Pontec PondoMax Eco 1500 User manual

EN
Operating instructions
PondoMax Eco
1500/2500/3500/5000/8000/11000/14000/17000
Downloaded from www.watergardeningdirect.com

--
2
Pos: 4/ Pum p en/S chl amm sa ug er/ Pon doM ax/ Pon doM ax Eco/ ABB M on tag e @ 93\mod_1498807349395_0.docx@ 451883@ @ 1
A
PMX0002
Pos: 5/ P um p en /Sc hl amm sa ug er / Pon doM ax/ Po n doM ax Ec o/ AB B T eic h A bs t and get a uch t @ 93\mod_1498807022579_0.docx@ 451856@ @ 1
B
PMX0001
Pos: 6/ A ll e Produkte/Ueberschriften/Head2/H2PondoMaxEco 1500/2500@ 114\mod_1535122595187_0.docx@ 516580@ @ 1
PondoMax Eco 1500/2500
Pos: 7/ P um p en /Sc hl amm sa ug er / Pon doM ax/ Po n doM ax Ec o/ AB B La uf ei nh ei t r ei nig e n/ er se tz en Pond oM ax Eco 1500/ 25 0 0 @ 93\mod_1498807453817_0.docx@ 451910@ @ 1
C
PMX0007
Pos: 8/ A ll e Pr o d ukt e/D umm y_m o dul e/> = == = S ei t enw ec hs el === =< @ 0\m od_1125648978015_0.docx@ 1630@ @ 1
Downloaded from www.watergardeningdirect.com

--
3
Pos: 9 /A lle Pro dukte/ Ueber schr iften /Hea d 2/H2 Po ndoMa x Eco 35 00 @ 114\mod_1535122680484_0.docx@ 516607@ @ 1
PondoMax Eco 3500
Pos: 10 / P um pe n/ Sc hlam m s aug er/ P ond oM a x/ P ond oM ax Eco/A BB La uf ein hei t rei ni ge n/ we chs el n P o nd oM ax Eco 3 5 00 @ 114 \mod_1535124742741_0.docx @ 516688@ @ 1
D
PMX0013
Pos: 11 /A lle Pr odukte /Ueb erschr ifte n/He ad 2/H2 P ondoM ax Eco 5 000/80 00/11 000/1 4000/ 170 00 @ 114\mod_1535122762289_0.docx@ 516634@ @1
PondoMax Eco 5000/8000/11000/14000/17000
Pos: 12 /P um pe n/ Sc hlam ms aug er /P ond oM ax /P ond oM ax Eco/ ABB La ufei n hei t r ei nig e n/er s etz en Pon doM ax Eco 50 00-17000@ 93\mod_1498807605558_0.docx@ 451937@ @ 1
E
PMX0003
=== E nde der List e f ür Tex tm ar ke Inh alt 1 == =
Downloaded from www.watergardeningdirect.com

-EN -
9
Pos: 167 /A ll e Pr od ukt e/ L än d erk enn z eic h en/ In ter na tio nal ne u/ 02= == EN == = @ 46 \mod_1416240827988_0.docx@ 256482@ @ 1
-EN -
Pos: 168 /A ll e Pr od ukt e/ Ei nl ei t ung/ O ri g inal Gebr auc hs anl eit ung @ 16\mod_1265714347697_121.docx @ 101453@ @ 1
Translation of the original Operating Instructions
Pos: 16 9 /Alle Pr odukt e/Dum my_m odul e/==== = Abst and 6 pt === == @ 7\mod_1196627997106_0.docx@ 41651@ @ 1
Pos: 170 /A lle Pr oduk te/ D umm y _mo d ule/= == == WAR NUNG hidden ===== @ 127\mod_1557413234418_121.docx@ 575932@ @ 1
EN
WARNING
Pos: 171 /A lle Prod ukt e/W ar nhi nw eis e/N eu /WAR NU N G/WA R - W ar nwor t m it W ar ndr ei eck 3 mm @ 7 3\mod_1467192284435_121.docx@ 381565@ @ 1
WARNING
Pos: 172 /A lle Pr oduk te/ W arn hi nw eis e/N eu /3-mm-H inw ei s e/ ul_ 3mm _ Kin der ab 8 J a hre n @ 58\m od_1444133985981_121.docx@ 314427@ @ 1
•This unit can be used by children aged 8 and above and by per-
sons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they are supervised or have been
instructed on how to use the unit in a safe way and they understand
the hazards involved.
•Do not allow children to play with the unit.
•Only allow children to carry out cleaning and user maintenance un-
der supervision.
Pos: 173 /A lle Pr oduk te/ W arn hi nw eis e/N eu /3-mm-H inw eis e/ ul_ 3mm _Ger ät m us s ü ber FI mi t m ax . 30m A abges ich ert sei n @ 67\mod_1453997791078_121.docx@ 350951@ @ 1
•Ensure that the unit is fused for a rated fault current of max. 30 mA
by means of a fault current protection device.
