  9. POLA HP53 User manual

POLA HP53 User manual

HP53
MAIN SETTINGS (Run Mode)
VENTILATIONTEMPERATURESETTING.
Press °C VENT:
This message will be displayed instead of the °Set
Ventilation temperature value (start first speed).
Press + or - to modify, press °C VENT to confirm.
MINIMUMSPEEDSETTING.
Press MIN VENT:
This message will be displayed instead of the
Minimum Ventilation Speed.
Press +or - to modify, press MIN to confirm.
MAXIMUMSPEEDSETTING.
Press MAX VENT:
This message will be displayed instead of the
Maximum Ventilation Speed.
Press +or - to modify, press MAX to confirm.
In normal condition ambient temperature is displayed and in setting coindition
flashingmessageappear.
The normal condition become again after exit from setting mode (auto-exit is
performed after 5 seconds from last key stroke in setting condition).
Press +: will be displayed followed by
°Maximum Temperature Recording.
Press - : will be displayed followed by
°Minimum Temperature Recording.
VIEWING TEMPERATURE RECORDING
Values recorder are memory permanent stored: for memory clear keep pushed +
keysformorethan3seconds: CLEA messagewillbecomposedondisplaybefore
clearingoperation.
AMBIENT TEMPERATURE VIEWING
How to connect the sensors
Connect the temperature probe provided as shown in the diagram. For remote
connections use astandard0.5-squaremillimetertwo-polewire for eachsensor,
taking great care over the connections, by insulating and sealing the joins
carefully.
How to connect the line
Connect 220V line on terminals L-N.
How to connect the contacts
Connectterminals3-7/ ...11-13onthe terminal block(contactsupto4AMP.AC1).
Output contacts are N.O. (Normally Opened and free of voltage) on wich is
aplliable a 4AMP AC1 maximum load.
3-4= Speed 1 contact.
3-5= Speed 2 contact.
3-6= Speed 3 contatc.
3-7= Speed 4 contact.
11-12= Heat contact.
12-13= Cool contact
INSTALLATION
PRESET PROGRAMS
Atdeliverythisprocessorisreadyprogrammedwith the following(variable)
settings. To return to these settings at any time:
Power off the processor, press MAX VENT key and keep it pressed giving
power on: boot message will be displayed (release now MAX VENT key).
°C VENT=25.0° MIN VENT=0 MAX VENT=4
The COSt values are shown in COSt paragraphs. Handbook
Steps-Controller
SL 2.0
.
HP53
FUSE 4A T
H=1500A
H=1500A
FUSE 4A T
230V LINE *
COMMON
SPEED 4
SPEED 3
SPEED 2
SPEED 1
TEMPER. PROBE
COOL
COMMON.
HEAT
* Other power voltage if you required
As it company policy to continually improve the products the Manufacturers
reserve the right to make any modifications thereto without prior notice. They
cannot be held liable for any damage due to malfunction.
19.07.06
These settings refer to the mode of operation of the system and must be
made on initial start-up. Press - / + together for at least one second.
the message C.O.S.t. will be displayed.
Press than repeatly MAX VENT until interested variable's message is
displayed (see table below) : variable value and related message will be
displayed. Press + or - to set a new value and then MAX VENT to confirm.
The next system constant will then appear. You can press MAX VENT for a least two second
to escape and return to the Run Mode.
COSt PROGRAMMING (System constants)
"HAND MODE"
In some start-up conditions may be useful to work in "hand" mode.
Power off theprocessor, press + key and keep it pressed giving power on:
HAnd message will be displayed (release now + key).
Push + until is displayed number required to be handed (see table relays
"N° Relay") and push MAX VENT for activing relay.
Pushingagain + forincreaserelaynumberpreviousrelayisdisactivated.Youcan
press MAX VENT for a least two seconds to escape and return to the Run Mode.
STATUS INDICATION LAMPS
VEL 4 ON
ProP
1/3 ProP
1/3 ProP1/3 ProP
HEAT
VEL. 1 OFF
r.HEA HEAT ON
vEnt °C VENT
key setting
0.2°
0.2°
0.2°
0.2°
Minimum
Ventilation
conditioned
Step from 0to 1become
according to chosed COSt
option tYPE 1-2-3-4.
d.HEA
TEMP.AMB.
HEAT ON
V1
V2
V3
V4 Maximum
Ventilation
conditioned
OPERATING DIAGRAM
The lights situated at the bottom of the display show the state of the various relays as set out below.
Speed 3 Selected
Speed 4 Selected
Speed 2 Selected
Speed 1 Selected
Speed 0 Selected
Heating On
Lamp. N° Relay
HEAT 0 1 2 3 4
HEAT 1 0 0 0 0 0 5
VENT 1 0 0 10 0 0 1
VENT 2 00010 0 2
VENT 3 0 0 0 0 103
VENT 4 0 0 0 0 0 1 4
Output relay
Table of relay Outputs with tYPE= 1-2-3-4-9 (Variable speed control)
Lamp. N° Relay
HEAT 0 1 2 3 4
HEAT 10 0 0 0 0 5
VENT 1 0 0 10 0 0 1
VENT 2 0 0 1 1 0 0 2
VENT 3 0 0 1 1 1 03
VENT 4 0 0 1 1 1 1 4
Output relays with tYPE = 14 (see COSt)
Table of relay Outputs with tYPE = 14 (On-Off regulation type)
Mess. Value Meaning Note
ProP 3.0° ° Ventilation proportional band *1)
r.HEA -0.5° ° HEAT setting referring to °C VENT *2)
d.HEA 0.2° ° HEAT differential *2)
tEnP =1 Temperature representation *3)
Ad.tE 0.0° ° input sensor temperature correction *4)
tYPE =1 Start ventilation actioning mode *5)
*1) From lower value ventilators starts at speed n°1 at temperature setted on
°C VENT key and reach speed n°4 at temperature °C VENT + ProP.
*2) This set is a relative set reffered to temperature setted on°C VENT key.
For example if is setted °C VENT=25.0° and r.HEA=-0.5° heating command
(HEAT) will start at 24.5° (25.0°-0.5°).
Heating will be OFF after 0.2° (value d.HEA).
*3) tEnP =0 : °C Temperature range.
tEnP =1 : °F Temperature range.
*4) You can correct the readings on the sensor (+ or -).
*5) Different mode of ventilator initial start-up optionally settable (step from 0 to 1
speed).
tYPE= 1 : 0 to 1 step become in normal mode.
tYPE= 2 : 0 to 1 step become with a momentary 10 seconds at speed 2.
tYPE= 3 : 0 to 1 step become with a momentary 5 seconds at speed 3.
tYPE= 4 : 0 to 1 step become with a momentary 5 seconds at speed 4.
tYPE=13 : Heating mode ventilation.
tYPE=14 : Progressive speed (On-Off regulation type).
Options 2,3,4 permitstomakeaneasyopeningofshuttermodelsventilators.
Option 13 permits Heater mode ventilation (low temperature = hight speed; in
other options high temperature= high speed).
Option 14 permits On-Off regulation speed (in other condition regulation is for
variable speed control).
With tYPE = 13 :
V0 V4
V1 V3
V2 V2
V3 V1
V3 V0
Heater mode ventilation
