Polar Electro GG755-A User manual

Model:
GG755-A
Counter top
Cooler
Instruction manual
GG755-A_A5_v1_20230323.indb 1GG755-A_A5_v1_20230323.indb 1 2023/3/23 10:282023/3/23 10:28

2
EN Telephone Helpline: 1300225960
Safety Instructions
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- Fire Precautions
- IEE Wiring Regulations
- Building Regulations
• DO NOT immerse the appliance in water, or use jet/pressure
washers to clean the appliance.
• DO NOT allow oil or fat to come into contact with the plastic
components or door seal. Clean immediately if contact occurs.
• DO NOT store products on top of the appliance.
• Always carry, store and handle the appliance in a vertical
position and move by holding the base of the appliance.
• Always switch off and disconnect the power supply to the
appliance when not in use.
• Not suitable for outdoor use.
• Keep all packaging away from children. Dispose of the
packaging in accordance to the regulations of local authorities.
• If the power cord is damaged, it must be replaced by a POLAR
agent or a recommended qualified technician in order to avoid
a hazard.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning the use of the
appliance by a person responsible for their safety.
GG755-A_A5_v1_20230323.indb 2GG755-A_A5_v1_20230323.indb 2 2023/3/23 10:282023/3/23 10:28

3
AUEN
Telephone Helpline: 1300225960
• Children should be supervised to ensure that they do not play
with the appliance.
• POLAR recommend that this appliance should be periodically
tested (at least annually) by a Competent Person. Testing
should include, but not be limited to: Visual Inspection,
Polarity Test, Earth Continuity, Insulation Continuity and
Functional Testing.
Caution: Risk of fire/Flammable materials
• Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
Warning: Keep all ventilation openings clear of
obstruction. Unit should not be boxed in without
adequate ventilation.
• Warning: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Warning: Do not damage the refrigerant circuit.
• Warning: Do not use electrical appliances inside the food
storage compartments of the appliance.
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and operation of
this machine will provide the best possible performance from your POLAR product.
Pack Contents
The following is included:
• Counter top cooler
• Instruction Manual
POLAR prides itself on quality and service, ensuring that at the time of unpacking the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your POLAR dealer immediately.
GG755-A_A5_v1_20230323.indb 3GG755-A_A5_v1_20230323.indb 3 2023/3/23 10:282023/3/23 10:28

4
EN Telephone Helpline: 1300225960
Installation
Note: Not for use in vans or trailers, food
trucks or similar vehicles.
Note: If the unit has not been stored or
moved in an upright position, let it stand
upright for approximately 12 hours before
operation. If in doubt allow to stand.
1. Remove the appliance from the packaging.
Make sure that all protective plastic film and
coatings are thoroughly removed from all
surfaces.
2. To optimize performance and longevity, ensure
a minimum clearance of 2.5cm is maintained
between the unit and walls and other objects,
with a minimum 20cm clearance on the top.
NEVER LOCATE NEXT TO A HEAT SOURCE.
Note: Before using the appliance for the
first time, clean the interior with soapy
water then dry well.
Operation
• The appliance is designed for display
purpose only and not for storage.
• Remove any water that may be present
before and after use, using the drain
hose beneath the base.
Control panel
On/off switch
Refrigerant LED:
During refrigerating, LED is on; When
the set temperature is reached and
constant, LED is off.
Defrost LED:
During defrosting, LED is on; When
defrosting finishes, LED is off.
Up Button
Down Button
Manual defrost button/light button
SET Set button
Turn On
1. Close the door of the appliance.
2. Connect the appliance to the mains power
supply.
3. Press On/off switch located on the rear.
Adjusting the Temperature
1. Press SET button. The set temperature is
displayed.
2. Press up button or down button to
change the set temperature.
3. Press SET button to exit.
Internal light
Press the button on the controller to turn the
internal light on/off.
Manual Defrost
To start/stop manual defrost, press and hold
defrost button for 6 seconds.
GG755-A_A5_v1_20230323.indb 4GG755-A_A5_v1_20230323.indb 4 2023/3/23 10:282023/3/23 10:28

5
AUEN
Telephone Helpline: 1300225960
Tips for use:
• Only store foodstuff in the appliance when it has reached the correct operating temperature.
• Avoid opening the door too often. Opening the door for long periods can cause a significant increase
of the temperature in the appliance.
• Clean regularly surfaces that can come in contact with food and accessible drainage system.
Cleaning, Care & Maintenance
• Switch off and disconnect from the power supply before cleaning.
• Clean the interior of the appliance as often as possible.
• Do not use abrasive cleaning agents. These can leave harmful residues.
• Always wipe dry after cleaning.
Condensation and ice will form with frequent and prolonged opening of the doors.
Operating outside of the recommend temperature range and placing next to a heat source
will also increase the amount of ice and internal/external condensation. If external
condensation occurs wipe the surface down with a cloth.
Excessive ice will result in longer running times that will increase energy consumption and
increase the deterioration of components.
If the gasket or seal is damaged or deformed, energy consumption will increase. To restore
efficiency, replace gasket.
Cleaning the Condenser
Periodic cleaning of the Condenser can extend the life of the appliance.
POLAR recommend that a POLAR agent or qualified technician clean the condenser.
Troubleshooting
A qualified technician must carry out repairs if required.
Fault Probable Cause Solution
The appliance is not
working
The unit is not switched on
Check unit is plugged in correctly and
switched on
Plug or lead is damaged Replace plug or lead
Mains power supply fault Check mains power supply
The appliance is not
cooling
Coolant Leak Consult a qualified technician
Airflow to the condenser
obstructed
Increase the gap between appliance and
obstacles/heat source
Condenser is clogged Consult a qualified technician
Appliance is overloaded Reduce the amount of food stored in the
appliance
The appliance is noisy Appliance is not level Adjust position to make it level
Appliance is too close to a wall
or other object
Move to a more suitable location
GG755-A_A5_v1_20230323.indb 5GG755-A_A5_v1_20230323.indb 5 2023/3/23 10:282023/3/23 10:28