Pos: 174 /A lle Pr oduk te/ W arn hi nw eis e/N eu /3-mm-H inw ei se/ ul _3m m_ Ger ät n ur a nsc hli eß en, w e nn D at e n üb erei ns tim m en @ 77\mod_1470127294883_121.docx@ 394338@ @ 1
•Only connect the unit if the electrical data of the unit and the power
supply correspond. The unit data is to be found on the unit type
plate, on the packaging or in this manual.
Pos: 175 /A lle Pr oduk te/ W arn hi nw eis e/N eu /3-mm-H inw eis e/ ul_ 3m m_ St rom schl ag g ef ahr! Vor G ri f f i ns W ass er G er ät e i m W ass er v omStromnetz trennen@101\mod_1515745518711_121.docx@ 480932@ @ 1
•Possible death or severe injury from electrocution! Before reaching
into the water, disconnect all electrical units in the water from the
mains.
Pos: 176 /A lle Pr oduk te/ W arn hi nw eis e/N eu /3-mm-Hinw ei s e/ ul_ 3mm _ Ger ät nur b etr eib en , w en n k ei ne Pers on en im W ass er @ 10 3\mod_1516964737039_121.docx@ 484822@ @ 1
•Only operate the unit if no persons are in the water.
Pos: 177 /A lle Pr oduk te/ W arn hi nw eis e/N eu /3-mm-H inw ei s e/ ul_ 3mm _ Ger ät nicht v er we n den, we nn L eit u ngen od er G e hä us e bes c hädi gt sin d @ 74\mod_1467618275382_121.docx@ 383417@ @ 1
•Do not use the unit if electrical cables or housings are damaged.
Pos: 178 /A lle Pr oduk te/ W arn hi nw eis e/N eu /3-mm-H inw ei s e/ ul_ 3mm _ Bes ch ädi g te A nsc hl ussl eit ung is t ni c ht er s etz b ar. Gerät ents or gen . @ 77\mod_1470127302834_121.docx@ 394419@ @ 1
•A damaged connection cable cannot be replaced. Dispose of the
unit.
Pos: 179 /A lle Pr oduk te/ D umm y _mo d ule/> == == Seit e nwe chs el ==== < @ 0\mod_1125648978015_0.docx@ 1631 @ @ 1
Downloaded from www.watergardeningdirect.com

-EN -
10
Pos: 18 0 /Alle Pr odukt e/Ue bersc hrift en/H ead 1/H 1 Sicher heits hinwei se @ 57\mod_1441381284781_121.docx@ 306113@ @ 1
Safety information
Pos: 18 1 /Alle Pr odukt e/Ue bersc hrift en/H ead 2/H 2 Vorsc hriftsm äßig e elektr isc he Instal lati on @ 7\mod_1204019051664_121.docx @ 44619@ @ 1
Correct electrical installation
Pos: 182 /A lle Pr oduk te/ Si c her heit /E l ektr isc h er Ansc hlus s /N eu /ul _Er ri ch ter be sti mm ung e n @ 54\mod_1437721596294_121.docx@ 296721@ @ 1
•Electrical installations must meet the national regulations and may only be carried out by a qualified electrician.
•A person is regarded as a qualified electrician if, due to his/her vocational education, knowledge and experience, he
or she is capable of and authorised to judge and carry out the work commissioned to him/her. This also includes the
recognition of possible hazards and the adherence to the pertinent regional and national standards, rules and regu-
lations.
Pos: 183 /A lle Pr oduk te/ Si c her heit /E l ektr isc h er Ansc hlus s /N eu /ul _B ei Fr ag en/ Pr obl em en an El ektr of ac hk ra ft wenden@ 54\mod_1437721665497_121.docx@ 296749@ @ 1
•For your own safety, please consult a qualified electrician.
Pos: 184 /A ll e Pr od ukt e/ Si c her hei t /El ektr is c h er A ns c hlus s /N eu /ul _V erä ng er ung sl ei tu ng en/ S trom ver t ei ler müss e n f ür auß en g e eig net s ein@ 57\mod_1441381377609_121.docx@ 306225@ @ 1
•Extension cables and power distributors (e.g. outlet strips) must be suitable for outdoor use (splash-proof).
Pos: 185 /A lle Pr oduk te/ Si c her heit /E l ektr isc h er Ansc hlus s /N eu /ul _S tec ker v erbi nd u ngen vor Feuc hti gk ei t s c hützen@ 74\mod_1467615634424_121.docx @ 383363@ @ 1
•Protect the plug connection from moisture.
Pos: 186 /A lle Pr oduk te/ Si c her heit /E l ektr isc h er Ansc hlus s /N eu /ul _G erä t n ur an v or schr if ts mäßi g er Steck d os e a nsc hl ie ße n @ 74\mod_1467615797269_121.docx@ 383390@ @ 1
•Only connect the unit to a correctly fitted socket.
