POLARIA VPK 550 User manual

VAKIOMETALLI OY
Yrittäjäntie 4
52700 Mäntyharju
Tel. [phone]
Fax. [phone]
www.polaria.fi
All POLARIA products
have a two-year warranty!
MOUNTING AND CABLE OPENINGS
Cable opening top of the cabinet Ø 20 mm.
Cable openings behind the cabinet Ø 20 mm, 2 pcs.
To facilitate electrical installations there is free space behind the entire lamp construction 15 mm.
Diamond-shaped mounting holes. Size of the hole 12x20 mm.
Protection class IP34 (splash protection classification).
3/2014
firts name.last name@polaria.fi
myynti@polaria.fi
Business ID: 0165730-3
We reserve the right to make
changes.
550
445
461
~50
~ 45
600
275
255
25
~100
MIRROR CABINET WITH
LIGHT - VPK 550
Package includes:
1 VPK 550 mirror cabinet with light
4 mounting screws
4 mounting plugs
2 removable shelves
1 maintenance instructions
Width 550 mm
Height 600 mm
Depth 180/145 mm

VAKIOMETALLI OY
Yrittäjäntie 4
52700 Mäntyharju
Tel. [phone]
Fax. [phone]
www.polaria.fi
All POLARIA products
have a two-year warranty!
Note! To facilitate installation you can remove the mirrors before installing the handles and mounting the
mirror cabinet on the wall. Finally tighten the screws carefully. Make sure that the silicon bits at the end of
the screws are still intact.
INSTALLATION OF THE MIRROR CABINET
Note! If light wiring and outlet wiring have not separate electric circuit you need to connect L¹ and L² with
conducting wire (0,5 mm²).
HANDLE INSTALLATION
Remove the backing from the handle pad from
the side on which it covers the entire area of the
pad. Attach the handle pad as shown in the
picture. Remove the backing from the other side.
Push the handle evenly into position.
NOTE! ONLY A QUALIFIED ELECTRICIAN MAY REPAIR FAULTY ELECTRICAL EQUIPMENT!
3/2014
firts name.last name@polaria.fi
myynti@polaria.fi
Business ID: 0165730-3
We reserve the right to make
changes.
POWER
SOCKET
FLUORESCENT LAMP
BALLAST
RESIDUAL
CURRENT
DEVICE
NEUTRAL WIRE
PROTECTIVE GROUNDING
LIVE WIRE FOR LIGHT
LIVE WIRE FOR OUTLET
BALLAST
POWER
SOCKET
FLUORESCENT LAMP
NEUTRAL WIRE
PROTECTIVE GROUNDING
LIVE WIRE FOR LIGHT
LIVE WIRE FOR OUTLET
