Polar Electro UA023-A User manual

Model:
UA023-A / UA024-A
Refrigerated
Counter
Instruction manual
UA023-A_UA024-A_A5_v1_20220304.indb 1UA023-A_UA024-A_A5_v1_20220304.indb 1 2022/3/4 16:162022/3/4 16:16

2
EN Telephone Helpline: 1300225960
Safety Instructions
Please take a few moments to carefully read through this
manual. Correct maintenance and operation of this machine will
provide the best possible performance from your POLAR product.
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components or service panels on this product.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- Fire Precautions
- Wiring Regulations
- Building Regulations
• DO NOT use jet/pressure washers to clean the appliance.
• DO NOT use the appliance outside.
• DO NOT use this appliance to store medical supplies.
• DO NOT stand or support yourself on the base, drawers or
doors.
• DO NOT allow oil or fat to come into contact with the plastic
components or door seal. Clean immediately if contact occurs.
• Bottles that contain a high percentage of alcohol must be
sealed and placed vertically in the refrigerator.
• Always carry, store and handle the appliance in a vertical
position and move by holding the base of the appliance.
• Always switch off and disconnect the power supply to the unit
before cleaning.
• Keep all packaging away from children. Dispose of the
packaging in accordance with the regulations of local
authorities.
• Children should be supervised to ensure that they do not play
with the appliance.
UA023-A_UA024-A_A5_v1_20220304.indb 2UA023-A_UA024-A_A5_v1_20220304.indb 2 2022/3/4 16:162022/3/4 16:16

3
AUEN
Telephone Helpline: 1300225960
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience or knowledge, unless they have been
given supervision or instruction concerning the use of the
appliance by a person responsible for their safety.
• POLAR recommend that this appliance should be periodically
tested (at least annually) by a Competent Person. Testing
should include, but not be limited to: Visual Inspection,
Polarity Test, Earth Continuity, Insulation Continuity and
Functional Testing.
Caution: Risk of Fire
• Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
Warning: Keep all ventilation openings clear of
obstruction. Unit should not be boxed in without
adequate ventilation.
•Warning: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
•Warning: Do not damage the refrigerant circuit.
•Warning: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are the
type recommended by the manufacturer.
Pack Contents
The following is included:
• POLAR Refrigerator • Instruction Manual
POLAR prides itself on quality and service, ensuring that at the time of packaging the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your POLAR dealer immediately.
UA023-A_UA024-A_A5_v1_20220304.indb 3UA023-A_UA024-A_A5_v1_20220304.indb 3 2022/3/4 16:162022/3/4 16:16

4
EN Telephone Helpline: 1300225960
Installation
Note: If the unit has not been stored or
moved in an upright position, let it stand
upright for approximately 12 hours before
operation. If in doubt allow to stand.
1. Remove the appliance from the packaging.
Make sure that all protective plastic film and
coatings are thoroughly removed from all
surfaces.
2. To optimize performance and longevity, ensure
a minimum clearance of 2.5cm is maintained
between the unit and walls and other objects,
with a minimum 5cm clearance on the top.
NEVER LOCATE NEXT TO A HEAT SOURCE.
Note: Before using the appliance for the
first time, clean the shelves and interior
with soapy water.
3. Set the brakes on the castors to keep the
appliance in position.
Operation
Control Panel
A B
A - Power Switch
B - Light Switch
Turn On
1. Close the door(s) of the appliance.
2. Switch on the Power Switch [I]. The current
temperature within the appliance is displayed.
3. Turn the light switch On [I] or Off [O] as
desired.
Set the Operating Temperature
1. Hold the SET button for 3 seconds. The value
of the current set point will be displayed.
2. Press the or buttons to display the
required temperature.
3. Press the SET button to store the temperature.
Manual Defrost
Press and hold the defrost button "aux" for
2 seconds to begin a manual defrost. The defrost
light illuminates.
Cleaning, Care &
Maintenance
•Switch off and disconnect from the power
supply before cleaning.
• Clean the interior of the appliance as often as
possible.
• Do not use abrasive cleaning agents. These
can leave harmful residues.
• Clean the door seal with warm soapy water.
• Always wipe dry after cleaning.
• Do not allow water used in cleaning to run
through the drain hole into the evaporation
pan.
• Take care when cleaning the rear of the
appliance. Sharp edges can cut.
Condensation will form in refrigeration with
frequent opening of the doors and on hot
humid days, please ensure condensation is
allowed to drain properly or is wiped dry.
Condenser Cleaning
• The condenser is part of the refrigeration
system. The condenser requires monthly
cleaning.
• Always disconnect power supply before
carrying out Routine Maintenance.
• Failure to clean the condenser will reduce the
performance and life of your Polar unit and
may invalidate your warranty.
• These models have a removable filter which
can be cleaned with a vacuum cleaner.
UA023-A_UA024-A_A5_v1_20220304.indb 4UA023-A_UA024-A_A5_v1_20220304.indb 4 2022/3/4 16:162022/3/4 16:16