Pos: 18 7 /Alle Pr odukt e/Dum my_m odul e/==== = Abst and 6 pt === == @ 7\mod_1196627997106_0.docx@ 41651@ @ 1
Pos: 18 8 /Alle Pr odukt e/Ue bersc hrift en/H ead 2/H 2 Sicher er Betr ieb @ 57 \mod_1441381472812_121.d ocx @ 30630 9 @ @ 1
Safe operation
Pos: 189 /A ll e Pr od ukt e/ Si c her hei t /Si c h erer Bet ri e b/ul _ La uf ein h ei t i m Ger ät mi t star kem Mag net fel d @ 57 \mod_1441381515499_121.docx@ 306365@ @ 1
•The impeller unit in the pump contains a magnet with a strong magnetic field that may affect the operation of pace-
makers or implantable cardioverter defibrillators (ICDs). Always keep magnets at least 0.2 m away from implanted
devices.
Pos: 190 /A ll e Pr od ukt e/ Si c her hei t /Si c h erer Bet ri e b/Ni c ht m ehr verw en d en /4. 1 2 SI C ERW Betri eb -S te ck dos e/N etz s tec ker trock e n @1 1\mod_1252350585923_121.docx@ 73043@ @ 1
•Keep the socket and power plug dry.
Pos: 191 /A ll e Pr od ukt e/ Si c her hei t /Si c h erer Bet ri e b/ul _ Lei t ung : N ic ht trag e n od er dar a n z ie h en @ 77\mod_1471510911493_121.docx@ 397246@ @ 1
•Never carry or pull the unit by the electrical cable.
Pos: 192 /A ll e Pr od ukt e/ Si c her hei t /Si c h erer Bet ri e b/ul _ Lei t ung : G es c h ützt ver leg e n @ 77\mod_1471511062014_121.docx@ 397273@ @ 1
•Route cables such that they are protected from damage and do not present a tripping hazard.
Pos: 193 /A lle Pr oduk te/ Si c her heit /S ic h erer Betr ie b/ul _N iem al s te ch ni sc he Ä nd eru ng e n am Ger ät v or ne hme n @ 73\mod_1467298393693_121.docx@ 382264@ @ 1
•Never carry out technical changes to the unit.
Pos: 19 4 /Alle Pr odukt e/Sic her heit/Si cher er Betr ieb/ul _Nur Ar beit en durc hführ en, die in G A besc hrieb en sind @ 73\m od_1467298411662_121.docx @ 382318 @ @ 1
•Only carry out work on the unit that is described in this manual. If problems cannot be overcome, please contact an
authorised customer service point or, if in doubt, the manufacturer.
Pos: 195 /A lle Pr oduk te/ Si c her heit /S ic h erer Betr ie b/ul _N ur O ri gi nal Ers atz teil e un d Z u behör ver w end en @ 7 3\mod_1467299941623_121.docx@ 382372@ @ 1
•Only use original spare parts and accessories for the unit.
Pos: 196 /A lle Pr oduk te/ D umm y _mo d ule/= == == Abs ta nd 12pt = == == @ 27\mod_1325898123757_0.docx@ 155185@ @ 1
Pos: 197 /A lle Pr oduk te/ U eber sc hr ift e n/H ea d 1/ H 1 H i nwei s e z u dieser Gebr auc hs anl ei t ung @ 10 \mod_1248768026340_121.docx@ 66253@ @ 1
Information about these operating instructions
Pos: 19 8 /Alle Pr odukt e/Einl eit ung/Hi nwei se zur A nleitung _oh ne Firm enang abe @ 19\m od_1277988964832_121.docx@ 118693@ @ 1
You made a good choice with the purchase of this product PondoMax Eco
1500/2500/3500/5000/8000/11000/14000/17000.
Prior to commissioning the unit, please read the instructions of use carefully and fully familiarise yourself with the unit.
Ensure that all work on and with this unit is only carried out in accordance with these instructions.
Adhere to the safety information for the correct and safe use of the unit.
Keep these instructions in a safe place! Please also hand over the instructions when passing the unit on to a new
owner.
Pos: 19 9 /Alle Pr odukt e/Dummy_module/===== Abstand3 pt===== @ 1 1\mod_1251901846864_0.docx@ 72826 @ @ 1
Pos: 20 0 /Alle Pr odukt e/Ue bersc hrift en/H ead 2/H 2W arnhi nweis e in dies er Anlei tung @ 1 02\mod_1516278445108_121.docx @ 483044@ @1
Warnings used in these instructions
Pos: 201 /A ll e Pr od ukt e/ Ei nl ei t ung/ W ar n hinw eis e G A 1 I nt ro @ 57 \mod_1441698283164_121.docx@ 306827@ @ 1
The warning information is categorised by signal words, which indicate the extent of the hazard.
