Poly 03A User manual

1
Zhaoqing Dinghu Huyou Health and Rehabilitation Products Co., Ltd.
Manufacturing Address: HuYou Industrial Park, Guicheng Town, Dinghu District, Zhaoqing
City, Guangdong Prpvomce, P.R. China, 526070
http://www.chinawheelchair.com
http://www.polywheelchair.com
http://www.poly-medical.com
Infrared Thermometer 03A:
(Forehead Temperature Type)
User's Manual
Please read the user's manual closely before using!
E-mail:
[email protected]
[email protected]
[email protected]
TABLE OF CONTENTS
Ⅰ.Product Introduction and classification-------------------------------------------------------------------2
Ⅱ.Basic Working Principle-------------------------------------------------------------------------------------2
Ⅲ.Product Features---------------------------------------------------------------------------------------------2
Ⅳ. Main Technical Specification------------------------------------------------------------------------------3
Ⅴ.Basic Component & figure Structure(As Shown) ------------------------------------------------------3
Ⅵ.Instruction-----------------------------------------------------------------------------------------------------3
Ⅶ.Configuration------------------------------------------------------------------------------------------------4
Ⅷ.Precautions--------------------------------------------------------------------------------------------------5
Ⅸ.Storage & Transportation----------------------------------------------------------------------------------5
Ⅺ:Calibration Method------------------------------------------------------------------------------------------6
Ⅻ.Quality Warranty & Service------------------------------------------------------------------------------6

2
Infrared Thermometer 03A：
(Forehead Temperature Type)
This product complies with EN60601-1, EN12470-5 required standard
Ⅰ.Product Introduction and classification
This infrared forehead temperature sensor is a kind of body temperature sensor based on infrared ray transmission
and reception principle. It is convenient to aim the detection window at one’s forehead when using it, which will
get the body temperature in a quick and exact way. Product Classification:
Product Classification: B
Ⅱ.Basic Working Principle
Any object in which temperature is higher than absolute zero degree will transmit some infrared radiation energy
according to its own temperature. The radiation energy and its distribution per wavelength are closely associated
with its surface temperature. The wavelength transmitted by human body(temperature 36~37℃)is 9~13 ūm. Based
on the principle, it is possible to measure the forehead surface temperature and then adjust the offset between
forehead temperature and actual body temperature, which will result in the correct display of body temperature.
Ⅲ.Product Features
Special design for body & forehead temperature with working temperature and forehead temperature dynamic
compensation.
HEIMANN infrared detection probe is exclusively applied to improve measurement
precision and performance stability.
Optional model provides reminder functionality when body temperature is higher than limit value.

3
32-Reading Data Storage
LED Digital Display
Two Temperature Systems including Fahrenheit and Celsius
Automatic Shutdown Power saving functionality
Small Size, Reasonable structure and easy operation.
Ⅳ. Main Technical Specification
(1) Normal Working Condition:
Working Temperature:10~40℃ Relative
Temperature:≤85%. Power:DC3V (2pcs AA Batteries)
power consumption: ≤50mw
(2) Dimensions:
159mm* 38mm * 89mm (Length*Width*Height)
(3) Weight:119g(no battery)
(4) Display Accuracy:0.1℃
(5) Measurement Range:30~50℃
(6) Consumption Power: ≤50mw
(7) Display Error: Under Normal Environment:+0.2℃
Above Normal Environment: +0.3℃
(8) Response Time: ≤0.5 second
(9) Measurement Distance:50~100mm (10)Automatic Shut Down Time:6 seconds
Ⅴ.Basic Component & figure Structure(As Shown)
Ⅵ.Instruction
Aim the detecting probe at forehead and press the measurement button in the handle, which will start on the
power automatically and then the result will be displayed.