5
AUEN
Telephone Helpline: 1300225960
Troubleshooting
A qualified technician must carry out repairs if required.
Fault Probable Cause Solution
The appliance is not
working
The unit is not switched on Check the unit is plugged in correctly and
switched on
Plug or lead is damaged Replace plug or lead
Mains power supply fault Check mains power supply
The appliance turns on,
but the temperature is
too high/low
Too much ice on the evaporator Defrost the appliance
Condenser blocked with dust Clean the Condenser
Doors are not shut properly Check doors are shut and seals are not
damaged
Appliance is located near a
heat source or air flow to the
condenser is being interrupted
Move the refrigerator to a more suitable
location
Ambient temperature is too high Increase ventilation or move appliance to a
cooler position
Unsuitable foodstuffs are being
stored in the appliance
Remove any excessive hot foodstuffs or
blockages to the fan
Appliance is overloaded Reduce the amount of food stored in the
appliance
The appliance is
leaking water
The appliance is not properly
levelled
Adjust the screw feet to level the appliance
(if applicable)
The discharge outlet is blocked Clear the discharge outlet
Movement of water to the drain is
obstructed
Clear the floor of the appliance (if
applicable)
The drip tray is overflowing Empty the drip tray (if applicable)
The appliance is
unusually loud
Loose nut/screw Check and tighten all nuts and screws
The appliance has not been
installed in a level or stable
position
Check installation position and change if
necessary
Technical Specifications
Model Voltage Power Current Temperature
Range Refrigerant Dimensions H x W x D mm
Weight
(kg)
UA023-A 220-240V~
50Hz
300W 1.8A 2°C - 8°C R600a 95g 860 x 1360 x
700
98
UA024-A 300W 1.8A 2°C - 8°C R600a 95g 860 x 1795 x
700
134
UA023-A_UA024-A_A5_v1_20220304.indb 5UA023-A_UA024-A_A5_v1_20220304.indb 5 2022/3/4 16:162022/3/4 16:16

6
EN Telephone Helpline: 1300225960
Electrical Wiring
The plug is to be connected to a suitable mains socket.
This appliance is wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
The appliances must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The product must not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and environmentally safe
recycling process. For further information on how to dispose of this product correctly, contact the product
supplier, or the local authority responsible for waste disposal in your area.
POLAR parts have undergone strict product testing in order to comply with regulatory
standards and specifications set by international, independent, and federal authorities.
POLAR products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of POLAR.
Every effort is made to ensure all details are correct at the time of going to press, however, POLAR reserve the right to
change specifications without notice.
UA023-A_UA024-A_A5_v1_20220304.indb 6UA023-A_UA024-A_A5_v1_20220304.indb 6 2022/3/4 16:162022/3/4 16:16