Pos: 20 2 /Alle Pr odukt e/Dum my_m odul e/==== = Abst and 3 pt ===== @ 11\mod_1251901846864_0.docx@ 72826@ @ 1
Pos: 203 /A ll e Pr od ukt e/ Ei nl ei t ung/ W ar n hinw eis e G A 3 W ar n ung @ 57 \mod_1441698286242_121.docx @ 306855@ @1
WARNING
•Indicates a possibly hazardous situation.
•Non-observance may lead to death or serious injuries.
Pos: 20 4 /Alle Pr odukt e/Dum my_m odul e/==== = Abst and 6 pt === == @ 7\mod_1196627997106_0.docx@ 41651@ @ 1
Pos: 205 /A ll e Pr od ukt e/ Ei nl ei t ung/ W ar n hinw eis e G A 4 Vor si c ht @ 5 7\mod_1441698287508_121.docx@ 306883@ @ 1
CAUTION
•Indicates a possibly hazardous situation.
•Non-observance may lead to slight or minor injuries.
Pos: 20 6 /Alle Pr odukt e/Dum my_m odul e/==== = Abst and 6 pt === == @ 7\mod_1196627997106_0.docx@ 41651@ @ 1
Pos: 20 7 /Alle Pr od ukt e/ Ei nl eit ung /W ar n hinw eis e G A 6H i nw eis @ 8 0\m od_1474457643625_121.docx@ 406812@ @ 1
NOTE
Information for the purpose of clarification or for preventing possible damage to assets or to the environment.
Pos: 20 8 /Alle Pr odukt e/D um m y _mo dul e/= == == Abs tan d 6 pt = == == @ 7\mod_1196627997106_0.docx@ 41651@ @ 1
Pos: 20 9 /Alle Pr odukt e/Ue bersc hrift en/H ead 2/H 2 Verwei se in di eser Anl eitu ng @ 102\mod_1516278655269_121.docx@ 483071@ @ 1
Cross-references used in these instructions
Pos: 210 /A ll e Pr od ukt e/ Ei nl ei t ung/ 3. S ym bol l eg en d e: Verw eis auf Abbil du ng @ 1 14 \mod_1536067861639_121.docx@ 517431@ @ 1
A reference to a figure, e.g. figure A.
Pos: 211 /A ll e Pr od ukt e/ Ei nl ei t ung/ 4. S ym bol l eg en d e: Verw eis auf ander es Kapi tel @ 57 \mod_1441697668039_121.docx@ 306799@ @ 1
→Reference to another section.
Pos: 212 /A lle Pr oduk te/ D umm y _mo d ule/> == == Seit e nwe chs el ==== < @ 0\mod_1125648978015_0.docx@ 1631 @ @ 1
Downloaded from www.watergardeningdirect.com

-EN -
11
Pos: 21 3 /Alle Pr odukt e/Ue bersc hrift en/H ead 1/H 1 Bestim mung sgemä ße Verw endu ng @ 9\mod_1224861446432_121.docx @ 54763@ @1
Intended use
Pos: 21 4 /Alle Pr odukt e/B estimm ungsg emäße V erwe ndung /Neu /ad_D as in die ser Anl eitung besc hrie bene Pr odukt a usschl ießl ich wie fol gt verw ende n: @ 129 \mod_1561984075759_121.docx@ 581162@ @ 1
Only use the product described in this manual as follows:
Pos: 21 5 /Alle Pr odukt e/B estimm ungsg emäße V erwe ndung /Neu /ul_P umpe nv on Was ser in Spri ngbr unne n und Font äne n@ 1 7\mod_1267533825456_121.docx@ 109111@ @1
•For pumping normal pond water for water features and fountains.
Pos: 21 6 /Alle Pr odukt e/B estimm ungsg emäße V erwe ndung /Neu /ul_N ur für pri vate Zw ecke v erwend en @ 13 1\mod_1568792894421_121.docx@ 592960@ @ 1
•Use for private purposes only.
Pos: 217 /A ll e Pr od ukt e/ B est im mu ng sg em äße Verw e n dung /N eu /ul _B etr i eb unt er Ei nh alt ung der tech nis c h en D at e n @ 1 4\m od_1260375260762_121.docx@ 86864@ @ 1
•Operate in accordance with instructions.
Pos: 21 8 /Alle Pr odukt e/Dum my_m odul e/==== = Abst and 3 pt === == @ 11\m od_1251901846864_0.docx@ 72826 @ @ 1
Pos: 21 9 /Alle Pr odukt e/B esti mmu ngsg em äße V erwe ndu ng/N eu/ ad_E insc hr änku ng All gem ein (Für das Ger ät) @ 14\mod_1260374219037_121.docx@ 86810@ @ 1
The following restrictions apply to the unit:
Pos: 22 0 /Alle Pr odukt e/B estimm ungsg emäße V erwe ndung /Neu /ul_N icht in Sc hwimm teich e n v er we n den @ 14\m od_1260375530389_121.docx@ 86891@ @ 1
•Do not use in swimming ponds.