6
EN Telephone Helpline: 1300225960
Technical Specifications
Note: Due to our continuing program of research and development, the specifications herein may be
subject to change without notice.
Model Voltage Power Current Capacity Temp.
range Refrigerant Dimensions H x W x D mm Weight
GG755-A 220-240V~
50Hz
105W 0.7A 40L 2°C ~ 6°C R600a 357 x 676 x 575 25kg
Note: For optimal product performance and efficiency, please ensure to mind the net usable capacity (load
limit) when filling.
Electrical Wiring
The plug is to be connected to a suitable mains socket.
This appliance is wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
The appliances must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The product must not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and environmentally safe
recycling process. For further information on how to dispose of this product correctly, contact the product
supplier, or the local authority responsible for waste disposal in your area.
POLAR parts have undergone strict product testing in order to comply with regulatory
standards and specifications set by international, independent, and federal authorities.
POLAR products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of POLAR.
Every effort is made to ensure all details are correct at the time of going to press, however, POLAR reserve the right to
change specifications without notice.
GG755-A_A5_v1_20230323.indb 6GG755-A_A5_v1_20230323.indb 6 2023/3/23 10:282023/3/23 10:28

DECLARATION OF CONFORMITY
• Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •
• Declaración de conformidad
Equipment Type • Uitrustingstype • Type d'équipement • Gerätetyp
• Tipo di apparecchiatura • Tipo de equipo
Model • Modèle • Modell • Modello
• Modelo
G-series Counter top Cooler
GG755 (-E & -A)
Application of Territory Legislation
& Council Directives(s)
Toepassing van Europese
Richtlijn(en) • Application de la/des
directive(s) du Conseil • Anwendbare
EU-Richtlinie(n) • Applicazione delle
Direttive
• Aplicación de la(s) directiva(s) del
consejo
Low Voltage Directive (LVD) - 2014/35/EU
Electrical Equipment (Safety) Regulations 2016
(BS) EN 60335-1:2012 +A11:2014 +A13:2017
+A1:2019 +A14:2019 +A15:2021
(BS) EN 60335-2-89:2010 +A1:2016 +A2:2017
(BS) EN 62233:2008
Electro-Magnetic Compatibility (EMC) Directive
2014/30/EU - recast of 2004/108/EC
Electromagnetic Compatibility Regulations 2016
(S.I. 2016/1091)
(BS) EN IEC 61000-6-1:2019
(BS) EN 61000-6-3:2021
Restriction of Hazardous Substances Directive
(RoHS) 2015/863 amending Annex II to Directive
2011/65/EU
Restriction of the Use of Certain Hazardous
Substances in Electrical and Electronic
Equipment Regulations 2012 (S.I. 2012/3032)
Electrical Safety
IEC 60335-1:2010 +A1:2013
+A2:2016
IEC 60335-2-89:2019
EN 62233:2008
Electromagnetic Compatibility
EN IEC 61000-6-1:2019
EN 61000-6-3:2021
Producer Name • Naam fabrikant • Nom du producteur • Name des Herstellers
• Nome del produttore • Nombre del fabricante
Polar
I, the undersigned, hereby declare that the equipment specified above conforms to the above Territory Legislation, Directive(s)
and Standard(s).
Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de bovenstaande
Richtlijn(en) en Standaard(en).
Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus
Ich, der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n) und
Norm(en) entspricht.
Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati.
El abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y
estándar(es) arriba mencionadas.
Date • Data • Date • Datum • Data •
Fecha • Data
13th January 2023
Signature • Handtekening •
Signature • Unterschrift Firma •
Firma
Full Name • Volledige naam • Nom
et prénom • Vollständiger Name •
Nome completo • Nombre completo
Ashley Hooper
Eoghan Donnellan
Brendan Denmeade
Position • Functie • Fonction •
Position • Qualifica • Posición
Technical & Quality
Manager
Commercial Manager/
Importer
Commercial Manager/ Responsible
Supplier
Producer Address • Adres fabrikant •
Adresse du producteur • Anschrift
des Herstellers • Indirizzo del
produttore • Dirección del fabricante
Fourth Way,
Avonmouth,
Bristol,
BS11 8TB
United Kingdom
Unit 9003,
Blarney Business Park,
Blarney,
Co. Cork
Ireland
15 Bagdally Road,
Campbelltown
NSW 2560
DocuSign Envelope ID: 9B553A82-5955-442D-A8CE-F1E669F04AAC
GG755-A_A5_v1_20230323.indb 7GG755-A_A5_v1_20230323.indb 7 2023/3/23 10:282023/3/23 10:28

http://www.polar-refrigerator.com/
GG755-A_A5_v1_2023/03/23
GG755-A_A5_v1_20230323.indb 8GG755-A_A5_v1_20230323.indb 8 2023/3/23 10:282023/3/23 10:28
