of our general wiring and
troubleshooting guide

Mounting
Once you have attached all cables
needed to the vehicle dock, attach the
mounting/interface plate to the dock
using the 4 supplied 10-24 UNC screws as
shown
The standard mounting/interface plate
that comes with the PMT G1 TrimLine
vehicle dock features an industry
standard VESA 75mm x 75mm bolt
pattern. This allows easy mounting to
many pre-existing mounts as well as
dedicated mounts from PMT. The
screws needed for this are M4 x 12mm.
For more info visit: www.precisionmounts.com
Or call us at 1-888-869-7652
[e-mail]
Description
Part
Number
PMT VESA 75mm x 75mm
mounting/interface plate
AS7.P001.001