Pos: 221 /A lle Prod ukt e/ Best imm ung sg em äße V erw en du ng/N eu /ul _Ni em als m it ander en F l üssi gk eite n al s W as ser betr eib en @ 10 2\mod_1516359269581_121.docx@ 483725@ @ 1
•Never use the unit with fluids other than water.
Pos: 22 2 /Alle Pr odukt e/B estimm ungsg emäße V erwe ndung /Neu /ul_N iemal s ohne Wa sser b etreib en @ 14\mod_1260375960673_121.docx@ 86946@ @ 1
•Never run the unit without water.
Pos: 223 /A ll e Pr od ukt e/ B est im mu ng sg em äß e V er we ndu ng/ N eu/ul _N ich t i n V er bi ndu ng m it C hem ik al ie n @ 16\mod_1265628525047_121.docx@ 100616@ @ 1
•Do not use in conjunction with chemicals, foodstuff, easily flammable or explosive substances.
Pos: 224 /A lle Prod ukt e/ Bes tim mu ngs gem äß e V er we ndu ng/N eu /ul _G erät nic ht a n H a uswa sser l eitu ng en ansc hli eß en. @ 32\mod_1345554566452_121.docx@ 181310@ @ 1
•Do not connect to the domestic water supply.
Pos: 225 /A lle Pr oduk te/ D umm y _mo d ule/= == == Abs ta nd 12pt = == == @ 27\mod_1325898123757_0.docx@ 155185@ @ 1
Pos: 22 6 /Alle Pr odukt e/Ue bersc hrift en/H ead 1/H 1 Aufst ellen un d Anschl ieße n @ 65\mod_1450421830354_121.docx @ 342103@ @ 1
Installation and connection
Pos: 22 7 /Alle Pr odukt e/Ue bersc hrift en/H ead 3/H 3 Schla uch ansc hließ en @ 68\mod_1455640812134_121.docx@ 35 3503 @ @ 1
Connecting the hose
Pos: 228 /A lle Pr oduk te/ U eber sc hr ift e n/< So g eh en Si e v or :> >> >> >> >> >> >> > @ 4 4\mod_1399394612025_121.docx@ 240393@ @ 1
How to proceed:
Pos: 22 9 /Alle Pr odukt e/Bil dverv weis e (spr achneu tral!)/A @ 25\mod_1317992577723_0.docx@ 144196@ @ 1
A
Pos: 230 /A lle Pr oduk te/ M ont ag e un d D em on tag e /S chl auc ht üll en, Schl ä uc he, R ohr l ei tung e n/ ol_ Sc hla uc ht uell e au f A usg ang schr au be n @ 32 \mod_1345543910462_121.docx@ 181023@ @ 1
1. Screw the stepped hose adapter to the outlet.
Pos: 231 /A ll e Pr od ukt e/M o nt ag e un d D em on tag e/ Sc hl auc ht ül le n, Schl ä uc h e, R ohr l ei t unge n/ ol _ Fal ls erf ord er li ch, Schl auc ht u ell e k u er ze n @ 33\mod_1352905295591_121.docx@ 188027@ @ 1
2. Shorten the stepped hose adapter to the diameter of the hose used if necessary.
– This reduces pressure losses.
Pos: 232 /A lle Pr oduk te/ M ont ag e un d D em on tag e /S chl auc ht üll en, Schl ä uc he, R ohr l ei tung e n/ ol_ Sc hla uc h auf Sc hl auc ht uel le steck en , m it Schel l e si c her n @ 62\m od_1446388475640_121.docx@ 328077@ @ 1
3. Slip the hose clip over the hose, fit the hose onto the hose connector and secure with the hose clip.
Pos: 23 3 /Alle Pr odukt e/Dum my_m odul e/==== = Abst and 6 pt === == @ 7\mod_1196627997106_0.docx@ 41651@ @ 1
Pos: 23 4 /Alle Pr odukt e/Ue bersc hrift en/H ead 2/H 2 Gerät a ufst el l en @ 10 3\mod_1517498525579_121.docx@ 485402@ @ 1
Installing the unit
Pos: 235 /Alle Prod ukt e/Bi ldv ervw eise (spr ach neu tral!) /B @ 25 \mod_1317992303682_0.docx@ 144115@ @ 1
B
Pos: 236 /A ll e Pr od ukt e/ A ufs t ell en/ A uf st ell i nf os /ul _G er ä t ni em als i m Schwi mmt eich be treibe n @ 44\mod_1405946030257_121.docx@ 242686@ @ 1
•Never operate the pump in a swimming pond.
Pos: 237 /A ll e Pr od ukt e/ A ufs t ell en/ A uf st ell i nf os /ul _N e tza nsc hl uss muss mi n. 2 m vom Was ser entf er n t li eg en @ 8 8\mod_1485445088964_121.docx@ 430101@ @ 1
•Ensure that the connection to the power supply is at least 2 m from the pond.
