PMT TrimLine AS7.D011.100 User manual

TrimLine Vehicle Dock
For Durabook U11 Tablet Computers
User Guide
www.precisionmounts.com
call us at 1-888-869-7652 | [email protected]Description Part Number
TrimLine Dock for Durabook U11 tablet, tandard, NPT A 7.D011.100
TrimLine Dock for Durabook U11 tablet, tandard, TPT A 7.D011.103
TrimLine Cradle for Durabook U11 tablet, tandard, NPT A 7.D011.104
TrimLine Cradle for Durabook U11 tablet, tandard, TPT A 7.D011.105
TrimLine Dock for Durabook U11 tablet, Extended, NPT A 7.D011.200
TrimLine Dock for Durabook U11 tablet, Extended, TPT A 7.D011.203
TrimLine Cradle for Durabook U11 tablet, Extended, NPT A 7.D011.204
TrimLine Cradle for Durabook U11 tablet, Extended, TPT A 7.D011.205

General Instructions
POWER:
•The power input should be 19 VDC, 65W. Use a recommended power supply for the dock.
ACCESSORIES:
•Only EXTENDED dock will accommodate tablet additional accessory attachments such as
extended battery, hand strap etc.
•Rear camera and finger print scanner are accessible even when the tablet is docked (in both
dock variants).
WIRING:
•PMT does not recommend relying on a cigarette socket adaptor for powering vehicle docks.
We recommend hard wiring using a good clean ground direct from the vehicle battery (-) post,
and (+) supply from a fused 12v location also directly from the vehicle battery. All Peripherals
connecting to the docking station should get power and ground from the same location as the
dock.
•Visit www.precisionmounts.com/support/installation-user-guides.html for a copy of our
general wiring and troubleshooting guide.
SERVICING [ENTRETIEN]:
•If the dock does not work as intended, please contact PMT for troubleshooting or to schedule
a service. [Si le dock ne fonctionne pas comme prévu, contactez PMT pour le dépannage ou
pour planifier un service.]
•ervicing of the dock should be only done by authorized service center personnel.
Unauthorized servicing of the dock will void its warranty. [L'entretien du dock ne doit tre
effectué que par le personnel du centre de service autorisé. Un entretien non autorisé du dock
annulera sa garantie.]

Description of Parts and Layout
Lock
Docking Connector
RF pass thru
connectors
Top Clamp
Top Ear (2)
Mounting Bracket
attachment holes
(4) 2 each side
Front View
Note: All pictures used in this guide are of Extended, triple pass thru (TPT) vehicle dock
(Part no: A 7.D011.203). However processes and information relate to other variants of
the same dock mentioned in previous page.
Grounding Pin (2)
upport bracket
(only for extended
docks)

Description of Parts Continued
Power
19 Vdc IN
Ethernet
U B 3.0 (2)
U B 2.0 (2)
HDMI
erial
VGA
lider Latch Rear View
peaker and
Microphone
MA Antenna
Connectors (Optional)

Docking the Tablet
tep 1:
Ensure that the dock is unlocked
and unlatched. If locked, insert key
and rotate lock 90 degrees
counter-clockwise. To unlatch, pull
the lider Latch away from the
center. This allows the Top Clamp
to spring up to open position.
tep 2:
Lead the bottom of the tablet into
the dock using the guide pins for
positioning.
tep 3:
Push the top of the tablet back into
the dock. The tablet should be held
in place by the Top Ears. Gently
push the Top Clamp downward till
it latches and a click sound is
heard.
tep 4:
[Additional security] Rotate key 90
degrees clockwise and remove the
key to lock the tablet in the
docking station. The tablet is only
fully secure once the key is
removed.

Undocking the Tablet
tep 1:
Ensure that the dock is unlocked.
If locked, insert key and rotate
lock 90 degrees counter-
clockwise.
tep 2:
Unlatch the dock by pulling the
Latch lider away from the center.
This allows the Top Clamp to
spring up to open position.
tep 3:
Tilt the top of the tablet out and
past the Top Clamp, then remove
from the dock.
The dock can be left as is making
re-docking of the tablet easier.
tep 4:
[Optional] Push the Top Clamp
downward to the latched
position.

Cable Management & Mounting
Connect all cables securely to
dock ports, and use tie straps to
secure cables to the “Mounting
Bracket” as shown.
The mounting bracket has slots,
so that the tie straps can be
secured at desired location.
Once you have attached all cables
needed to the vehicle dock, attach
the mounting bracket to the dock
using the 4 supplied #10-24 UNC
screws (2 on each side)
The standard mounting bracket that
comes with the PMT U11 tablet
dock features an industry standard
VE A 75mm x 75mm bolt pattern.
This allows easy mounting to many
pre-existing mounts as well as
dedicated mounts from PMT. Use
the supplied #¼-20 hardware for
mounting.