DECLARATION OF CONFORMITY
• Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •
• Declaración de conformidad
Equipment Type • Uitrustingstype • Type d'équipement • Gerätetyp
• Tipo di apparecchiatura • Tipo de equipo
Model • Modèle • Modell • Modello
• Modelo
U-Series 2 Door Counter with Glass Doors
U-Series 3 Door Counter with Glass Doors
UA023 (-E & -A)
UA024 (-E & -A)
Application of Territory Legislation &
Council Directives(s)
Toepassing van Europese Richtlijn(en) •
Application de la/des directive(s) du
Conseil • Anwendbare EU-Richtlinie(n)
• Applicazione delle Direttive
• Aplicación de la(s) directiva(s) del
consejo
Machinery Directive 2006/42/EC
Supply of Machinery (Safety) Regulations 2008
EN 60335-1:2012 +A11:2014 +A13:2017 +A1:2019
+A14:2019 +A2:2019
EN 60335-2-89:2010 +A1:2016 +A2:2017
EN 62233:2008
Electro-Magnetic Compatibility (EMC) Directive
2014/30/EU - recast of 2004/108/EC
Electromagnetic Compatibility Regulations 2016
(S.I. 2016/1091)
EN 55014-1: 2017
EN 55014-2:2015
EN 61000-3-2: 2014
EN 61000-3-3:2013
Regulation (EU) 2019/2024 - Ecodesign direct
sales refrigerators
ISO 23953-2:2015
Restriction of Hazardous Substances Directive
(RoHS) 2015/863 amending Annex II to Directive
2011/65/EU
Restriction of the Use of Certain Hazardous
Substances in Electrical and Electronic
Equipment Regulations 2012 (S.I. 2012/3032)
Electrical Safety
IEC 60335-1:2010 +A1:2013 +A2:2016
IEC 60335-2-89:2010 +A1:2012 +A2:2015
Electromagnetic Compatibility
EN 55014-1: 2017
EN 55014-2:2015
EN 61000-3-2: 2014
EN 61000-3-3: 2013
Producer Name • Naam fabrikant • Nom du producteur • Name des Herstellers
• Nome del produttore • Nombre del fabricante
Polar
I, the undersigned, hereby declare that the equipment specified above conforms to the above Territory Legislation, Directive(s) and
Standard(s).
Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de bovenstaande Richtlijn(en) en
Standaard(en).
Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus
Ich, der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n) und Norm(en) entspricht.
Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati.
El abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y estándar(es) arriba
mencionadas.
Date • Data • Date • Datum • Data •
Fecha • Data
21st January 2022
Signature • Handtekening •
Signature • Unterschrift Firma •
Firma
Full Name • Volledige naam • Nom
et prénom • Vollständiger Name •
Nome completo • Nombre completo
Ashley Hooper
Eoghan Donnellan
Nerida Pearse
Position • Functie • Fonction •
Position • Qualifica • Posición
Technical & Quality
Manager
Commercial
Manager/ Importer
Commercial Manager/ Responsible
Supplier
Producer Address • Adres fabrikant •
Adresse du producteur • Anschrift
des Herstellers • Indirizzo del
produttore • Dirección del fabricante
Fourth Way,
Avonmouth,
Bristol,
BS11 8TB
United Kingdom
42 North Point
Business Park
New Mallow Road
Cork
Ireland
15 Bagdally Road,
Campbelltown
NSW 2560
DocuSign Envelope ID: 4A6B3393-039D-4133-B313-35379F296FE4
UA023-A_UA024-A_A5_v1_20220304.indb 7UA023-A_UA024-A_A5_v1_20220304.indb 7 2022/3/4 16:162022/3/4 16:16

UA023-A_UA024-A_A5_v1_20220304
http://www.polar-refrigerator.com/
UA023-A_UA024-A_A5_v1_20220304.indb 8UA023-A_UA024-A_A5_v1_20220304.indb 8 2022/3/4 16:162022/3/4 16:16
