RS-232 Command Set:
Vortex EF2201 Programming Guide
Copyright © 2003 Polycom, Inc.
Polycom  and the Polycom logo are registered trademarks of Polycom, Inc.
ASPI, Vortex, VS4000, Viewstation, and iPower are
registered trademarks of Polycom, Inc.
All other brand names, product names, and trademarks are the
sole property of their respective owners

Vortex EF2201 Programming Guide
Table of Contents
1. Introduction
2. RS-232 Hardware
3. Programming Tips
3.1. Initialization
3.2. Wildcard Characters
3.3. Using Acknowledgements
3.4. Macros and Presets
4. Command Structure
4.1. Device Type
4.2. Device ID
4.3. Command Name
4.4. Command Data
4.5. Command Terminator
4.6. Examples
5. Status Messages
6. Command Types
6.1. Boolean Commands
6.2. Integer Commands
6.3. Channel Commands
6.4. Matrix Commands
6.5. Miscellaneous Commands
7. Command List
8. Command Reference
8.1. AA -- Enable or Disable Auto Answer Mode
8.2. ACKMOD -- Enable or Disable Acknowledgment Mode
8.3. AGC -- Enable or Disable Mic/Line Input Automatic Gain Control
8.4. AGCMAX -- Set Maximum Allowed Mic/Line Input AGC Gain
8.5. AGCMIN -- Set Minimum Allowed Mic/Line Input AGC Gain
8.6. AGCRATE -- Set Ramp Rate of Mic/Line Input AGC
8.7. AHCP -- Enable or Disable Call Progress Based Auto Hangup
8.8. AHLD -- Enable or Disable Loop Drop Based Auto Hangup
8.9. AMNOMAT -- Select NOM Attenuation on Each Output
8.10. BAUD -- Set Baud Rate for RS-232 Port
8.11. BLAUTO -- Enable Automatic BLDATA Messages
8.12. BLDATA -- Request Level Information
8.13. BLINFO -- Select Information to be Reported in BLDATA
8.14. BROAD2 -- Broadcast Arbitrary Command Strings to RS-232 Port
8.15. BROADA -- Broadcast Commands to Other Connected Devices
8.16. COUNTRY -- Specify Country Definitions for Phone Interface

8.17. DELAYO -- Set Output Delay
8.18. DELAYOE -- Enable Output Delay
8.19. DIAL -- Send DTMF Digits to Phone Interface
8.20. DSPAUTO -- Enable Automatic DSPLOAD Status Messages
8.21. DSPLOAD -- Query Percentage of Variable DSP Resources Used
8.22. ERROR -- Enable or Disable Error Messages
8.23. FADERI -- Set Input Gain Fader
8.24. FLASH -- Execute Hook Flash
8.25. FLOW -- Set Flow Control Mode for RS-232 Port
8.26. FPLOCK -- Lock/Unlock Front Panel
8.27. FPPSWD -- Change Front Panel Password
8.28. GAINA -- Set Phone Input Gain
8.29. GAIND -- Set Gain of Incoming DTMF Tones
8.30. GAINDIT -- Set Gain of Incoming DTMF Tones
8.31. GAINDT -- Set Dial Tone Gain
8.32. GAINI -- Set Input Gain
8.33. GAINO -- Set Output Gain
8.34. GAINP -- Set Phone Output Gain
8.35. GAINSIT -- Set From Phone User Tone Gain
8.36. GAINSOT -- Set To Phone User Tone Gain
8.37. GMUTEO -- Mute All Outputs
8.38. ID -- Set Device ID
8.39. LABEL -- Set or Query one of the Device Labels
8.40. LEC -- Enable or Disable LEC
8.41. LECMODE -- Set Amount of Double Talk Suppression used in the LEC.
8.42. LI -- Query State of Logic Inputs
8.43. LIA -- Assign Action for when Logic Input is Activated
8.44. LID -- Assign Action for when Logic Input is Deactivated
8.45. LIH -- Assign Action for when Logic Input is Held
8.46. LIEN -- Enable Automatic Logic Input Status Messages
8.47. LIG -- Configure Logic Input Pins Into a Group
8.48. LIK -- Delete One or All Logic Input Pin Commands
8.49. LIM -- Mask Logic Input Pins
8.50. LIN -- Assign Command to Logic Input Group
8.51. LIP -- Set Polarity for Logic Inputs
8.52. LO -- Query or Set Status of Logic Output Pins
8.53. LOA -- Define Behavior for Logic Output Activated State
8.54. LOD -- Define Behavior for Logic Output Deactivated Status
8.55. LOEN -- Enable Automatic Logic Output Status Messages
8.56. LOK -- Delete One or All Logic Output Pin Commands
8.57. LOM -- Mask Logic Output Pins
8.58. LOP -- Set Polarity for Logic Outputs
8.59. MACROA -- Add Command to Current Macro
8.60. MACROK -- Delete One or All Macros
8.61. MACROL -- List All Commmands in a Macro
8.62. MACROQ -- Execute Macro Quietly

