PodSpeakers MiniPod Bluetooth User manual

USER GUIDE - ENGLISH
Wall Mount
for MiniPod

THANK YOU!
Dear Customer,
Congratulations on your new MiniPod Wall Mount.
We wish you many years of audible and visible enjoyment together
with your MiniPod.
Best regards from,
Your Podspeakers Team
Model: MiniPod Wall Mount – User Guide revision v1.0 – Oct 2017
We accept no liability for printing errors.
Mounting the wall mount is at your own risk.
Specications are subject to change without notice.
PODSPEAKERS 2017
EET Group A/S, Tempovej 41, DK2750 Ballerup, Denmark
USER GUIDE
www.podspeakers.com

4 5
USER GUIDE - INDEX
IN THE BOX 5
CONNECT SPEAKER CABLES 6
MOUNT BASE PLATE 6
MOUNT WALL PLATE 8
MOUNT THE SPEAKER 9
PARING/RESET 11
What’s in the box?
A : 1 x Wall plate
B : 1 x Wall plate cover
C : 1 x Base plate
D (115) : 1 x Arm for downward angled wall mounting
D (100) : 1 x Arm for straight wall mounting
E : 1 x Allen wrench
F : 1 x Bolt for mounting arm in wall plate
G : 1 x M6x60 bolt for mounting speaker on base plate and arm
H : 2 x M6x50 bolt for mounting speaker on base plate
I : 2 x Pin for operating speaker buttons through base plate
W-A : 6 x screws for wall mounting
W-B : 6 x washers for wall mounting
IN THE BOX
W-A )(x6 W-B )(x6
E )(x1
F )(x1
G
M6x60 (x1)
H
M6X50 (x2)
D (115)
x1 D (100)
x1°
A (x1) B (x1) C (x1)
I )(x2

6 7
CONNECT SPEAKER CABLES
Connect all cables to the speakers.
Please see Speaker Manual for instructions.
MOUNT BASE PLATE
MOUNT BASE PLATE
Mount the base plate to the speaker (including the
Aluminum Arm).
Make sure the cables are directed into the gap, so they
are not damaged.
Do not tighten the 3 screws too much (it might damage
the speaker or wall mount)
D(115) / D(100°)
C
E
HH
G

8 9
MOUNT WALL PLATE
Mount the wall plate on the wall (in a vertical position). Make sure to use proper
screw to match the wall type. The included screw might not work well on all
wall types.
Mount the speaker on the wall mount by inserting the arm into the wall mount
and tighten the top bolt so the speaker won’t turn by itself. Adjust speaker to
preferred angle before tightening the bolt. The bolt shall only be tightened so it
keep the speaker rmly in position (not too much). Once in position place the
cover plate over the wall plate.
MOUNT THE SPEAKER
60mm
(2.4")
ø 10mm
(ø 3/8")
W-B
W-A
2
1
X X
√
A
B
E
F

10 11
PARING/RESET PARING/RESET
Once the speaker is wall mounted you may, at some later point, need to reset
and/or do stereo pairing.
For that purpose please use the included pin tools.
For Stereo paring use one pin to
press button through the middle
hole.
To reset use two pins to press
buttons through the left and right
hole (press simultaneously).
For further instructions about Stereo Pairing or Reset please refer to
the MiniPod Bluetooth user manual.
