Polar Electro CM359-A User manual

Model:
CM359-A
Wine Cooler
Instruction manual
CM359-A_A5_v1_20191106.indb 1 2019/11/6 16:20

2
AU Telephone Helpline: 1300225960
Safety Tips
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components or service panels on this product.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- Fire Precautions
- Wiring Regulations
- Building Regulations
• DO NOT use jet/pressure washers to clean the appliance
• DO NOT use the appliance outside
• DO NOT use the appliance to store medical supplies
• DO NOT use electrical appliances inside the appliance (e.g.
heaters, ice-cream makers, etc.)
• DO NOT allow oil or fat to come into contact with the plastic
components or door seal. Clean immediately if contact occurs
• DO NOT store products on top of the appliance
• Bottles that contain a high percentage of alcohol must be
sealed and placed vertically in the refrigerator
• Always carry, store and handle the appliance in a vertical
position and move by holding the base of the appliance
• Always switch off and disconnect the power supply to the unit
before cleaning
• Keep all packaging away from children. Dispose of the
packaging in accordance with the regulations of local
authorities.
• If the power cord is damaged, it must be replaced by a POLAR
agent or a recommended qualified technician in order to avoid
a hazard.
• This appliance is intended to be used exclusively for the
storage of wine.
CM359-A_A5_v1_20191106.indb 2 2019/11/6 16:20

3
AU
Telephone Helpline: 1300225960
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience or knowledge, unless they have been
given supervision or instruction concerning the use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play
with the appliance.
• Polar recommends that this appliance should be periodically
tested (at least annually) by a Competent Person. Testing
should include, but not be limited to: Visual Inspection,
Polarity Test, Earth Continuity, Insulation Continuity and
Functional Testing.
Warning: Risk of Fire / flammable materials
• The refrigerant gas contained in this appliance is isobutene
(R600a), which is low-polluting but flammable.
• Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
Warning: Keep all ventilation openings clear of
obstruction. Unit should not be boxed in without
adequate ventilation.
• Warning: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Warning: Do not damage the refrigerant circuit.
• Warning: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are the
type recommended by the manufacturer.
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and operation of
this machine will provide the best possible performance from your POLAR product.
Product Description
CM359: Polar Wine Chiller – 54 Bottle Capacity
CM359-A_A5_v1_20191106.indb 3 2019/11/6 16:20

4
AU Telephone Helpline: 1300225960
Pack Contents
The following is included:
• Polar Wine Chiller • Keys • Instruction manual
POLAR prides itself on quality and service, ensuring that at the time of packaging the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your POLAR dealer immediately.
Installation
WARNING: When positioning the appliance, ensure the supply cord is not
trapped or damaged.
WARNING: Do not locate multiple portable socket-outlets or portable power
supplies at the rear of the appliance.
Before using your wine chiller
1. Remove all the exterior and interior packaging.
2. Before connecting the chiller to the power supply, let the chiller stand upright for approximately 12
hours.
3. Clean the interior with lukewarm water, using a soft cloth.
4. The door can be opened from either the left or right side. When delivered, the door can be opened
from the left. Should you want to open it from the right, follow the instructions for “reversing the
door swing of your appliance”.
Installing your wine chiller
1. The product is designed to be built-in, recessed, or free standing.
2. Place the chiller on a floor that is able to support it once fully loaded. To level the chiller, adjust the
front levelling leg at the bottom of the chiller.
3. Do not place the chiller in direct sunlight or near other heat sources.
4. Avoid placing the chiller in damp areas.
5. Plug the chiller into the socket.
6. Ensure that the air vent at the front of the chiller is never blocked or covered.
Installing the handle
1. Remove the door gasket on the side you want to install the handle – there are two designated holes
for the handle installation.
2. Install the handle tightly with two screws, lock washers and flat washers provided.
3. Replace the door gasket.
Operating you wine chiller
NB: the chiller should be placed in an area where the ambient temperature is
between 16-35°C.
• When using the chiller for the first time, or re-starting it after a long period of time, there may be
a few degrees variance between the selected temperature and what is shown on the LED readout.
Once the chiller has been switched on for a few hours, this should rectify itself.
• If the unit is unplugged, has lost power or been turned off, wait 3 to 5 minutes before restarting the
chiller.
CM359-A_A5_v1_20191106.indb 4 2019/11/6 16:20

5
AU
Telephone Helpline: 1300225960
The controls of your wine chiller
Power To switch on/off button must be held for 5 seconds
Light To control the inner light on/off
Up Used to increase the temperatures by 1°C
Down Used to decrease the temperature by 1°C
Select the temperature display setting in Fahrenheit or Celsius
& Pressed simultaneously will lock / unlock the control panel. When locked control panel
will be disabled
Wine Indicator
Lights
Red LED for
red wine
Green LED for white wine
Amber LED for
sparkling wine
Setting the temperature control
1. When using the temperature controls for the first time, the LED will display the previous temperature
(The factory setting is 12°C).
2. The temperature settings is adjustable with the range 5-22°C.
3. The temperature increases by 1°C or 1°F if you touch the UP button once, and will decrease by 1°C
or 1°F if the DOWN button is touched once.
4. When storing mainly red wine, the temperature should be set at 15-18°C, and the red LED will be lit.
5. When storing mainly white wine, the temperature should be set at 9-14°C, and the green LED will be
lit.
6. When storing mainly sparkling wine, the temperature should be set at 5-8°C, and the amber LED will
be lit.
7. To view the current temperature of the chiller, press either the UP or DOWN button and the
temperature will flash on the display for five seconds.
CM359-A_A5_v1_20191106.indb 5 2019/11/6 16:20

