Police force Pftb12r User manual

1Full Press: When fully pressed, you will hear a clicking sound. Rev 7/6/2020

PFTB12R Instructions

INSERTING AND CHARGING THE RECHARGEABLE BATTERIES

1. We recommend fully charging the rechargeable batteries before inserting them into the unit. To do so, insert both 18650 4000mAh 3.7V li-ion batteries

(included) into the charging port according to the polarity diagram shown on the port. If the batteries are inserted correctly a red light will illuminate on the

charging port. Next, plug the slide-out plug into a standard wall outlet. When plugged into a standard wall outlet, a red light on the wall charger will come on

while the batteries are charging. IMPORTANT: Do not charge for more than 8 hours at a time. Overcharging can damage the batteries and void the warranty.

If the flashlight becomes dim or if the electrical stun current becomes noticeably weaker, the batteries will need to be charged. When not in use, charge the

batteries every 60 days to ensure the unit will function optimally when needed.

2. To insert the batteries into the stun baton, unscrew the end cap by turning it in a counterclockwise direction (See above diagram for location to unscrew).

3. Insert the batteries according to the polarity diagram below. IMPORTANT: Batteries must be inserted as shown below. Inserting the batteries incorrectly

could damage the unit and void the warranty. Replace the end cap by turning in a clockwise direction until snug. Do not over tighten.

USING THE FLASHLIGHT

Overview: This unit features three (2) light strengths (High & Low) and one light pattern (Strobe). When the situation does not require maximum light strength, the

lower light setting can be used to extend the battery life.

1. Fully press the Push-Button Tail Switch. You will hear the button click and the green LED will come on indicating that the power to the unit is on. If the

Function – Select Button is in Light mode the flashlight will turn on. If the flashlight does not turn on see #3 below.

2. Once the flashlight turns on you can change the light mode by Half Pressing either the Push-Button Tail Switch or the Function-Select Button. If you press

either of these buttons too hard you will hear a click and the flashlight will turn off.

3. If you press the Push-Button Tail Switch and the flashlight does not turn on, then the Function-Select Button is either set to Stun or OFF mode. If both the

green and red LED lights are on, then it is in Stun mode. Fully press (you will hear a click) the Function-Select Button two times to get to Light mode. If only

the green light is on, but the flashlight is not, it is in the OFF mode. Fully press (you will hear a click) the Function-Select Button one time to get to Light

mode.

4. To turn off the light, fully press1either the Function-Select Button or the Push-Button Tail Switch.

5. If you turn the light off by fully pressing1the Push-Button Tail Switch, you will need to press this same button again to turn it on. If you turn it off by fully

pressing1the Function-Select Button, be careful to note that you are now in stun mode (red light will be ON) and pressing the Stun Activation Button will

activate the stun feature. To return to light function, you will need to fully press1the Function-Select Button two more times.

LED Flashlight

Triple Stun

Contact Probes

Stun Activation Button

Function-Select Button

(Light, Stun, OFF)

Push-Button Tail Switch (Not Shown):

• Full Press1 turns unit ON/OFF.

• Half Press changes light mode.

Test Probes

Unscrew Here to

Insert Batteries

Negative ( - )

Positive ( + )

End Cap

Stun Mode ON: Red Light

Power Indicator: Green Light

IMPORTANT: Before using we recommend that you take time to familiarize yourself with this unit.

The key to understanding how it operates is the “Function-Select Button.” Each time this button

is pressed, the function changes in the following order: Light, Stun, Off. To help you remember

the order, the corresponding symbol is shown below the Function-Select Button:

for Light, for stun, and for off.

1Full Press: When fully pressed, you will hear a clicking sound. Rev 7/6/2020

TESTING THE STUN BATON

(WARNING: Do not test fire the stun baton for more than 1 second as this will damage the unit and void the warranty.)

1. Fully press1the Push-Button Tail Switch to turn on the unit. If both the red and green LED lights turn on it is in stun mode and ready to test the stun baton.

Go to #3 below. If only the green LED is on and the flashlight is on it is in the Light mode. Fully press1the Function-Select Button one time to move to the

STUN mode. If only the green LED is on and the flashlight is off it is in the OFF mode. Fully press1the Function-Select Button two times to move to the

STUN mode.

2. Be sure both the red and green LED lights are on to confirm it is in the STUN Mode.

3. Press the STUN Activation Button to test fire the unit. Do not hold the button down for more than 1 second. You will see and hear the electrical current fire

across the top of the unit between the contact probes.

4. Once your test is complete, fully press1either the Push-Button Tail Switch or the Function-Select Button to turn the unit off.

USING THE STUN BATON IN SELF DEFENSE

1. Before using the stun baton in self-defense, we recommend you become familiar with how this unit operates so you can

quickly protect yourself with the Stun Function. See How to Quickly Access the Stun Function below.

2. Using the directions above, move the unit into the Stun Mode.

3. Touch your assailant’s body with the contact probes and press the Stun Activation Button.

4. Touching anywhere on the assailant’s body will have an effect. However, the maximum effect is achieved in the areas

shown to the right:

5. When touching the assailant’s body, you will not see or hear the electrical current as you do when the unit is test fired.

You can hold the Stun Activation Button down for more than 1 second, as this will not damage the unit, as it will when

being test fired.

6. You do not have to be concerned about the effects of the charge being transferred to you. Even if the assailant touches

you while being stunned, you will not feel the effects of the charge.

HOW TO QUICKLY ACCESS THE STUN FUNCTION

1. When the Flashlight is on, fully press1the Function-Select Button then press the Stun Activation Button.

2. When the flashlight is not in use, we recommend leaving the Function-Select Button in the Stun position (with both the red and green LED lights on) and

fully pressing1the Push Button Tail Switch to turn the unit off. When you want to quickly use the Stun Function, fully press1the Push-Button Tail Switch

then the Stun Activation Button.

EFFECTS OF THE UNIT ON AN ASSAILANT

1. Touching an assailant for less than 1 second will cause minor muscle contractions and have a repelling effect.

2. Touching an assailant for 1 to 2 seconds will cause muscle spasms and a dazed mental state.

3. Touching an assailant for 3 to 5 seconds will cause loss of balance and muscle control, total mental confusion, and disorientation. All effects to the

assailant are temporary; the stun baton can cause no permanent harm. (NOTE: The device should not be used for longer than 5 seconds.)

WARRANTY

Cutting Edge Products, Inc. extends a lifetime warranty to the PFTB12R for the product against defects in materials or workmanship, with the

following exceptions:

1. The warranty does not cover damage resulting from accident, misuse or abuse, lack of reasonable care, moisture, the affixing of any attachment not

provided with the product, loss of parts, or recharging the unit in any manner not in accordance with the included instructions.

2. The warranty will be voided if the unit has been opened or tampered with in any way (unless by an authorized dealer) or if any unauthorized replacement

parts have been used.

3. The lifetime warranty extends to the stun gun and flashlight only. The batteries and the battery charger have a one-year warranty.

NOTICE

Purchaser must check and abide by all local laws governing the possession and use of stun batons. In addition, the stun batons must only be used in a lawful

manner for self-defense. NOTE: Not to be used on children, persons with heart disease, or any vital part of the human body. Not to be stored or used in

environments where it is damp or humid or where there are extreme hot or cold temperatures. Do not use on metal objects.

CONDITIONS OF SALE

Purchase of this product is an agreement by the purchaser/user to hold all sellers and manufacturers harmless of all liabilities and damages.

TO OBTAIN SERVICE

Contact the Authorized Dealer from whom you purchased this unit for a Return Merchandise Authorization. The return unit must be sent postage prepaid and