8.63. MACROS -- Start a New Macro
8.64. MACROW -- Write Macro to Non-Volatile Memory
8.65. MACROX -- Execute Macro
8.66. METER -- Select which Signal is Displayed on the Front Panel LED Meter
8.67. MGAIN -- Set Crosspoint Gains in Main Matrix or Submatrix
8.68. MINI -- Enable Modem Initialization String
8.69. MINISTR -- Set Modem Initialization String
8.70. MMUTE -- Mute Crosspoint in Main Matrix or Submatrix
8.71. MUTEI -- Mute One or More Inputs
8.72. MUTEO -- Mute One or More Outputs
8.73. NC -- Enable Noise Cancellation
8.74. NCL -- Set Noise Cancellation Attenuation
8.75. NVINIT -- Reinitialize Non-Volatile Memory
8.76. NVLOCK -- Lock/Unlock Non-Volatile Memory
8.77. NVPSWD -- Change Non-Volatile Memory Password
8.78. PEQIA -- Set All Parameters for Specified Parametric EQ Input Stage
8.79. PEQIB -- Set Bandwidth Parameter for Specified Parametric EQ Input Stage
8.80. PEQIE -- Set Enabled Parameter for Specified Parametric EQ Input Stage
8.81. PEQIF -- Set Frequency Parameter for Specified Parametric EQ Input Stage
8.82. PEQIG -- Set Gain Parameter for Specified Parametric EQ Input Stage
8.83. PEQIS -- Set Slope Parameter for Specified Parametric EQ Input Stage
8.84. PEQIT -- Set Type Parameter for Specified Parametric EQ Input Stage
8.85. PEQOA -- Set All Parameters for Specified Parametric EQ Output Stage
8.86. PEQOB -- Set Bandwidth Parameter for Specified Parametric EQ Output Stage
8.87. PEQOE -- Set Enabled Parameter for Specified Parametric EQ Output Stage
8.88. PEQOF -- Set Frequency Parameter for Specified Parametric EQ Output Stage
8.89. PEQOG -- Set Gain Parameter for Specified Parametric EQ Output Stage
8.90. PEQOS -- Set Slope Parameter for Specified Parametric EQ Output Stage
8.91. PEQOT -- Set Type Parameter for Specified Parametric EQ Output Stage
8.92. PHONE -- Take Phone On-Hook or Off-Hook
8.93. PING -- See Which Devices Are Present
8.94. PRESETK -- Delete One or All Presets
8.95. PRESETL -- List All Commmands in a Preset
8.96. PRESETP -- Set Which Preset Will Be Activated At Power-Up
8.97. PRESETQ -- Execute a Preset Quietly
8.98. PRESETW -- Save a Preset
8.99. PRESETX -- Execute a Preset
8.100. REDIAL -- Redial the Last Dialed Phone Number
8.101. RING -- Enable or Disable Ring Messages
8.102. SGGAIN -- Set Gain of Signal Generator
8.103. SGMUTE -- Mute Signal Generator
8.104. SGTYPE -- Set Type of Signal Produced by Signal Generator
8.105. SOUNDL -- Play Sound Locally
8.106. SOUNDP -- Play Sound to Phone
8.107. SSDELAY -- Set Delay Between Screen Saver Screens
8.108. SSEN -- Enable or Disable Screen Saver

8.109. SSSTART -- Set Idle Time Required for Screen Saver to Start
8.110. SSTEXT -- Set Text to be Displayed by Screen Saver
8.111. SWRESET -- Perform Soft Reset of System
8.112. SWVER -- Query Software Version
8.113. TONEE -- Enable or Disable Entry and Exit Tones
8.114. TONER -- Enable or Disable Ring Tones
1. Introduction
This document describes the command protocol that is used to communicate with the Vortex EF2201
via its RS-232 port.
2. RS-232 Hardware
The communication between the Vortex and a host controller is conducted via the RS-232 port on the
back panel of the Vortex. The Vortex's RS-232 port operates at the following settings:
●Bit Rate (bps): 9600 (default), 19200, or 38400
●Data Format: 8 data bits, no parity, 1 stop bit (8N1)
●Flow Control: none (default) or hardware (RTS, CTS)
Note that although the flow control setting is user selectable to none or hardware, hardware flow
control must be used when updating the firmware of the Vortex. This means that while a 3-wire RS-232
cable (RX, TX, GND) is acceptable for control of the Vortex, the minimum cable for updating firmware
should contain 5 wires (RX, TX, RTS, CTS, GND).
3. Programming Tips
3.1. Initialization
During power up of the Vortex device or initialization of the host program, electrical fluctuations on the
RS-232 lines may cause the Vortex to receive spurious data. After initialization, the host program should
send a few carriage return characters (^M, ASCII 13) to the connected Vortex to flush out any spurious
characters it may have received. Failure to do this could result in the Vortex ignoring the first command
received after initialization.
As part of the host program initialization, the host will want to synchronize the status of its controls
with the current status of the Vortex devices that are being controlled. The host could initialize its
controls to default values and then send commands to the Vortexes to set them to the same state. This
approach has significant disadvantages since initializing the host program could undo settings made by
other host programs or by the front panel controls of one of the linked Vortex devices. A better
approach is to query the linked Vortex devices for their status and set the host program controls based
on the return values.
3.2. Wildcard Characters