Pos: 238 /A ll e Pr od ukt e/ A ufs t ell en/ ul _ G erät wa ager ech t und s ta n dsic h er auf f es t em U nt erg r un d a ufs t ell e n @ 23\mod_1310733702165_121.docx@ 136080@ @ 1
Place the unit horizontally on the ground ensuring its stable position.
Pos: 239 /A lle Pr oduk te/ D umm y _mo d ule/= == == Abs ta nd 12pt = == == @ 27\mod_1325898123757_0.docx@ 155185@ @ 1
Pos: 24 0 /Alle Pr odukt e/Ue bersc hrift en/H ead 1/H 1I nbetr iebn ahme @ 57 \mod_1439987101750_121.docx@ 303311@ @ 1
Commissioning/start-up
Pos: 24 1 /Alle Pr odukt e/Dum my_m odul e/==== = Abst and 3 pt === == @ 11\m od_1251901846864_0.docx@ 72826 @ @ 1
Pos: 242. 1 / Al le Pr oduk t e/W ar n hinw ei s e/N eu /H IN WE IS /H IN -W ar nw ort m it i-Sym bol @ 8 7\mod_1484582040551_121.docx@ 428396@ @ 1
NOTE
Pos: 242. 2 / Al le Pr oduk t e/W ar n hinw ei s e/N eu /H IN WE IS /A rt und F olg en /a f_ Ger ät wi r d z er st ör t, w e nn es mi t einem Dimm er b etr ie b en wird @ 102\mod_1516282962966_121.docx@ 483294@ @ 1
The unit will be destroyed if it is operated with a dimmer. It contains sensitive electrical components.
Pos: 242. 3 / All e Pr od ukt e/W ar n hinw ei s e/N eu /Sc h utzm aß na hm en/ ul _Ger ät nic ht a n ei n e di mm bar e St r omv ers or g ung ansc hli eß e n @ 102\mod_1516283084727_121.docx@ 483321@ @ 1
•Do not connect the unit to a dimmable power supply.
Pos: 24 3 /Alle Pr odukt e/Dum my_m odul e/==== = Abst and 3 pt === == @ 11\m od_1251901846864_0.docx@ 72826 @ @ 1
Pos:244/AlleProdukte/Inbetriebnahme/7.13Inbetriebnahme- Netzstecker st ecken/ziehen@ 63\mod_1448355967608_121.docx@ 334601@ @ 1
Switching on: Connect the unit to the mains. The unit switches on immediately.
Switching off: Disconnect the unit from the mains.
Pos: 245 /A lle Pr oduk te/ D umm y _mo d ule/= == == Abs ta nd 12pt = == == @ 27\mod_1325898123757_0.docx@ 155185@ @ 1
Pos: 24 6 /Alle Pr odukt e/Ue bersc hrift en/H ead 1/H 1 Störu ngsbes eitig ung @ 87 \mod_1484836523686_121.docx@ 429203@ @ 1
Remedy of faults
Pos: 247 /P um p e n/S c hl am ms a ug er/ P on d oM ax /P on d oM ax Eco/ tb _ St ör u ng sb es ei ti g ung @ 32 \mod_1345535144527_121.docx@ 180733@ @ 1
Malfunction
Cause
Remedy
Pump does not start
No mains voltage
Check mains voltage
Clean/check supply lines
Pump does not deliver
Filter housing clogged
Clean strainer casings
Reduce hose length to the necessary minimum,
do not use unnecessary connection parts
Insufficient delivered quantity
Filter housing clogged
Excessive loss in the supply hoses
Clean strainer casings
Reduce hose length to the necessary minimum,
do not use unnecessary connection parts
Pump switches off after a short running time
Excessively soiled water
Water temperature too high
Clean pump
Note maximum water temperature of +35 °C
Pos: 248 /A lle Pr oduk te/ D umm y _mo d ule/> == == Seit e nwe chs el ==== < @ 0\mod_1125648978015_0.docx@ 1631 @ @ 1
Downloaded from www.watergardeningdirect.com

-EN -
12
Pos: 249 /A lle Prod ukt e/U e bersc hr ift e n/H ead 1/H1 R ei nig ung und W ar tu ng @ 7\mod_1196625212761_121.docx@ 41469@ @ 1
Maintenance and cleaning
Pos: 25 0 /Alle Pr odukt e/Ue bersc hrift en/H ead 2/H 2 Gerät r einige n @ 102\mod_1516113982020_121.docx@ 482142@ @ 1
Cleaning the device
Pos: 25 1 /Alle Pr odukt e/Dum my_m odul e/==== = Abst and 3 pt === == @ 11\m od_1251901846864_0.docx@ 72826 @ @ 1
Pos: 252. 1 / Al le Pr oduk t e/W ar n hinw ei s e/> >> >> W arn hi nw ei s Lini e o be n<< < << @ 7 1\mod_1462791699897_121.docx@ 367011@ @ 1
Pos: 252. 2 / Al le Pr oduk t e/W ar n hinw ei s e/N eu /T I P/Ar t un d F ol g e n/ af_ Em pf ehl ung : @ 1 02 \mod_1516285094029_121.docx @ 483402@ @ 1
Recommendation regarding cleaning:
Pos: 252. 3 / Al le Pr oduk t e/W ar n hinw ei s e/N eu /Sc h utzm aßn a hme n/ ul _ Ger ät m i n d. 2-mal j ähr li ch r ei nig en @ 10 2\mod _1516285609391_121.docx@ 483456@ @ 1
•Clean the unit as required but at least twice a year.
