Polaroid Zip User manual

P0LMP01
User’s manual
Android
GK07X0000400

Any changes or modifications in construction of this
device which are not expressly approved by the party
responsible for compliance could void the user's
authority to operate the equipment.
CAUTION
1 Avoid contact with leaking or a damaged battery.
2 Do not short battery terminals.
3 Adult supervision is recommended when product is
used by young children.
4 Avoid areas of excessive heat or moisture.
5 Do not disassemble the battery.
This product contains electrical or electronic
materials. The presence of these materials
may. if not disposed of properly, have
potential adverse effects on the environment
and human health.
Presence of this label on the product means it should
not be disposed of as unsorted waste and must be
collected separately. As a consumer, you are responsible
for ensuring that this product is disposed of properly.
Risk of explosion if Battery is replaced by an incorrect type.
Dispose of used Batteries according to the instructions.
To charge this product, you must always use a DC 5V, 1A
or more. Certified/Listed Adapter which complies with LPS.
BATTERY WARNINGS
If the optimum operating temperature of (15~32°C) is not met
when using this device, it may not print or lead to failure to provide
the best print quality. (For stability of the product, refrain from
using it at a low temperature in the winter.)
Operating Temperature
Safety Precautions
2

Federal Communication Commission
Interference Statement
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is encour-
aged to try to correct the interference by one of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and
receiver.
-Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV
technician for help.
FCC Caution: Any changes or modifications not expressly
approved by the party responsible for compliance could
void the user's authority to operate this equipment.

Radiation Exposure Statement:
The product comply with the FCC portable RF exposure
limit set forth for an uncontrolled environment and are
safe for intended operation as described in this manual.
The further RF exposure reduction can be achieved if the
product can be kept as far as possible from the user body
or set the device to lower output power if such function is
available.
This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
4

Keep out of direct sunlight and
away from a heat source.
Do not place heavy objects
on the product.
Do not place containers of
liquid on the product.
Do not spray water directly
onto the product when cleaning.
Do not place the product
in very low temperatures.
Do not attempt
to disassemble, repair and
remodel it for yourself.
Do not drop or give it impact.
Comply with rated (5V1A) voltage
and current.
Do not place the product in a hot
or humid place.
Keep out of the reach
of children.
Keep away from magnetic
interference.
Do not place the
product in a place with humidity,
dust and soot.
Wipe it with a dry cloth when
cleaning.
A violation of labeling regulations can cause
serious injury or death.
WARNING
NOTICE
A violation of labeling regulations
causes minor injury or damage to the product.

1. Items confirmed before use
Installation in Store
3. Cover Open methodㅤ
Zink Smart Sheet
7
9
11
11
13
14
15
Table of Contents
Components
Names of parts
Power on/off
Charging the battery
2. Application installation
Installation with QR Code
4. Inserting printing paper
5. Description of LED Status Indicators
6. Product specifications
7. Items to check before reporting
a malfunction
8. Warranty Card 17
6

1. Items confirmed before use
Components
Printer USB cable for charging
Zink photo paper Manual
Names of parts

Power on/off
ON Press the power button
at least 3 seconds.
OFF Press the power button
for about 3 seconds.
Note
When you turn on the power, the operating status LED indicator
blinks for about 5 seconds. You can print it out when the blinking
ends, and the LED is turned on white.
Charging the battery
This device has a built-in battery.
Make sure that the battery
is charged fully before use.
Average charging time :
About 1 hour and 30 minutes.
Charging status indicator Description of status
Charging in progress
Charging completed
Use the standard charger provided by this device.
The use of a non-standard charger can cause malfunction
and exception from the subjects of warranty service.
Do not give abnormal impacts.
Notice
There may be the risk of electric shock during the process
of charging, so please use with care.
Checking charging status indicator
8

2. Application installation

Description of Settings Details
Function Description
Auto Exposure Automatic exposure settings
Print Mode Print mode settings
(Image Full, Paper Full)
Auto Power OFF
Auto power off setting
(None, 3 minutes, 5 minutes,
10 minutes)
Device Status Device status
(Idle, Busy, Paper Empty, etc.)
Battery Battery level
Number of
page Printed
The total number of pages
printed
MAC Address
Update Firmware and color correction
data updates
Bluetooth MAC address
10

3. Cover Open method
4. Inserting printing paper
Prepare the blue Smart Sheet and white printing paper
after unpacking the photo printing paper pack.
Open the top cover and insert the Smart Sheet and
printing paper as shown in the figure.
Push Open
Notice
Do not open the Cover while printing.
Printing quality of output cannot be guaranteed
in case of using Zink paper of other companies.
ZINK

Zink Smart Sheet
Features
Provide optimum image quality correction suitable
for each printing paper pack
Remove foreign objects from printer head.
How to use
Eject automatically before printing out the paper
in initial output.
Poor quality and occurrence of horizontal lines can be
improved by repeatedly printing 2 to 3 times.
Recycle until the printing paper of each printing paper
pack is exhausted.
Optimum image quality cannot be guaranteed when the
Smart Sheet of each printing paper pack is not used,
or the bar code is damaged.
Long-term storage after opening the printing paper pack
can have a bad effect on printing quality due to a
discoloration or distortion of printing paper.
Notice
12