The use of the wildcard character, '*', can make programming the host controller much easier. Be
careful when using wildcards, however, since they can generate a lot of traffic on the digital bus.
3.3. Using Acknowledgements
It is a good idea for the host program or control system to make sure that all connected Vortex devices
have acknowledgment mode enabled (see the ACKMOD command). When acknowledgment mode is on,
a Vortex device will send an acknowledgment for each command it receives. Proper use of
acknowledgments makes the host program more robust and makes supporting multiple hosts effortless.
The rest of this section describes how to use acknowledgments to achieve these goals.
As a convenient example, let us imagine a host program with a graphical user interface (GUI). The user
presses buttons on the GUI to enable or disable features of various linked Vortex devices. The buttons
on the GUI reflect the current status of the corresponding feature.
When the user presses a button on the GUI to enable or disable a feature, the host program should
send the corresponding command to the selected Vortex device. It may be tempting to update the
status of the GUI button at this point, but this can cause problems if there are transmission errors or if
there are multiple host controllers. The proper way to handle this is to only update the GUI controls
based on acknowledgments received from the Vortex device.
To implement this, organize your code so that the functions that send commands are totally separate
from the functions that receive responses from the Vortex devices. This also enables your host program
to support the presence of multiple host controllers. For example, consider the following sequence of
events.
1. Another host sends a command to a Vortex device.
2. The Vortex device responds with an acknowledgment that is broadcast to all of the other hosts.
3. Your host program receives the acknowledgment and updates the status of the corresponding
control.
The result of this programming model is that all hosts and linked Vortex devices will always be
synchronized.
For simple on/off features, your host program can make use of the toggle arguments to some
commands (e.g., 'SSEN2'). By sending a toggle command when a button is pressed, and updating the
button based on acknowledgments, your host program will not have to keep track of the status of the
button.
In a similar fashion, many of the integer commands (such as gains) can be controlled by incrementing
or decrementing them by a specific amount. For example, the command ' GAINIT>1' increments the
input gain on channel T by 1 dB. The acknowledgment for this command will return the actual value
that the gain was incremented to. Thus, to implement a volume control, your control program can send
a command to increment the gain by 1 dB when the "up" button is pressed and decrement the gain by
1 dB when the "down" button is pressed. The control can update its level indicator based on the
acknowledgment that is received.

3.4. Macros and Presets
Although macros and presets are similar, there are times when using one is better than the other.
Presets store the absolute values of all of the non-global settings of the device. This includes, but is not
limited to, input and output gain settings, matrix settings, algorithm settings, parametric EQ settings,
and automixer settings. See Section 7 for a list showing all the commands and which are saved to
presets.
Presets should be used when you really want to change all the settings in a device. One example would
be when you want to have one unit be able to control different rooms. In this case, having a preset for
each different room is the easiest solution.
Macros are like mini-presets. You can define them to change only the settings you are interested in.
One advantage of macros over presets is that macros can make relative changes in addition to absolute
changes. An absolute change is something like "set the input gain to -3 dB". A relative change is
something like "raise the input gain by 3 dB". One example of using macros for a relative change is
stereo volume ramping. If you have two outputs setup to have left and right program audio, then you
could build a macro that contains two commands: one to increment the left channel by 1 dB and the
other to increment the right channel by 1 dB. Then, by calling that macro, you can ramp the stereo
outputs. A similar thing can be done with decreasing the volume.
Another thing to consider when using macros and presets is to use the MACROQ and PRESETQ
commands instead of the MACROX and PRESETX commands. Both the Qand Xversions execute the
macro or preset, but the Xversions produce acknowledgements for the settings that change, while the
Qversions don't. If your control system updates its status by looking at the acknowledgements that
come back, then you'll probably want to use the Xversions. Another option would be to use the Q
versions and then manually query the values you're interested in. If your control system does not need
use acknowledgements, or if you are manually querying the values you're interested in, using the Q
versions is better since it doesn't generate acknowledgements and thus reduces RS-232 traffic.
4. Command Structure
A Vortex command consists of a series of ASCII characters with the following structure.
Description Number of Characters Range of Values
Device Type 1 0-9, A-Z, *
Device ID 2 0-9, *
Command Name 1-7 0-9, A-Z
Command Data 0-64 ASCII characters
Command Terminator 1 ^M (ASCII 13)
4.1. Device Type
A single alphanumeric character is used to indicate the device type. The devices in Polycom's EchoFree
family have the following device types.