4
Ⅶ.Configuration
(1) Temperature System Selection
1.Keep pressing configuration button for more than 3 seconds and then F1 is displayed on LED.
2.Press“+” button once to select Celsius(℃)
3.Press“-”button to select Fahrenheit(℉)
(2)Warning Threshold Value Setup
1.Keep pressing configuration button for more than 3 seconds and then F1 is displayed on LED.
2.Press configuration button once again to display F2
3.Press “+” button once to increase warning threshold value by 0.1℃ each time.
4.Press “-” button to decrease warning threshold value by 0.1℃ each time.
Note: Warning threshold value is between 33.0℃ and 40.0℃,the default value is 37.5 ℃.
(3)Display Mode Switch between Forehead Temperature & Body Temperature.
1.Keep pressing configuration button for more than 3 seconds and then F1 is display on LED.
2.Press configuration button twice to display F3.
3.Press “+” button to display “1”, which means that it will display forehead temperature.
4. Press “-” button to display “0”, which means that it will display body temperature. Note: The display
result of body temperature is based on dynamic compensation working temperature and forehead
temperature.
(4)Integer Offset Value Setup
1.Keep pressing configuration button for more than 3 seconds to display F1 ON LED.
2.Press configuration button three times to display F4.
3.Press “+” to increase warning threshold value by 0.1℃ 4.Press “--” button to
decrease warning threshold value by 0.1℃.
Note: The actual temperature may be adjusted according to the actual measurement distance and measurement
environment, which adjustment range varies between -0.3 ℃ and +0.3℃. For example, the body temperature
result is 35.9℃ in same special environment, while the actual body temperature is 36.6℃.In this case, you may
get the correct result 36.6℃ using the F4 setup value.
(5)Voice identification Setup
1. Keep pressing configuration button for more than 4 seconds and then F5 is display on LED.
2. The “1” symbol showing, press the “—“ button then it transfer to “0” , closing the voice identification.
3. Press “+ “ back to “1 “ symbol and keep the voice identification setting.
(6)Quit Configuration Mode
1.Keep pressing configuration button for more than 3 seconds to display F1 on 4 LED.
2.Press configuration button four times to quit configuration mode.
(7)Battery Replacement
Display: When the signal “Battery” is displayed on LED, it means that the batteries are almost running out power.
Operation: Open battery cover and replace the old batteries with two pieces of new AA-5 alkaline
batteries.

5
Ⅷ.Precautions
(1) Fence glass for detection probe is most possible to be destroyed, which shall Be destroyed, which shall be
protected carefully.
(2) Cleaning method for detection probe: wipe it gently with cotton swab or soft cloth with water or alcohol.
(3) The battery must not be recharged or disposes of in fire. Please dispose of it in appointed reclaimed place, Using
disqualified battery may cause fire or explosion.
(4) Special Notice: The batteries shall be taken out if this product will be not used for a long period of time.
(5) This product must be protected against water or direct sun light.
(6) Avoid dropping or impacting the product, otherwise it may be damaged.
(7) The battery should be taken out when the product is invalidated. (No special circumstances required)
Ⅸ.Storage & Transportation
The forehead temperature sensor with packaging shall be stored in a well-ventilated room free of corrosive gases,
with a temperature of -25~55℃ and a relative humidity of not higher than 90%.Sling,stress,drench or trample on the
package shall be avoided during transportation and loading/unloading. Besides, it shall be placed according to the
marked direction on the packaging. Ⅹ.Products Troubleshooting
symptom of machine
failure
solution other method
Measured
temperature lower or higher
1. View whether the function key “F4”
has been changed, the factory default
value is 0.0.
2.The machine can automatically
compensate for ambient temperature
variations, but if the ambient temperature
changes too much or test in a high-
temperature environments then quickly
transfer to a low-temperature
environments, the equipment required to be
kept in a stable environment for 10 ~ 30
minutes for the next measurement. Note:
the effective measurement of distance is 5
to 10cm
1. To the designated
maintenance department for
repair
2. Return to distributors,
dealers, then transfer to the
factory for repair or replace.
Key trigger invalid, no
response
Do not self-demolish thermometer
Same as above
No display or display lack
of strokes
Do not self-demolish thermometer
Same as above
No voice prompts
See whether the voice prompts switch is
Same as above
turned on, identification: “1” is turn on
the sound, “0” is off the sound;
Press measuring key
is invalid, no
response
1.Low battery, please replace the new
battery;
2.Whether the battery polarity is correctly
installed.

6
Ⅺ:Calibration Method
Frequency: Calibrated one time in one month.
Calibration methods: via Clinical thermometers (such as the axillary mercury thermometer) measurement the
temperature, to compare the result testing by this machine. If the deviation is too large, it can be offset
compensation key “F4” to fix the correct value.
Note:
If the measurement results is large different from the temperature tested by the Clinical thermometers, the machine
should immediately be calibrated.
Ⅻ.Quality Warranty & Service
The product is warranted for 1 year from date of purchase.
Warning: this warranty dose not cover damages caused by abnormal use or unauthorized disassembly.
Note: Please properly keep the warranty card and purchase document for future guarantee.
*.List of Accessories
This product complies with EN60601-1, EN12470-5 required standard
Instruction Manual 1 PC
Warranty Card 1 PC