5. Description of LED Status
Indicators
DetailsCharging
status
indicator
Operating
status
indicator
Current
status
Off Turn on the power
to print.
Standby
/ On
Wait for print
command. Turn off
automatically after
the set time.
Charging in
progress
The battery is
being charged.
The battery is fully
charged.
Charging in
completed
Operating
/ Flashing
No paper, paper jam,
cancel operation,
low battery, image not
supported, update
failure, etc.
Power off, image
transmission, image
processing, printing,
cooling standby
Error
/ Flashing

6. Product specifications
Type Size
Paper size 50 x 76 (mm)
Type of supported
image file/size
PNG(2550x3300)JPEG(baseline)
Within a maximum of 10M Byte
Progressive JPEG not supported
Paper used ZINK Paper
Paper storage
conditions
Temperature : 20 ~ 25°C
Humidity : 40 ~ 55% RH
Product operating
conditions
Temperature : 5 ~ 40°C
Humidity : Less than 70% RH (35°C)
Optimal print
conditions
Temperature : 15 ~ 32°C
Humidity : Less than 70% RH (32°C)
LED display Power on/Standby/
Communication/Charge/Error/
Print/Update
Communication Bluetooth 4.0
External connection
terminal Micro USB port (charging only)
USB power supply Rated DC 5V / 1.0A
adapter (optional)
Built-in battery 500mAh lithium polymer
(rechargeable)
※Product design and specifications are subject to change
without notice.
Android : 6.0 and higher
iOS : 8.0 and higher
(Support may not be provided
depending on the user’s Smart phone
version and environment.)
Support App
version
Proper image
resolution More than 1280 x 2448 pixel
Weight
Size(WxHxD)
187g
74 x 119 x 22.9
14

7. Items to check before
reporting a malfunction
Problems Checklist
The power does
not turn on.
Check to see if the battery is
charged.
Bluetooth
connection is not
established.
Reboot the Bluetooth of the
phone, or connect directly from the
Settings menu.
Try connecting in about 5
minutes after turning on the power
to the device.
Printing paper
seems to be
jammed.
Stopped during
printing operation.
The paper is automatically
ejected if you turn on the power
after turning it off. Print it after
printing out the Smart Sheet 2 to
3 times.
The printing paper should be
stored in an environment with low
temperature/humidity.
Do not fold or crumble the paper.
The power turns
off automatically
after a certain
period of time.
Check the Auto Time Off value
within “Settings” of the App.
(None, 3 minutes, 5 minutes,
10 minutes)
The operating status LED
flickering Red indicates there is no
power remaining on the battery.
In this case, charge the battery
with a dedicated cable.
The printed photo
shows a line.
A slash mark appears
in the middle of the
photo.
Print it again after printing out
the Smart Sheet 2 to 3 times.
(A line may appear in case an impact
is applied to the printer during the
printing operation.)

Polaroid ZIP does not support all mobile phones and may not work properly
in certain models. Polaroid ZIP requires iOS 8.0 and higher or Android 6.0
and higher.
If Polaroid ZIP does not appear to be working properly even using one of
these operating systems, please contact us via our website .
Problems Checklist
White LED flashes
and printed paper
does not come out.
This device requires the proper
temperature of (15~32°C) to facilitate
smooth printing operation. Thus,
a greater warm-up time is required
in temperatures that are lower than
ideal, and cooling times are greater
when the temperature is higher than
ideal. Please wait a moment to reach
the proper temperature.
Printed paper
comes out too late.
The printed image
quality differs
greatly from the
original image
quality.
The image quality is somewhat
degraded when editing the image
using Polaroid ZIP App Edit menu.
Print it again after printing out the
Smart Sheet 2 to 3 times.
The Smart Sheet within the same
pack with printing paper should
be used.
Check to see if the image has the
proper resolution (1280x2448) or
higher.
The printed image quality cannot
be guaranteed in case you use
printing paper of other companies.
Use the original printing paper.
Turn on the power after pressing
the Reset Hole with a pointed
object.
The above methods
do not resolve the
problems.
Caution
16

Warranty Card
Warranty Policy
• Warranty
If the product fails during normal and proper use
within the warranty period, it shall be repaired or
exchanged free of charge in accordance with the
warranty terms and conditions.
This warranty covers the body only, not the
components. This warranty is valid in Japan only.
Any repair of the failed or damaged product which
falls under the following cases will be charged a fee
for service:
1. The warranty is not presented or attached upon
request for the repair
2. The warranty does not state when and where
the Product was purchased, or the information
has been forged or altered in some way
3. The product defect or damage has been
caused by misuse or negligence such as being
dropped or impact during transportation
4. Product defect or damage is caused by abnormal
voltage or fire, earthquake, floods and other
disasters
5. The product defect or damage arises from the
other device to which it is connected
6. The product is repaired or remodeled by an
unauthorized service center
7. The product defect or damage is caused by
the violation of the manuals and instructions as
furnished by the Company
• Exclusions
• Please send the product to the address stated
on the website.