Device Device Type
EF200 A
EF1210 C
EF2280 F
EF2241 B
EF2211 S
EF2210 Q
EF2201 T
Device type '*' can be used to send a command to all device types simultaneously.
4.2. Device ID
Two numeric characters are used to indicate the device ID. The Vortex can be configured for device IDs
from '00' to '07'. Note that even though the device ID is less than 10, the leading '0' must be included.
Device ID '**' can be used to send a command to all device IDs simultaneously. Some examples of
using wildcard characters are given below.
●'T**' broadcasts to all EF2201 devices that are linked together.
●'*07' broadcasts to all devices with device ID 07 (this format is not commonly used).
●'***' broadcasts to all devices that are linked together.
4.3. Command Name
The command name can be from 1 to 7 characters long. Command names will be specific to device
types. In other words, the EF2280 has its own command set, which is different from the EF2241's,
which is different from the EF1210's, etc. There are some commands, such as 'PING', that are common
among all the various command sets.
4.4. Command Data
The command data is a series of 0-64 characters containing payload data for the command. Obviously,
the command data will be specific to the command type. note that the maximum number of payload
characters for the EF200 and EF1210 is 32, but the Vortex devices support up to 64 characters in the
payload. This increase was necessary to accommodate the matrix gain and macro/preset commands.
4.5. Command Terminator
The command terminator is a single character indicating the end of a command. ASCII 13 (^M) was
chosen as the terminator to allow manually typing commands using a simple text terminal.
4.6. Examples

In the following examples, Vortex commands are enclosed in single quotes, 'like this'. Also, the
terminator character is not explicitly shown, but its presence is implied.
Consider the command '***PING'. The device type and ID for this command are wildcards, thus the
command will be sent to all devices. The command name in this case is 'PING', and there are no data
characters (payload). Note that the 'PING' command is supported by all of the Vortex devices, thus
broadcasting the command to all devices makes sense.
Consider the command 'T**GAINIT10'. The device type for this command is 'T' and the device ID is a
wildcard, thus the command will be broadcast to all EF2201 devices linked together. The command
name in this case is 'GAINIT' and the command data (payload) is '10'. This command sets the gain on
input T of all connected EF2201's to 10 dB.
Command Effects
***PING Requests PONG response from all linked Vortex devices.
T**GAINIT10 Sets the gain on input T of all connected EF2201 devices to 10 dB.
5. Status Messages
The Vortex sends status messages via RS-232 and EF Bus any time one of its internal parameters
changes. This means that the host program does not need to continually poll the Vortex in order to
detect status changes. Status messages are in the same format as the commands used to set the
corresponding parameter.
For example, suppose you send the command 'T**GAINIT10' and there are two EF2201's linked
together with device IDs 3 and 7. The EF2201's will respond with 'T03GAINIT10' and 'T07GAINIT10',
respectively. Now, someone uses the front panel of the EF2201 set to ID 7 to decrease input T's gain
by 1 dB. When this happens, the EF2201 will respond with 'T07GAINIT9'. This example illustrates that
status messages can be sent as the result of an RS-232 command or as the result of some other
change in the Vortex device such as front panel adjustments, logic inputs, etc.
Status messages can be turned off via the ACKMOD command. ACKMOD refers to acknowledgement
mode since the term status message and acknowledgement are synonymous for our purposes.
6. Command Types
Many of the Vortex commands have similar formats. The main formats are described here in order to
provide a better understanding of the command set.
6.1. Boolean Commands
Boolean commands take one of the three following arguments.
●'0' indicates that the parameter should be turned off.

●'1' indicates that the parameter should be turned on.
●'2' indicates that the parameter should be toggled (i.e., '0' becomes '1' and '1' becomes '0').
Parameters associated with boolean commands can be queried using the '?' character. For example, if
input T is muted, and you send ' T04MUTEIT?', the EF2201 will respond with a status message of '
T04MUTEIT1'. When a status message is generated for a boolean command, the command data will
either be a '0' or '1', since '2' is obviously not a valid state.
6.2. Integer Commands
Integer commands can take one of two types of arguments. The first argument type is absolute,
meaning that the parameter will be set to the specified number. For example, ' T04GAINIT10' means
that the gain on input T will be set to 10 dB. In this case, the device will respond with a status message
of ' T04GAINIT10'.
The second argument type is relative, meaning that the parameter will be incremented or decremented
by the specified amount. The increment character is '>' and the decrement character is '<'. For
example, ' T04GAINIT>3' increments the gain on input T by 3 dB. If the input's gain was previously
set to 6 dB, then it would now be set to 9 dB. In this case the device would respond with a status
message of ' T04GAINIT9'.
The numeric part of both the absolute and relative arguments can contain a '+' or '-' to indicate the
algebraic sign of the argument. If no sign is given, '+' is assumed.
The parameters associated with integer commands have maximum and minimum values associated
with them. If you try to set a parameter above its maximum or below its minimum, the parameter will
be set to its maximum or minimum value, respectively.
Parameters associated with integer commands can be queried using the '?' character. For example, if
input T's gain is set to 12, and you send ' T04GAINIT?', the device will respond with a status message
of ' T04GAINIT12'.
6.3. Channel Commands
A command can be a channel command in addition to being one of the other types of commands
(integer or boolean). A channel command means that the command applies to a specific input or output
channel. The channel is specified by a single character (e.g., 'T') occurring before any other payload
data.
An example of a boolean channel command is the 'AGC' (Automatic Gain Control) command. '
T04AGCT0' disables the AEC on input channel T. After sending this command, the device will respond
with a status message of ' T04AGCT0'.
An example of an integer channel command is the 'GAINI' command, which adjusts the gain on the
input channels. ' T04GAINIT12' sets the input gain of channel T to 12 dB. After sending this
command, the device will respond with a status message of ' T04GAINIT12'.