6
AU Telephone Helpline: 1300225960
Storage
54 wine bottles can be stored with 8 bottles on each full size
and 6 bottles on the bottom half size shelf.
NB: Bottle capacities are approximate maximums when storing traditional
Bordeaux 750ml bottles and include bulk storage.
Shelves
• To prevent damage to the door gasket, ensure the door is fully open when pulling shelves out of the
rail compartment.
• For easy access to the bottles, pull the shelf out by about 1/3. The shelf will stop automatically if they
are being taken out too far when housing wine bottles. Only pull out 1 half at a time.
Water Reservoir Box
Your Polar Wine Cooler is supplied with a water reservoir box, positioned on the top shelf of the unit.
Adding water to this box will help maintain the humidity levels within the cabinet and reduce the drying
out / shrinkage of natural corks.
Cleaning, Care & Maintenance
Cleaning your wine chiller
1. Turn off the power, unplug the appliance and take out all items including shelves and racks.
2. Wash the inside surfaces with a mild detergent.
3. Wash the shelves with a mild detergent.
NB: Ensure that excess water is wrung out when cleaning any area of the
controls.
4. Wash the outside of the cooler with a mild detergent. Rinse well and wipe dry with a soft, clean cloth.
Defrosting
The unit defrosts automatically.
CM359-A_A5_v1_20191106.indb 6 2019/11/6 16:20

7
AU
Telephone Helpline: 1300225960
Reversing the door swing of your appliance
1. Open the glass door (4) and remove the two lock screws (2) that hold the door shaft assembly to the
door. Make sure that you hold the door firmly once the screws have been removed (Fig. 1).
2. Pull down to remove the door and lay it on a padded surface to prevent scratching.
3. Remove the two screws from the bottom of the door on the left hand side and install them on the
right hand side of bottom of the door (Fig. 3).
4. Remove the right lower door hinge (1). Install it in designated position on the left hand side. Then
install the door shaft assembly (Fig. 2).
5. Remove the door axle (5) from the right upper hinge, install and tighten it in the upper left hinge
(Fig. 4).
6. Position the door in the designated position and install the two lock screws (2) to connect the door
shaft assembly (3) to the glass door. Tighten them before the door is levelled (Fig. 5).
7. Remove the handle from the left hand side of the door and install it on the right.
CM359-A_A5_v1_20191106.indb 7 2019/11/6 16:20

8
AU Telephone Helpline: 1300225960
Troubleshooting
If your POLAR appliance develops a fault, please check the following table before making a call to the
Helpline or your POLAR dealer.
Fault Probable Cause Solution
The appliance is not
working
The unit is not switched on Check the unit is plugged in correctly and
switched on
Plug and lead are damaged Call POLAR agent or qualified Technician
Fuse in the plug has blown Replace the fuse
Power supply Check power supply
Internal wiring fault Call POLAR agent or qualified Technician
The wine chiller is not
cold enough or turns
on/off frequently
Temperature incorrectly set Check the temperature setting
The door is not completely shut Shut door
The door gasket is not sealing
properly
Check door seal fitted correctly
The room temperature is warmer
than normal
Reduce room temperature
The door is opened too frequently Reduce number of times door is opened
The light does not
work
The light switch is set to “OFF” Set light switch to “ON”
Unit may not be plugged in or
switched on
Plug in and switch on chiller
The display shows “EL”
or “EH”
The air temperature sensor has
failed
Contact Polar agent or qualified technician
Technical Specifications
Model Voltage Power Current Bottle
Capacity Refrigerant Temp. Range
Dimensions
H x W x D mm
Weight
(kg)
CM359-A 220-240V~
50Hz
100W 1.2A 54 R600a 30g 5-22°C 865 x 595 x 570 47
CM359-A_A5_v1_20191106.indb 8 2019/11/6 16:20

9
AU
Telephone Helpline: 1300225960
Electrical Wiring
The plug is to be connected to a suitable mains socket.
POLAR appliances are wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The product must not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and environmentally safe
recycling process. For further information on how to dispose of this product correctly, contact the product
supplier, or the local authority responsible for waste disposal in your area.
POLAR parts have undergone strict product testing in order to comply with
regulatory standards and specifications set by international, independent, and
federal authorities.
POLAR products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of POLAR.
Every effort is made to ensure all details are correct at the time of going to press, however, POLAR reserve the right to
change specifications without notice.
CM359-A_A5_v1_20191106.indb 9 2019/11/6 16:20

DECLARATION OF CONFORMITY
Equipment Type
G-Series Wine Fridge Black 54 Bottle
G-Series Dual Zone Wine Fridge 92 Bottle
G-Series Dual Zone Wine Fridge 155 Bottle
Model
CM359-A
CE217-A
CE218-A
Legislation
Electrical Safety
Electromagnetic Compatibility
Standards
AS/NZS 60335.1:2011 +A1:2012 +A2:2014 +A3:2015 +A4:2017
AS/NZS 60335-2-24:2010 +A1:2013
AS CISPR 14.1:2018
Producer Name
Polar
Producer Address
15 Badgally Road,
Campbelltown,
NSW 2560
I, the undersigned, hereby declare that the equipment specified above conforms to the above Legislation and Standard(s).
Date
5th November 2019
Signature
Full Name
Ashley Hooper
Position
Global Quality Manager
Date
5th November 2019
Signature
Full Name
Josie Holt
Position
Commercial Manager/ Responsible Supplier
CM359-A_A5_v1_20191106.indb 10 2019/11/6 16:20

CM359-A_A5_v1_20191106.indb 11 2019/11/6 16:20

CM359-A_A5_v1_20191106
http://www.polar-refrigerator.com/
CM359-A_A5_v1_20191106.indb 12 2019/11/6 16:20