Pos: 252. 4 / Al le Pr oduk t e/W ar n hinw ei s e/N eu /Sc h utzm aßn a hme n/ ul _ B eso n ders Lau fei nh ei t u nd Pum pe ng e häus e r ei nig e n @ 77\mod_1470321302408_121.docx@ 395142@ @ 1
•When cleaning the pump, pay particular attention to the cleaning of the impeller unit and pump housing.
Pos: 252. 5 / Al le Pr oduk t e/W ar n hinw ei s e/> >> >> W arn hi nw ei s Lini e u nt en< << < < @ 71\mod_1462792106537_121.docx@ 367038@ @ 1
Pos: 253 /A lle Pr oduk te/ D umm y _mo d ule/=====Abstand 3 pt===== @ 11\mod_1251901846864_0.docx@ 72826 @ @ 1
Pos: 254 /A ll e Pr od ukt e/R ei ni g ung/ W ar tu ng /R+ W M i t tel/ ul _ B ei n ac hl as se n der Leis t ung Ger ät m i t W as s er und B ür st e r ei ni ge n @ 32\mod_1345554978557_121.docx@ 181337@ @ 1
•In the event of the filter housing capacity reducing, clean the unit under running water using a brush.
Pos: 255 /A ll e Pr od ukt e/R ei ni g ung/ W ar tu ng /R+ W M i t tel/ ul _ K ein e R ei nig u ng sm itt el oder chem is c he Lösu ng e n v er w en de n @ 64 \mod_1449238101090_121.docx@ 337331@ @ 1
•Do not not use cleaning agents or chemical solutions.
Pos: 256 /A ll e Pr od ukt e/R ei ni g ung/ W ar tu ng /R+ W M i t tel/ ul _ Em pf. Rei ni gung s mi t tel bei hart näc ki g er Verk alk ung : @ 44 \mod_1407159944343_121.docx @ 243379@ @1
•Recommended cleaning agent for removing stubborn limescale deposits:
Pos: 257 /A ll e Pr od ukt e/R ei ni g ung/ W ar tu ng /R+ W M i t tel/ v l_ Es sig - u nd c hl orfr ei en H aus h altsr ei nig er @ 44\m od_1408108796310_121.docx@ 244030@ @ 1
– Vinegar- and chlorine-free household cleaning agent.
Pos: 258 /A lle Prod ukt e/R ei ni gung /W art ung /R+W Mi ttel/ ul_N ach dem R einig en alle T eile mi tkl arem W asser g ründl ich ab spüle n @ 45\mod_1409733590605_121.docx @ 246183@ @ 1
•After cleaning, thoroughly rinse all parts in clean water.
Pos: 25 9 /Alle Pr odukt e/Dum my_m odul e/==== = Abst and 6 pt === == @ 7\mod_1196627997106_0.docx@ 41651@ @ 1
Pos: 26 0 /Alle Pr odukt e/Ue bersc hrift en/H ead 2/H 2 PondoM ax Ec o 1500/2 500 @ 114 \mod_1535122595187_0.docx @ 516592 @ @ 1
PondoMax Eco 1500/2500
Pos: 261 /Alle Prod ukt e/R eini gung/ War tung /Pum pe n (i nkl. Pump eng ehä use)/ ad_ Lau fei nh ei t r ei nig e n/ ers etz en @ 1 14 \mod_1535122968011_121.docx @ 516673@ @1
Cleaning/replacing the impeller unit
Pos: 26 2 /Alle Pr odukt e/Dum my_m odul e/==== = Abst and 3 pt === == @ 11\m od_1251901846864_0.docx@ 72826 @ @ 1
Pos: 26 3 /Alle Pr odukt e/Ue berschriften/<Sog ehen Sie vor:>>>>>>>>>>>>>> @ 44\mod_1399394612025_121.docx@ 240393@ @ 1
How to proceed:
Pos: 264 /Alle Prod ukt e/Bi ldv ervw eise (spr ach neu tral!) /C @ 24\m od_1314277815262_0.docx @ 138214 @ @ 1
C
Pos: 265 /A ll e Pr od ukt e/M o nt ag e un d D em on tag e/ Sc hr au be n/ ol _Sc hra u be n en tf er n en @ 3 2\mod_1345550761227_121.docx@ 181153@ @ 1
1. Remove screws.
Pos: 266 /A lle Prod ukt e/M o ntag e un d D em on tage /S chr aube n/- Sc hrau ben die nen als Tr ansp ortsic heru ng @ 32\mod_1345550985267_121.docx @ 1811 79 @ @ 1
– The screws are used as transport protection and not required for operation.
