PMT AS7.P201.100 User manual

515 58th Ave SE, Calgary, Alberta, T2H 0P7
1-888-869-7652 | [email protected]
WWW.PRECISIONMOUNTS.COM
TRIMLINE VEHICLE DOCK FOR
PANASONIC G1/G2 TABLET
COMPUTERS
Description Part Number
Docking Station for Panasonic Toughbook® G2 NPT AS7.P201.100
Docking Station for Panasonic Toughbook® G2 NPT AS7.P201.102
Cradle for Panasonic Toughbook® G2 AS7.P201.104
Docking Station for Panasonic Toughbook® G2 Extended NPT AS7.P201.200
Docking Station for Panasonic Toughbook® G2 Extended DPT AS7.P201.202
Cradle for Panasonic Toughbook® G2 Extended AS7.P201.204
Docking Station for Panasonic Toughbook® G2 Lite NPT AS7.P201.120
Docking Station for Panasonic Toughbook® G2 Lite DPT AS7.P201.122
Docking Station for Panasonic Toughbook® G2 Extended Lite NPT AS7.P201.220
Docking Station for Panasonic Toughbook® G2 Extended Lite DPT AS7.P201.222
USER GUIDE
Bundles with power adapters are available and are indicated with –PS suffix
added to the part number. Extended models are compatible with tablets with
rear mounted hand straps installed.

515 58th Ave SE, Calgary, Alberta, T2H 0P7
1-888-869-7652 | [email protected]
WWW.PRECISIONMOUNTS.COM
GENERAL INSTRUCTIONS
SAFETY:
•Safety is dependent on the proper installation and servicing of this docking station. It is important to read and
follow all instructions before installing this product.
•Proper installation requires a good understanding of automotive electrical systems and is recommended to be
performed by qualified technicians only.
•There are no adjustments or user serviceable parts within the docking station. Opening the docking station will void
the product warranty
•Do not install equipment or route wires in the deployment path of any air bag, or where it may interfere with critical
safety or operating controls of any vehicle.
POWER:
•The power input should be 15.0Vdc / 5.5 A. The dock is meant to operate on 14.5 Vdc to 16 Vdc. Use a
recommended power supply for the dock. Panasonic recommends using a Lind Auto Adapter (PMT part#: PS002)
for this dock.
WIRING:
•PMT does not recommend relying on a cigarette socket adaptor for powering vehicle docks. We recommend hard
wiring the power adapter using a good clean ground direct from the vehicle battery neg(-) post, and pos(+) supply
from a fused 12vdc location also directly from the vehicle battery. All peripherals connecting to the docking station
requiring external power should get power and ground from the same location as the dock.
•Visit www.precisionmounts.com/support/installation-user-guides.html for a copy of our general wiring and
troubleshooting guide.
Proper Use and Care:
•Proper care and use of this product is critical to maximize safety and to prevent damage to the docking station and
tablet.
•Do not store, place, or drag any object on top of the docking station.
•Visually inspect the docking station and tablet for any defect before using the dock or docking the laptop. Do not
use if damaged.
•Do not attempt to dock a computer or dock with wet contacts
Environmental:
•Storage: -51°C to 71°C (-59°F to 160°F)
•Operating: -29°C to 60°C (-20°F to 140°F)
SERVICING [ENTRETIEN]:
•If the dock does not work as intended, please contact PMT for troubleshooting or to schedule a service. [Si le dock
ne fonctionne pas comme prévu, contactez PMT pour le dépannage ou pour planifier un service.]
•Servicing of the dock should be only done by authorized service center personnel. Unauthorized servicing of the
dock will void its warranty. [L'entretien du dock ne doit être effectué que par le personnel du centre de service
autorisé. Un entretien non autorisé du dock annulera sa garantie.]
Product Mounting Disclaimer
Precision Mounting Technologies Ltd (PMT) are not liable under any theory of contract or tort law for any loss, damage, personal injury,
special, incidental or consequential damages for personal injury or other damage of any nature arising directly or indirectly as a result of
the improper installation or use of its products in vehicle or any other application. In order to safely install and use PMT products full
consideration of vehicle occupants, vehicle systems (i.e., the location of fuel lines, brake lines, electrical, drive train or other systems), air-
bags and other safety equipment is required. PMT specifically disclaims any responsibility for the improper use or installation of its
products not consistent with original vehicle manufactures specifications and recommendations, PMT product instruction sheets, or
workmanship standards as endorsed through PMT policies and EULA.

