Polar Electro Deli CG841-A User manual

Model:
CG841-A
Deli Display Fridge
Instruction manual
CG841-A_A5_v2_20230926.indb 1CG841-A_A5_v2_20230926.indb 1 2023/9/26 16:132023/9/26 16:13

2
EN Telephone Helpline: 1300225960
Safety Instructions
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components or service panels on this product.
- In Queensland the service agent/qualified technician
MUST hold a Gas Work Authorisation or License for
hydrocarbon refrigerants if the appliance gas system is
being opened or charged.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- Fire Precautions
- Wiring Regulations
- Building Regulations
• DO NOT immerse the appliance in water, or use jet/pressure
washers to clean the appliance.
• Do not use the appliance for anything other than its intended
use.
• Always switch off and disconnect the power supply to the
appliance when not in use.
• Not suitable for outdoor use.
• Keep all packaging away from children. Dispose of the
packaging in accordance to the regulations of local authorities.
• If the power cord is damaged, it must be replaced by a POLAR
agent or a recommended qualified technician in order to avoid
a hazard.
• Children should be supervised to ensure that they do not play
with the appliance.
CG841-A_A5_v2_20230926.indb 2CG841-A_A5_v2_20230926.indb 2 2023/9/26 16:132023/9/26 16:13

3
EN
Telephone Helpline: 1300225960
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning the use of the
appliance by a person responsible for their safety.
• POLAR recommend that this appliance should be periodically
tested (at least annually) by a Competent Person. Testing
should include, but not be limited to: Visual Inspection,
Polarity Test, Earth Continuity, Insulation Continuity and
Functional Testing.
Caution: Risk of Fire
• Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
Warning: Keep all ventilation openings clear of
obstruction. Unit should not be boxed in without
adequate ventilation.
• To comply with AS/NZS 60079.10.1:2009: Ensure there
are not sources of ignition in any area where refrigerant
could gather in the event of a leak.
• Electrical equipment should not be placed under the vent
or where refrigerant could gather in the event of a leak.
• Warning: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Warning: Do not damage the refrigerant circuit.
• Warning: Do not use electrical appliances inside the food
storage compartments of the appliance.
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and operation of
this machine will provide the best possible performance from your POLAR product.
CG841-A_A5_v2_20230926.indb 3CG841-A_A5_v2_20230926.indb 3 2023/9/26 16:132023/9/26 16:13

4
EN Telephone Helpline: 1300225960
Pack Contents
The following is included:
• POLAR Deli Display Fridge
• Instruction Manual
POLAR prides itself on quality and service, ensuring
that at the time of unpacking the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit,
please contact your POLAR dealer immediately.
Installation
Note: Not for use in vans or trailers, food
trucks or similar vehicles.
Note: If the unit has not been stored or
moved in an upright position, let it stand
upright for approximately 12 hours before
operation. If in doubt allow to stand.
1. Remove the appliance from the packaging and
remove the protective film from all surfaces.
2. To optimize performance and longevity, ensure
a minimum clearance of 2.5cm is maintained
between the unit and walls and other objects,
with a minimum 20cm clearance on the top.
NEVER LOCATE NEXT TO A HEAT SOURCE.
Note: Maximum load of shelves is 15kg.
Note: Before using the appliance for the
first time, clean the shelves and interior
with soapy water then dry well.
Operation
Control Panel
The control panel is located below the doors on the
rear of the appliance.
Refrigerant LED is on. Compressor is
running
Defrost LED is on. Unit is defrosting,
compressor is not running
Up Button
Down Button
Light button
SET Set button
I/O On / Off
Turn On
1. Close the door(s) of the appliance.
2. Ensure the power switch is set to [O] and turn
on at the socket.
3. Switch on the Power [I].
Adjusting the Temperature
1. Press SET button. The set temperature is
displayed.
2. Press up button or down button to
change set temperature.
3. Press SET button to exit.
Display Lighting
Press Light button to switch internal display
lighting ON / OFF.
Manual Defrost
1. To start manual defrost press the Light button
and hold for 6 seconds.
2. To stop manual or automatic defrost press the
Light button and hold for 6 seconds.
CG841-A_A5_v2_20230926.indb 4CG841-A_A5_v2_20230926.indb 4 2023/9/26 16:132023/9/26 16:13

5
EN
Telephone Helpline: 1300225960
Cleaning, Care & Maintenance
Switch off and disconnect from the power supply before cleaning
• The doors can be removed for ease of cleaning
• Clean the interior of the appliance as often as possible
• Do not use abrasive cleaning agents. These can leave harmful residues
• Clean the door seals with warm soapy water
• Always wipe dry after cleaning
Condensation and ice will form with frequent and prolonged opening of the doors.
Operating outside of the recommend temperature range and placing next to a heat source
will also increase the amount of ice and internal/external condensation. If external
condensation occurs wipe the surface down with a cloth.
Excessive ice will result in longer running times that will increase energy consumption and
increase the deterioration of components.
Cleaning the Condenser
Periodic cleaning of the Condenser can extend the life of the appliance, POLAR recommend that a POLAR
agent or qualified technician clean the condenser.
Troubleshooting
A qualified technician must carry out repairs if required.
Fault Probable Cause Solution
The appliance is not
working
The unit is not switched on Check the unit is plugged in correctly and
switched on
Plug or lead is damaged Replace plug or lead
Mains power supply fault Check mains power supply
The appliance is not
cooling
Coolant Leak Consult a qualified Technician
Fan Motor Failed Consult a qualified Technician
Airflow to the condenser
obstructed
Increase the gap between appliance and
obstacles/heat source
Condenser is clogged Consult a qualified Technician
The Light does not
work
Bulb has blown • Consult a qualified Technician
CG841-A_A5_v2_20230926.indb 5CG841-A_A5_v2_20230926.indb 5 2023/9/26 16:132023/9/26 16:13

