Operation Manual
Model:8903/8904/8906
10cm Vane Air Flow Meter
with Airflow cone
Model:
8916
8917
8919

Thank you for purchasing this air flow
meter. This meter is specially designed
for HVAC&R application that combines
those required measurements, like Air
Velocity, Air volume, Temp., RH, WBT,
DP, and CO2 in one handy meter.
The Air flow cone compatibility also
helps in quick volume measurement.
Users can be freed from the hassle of
calculating dimensions.
Features :
1
INTRODUCTION
Big LCD digital display
Multi-points and Timed average
Metric& Imperial units selectable
Round & Square airflow cone compatible
Fast response &
Dew Point calculated in seconds
Wet Bulb calculated in seconds
Blue back light for dark places use
Accurate reading
Low battery indication
Handheld size, easy to carry
Measures air velocity, air volume,
temp., RH, WBT, DP, and CO2.
Function Table
CO2
8916 89198917
Air temp.
Humidity
Dew Point
Wet Bulb
Air Velocity
Air volume

2
The meter x 1
Battery x 4 (AAA size )
Operation manual x1
Hard carry case x1
This package contains:
MATERIAL SUPPLIED
Airflow cone set:
Round conex1 (dia.210mm)
Square conex1 (346x346mm)
Optional accessory:
CONTROLS AND INDICATORS
LCD DISPLAY
OO
F
OO
C
2
inch
cm2
MAX MIN
fpm
m/s
CFM
CMM
AVG
DP
WBT
HOLD
ppm
%RH
Upper display: air velocity, RH, CO2 value
duration time in average.
Lower display: temp., air volume readings.
: freezes the current reading.
MAXMIN:maximum and minimum reading
HOLD
AVG: mul ti-po ints mean & timed average
: battery low voltage indicator
m/s,fpm: air velocity unit
%RH : relative humidity
: temperature units
CMM,CFM: air volume units
WBT, DP : wet bulb, dew point temp.
: area dimension units
: air flow cone indicator
: vain icon in this meter
OO
F
OO
C
2
inch cm2
ppm :CO2 unit

3
KEY PAD
-Turns the meter on and off.
-Long press to go in and out setup
mode.
-Freezes current reading on LCD
-Long press to review MIN and MAX
-In average mode, press to record
data or start timed recording.
-In setup mode, press to enter data
settings.
-Switches upper display.
-Long press to go into average mode.
-In average mode, press to average
and return to normal mode.
-In setup mode, press to select
category or increase value.
-Switches lower display.
-In average mode, press to view
recorded and average reading of
all parameters.
-In setup mode, press to select
category or decrease value.
+ -Disables auto power off.

4
MEASUREMENT
POWER ON/OFF
Press to turn on the meter. The
screen shows full display with blue
backlight on and enter normal mode.
(Model 8916/8917). For model 8919,
it proceeds 30 seconds warm up when
turned on, then goes into normal mode.
Press again in any mode to turn
off the meter.
The meter is preset auto sleep in 20
minutes of inactivity. To disable this
function, hold down and for 2
seconds to turn on the meter while it is
off. It shows “n” on the LCD (see Fig.A)
and goes into normal mode(or 30 sec.
warm up for model 8919) and won’t
turn off itself until is pressed or out
of voltage.
Fig.A
SWITCH DISPLAY
When the meter is turned on, it shows
the current readings of air velocity on
the upper display and air temp. on the
lower(see Fig.B). To switch display of
other measurements, press or .
Fig.B
m/s
OO
C

5
Short press , the upper display will
cycle among air velocity, RH, and
CO2 (8919 only).
And short press , the lower display
cycles among air temp. air volume
WBT(wet bulb temp) DP(dew
point temp)(Fig.C).
Fig.C
%RH
AIR VOLUME
To measure air volume, it is necessary
to get the outlet dimensions. Go to
Setup mode and input the AREA value
first before taking measurement. (See
page 9 , P2.0)
CMM
After AREA setting is completed, press
to switch the display to air volume
and the measured air volume will be
displayed on the lower LCD.
Measure with airflow cones
Two airflow cones are available
for using with this anemometer and
are sold as a set.
Square
346x346mm
Round
dia. 210mm

pic.1
Lock
6
RH(8917/8919 only)
The capacitive humidity sensor is built
in the center of the vane to measure air
flow relative humidity and is used for
calculating dew point and wet bulb
temperatures.
Press to switch to RH display. It
shows measured RH readings on the
upper display. And it is also possible to
display with RH offset. Go to Setup
mode (see page 9, P3.0) and input
offset value, then the displayed readings
will be the measured data with offset.
To measure air volume with use of an
airflow cone. Just plug on the cone and
the meter will automatically recognize
it and shows a on the display(Fig.C).
Then the meter will calculate the air
volume by the default dimensions
despite of any AREA value is input.
Note:
Be sure the airflow cone is well mounted
and locked tight. (See pic.1)

MIN/MAX
In normal mode, long press for 3
seconds and it displays the minimum
readings of all parameters since power
on with MIN icon on the top. Long press
this button again, it shows the maximum
readings with MAX on the top. (Fig.D)
Long press again and it returns to the
normal mode.
OO
C
MAX m/s
OO
C
MAX m/s
Fig.D
While reviewing the minimum and
maximum data, press and
and it switches to display MIN and MAX
readings of other parameters.
7
CO2 (8919 only)
Model 8919 features additional CO2
measurement for HVAC application.
The NDIR CO2 sensor is built in the rear
side of the meter. Press to switch
to CO2 display and the current reading
will show on the upper LCD.
For places in high altitude, the pressure
compensation needs to be considered
in order to get accurate CO2 readings.
Go to Setup mode P4.0 and input the
pressure value according to your
location before taking measurements.
DATA HOLD
In normal mode, press and the
current readings are fixed on the LCD
with HOLD icon on the top and won’t
change until a second press on .