515 58th Ave SE, Calgary, Alberta, T2H 0P7
1-888-869-7652 | [email protected]
WWW.PRECISIONMOUNTS.COM
DESCRIPTION OF PARTS
Top clamp
Lock
Docking connector
RF pass thru pins (optional)
Corner clamps

515 58th Ave SE, Calgary, Alberta, T2H 0P7
1-888-869-7652 | [email protected]
WWW.PRECISIONMOUNTS.COM
DESCRIPTION OF PARTS CONT’D
Mounting plate
With VESA 75
hole pattern and
¼-20 UNC hardware
Cable tie rail
Mounting plate attachment
screws.
10-32 UNF (x4)

515 58th Ave SE, Calgary, Alberta, T2H 0P7
1-888-869-7652 | [email protected]
WWW.PRECISIONMOUNTS.COM
PORT IDENTIFICATION
RF Pass thru connectors (optional)
(TNC)
Antennae switch
-Switch should be towards
outboard side of dock when
using external RF antennas
connected to dock
Power in
15 Vdc
Ethernet
RJ45
10/100
mbps
USB 3.0
(x2)
HDMI
(not present on
“lite” docks)
VGA
(not present on
“lite” docks)
Serial
RS-232

515 58th Ave SE, Calgary, Alberta, T2H 0P7
1-888-869-7652 | [email protected]
WWW.PRECISIONMOUNTS.COM
INSTALLATION
Step 1:
Remove mounting plate from
dock.
Step 2:
Install mounting plate onto
mounting location via the
VESA 75 interface and the
provided hardware.
Step 3:
Connect all required wiring to
the dock while utilizing plastic
tie straps and the cable tie rail
to secure cables/connections.
Step 4:
Attach dock to mounting plate
using the 4x 10-32 UNF button
head screws provided
Tip: Visit our website and review our “General wiring and
troubleshooting guide” for further information.

515 58th Ave SE, Calgary, Alberta, T2H 0P7
1-888-869-7652 | [email protected]
WWW.PRECISIONMOUNTS.COM
DOCKING THE TABLET
Step 1:
Ensure lock is in the unlocked
position
Step 2:
Place tablet bottom edge first
against the docking connector
Step 3:
Push the middle of the tablet
against the top clamp and back
towards the dock. Ensure that
the Top Clamp fully drops down
over the front face of the tablet
once in position. If excessive
force is required, stop and check
alignment and ensure dock is
unlocked.
Step 4:
For additional security and theft
deterrence, insert key and rotate
lock to the locked position.

515 58th Ave SE, Calgary, Alberta, T2H 0P7
1-888-869-7652 | [email protected]
WWW.PRECISIONMOUNTS.COM
UN-DOCKING THE TABLET
Step 1:
If previously locked, insert key
and rotate lock to the unlocked
position.
Step 2:
Using your thumb, push Top
Clamp up then pull the top of
the tablet away from the dock.
Step 3:
Once clear of the Top Clamp,
lift the tablet out and away
from the dock.

515 58th Ave SE, Calgary, Alberta, T2H 0P7
1-888-869-7652 | [email protected]
WWW.PRECISIONMOUNTS.COM
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions. (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Certifications and test standards:
MIL-STD-810G
RoHS(2011/65/EU)
Made in Canada