A wildcard character ('*') can be used as the channel specifier for many of the channel commands. If
this is the case, there are two options for specifying the values for the channels. The first method is to
specify a single value that will be applied to all the channels.
Using the wildcard character for channel commands is not common on the EF2201, since it has only
one input channel and one output channel. The wildcard character for channel commands is generally
more useful on devices with multiple inputs, such as the EF2280 and EF2241.
6.4. Matrix Commands
Matrix commands are used for controlling parameters that exist at the crosspoints of the mixing
matrices. Typical parameters include gain and mute. Before describing the matrix commands, it is
necessary to give a description of the matrices involved. During the following discussion, it will be
helpful to refer to the figure below, which shows all the matrices with their input and output labels.
The EF2201 has only one physical output, which is the telephone output, labeled T.

The EF2201 has only one physical input. This input comes from the telephone interface, and is labeled
T. The T input has signal processing which includes the following algorithms: Line Echo Cancellation,
Noise Cancellation, and AGC.
Vortex devices can be linked together so that they can share control information and digital audio
signals. The audio signals are shared on four digital busses labeled P, W, X, Y, and Z. All Vortex devices
can receive signals from all of these busses. Only certain devices can transmit on the busses. This
information is given in the following table.
Device Transmit on P Bus Transmit on W, X, Y, Z
Busses Receive P Bus Receive W, X, Y, Z Busses
EF2280 No Yes Yes Yes
EF2241 Yes Yes Yes Yes
EF2211 Yes Yes Yes Yes
EF2210 No Yes Yes Yes
EF2201 Yes No Yes Yes
The P bus is meant for routing telephone audio between the devices. The W, X, Y, and Z busses are
meant for routing microphone and auxiliary audio between the devices. The W, X, Y, and Z busses also
carry NOM (Number of Open Microphones) information from the automixer so that outputs created
from these busses can be appropriately attenuated for the number of open microphones.
The digital inputs consist of all of the signals placed on the EF Bus by the other connected Vortex
devices. Each P, W, X, Y, and Z bus can carry channels from up to eight other devices, so we have the
following digital inputs to each Vortex device: PB0-PB7, WB0-WB7, XB0-XB7, YB0-YB7, and ZB0-ZB7.
The inputs are designated by three characters: the bus letter (P, W, X, Y, or Z), a B indicating that it is
a bus input, and a number between 0 and 7 indicating the channel of the bus.
There is also an internal signal generator, labeled SG, that is capable of producing white or pink noise.
this signal is fed into the matrix so that it can be routed to the appropriate outputs for calibration or
testing.
The mixing capabilities of the Vortex devices can be broken down into two parts: the EF Bus
submatrices and the main matrix.
For each of the W, X, Y, and Z signal busses, there is a 8 x 3 matrix that allows the user to define up to
three mixes of each of the four signal busses. The inputs and outputs for the 8 x 3 matrices are as
follows.
W Submatrix
●Inputs: WB0-WB7
●Outputs: WM0-WM2
X Submatrix
●Inputs: XB0-XB7
●Outputs: XM0-XM2