8
m/sAVG m/sAVG m/sAVG m/sAVG AVG
%RH
AVG
%RH
Fig.E Fig.F
Timed average
In normal mode, press for 2 seconds
and it goes into multi-point average.
Press it again to enter timed average
mode. (See Fig.G, the upper display shows
the duration time in second, the maximum
time is 19999 seconds, and the lower is the
measured reading)
AVG
AVG
- Press to start recording, the upper
display starts the counting clock.
- Press to stop and calculate the
timed average. It shows the duration
seconds on the upper display and the
average readings at the lower display
with flashing” “. (See Fig.H)
AVERAGE
This meter calculates multi-points mean
and timed average of all parameters.
Multi-points average
In normal mode, press for 2 seconds
to enter multi-point average mode.(See
Fig.E, the upper display shows the record
number and the lower is the measured reading)
- Press to record readings.
- Press to see the multi-point mean
once all data is recorded. It shows the
average readings with flashing” “.
- Press to view the average reading
of each parameter.
AVGAVG
- Press to return to normal mode.
(See Fig.F, the upper display means total
20 recorded data; and the lower display is
the average reading of RH.)

SETUP
The setup mode is for those related
parameters setting that can ensure
more accurate measurements.
It includes:
P1.0: Unit selection
P2.0: AREA size
P3.0: RH offset
P4.0: Pressure input (model 8919 only)
P1.0: Unit selection
In P1.0 (Fig.I), press to enter units
selection (Fig.J). Then press or
to switch from Metric to Imperial unit.
The units include air velocity(m/s, fpm),
temp.(C, F), air volume(cmm,cfm), and
2 2
area size(cm ,inch ). After finishing the
setting, press to return to P1.0.
OO
C
cm2
m/s
CMM
OO
C
cm2
CMM
Fig.J
Fig.I
In normal mode, press for 2 seconds
to enter SETUP mode. It starts with P1.0
unit selection. Press or to select
among P1.0 to P4.0. Long press
again to return to normal mode.
9
- Press to view average reading of
other parameters.
- Press to return to normal mode.
Fig.G Fig.H
AVGAVGAVGAVG AVGAVG
ppmppm
OO
C
OO
C

Fig.K
cm2 cm2
Fig.L
P3.0: RH offset
In P3.0(Fig.M), press to enter RH
offset setting. It shows blinking 0.0 RH
reading on the upper display(Fig.N).
Press to increase the offset value
and to decrease it. When finished
the setting, press again to return
to P3.0.
%RH%RH
Fig.M Fig.N
P4.0:Pressure input (8919 only)
In P4.0 (Fig.O), press to enter
pressure input. It shows default 1013
hpa on the display with blinking value
at the upper (Fig.P). Press to
increase the pressure value and
to decrease it. Once finished, press
again to return to P3.0.
10
P2.0: AREA Size
In P2.0(Fig.K), press to enter AREA
size setting. It shows “99999” on the
lower display with the first digit flashing.
(Fig.L) The flashing digit means it is
ready to adjust. Press to change the
number and it will cycle from 0 to 9.
Press to move to next digit. After
completed, press again to return to
P2.0.

11
CO2 CALIBRATION
The meter is calibrated at standard
400ppm CO concentration in factory.
2
It’s suggested to do manual calibration
regularly to maintain good accuracy.
CAUTION:
Do not calibrate the meter in the air
with unknown CO concentration.
2
Otherwise, it will be calibrated as
default and leads to
inaccurate measurements.
400ppm
400ppm calibration is suggested to be
done in outdoor fresh air that is well
ventilated and in sunny weather.
400ppm calibration
Note:
When the accuracy becomes a concern
after a long time use, return to dealers
for standard calibration.
CALIBRATION
RH CALIBRATION
The humidity calibration of this meter
requires specific fixture and cannot be
done by end users. Please contact the
dealer for calibration service.
Place the meter in the calibration site
and follow the below procedure to
complete the 400ppm calibration.
Fig.O Fig.P

12
LOW-BATTERY
When the battery voltage falls below the
measurement required range, shows
on the LCD. Replace with fresh batteries
to ensure accurate measurements.
2. During calibration, a CO2 reading in
the range of 380 to 420ppm will be
flashing on the upper display.(Fig.U)
Fig.T Fig.U
ppm
NOTE:
Be sure the batteries are with full
voltage during the calibration to
prevent from interruption and fail
in the calibration.
1. While the meter is turned off, hold
down , and simultaneously
to enter CO2 calibration mode. It runs
30 seconds countdown with CAL at
lower display(Fig.T), and then starts
400ppm calibration.
3. Wait for 10 minutes until the reading
stops flashing, the 400ppm calibration
is completed and it returns to normal
mode automatically. .
To abort the calibration, turn off the
meter at any time.

