Polycom®Vortex®EF2201
DSP-based hone add for installed conferencing a lications
The ideal “ hone add” for installed conferencing a lications, the
EF2201 makes tele hone interfacing easy. With a variety of control
options, built-in DTMF dialer, and one-cable connection to other Vortex prod-
ucts, the EF220 simplifies the addition of telephone calls to your audio or
video conference.
When participants can't make it to a video con-
ference, or can only drop in for a short time, it's
easy to accommodate their needs. The Vortex
EF220 links directly to an analog (PSTN) tele-
phone line, connecting outside callers to your
meeting. In addition to providing crystal-clear
telephone audio to all participants, the Vortex
EF220 significantly reduces background noise
on the phone line, keeping unwanted sounds
from interfering with your conference. As the
next generation of digital hybrid telephone inter-
faces, the Vortex EF220 interfaces with other
Vortex products through a digital expansion bus.
Telephony signals are communicated with a
Vortex EF2280 over the digital P-bus channel of
the EF Bus, without the need for analog input or
output on the EF2280.The EF220 can be con-
trolled via RS232, Vortex Expansion bus, and
front panel controls. Additional features are
audible ring indications, user-configurable entry
and exit tones, up to 256 speed dial memories,
and controllable levels of DTMF and dial tone
signals. The full cross-point matrix allows users
to determine how the input and output signals
are sent to and from the telephony interface.
Settings are configured with Conference
Composer software (provided), and can be stored
as user presets.
The direct-link audio choice for The
Polycom Office™
With integrated video, voice, data, and Web capa-
bilities, The Polycom Office is the only solution
that offers you an easy way to connect, confer-
ence, and collaborate any way you want. The
Polycom Office is our commitment to making dis-
tance communications as natural and interactive
as being there. Work faster, smarter, and better
with the Polycom Vortex EF220 and The
Polycom Office.
Benefits
Easily add calls to conferences – Utilize tele-
phone hybrid with noise cancellation to add tele-
phone callers
Sim le, fully digital connection – Between
Vortex EF2200 series products with EF Bus, no
analog input / output is required
Productivity-enhancing features –
256 speed-dial memory, selectable auto hang-up
via loop drop and progress tone detection
Use it anywhere in the world – Country-specif-
ic telephone configuration settings
Consistent audio quality – Automatic gain con-
trol on the telephone audio receive path

Dimensions
• 9” (483 mm) W x 9.6” (244 mm) L x .75” (45 mm) H
(one rack unit)
Weight
• 4 lbs. ( .8 kg) dry, 5.5 lbs. (2.5 kg) shipping
Connectors
• RS-232: DB9F
• EF Bus In/Out: RJ45
• Control /Status: DB25F
• Telephone Line/Set: RJ (2)
Power
• External supply (provided)
• Input voltage of 0-240 VAC; 47-63 Hz; power
consumption 5 W (typical)
Micro hone In ut
• -30 dBu to +0 dBu/ -66 dBu to -33 dBu, nominal;
software selectable
Control In uts
• Contact closure
Status Out uts
• 5 V, 20mA each
Headroom
• 20 dB, nominal
Frequency Res onse
• 250 Hz - 3.6 kHz on telephony interface
Line Echo Canceller (tele hone hybrid)
• Echo cancellation 40 dB, total 60 dB
• Convergence 30 dB/second
• Cancellation span 32 msec
Part No. 3726-82201-001 Rev. 03/03
www. olycom.com
Polycom, Inc.: 4750 Willow Road, Pleasanton, CA 94588 (T) .800.POLYCOM (765.9266) for North America only.
For North America, Latin America and Caribbean (T) + .925.924.6000, (F) + .925.924.6 00
Polycom EMEA: 270 Bath Road, Slough, Berkshire SL 4DX, (T) [phone], (F) [phone]
Polycom Hong Kong Ltd.: Polycom Hong Kong Ltd., Rm 0 MassMutual Tower, 38 Gloucester Road, Wanchai, Hong Kong, (T) +852.286 .3 3, (F)+852.2866.8028
©2003 Polycom, Inc. All rights reserved.
Polycom, the Polycom logo, and Vortex are registered trademarks and The Polycom
Office is a trademark of Polycom, Inc. in the U.S. and various countries. All other
trademarks are the property of their respective companies. Specifications subject to
change without notice. For Architect's and Engineer's Specifications, please visit
Polycom.com, or contact the Installed Voice Business Group at .770.64 .4400.