6
EN Telephone Helpline: 1300225960
Technical Specifications
Note: Due to our continuing program of research and development, the specifications herein may be
subject to change without notice.
Model Voltage Power (W) Current (A) Capacity
(Litres) Refrigerant
CG841-A 220-240V~ 50Hz 480 2.75 295 R290
Dimensions
H x W x D mm
Weight
(kg) Climate Class Temperature range
1220 x 915 x 675 120 4 2°C ~ 12°C
Note: For optimal product performance and efficiency, please ensure to mind the net usable capacity (load
limit) when filling.
Electrical Wiring
The plug is to be connected to a suitable mains socket.
POLAR appliances are wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The product must not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and environmentally safe
recycling process. For further information on how to dispose of this product correctly, contact the product
supplier, or the local authority responsible for waste disposal in your area.
POLAR parts have undergone strict product testing in order to comply with regulatory
standards and specifications set by international, independent, and federal authorities.
POLAR products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of POLAR.
Every effort is made to ensure all details are correct at the time of going to press, however, POLAR reserve the right to
change specifications without notice.
CG841-A_A5_v2_20230926.indb 6CG841-A_A5_v2_20230926.indb 6 2023/9/26 16:132023/9/26 16:13

DECLARATION OF CONFORMITY
• Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •
• Declaración de conformidad
Equipment Type • Uitrustingstype • Type d'équipement • Gerätetyp
• Tipo di apparecchiatura • Tipo de equipo
Model • Modèle • Modell •
Modello • Modelo
G-Series Deli Display Fridge 270Ltr
CG841 (& -E -A)
Application of Territory Legislation
& Council Directives(s)
Toepassing van Europese
Richtlijn(en) • Application de la/des
directive(s) du Conseil • Anwendbare
EU-Richtlinie(n) • Applicazione delle
Direttive • Aplicación de la(s)
directiva(s) del consejo
Machinery Directive 2006/42/EC
Supply of Machinery (Safety) Regulations 2008
(BS) EN 60335-1:2012 +A11:2014 +A13:2017
+A1:2019 +A14:2019 +A2:2019
(BS) EN 60335-2-89:2010 +A1:2016 +A2:2017
(BS) EN 62233:2008
Electro-Magnetic Compatibility (EMC) Directive
2014/30/EU - recast of 2004/108/EC
Electromagnetic Compatibility Regulations 2016
(S.I. 2016/1091)
(BS) EN IEC 61000-6-1: 2019
(BS) EN IEC 61000-6-3: 2021
Eco-design energy-related products Directive
2009/125/EC; Regulation (EU)
2019/2024 - Ecodesign direct sales refrigerators
(BS) ISO 23953-1:2015
(BS) ISO 23953-2:2015
Restriction of Hazardous Substances Directive
(RoHS) 2015/863 amending Annex II to Directive
2011/65/EU
Restriction of the Use of Certain Hazardous
Substances in Electrical and Electronic
Equipment Regulations 2012 (S.I. 2012/3032)
Electrical Safety
EN 60335-1:2012 +A11:2014
+A13:2017 +A1:2019 +A14:2019
+A2:2019
EN 60335-2-89:2010 +A1:2016
+A2:2017
Electromagnetic Compatibility
EN IEC 61000-6-1: 2019
EN IEC 61000-6-3: 2021
Producer Name • Naam fabrikant • Nom du producteur • Name des Herstellers
• Nome del produttore • Nombre del fabricante
Polar
I, the undersigned, hereby declare that the equipment specified above conforms to the above Territory Legislation, Directive(s)
and Standard(s).
Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de bovenstaande
Richtlijn(en) en Standaard(en).
Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus
Ich, der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n) und
Norm(en) entspricht.
Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati.
El abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y
estándar(es) arriba mencionadas.
Date • Data • Date • Datum • Data •
Fecha
30th June 2023
Signature • Handtekening •
Signature • Unterschrift Firma •
Firma
Full Name • Volledige naam • Nom
et prénom • Vollständiger Name •
Nome completo • Nombre completo
Ashley Hooper
Eoghan Donnellan
Brendan Denmeade
Position • Functie • Fonction •
Position • Qualifica • Posición
Technical & Quality
Manager
Commercial Manager/
Importer
Commercial Manager/
Responsible Supplier
Producer Address • Adres fabrikant •
Adresse du producteur • Anschrift
des Herstellers • Indirizzo del
produttore • Dirección del fabricante
Fourth Way,
Avonmouth,
Bristol,
BS11 8TB
United Kingdom
Unit 9003,
Blarney Business Park,
Blarney,
Co. Cork
Ireland
15 Badgally Road,
Campbelltown
NSW 2560
DocuSign Envelope ID: 41847BDA-6757-4341-A7EA-79F00EABEF08
CG841-A_A5_v2_20230926.indb 7CG841-A_A5_v2_20230926.indb 7 2023/9/26 16:132023/9/26 16:13

CG841-A_A5_v2_2023/09/26
http://www.polar-refrigerator.com/
CG841-A_A5_v2_20230926.indb 8CG841-A_A5_v2_20230926.indb 8 2023/9/26 16:132023/9/26 16:13