Y Submatrix
●Inputs: YB0-YB7
●Outputs: YM0-YM2
Z Submatrix
●Inputs: ZB0-ZB7
●Outputs: ZM0-ZM2
For the P signal, bus there is a 7 x 2 matrix that allows the user to define up to two mixes of the P
signal bus. The reason the matrix is 7 x 2 instead of 8 x 2 is that since we can transmit on the P bus,
we do not need to mix our own channels in this matrix. The inputs and outputs for the 7 x 2 P bus
matrix are as follows.
P Submatrix
●Inputs: PB0-PB7 (with one invalid)
●Outputs: PM0-PM1
The crosspoint gains on all outputs are user adjustable. The "M" in the output labels of the submatrices
indicates that the signals are being fed into the Main Matrix.
The main matrix consists of the following inputs: the telephone input T, the signal generator (SG), the
outputs of the EF Bus submatrices PM0-PM1, WM0-WM2, XM0-XM2, YM0-YM2, and ZM0-ZM2. This is a
total of 16 inputs.
The main matrix consists of the following outputs: the output to the telephone interface T, and the EF
bus outputs P. This is a total of 2 outputs.
The matrix commands can adjust two types of parameters: integer and boolean. We will introduce the
matrix commands by using the MGAIN command as an example. This is an integer matrix command
that is used to set the gain (in dB) at any of the crosspoints in the main matrix or EF Bus submatrices.
Matrix commands are similar to channel commands except that instead of specifying a single channel, it
is necessary to specify a crosspoint (or range of crosspoints). In order to specify a single crosspoint,
you use the input and output labels discussed in this section. The first label always specifies the input
to the matrix and the second label always specifies the output of the matrix. For example, to set the
gain of the crosspoint (T, P) to -3 dB, you would send ' T04MGAINT,P,-3' which sets the gain at the
crosspoint to -3 dB. In this case, a status message will be generated similar to ' T04MGAINT,P,-3'.
It is also possible to use the wildcard character ('*') to specify ranges of crosspoints with the matrix
commands. The only restriction is that you can only use a wildcard to specify the input or output, but
not both simultaneously. Thus you could specify all the inputs going to a specific output (one column)
or the value of an input to all of the outputs (one row), but not the entire matrix. One example of using
a wildcard for an integer matrix command would be ' T04MGAINSG,*,0'. This will set all the
crosspoints in the signal generator row of the main matrix to 0 dB. Thus, the signal generator will be
added to all of the outputs of the main matrix with a gain of 0 dB. In this case a status message will be
generated that looks like ' T04MGAINSG,*,ää'. The binary representation used here is the same

method described in Section 6.3.
You can also use the wildcard character to set the crosspoints of a row or column individually. For
example, 'T04MGAINT,*,äx' sets the crosspoints of input 1 to 0 dB for output T, and -12 dB for
output P. In this case, the EF2201 will respoind with a status message of 'T04MGAINT,*,äx'.
Queries using the '?' character work in the usual manner. For example, ' T04MGAINT,P,?' might
return ' T04MGAINT,P,-6', while ' T04MGAINT,*,?' might return ' T04MGAIN2,*,ää'.
Boolean matrix commands work as you would expect. They use the characters '0', '1', and '2' as
described in Section 6.1. Here are some examples.
●' T04MMUTET,P,1' mutes crosspoint (T, P) of the main matrix. In other words, the signal at
input T will not be heard on output P A status message will be generated of the form '
T04MMUTET,P,1'.
●'T04MMUTET,*,10' sets the mutes for input T of the main matrix. The signal path from input T
to output T muted, while the signal path from input T to output P is unmuted. The EF2201 will
respond with a status message of 'T04MMUTET,*,10'.
●'T04MMUTET,*,2' toggles the mutes for input T of the main matrix. If this command follows
after the command in the above example, the EF2201 will respond with a status message of
'T04MMUTET,*,01'.
●'T04MMUTET,*,?' queries the status of the mutes for input T of the main matrix. If this
command follows after the commands in the above examples, the EF2201 will respond with a
status message of 'T04MMUTET,*,01'.
6.5. Miscellaneous Commands
Miscellaneous commands are those that don't fall under any of the other categories. See the description
of a given command for specific details on how it operates.
7. Command List
The following table is a list of the commands recognized by the EF2201 Detailed descriptions of each
command are given in the next section.
The Storage column contains one of the following values indicating when and where the parameter is
stored.
●"Global"
●"Preset"
●"-" = not stored or not applicable
Globally stored parameters are not changed when a preset is executed. Only one copy of a global
parameter is stored. Global parameters are written to non-volatile memory each time they are changed.
Globally stored parameters retain their values when the power is cycled.
Parameters stored in presets are changed each time a new preset is restored/executed. Preset

parameters are not saved in non-volatile memory until a PRESETW command is executed. Parameters
stored in the power-on preset (see PRESETP) are restored when the power is cycled.
Command Storage Description
AA Preset Enable or Disable Auto Answer Mode
ACKMOD Global Enable or Disable Acknowledgment Mode
AGC Preset Enable or Disable Mic/Line Input Automatic Gain Control
AGCMAX Preset Set Maximum Allowed Mic/Line Input AGC Gain
AGCMIN Preset Set Minimum Allowed Mic/Line Input AGC Gain
AGCRATE Preset Set Ramp Rate of Mic/Line Input AGC
AHCP Preset Enable or Disable Call Progress Based Auto Hangup
AHLD Preset Enable or Disable Loop Drop Based Auto Hangup
AMNOMAT Preset Select NOM Attenuation on Each Output
BAUD Global Set Baud Rate for RS-232 Port
BLAUTO Preset Enable Automatic BLDATA Messages
BLDATA - Request Level Information
BLINFO Preset Select Information to be Reported in BLDATA
BROAD2 - Broadcast Arbitrary Command Strings to RS-232 Port
BROADA - Broadcast Commands to Other Connected Devices
COUNTRY Global Specify Country Definitions for Phone Interface
DELAYO Preset Set Output Delay
DELAYOE Preset Enable Output Delay
DIAL - Send DTMF Digits to Phone Interface
DSPAUTO -Enable Automatic DSPLOAD Status Messages
DSPLOAD - Query Percentage of Variable DSP Resources Used
ERROR Global Enable or Disable Error Messages
FADERI Preset Set Input Gain Fader
FLASH - Execute Hook Flash
FLOW Global Set Flow Control Mode for RS-232 Port
FPLOCK Global Lock/Unlock Front Panel
FPPSWD - Change Front Panel Password
GAINA Preset Set Phone Input Gain
GAIND Preset Set Gain of Incoming DTMF Tones
GAINDIT Preset Set Gain of Incoming DTMF Tones
GAINDT Preset Set Dial Tone Gain

