9
Operation
TABLE OF CONTROLLER PARAMETERS
Par. Description Type Min Max UOM. Def. Parameter visible in models
PS Password. F 0 200 - 22 M/S (with 1 & 2 probes), X, Y, C
/2 Probe measurement stability. C 1 15 - 4M/S (with 1 & 2 probes), X, Y, C
/4 Select probe displayed. F 1 3 - 1 M/S (with 2 probes), X, Y, C
/5 Select °C/°F. C0 (°C) 1 (°F) - 0 M/S (with 1 & 2 probes), X, Y, C
/6 Disable decimal point. C 0 1 - 0 M/S (with 1 & 2 probes), X, Y, C
/7 Enable probe 2 alarm (model M only). C01- 0M
/C1 Probe 1 oset. F -50.0 50.0 °C/°F 0 M/S (with 1 & 2 probes), X, Y, C
/C2 Probe 2 oset. F -50.0 50.0 °C/°F 0 M/S (with 2 probes), X, Y, C
/C3 Probe 3 oset. F -50.0 50.0 °C/°F 0 M/S (with 2 probes), X, Y, C
St Set point. S r1 r2 °C/°F 4M/S (with 1 & 2 probes), X, Y, C
rd Control dierential. F 0 19.0 °C/°F 2S (with 1 & 2 probes), X, Y, C
r1 Minimum set point value. C -50 r2 °C/°F -50 M/S (with 1 & 2 probes), X, Y, C
r2 Maximum set point value. C r1 200 °C/°F 90 S (with 1 & 2 probes), X, Y, C
r3 Select direct/reverse operation. C02- 0 M/S (with 2 probes), X, Y, C
r4 Night-time set point delta. C-50 50 °C/°F 3 S (with 1 & 2 probes), X, Y, C
c0 Compressor and fan start delay on power up. C 0 100 min 0 S (with 1 & 2 probes), X, Y, C
c1 Minimum time between consecutive compressor
starts.
C0 100 min 0 S (with 1 & 2 probes), X, Y, C
c2 Minimum compressor o time. C0 100 min 0 S (with 1 & 2 probes), X, Y, C
c3 Minimum compressor on time. C 0 100 min 0 S (with 1 & 2 probes), X, Y, C
c4 Compressor on time with duty setting. C 0 100 min 0 S (with 1 & 2 probes), X, Y, C
cc Continuous cycle duration. C 0 15 h 4 S (with 1 & 2 probes), X, Y, C
c6 Temperature alarm bypass after continuous
cycle.
C0 15 h 2 S (with 1 & 2 probes), X, Y, C
d0 Type of defrost. C 04- 0 S (with 1 & 2 probes), X, Y, C
dl Interval between defrosts. F 0 199 h/min (see dC) 8S (with 1 & 2 probes), X, Y, C
dt End defrost temperature set point/defrost tem-
perature threshold with temp. control.
F -50 130 °C/°F 4S (with 2 probes), X, Y, C
dP Maximum defrost duration. F 1 199 min/s (see dC) 30 S (with 1 & 2 probes), X, Y, C
d4 Defrost when switching the instrument on. C 0 1 - 0 S (with 1 & 2 probes), X, Y, C
d5 Defrost delay on power-up or when enabled by
digital input.
C0 199 min 0 S (with 1 & 2 probes), X, Y, C
d6 Freeze control temperature display during
defrost.
C0 1 - 1 S (with 1 & 2 probes), X, Y, C
ALARM SIGNALS
When an alarm is activated, the display shows the corresponding message that ashes alternating with the
temperature.
• If tted and enabled, the buzzer and the alarm relay are also activated. All the alarms have automatic reset
(that is, they stop when the causes are no longer present), except for alarm ‘CHt’ which has manual reset
(instrument on/o using the UP button or by disconnecting the power supply).
• Pressing the SET button mutes the buzzer, while the code displayed, and the alarm relay only go o when
