1. System Synopsis
zThe PC-1074 is designed for high-security access control and real-time
monitoring environments from medium size to complex multi-site installations.
zIt is an independent processing 4 doors access control package with metal
enclosure, backup battery charger as an efficient space saving design.
zSuitable for applications with up to 64,000 users across a modular 1024 doors,
allowing maximum flexibility for securing a growing enterprise. Each unit
supports 8 Wiegands or RS-485 ports for entry & exit control.
zThe system support Bar Code, Magnetic Stripe, Biometric and Smart Card
Readers thru. Wiegand or ABA interface.
zDesigned with 4 DI (digital input) and 4 DO (digital outputs) for light, air
conditioning, surveillance, fire prevention or urgent rescuing system control.
2. System Features
zOnline Network with on board selectable RS-485/RS-232/RS-422 and optional
TCP/IP Ethernet.
zUp to 15,000 cards with 32,000 events. Optional 64,000 cards with 64,000
events.
zMulti technology of badges include proximity, smart card, biometric, hand free
active card, mag. cards, etc.
z8 wiegand readers for 4 doors. expandable to 16 wiegand readers for 8 doors.
Optional 8 or 16 RS-485 readers for 8 doors by 2nd RS-485 port.
z4 digital inputs and 4 digital outputs with expansible 24/48/64 relays output for
floors control.
zGlobal (4 or expandable 8 doors) or single doors APB without PC autonomous
decision at local level without degradation and removable connectors
zOptional baud rate from 2,400 to 38,400 with optional encryption for
communication security.
3. System Specifications
Metal Enclosure Dimensions
Board Dimensions 273(L) x 218(W) x 80(H) mm
160(L) x 115(W) x 24.5(H) mm (PC-1074B)
Weight PCB & Metal Enclosure 4.7kg ± 5%
PCB only 480g ± 5%(PC-1074B)
Power supply DC 15V ±10%, 1.7A
UPS 7.2A/H
Transmission rate 9,600 bps, N,8,1
Serial interface RS-485 <RS-232C, RS-422, TCP/IP(Option)>
Events 32,000 standard, up to 64,000
Card capacity 15,000 standard, up to 64,000
External reader Wiegand 26, 34bits reader
Time zone 8 personal time zones, 8 time zones for auto
operation mode
Memory 6 MB, EEPROM
Operation temperature 0℃~ 50℃
Humidity 5%~95%