GAINI Preset Set Input Gain
GAINO Preset Set Output Gain
GAINP Preset Set Phone Output Gain
GAINSIT Preset Set From Phone User Tone Gain
GAINSOT Preset Set To Phone User Tone Gain
GMUTEO Preset Mute All Outputs
ID Global Set Device ID
LABEL Global Set or Query one of the Device Labels
LEC Preset Enable or Disable LEC
LECMODE Preset Set Amount of Double Talk Suppression used in the LEC.
LI Global Query State of Logic Inputs
LIA Global Assign Action for when Logic Input is Activated
LID Global Assign Action for when Logic Input is Deactivated
LIH Global Assign Action for when Logic Input is Held
LIEN Preset Enable Automatic Logic Input Status Messages
LIG Global Configure Logic Input Pins Into a Group
LIK Global Delete One or All Logic Input Pin Commands
LIM Preset Mask Logic Input Pins
LIN Global Assign Command to Logic Input Group
LIP Global Set Polarity for Logic Inputs
LO - Query or Set Status of Logic Output Pins
LOA Global Define Behavior for Logic Output Activated State
LOD Global Define Behavior for Logic Output Deactivated Status
LOEN Preset Enable Automatic Logic Output Status Messages
LOK Global Delete One or All Logic Output Pin Commands
LOM Preset Mask Logic Output Pins
LOP Global Set Polarity for Logic Outputs
MACROA - Add Command to Current Macro
MACROK Global Delete One or All Macros
MACROL - List All Commmands in a Macro
MACROQ - Execute Macro Quietly
MACROS - Start a New Macro
MACROW Global Write Macro to Non-Volatile Memory
MACROX - Execute Macro
METER Preset Select which Signal is Displayed on the Front Panel LED Meter

MGAIN Preset Set Crosspoint Gains in Main Matrix or Submatrix
MINI Global Enable Modem Initialization String
MINISTR Global Set Modem Initialization String
MMUTE Preset Mute Crosspoint in Main Matrix or Submatrix
MUTEI Preset Mute One or More Inputs
MUTEO Preset Mute One or More Outputs
NC Preset Enable Noise Cancellation
NCL Preset Set Noise Cancellation Attenuation
NVINIT - Reinitialize Non-Volatile Memory
NVLOCK Global Lock/Unlock Non-Volatile Memory
NVPSWD - Change Non-Volatile Memory Password
PEQIA Preset Set All Parameters for Specified Parametric EQ Input Stage
PEQIB Preset Set Bandwidth Parameter for Specified Parametric EQ Input Stage
PEQIE Preset Set Enabled Parameter for Specified Parametric EQ Input Stage
PEQIF Preset Set Frequency Parameter for Specified Parametric EQ Input Stage
PEQIG Preset Set Gain Parameter for Specified Parametric EQ Input Stage
PEQIS Preset Set Slope Parameter for Specified Parametric EQ Input Stage
PEQIT Preset Set Type Parameter for Specified Parametric EQ Input Stage
PEQOA Preset Set All Parameters for Specified Parametric EQ Output Stage
PEQOB Preset Set Bandwidth Parameter for Specified Parametric EQ Output Stage
PEQOE Preset Set Enabled Parameter for Specified Parametric EQ Output Stage
PEQOF Preset Set Frequency Parameter for Specified Parametric EQ Output Stage
PEQOG Preset Set Gain Parameter for Specified Parametric EQ Output Stage
PEQOS Preset Set Slope Parameter for Specified Parametric EQ Output Stage
PEQOT Preset Set Type Parameter for Specified Parametric EQ Output Stage
PHONE - Take Phone On-Hook or Off-Hook
PING - See Which Devices Are Present
PRESETK Global Delete One or All Presets
PRESETL - List All Commmands in a Preset
PRESETP Global Set Which Preset Will Be Activated At Power-Up
PRESETQ - Execute a Preset Quietly
PRESETW Global Save a Preset
PRESETX - Execute a Preset
REDIAL - Redial the Last Dialed Phone Number
RING Preset Enable or Disable Ring Messages