13
TROUBLESHOOTING
1. Power on but no display
1) Make sure the time of pressing
key is more than 200mS.
2) Check the batteries are in good
contact with correct polarity.
3) Replace new batteries and try again.
2. Display disappeared
Check whether the low battery
indicator shows before display
disappears, if yes, replace with new
batteries.
3. Error code and solution
1)Air Temp.
E02: Temp. is under low range limit.
Put the meter in room temp for
30 minutes. If E02 still shows,
send to the dealer for repair.
E03: Temp. is over high range limit.
Put the meter in room temp for
30 minutes. If E03 still shows,
send to the dealer for repair.
E31: temperature measuring AD
damaged. Send to the dealer
for repair.
2) RH
E04: temperature error caused the
RH error. Check the temp.
error solution.
E11: RH calibration error.
Try recalibration or send for
repair if it still can’t work.
E33: RH measurement circuit error.
Send to the dealer for repair.

14
3) DP and WBT
E04: Temp. or RH error.
Check temp. or RH error
solution.
4) Air velocity
E03: Velocity is over high range limit.
Try in range measurement. If
it still shows in range velocity,
recalibrate it send for repair.
5) Air volume
E03: Reading exceeds display limit.
Check if the outlet area setting
is correct.
E04: Air velocity error.
Try recalibration or send for
repair if it still can’t work.
6)CO2
E03: Temp. is over high range limit.
Put the meter in room temp.
for 10 minutes and if E03 still
shows, recalibrate it or send
for repair.
E01/E33: Voltage too low or CO2
module error.
Check if battery low icon showed
on the LCD, if yes, replace with
new batteries.
Try recalibration, or send for
repair if it still can’t work.
7) Others
E32: Memory IC error.
Turn off the meter and turn it
on again. If E32 still shows,
send to the dealer for repair.

SPECIFICATION
Measuring range
o o
-20.0~60.0 C ( -5~140 F)
CO2
Temperature
Accuracy
CO2
Temperature o
+0.6 C
30 s econds
CO2 Warm-up t ime
Vane / Mete r siz e (mm)
Operatin g condition
(avoid condensation)
Storage c onditio n
Power supply
Standard p ackage
Optional a ccessory Air f low c one set ( w /soft c arry c ase )
Dia. 100, 269(L)x106(W)x51(H)
0 to 50 ° C, <80%RH
o
-10~ 5 0 C, <90%RH(avoid condensation)
AAA x 4 pcs
Meter, manual ,AAA bat.,Hard carry case
8916 8919
0~9999 ppm,
(5001~9999 ppm o ut of scale range)
+30ppm+5% o f rdg.(0~5000ppm)
Resolution o o
0.1m/s, 0.1(0~9999.9) or 1(10000~99999), 0.1 C/ F, 0 .1%RH
Relativ e Humidity
DP(Dew point temp.)
WBT(Wet b ulb t emp.)
0.1%~99.9%RH
o
-5.0~59.9 C
o
-20.0~59.9 C
Relativ e Humidity o
+3%RH(at 25 C, 10~90%RH) ; +5%RH( others )
N/A
N/A
N/A
8917
Air velocity 0.2~30m/s
Air volume 3
0 to 99999 m /s
N/A N/A
Air velocity +/-(1.5% of reading +0.3m/s) for under 20m/s
+/-(3% of reading +0.3m/s) for above 20m/s
N/A
N/A N/A
N/A N/A
Air flow cone size(mm)
Round Dia. 210
Square 346x346
15

Proof of purchase is required for
warranty repairs. Warranty is void if the
meter has been opened .
The meter is warranted to be free from
defects in material and workmanship
for a period of one year from the date
of purchase. This warranty covers
normal operation and does not cover
battery, misuse, abuse, alteration,
tampering, neglect, improper maintenance
or damage resulting from leaking batteries.
WARRANTY
Authorization must be obtained from the
supplier before returning items for any
reason. When requiring a RA (Return
Authorization) , please include data
regarding the defective reason, the
meters are returned along with good
packing to prevent any damage in
shipment and insured against possible
damage or loss.
RETURN AUTHORIZATION
16

Accuracy, the Zenith of
Measuring / Testing Instruments !
More products available !
Hygrometer/Psychrometer
Thermometer
Anemometer
Sound Level Meter
Air Flow meter
Infrared Thermometer
K type Thermometer
K.J.T. type Thermometer
K.J.T.R.S.E. type Thermometer
pH Meter
Conductivity Meter
T.D.S. Meter
D.O. Meter
Indoor Air Quality Meter
Manometer
Tacho Meter
Lux / Light Meter
Moisture Meter
Data logger
Temp./RH transmitter
Wireless Transmitter ..........
2012.12 v.01
www.ponpe.com
