Polygroup TG76M2AGMD21 User manual

*Electrical Rating For The Tree
(For Indoor Use Only)
Input: 120VAC, 60Hz, 0.38A
Output: 29V DC 0.621A
Fig. B - Tree and Light Assembly
Tree top
Section 2
Section 1
Top view Side view
Fig. C
MODEL #: TG76M2AGMD21
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Assemble the tree stand and place on a level surface. (See Fig. A)
TREE ASSEMBLY INSTRUCTIONS
1
NEED HELP?
DO NOT RETURN TO STORE. PLEASE VISIT US AT:
www.polygroupstore.com OR 1-888-919-0070
Fig. A - Tree Stand Assembly
Unfold the legs and lay the
stand in a flat area.Then slide
the locking disc downward and
snap into place.
Congratulations on purchasing your new tree from Polygroup®!
This tree comes with Quick Set® technology - allowing you to set up your tree and light it up in minutes!
Carefully follow the instructions below on how to quickly and easily set up your new tree.
3. Each tree section is numbered with a sticker. Please identify all sections before assembling.
4. Assemble the tree from bottom to the top.Start with the bottom section and remove the protective cap before inserting into the
assembled stand. Make sure the pole is firmly inserted and secured into the stand.
5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.
6. Allow branches to fall into place or gently pull up and out.When adjusting branches, be sure that all wires are free of branch hinges.
7. Insert green label adapter insert into the wall outlet (See Fig. B), your entire tree should now be lit.
8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from the pole and fan out one to
the right, one to the left and one at the center of the main stem. (See Fig. C)
Insert Green
Label Plug
into Adapter
Align both arrows
in a straight line
before sliding
down to insert
Open the
cap cover
Do Not Tamper
Internal Parts
Adapter
To Be Plugged
Into Wall
Outlet

2
TROUBLESHOOTING TIPS
For Pre-lit Trees, If The Tree Does Not Illuminate
1. Please check to make sure that all plugs are properly connected and the adapter is plugged into the wall outlet.
2.Turning the poles gently to make sure pole to pole are connected into place.
3. Check for loose connection between light string plugs and extension cords.
1. Extra hinge pins are included for repairing the hinges. Place the branch
into the slot of the bracket.
2. Insert a new hinge pin through the hole and secure using the retainer
washer.(See Fig. E)
Loose Hinge Pin
Fig.E
9. After shaping the entire tree following the previous step, slightly upsweep all branch tips for a uniform look. Shift branches to fill
any gaps.Your Christmas tree is now complete and ready to be decorated.
STORAGE INSTRUCTIONS
1. Unplug the power adapter from the wall outlet first and then remove all ornaments and decorations.
2. Disassemble the tree from the top to the bottom. Start with the tree top and gently lift straight up to remove from section
below and fold all branches toward the pole.
3. Continue by gently lifting straight up each section(s) from the section below and fold all branches
toward the pole until the bottom section is removed from the tree stand.Cover the cap on the
poles to avoid damaging the internal parts. (See Fig. D)
4. Carefully place all tree sections into shipping box and tape it shut.
5.When not in use, please store your tree in a cool, dry place away from sunlight. Exposing your tree
to excessive heat or humidity may damage your tree. Fig. D
HOW TO USE THE DUAL COLOR LIGHT CONTROLLER AND REMOTE CONTROL: Aselector
button
Bselector
button
Press Aselector button on the “Dual Color Light Controller” or “Remote
Controller” to select among:
(1) CLEAR AND MULTI-COLOR ALTERNATING;
(2) CLEAR LIGHTS; (3) MULTI LIGHTS
Press Bselector button on the “Dual Color Light Controller” or “Remote
Controller” to select among:
(1) COMBO (2) STEADY (3) SHIMMER (4) STARFIELD
(5) CHASER (6)LIGHTNING (7) STACKER
REMOTE CONTROL INSTRUCTIONS
Remove the insulation tab of the remote control.
Insulation Tab
WARNING:
This product may potentially trigger seizures for people with photosensitive epilepsy when using the motion effect light modes.

CAUTION:
To reduce the risk of fire and electric shock:
a) Use only the power supply that was provided with this product. Using a different adapter will damage the lights and may
cause fire, or electrical shock hazards.
b) Do not install on trees having needles, leaves or branch covering of metal or materials which look like metal.
c) Do not mount or support strings in a manner that can cut or damage wire insulation.
3
1. Loosen the screw of the battery cover with a screwdriver (not included).
Battery Replacement
2. Replace the used battery with a new CR2032 button cell battery (not included). Make sure that the battery is installed with the
correct polarity (+ and -).
3. Retighten the screw to close and secure the battery cover.
WARNING
1. This product is powered by a lithium battery. Due to their small size, lithium batteries can easily be swallowed by children.
Ingestion of such batteries has been known to cause death.
2. This is a lithium battery which if swallowed has been known to cause death.
3. Small parts, keep batteries out of reach of children.
4. Do not expose the remote controller to moisture.
5. Remove batteries when not used for an extended period of time, or when depleted.
6. Dispose of used batteries properly.
7. Use only CR2032 batteries for the remote controller.
8. Clean the battery contact surfaces gently prior to battery installation.
9. Do not dispose of batteries in fire. Batteries may explode or leak.

4
CUSTOMER SERVICE FOR CHRISTMAS TREES
For any questions, assistance, or missing parts, Do Not Return To Place Of Purchase. Please contact us at 1-888-919-0070
or visit our website at www.polygroupstore.com. One of our customer service representatives will be happy to assist you.
TREE ID# IS LOCATED ON END PANEL OF BOX.TREE ID# IS REQUIRED WHEN REQUESTING REPLACEMENT PARTS.
Customer Name:
Address:(No P.O. Boxes)
City & State:
Zip Code:
Day Phone:
Date Purchased:
Tree ID#:
Tree UPC#:
Store Purchased:
Specify Problem:
SPARE PARTS
Each tree includes hinge pins/washers.
If extra parts are needed, please contact our customer service center.
When using electrical products, basic precautions should always be followed including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
a) Do not use seasonal products outdoors unless marked suitable for indoor and outdoor use. When products are used in outdoor
applications, connect the product to a Ground Fault Circuit Interrupting (GFCI) outlet. If one is not provided, contact a qualified
electrician for proper installation.
b) This seasonal use product is not intended for permanent installation or use.
c) Do not mount or place near gas or electric heaters, fireplaces, candles or other similar sources of heat.
d) Do not secure the wiring of the product with staples or nails, or place on sharp hooks or nails.
e) Do not let lamps rest on the supply cord or on any wire.
f) Unplug the product when leaving the house, or when retiring for the night, or if left unattended.
g) This is an electric product – not a toy! To avoid risk of fire, burns, personal injury and electric shock it should not be played with
or placed where small children can reach it.
h) Do not use this product for other than its intended use.
i) Do not hang ornaments or other objects from cord, wire, or light string.
j) Do not close doors or windows on the product or extension cords as this may damage the wire insulation.
k) Do not cover the product with cloth, paper or any material not part of the product when in use.
l) The supply cord cannot be replaced. If the cord is damaged the product should be scrapped.
m)The lamps of this product are not replaceable. Do not attempt to change or modify the lamps.
n) For LED string only. To reduce the risk of fire or electric shock, do not attempt to replace lamps or modify string.
o) Read and follow all instructions that are on the product or provided with the product.
SAVE THESE INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