SGGAIN Preset Set Gain of Signal Generator
SGMUTE Preset Mute Signal Generator
SGTYPE Preset Set Type of Signal Produced by Signal Generator
SOUNDL - Play Sound Locally
SOUNDP - Play Sound to Phone
SSDELAY Preset Set Delay Between Screen Saver Screens
SSEN Preset Enable or Disable Screen Saver
SSSTART Preset Set Idle Time Required for Screen Saver to Start
SSTEXT Preset Set Text to be Displayed by Screen Saver
SWRESET - Perform Soft Reset of System
SWVER - Query Software Version
TONEE Preset Enable or Disable Entry and Exit Tones
TONER Preset Enable or Disable Ring Tones
8. Command Reference
8.1. AA -- Enable or Disable Auto Answer Mode
This command sets or queries the status of the auto answer feature.
This command is a boolean command. See Section 6.1 for more information on this type of command.
This command is saved to non-volatile memory only as part of a preset. The state of this command will
be restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example Description Status Message
T01AA1 Enable auto answer mode. T01AA1
T01AA0 Disable auto answer mode. T01AA0
T01AA2 Toggle auto answer mode. T01AAx, where xis 0or 1depending on the current state of
auto answer mode.
T01AA? Query auto answer mode. T01AAx, where xis 0or 1depending on the current state of
auto answer mode.
8.2. ACKMOD -- Enable or Disable Acknowledgment Mode
This command controls whether or not status messages are sent. See Section 5 for more information
on status messages. This parameter is enabled by default, and it is rarely turned off by the host
controller.

This command is a boolean command. See Section 6.1 for more information on this type of command.
This command is saved to global non-volatile memory and is not part of a preset. Its value is saved
each time it is changed. It will retain its value after power-down. Since this command writes to non-
volatile memory, there will be a delay before an acknowledgment is returned.
Example Description Status Message
T01ACKMOD1 Enable acknowledgement mode. T01ACKMOD1
T01ACKMOD0 Disable acknowledgement mode. T01ACKMOD0
T01ACKMOD2 Toggle acknowledgement mode. T01ACKMODx, where xis 0or 1depending on the
current state of acknowledgement mode.
T01ACKMOD? Query acknowledgement mode. T01ACKMODx, where xis 0or 1depending on the
current state of acknowledgement mode.
8.3. AGC -- Enable or Disable Mic/Line Input Automatic Gain
Control
This command sets or queries the status of the Automatic Gain Control (AGC) algorithm on input
channel T (the telephone input).
This command is a channel boolean command. See Section 6.3 and Section 6.1 for more information on
this type of command.
This command is saved to non-volatile memory only as part of a preset. The state of this command will
be restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example Description Status Message
T01AGCT1 Enable AGC on input channel T. T01AGCT1
T01AGCT0 Disable AGC on input channel T. T01AGCT0
T01AGCT2 Toggle AGC state on input channel T. T01AGCTx, where xis 0or 1depending on the
current state of the AGC on input channel T.
T01AGCT? Query AGC state on input channel T. T01AGCTx, where xis 0or 1depending on the
current state of the AGC on input channel T.
8.4. AGCMAX -- Set Maximum Allowed Mic/Line Input AGC
Gain
This command sets the maximum gain that the AGC can apply on input channel T (the telephone
input). For example, if AGCMAX is set to 10, then the AGC for that channel can apply a maximum of 10
dB of gain to the input signal.
This command is a channel integer command. See Section 6.3 and Section 6.2 for more information on
this type of command. The minimum and maximum values for this command are 0 and 15,

respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command will
be restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example Description Status Message
T01AGCMAXT3 Set AGC maximum gain on input
channel T to 3 dB. T01AGCMAXT3
T01AGCMAXT? Query the AGC maximum gain on input
channel T.
T01AGCMAXTx where xis a number between
0 and 15, depending on the current setting of
the AGC maximum gain on input channel T.
8.5. AGCMIN -- Set Minimum Allowed Mic/Line Input AGC
Gain
This command sets the minimum gain that the AGC can apply on input channel T (the telephone input).
For example, if AGCMIN is set to -10, then the AGC for that channel can apply a minimum of -10 dB of
gain to the input signal.
This command is a channel integer command. See Section 6.3 and Section 6.2 for more information on
this type of command. The minimum and maximum values for this command are -15 and 0,
respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command will
be restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example Description Status Message
T01AGCMINT-3 Set AGC minimum gain on input
channel T to -3 dB. T01AGCMINT-3
T01AGCMINT? Query the AGC minimum gain on input
channel T.
T01AGCMINTx where xis a number
between -15 and 0, depending on the
current setting of the AGC minimum gain on
input channel T.
8.6. AGCRATE -- Set Ramp Rate of Mic/Line Input AGC
This command sets or queries the maximum rate at which the AGC can increase or decrease the gain of
the signals on input channel T (the telephone input). The ramp rate is expressed in dB/sec.
This command is a channel integer command. See Section 6.3 and Section 6.2 for more information on
this type of command. The minimum and maximum values for this command are 1 and 5, respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command will
be restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