Pos: 267 /P um p e n/S chl am m sa ug er/ Al l e P um p en/ Sc hl am ms aug er /ol _Ras t hak en b et a eti g en und F il t er ob er sc hal e a uf kl app e n @ 32\mod_1345551055217_121.docx@ 181205@ @ 1
2. Actuate the engagement hook and fold up the strainer top casing.
Pos: 268 /P um p e n/S c hl am ms a ug er/ A ll e P um p e n/ Sc hl am ms aug er /ol _P um p e h er a usn e hm en @ 32 \mod_1345551169165_121.docx@ 181231@ @ 1
3. Remove pump.
Pos: 269 /A ll e Pr od ukt e/R ei ni g ung/ W ar tu ng / Pum pe n (i nkl . P umpeng eh äuse) /ol _P umpe nge haeu se: b) abdr e hen, Lauf einh eit hera uszi ehe n @ 3 2\mod_1345556405059_121.docx@ 181417@ @ 1
4. Unscrew the pump housing and pull out the impeller unit.
Pos: 270 /A ll e Pr od ukt e/R ei ni g ung/ W ar tu ng /R+ W M i t tel/ v l T eil e m it Wass er und Buer st e r ei nig e n, besc h ädig t e T ei le erset z e n @ 32\mod_1345557239441_121.docx@ 181443@ @1
– Clean all components under running water using a soft brush, replace damage parts.
Pos: 271 /A ll e Pr od ukt e/R ei ni g ung/ W ar tu ng / ol_ Ger ae t i n umg eke hr t er R ei h en folgezusammenbauen@ 32\mod_1345557416891_121.docx @ 181469@ @ 1
5. Reassemble the unit in the reverse order.
Pos: 272 /Alle Prod ukt e/R eini gung/ War tung /Pum pe n (i nkl. Pump eng ehä use)/- L ei t ung Pump e i n O eff n ung Filt er u nt ers c hal e l eg en @ 32\mod_1345557788129_121.docx @ 18 1521 @ @ 1
– Place the pump cable into the cable opening of the bottom strainer casing such that the cable will not be crushed
when closing the filter housing.
Pos: 27 3 /Alle Pr odukt e/Dum my_m odul e/==== = Abst and 6 pt === == @ 7\mod_1196627997106_0.doc x @ 41651 @ @ 1
Pos: 27 4 /Alle Pr odukt e/Ue bersc hrift en/H ead 2/H 2 PondoM ax Ec o 3500 @ 114 \mod_1535122680484_0.docx@ 516619@ @ 1
PondoMax Eco 3500
Pos: 275 /Alle Prod ukt e/R eini gung/ War tung /Pum pe n (i nkl. Pump eng ehä use)/ ad_ Lau feinh eit r eini ge n/ers etz en @ 114 \mod_1535122968011_121.docx@ 516673@ @ 1
Cleaning/replacing the impeller unit
Pos: 27 6 /Alle Pr odukt e/Dum my_m odul e/==== = Abst and 3 pt === == @ 11\m od_1251901846864_0.docx@ 72826 @ @ 1
Pos: 277 /A lle Pr oduk te/ U eber sc hr ift e n/< So g eh en Si e v or :> >>>>>>>>>>>>> @ 4 4\mod_1399394612025_121.docx@ 240393@ @ 1
How to proceed:
Pos: 278 /Alle Prod ukt e/Bi ldv ervw eise (spr ach neu tral!) /D @ 25\m od_1317992446522_0.docx @ 144142 @ @ 1
D
Pos: 27 9 /Alle Pr odukt e/Mo ntag e und Dem ontage /Schr aube n/ol _Schra uben en tfern en @ 32\mod_1345550761227_121.docx@ 181153@ @ 1
1. Remove screws.
Pos: 280 /A lle Prod ukt e/M o ntag e un d D em on tage /S chr aube n/- Sc hrau ben die nen als Tr ansp ortsic heru ng @ 32\mod_1345550985267_121.docx @ 181179@ @1
– The screws are used as transport protection and not required for operation.
Pos: 281 /P um p e n/S chl am m sa ug er/ Al l e P um p en/ Sc hl am ms aug er /ol _Ras t hak en b et a eti g en und F il t er ob er sc hal e a uf kl app e n @ 32\mod_1345551055217_121.docx@ 181205@ @ 1
2. Actuate the engagement hook and fold up the strainer top casing.
Pos: 282 /P um p e n/S c hl am ms a ug er/ A ll e P um p e n/ Sc hl am ms aug er /ol _P um p e h er a usn e hm en @ 32 \mod_1345551169165_121.docx@ 181231@ @ 1
3. Remove pump.
Pos: 283 /Alle Prod ukt e/R eini gung/ War tung /Pum pe n (i nkl. Pump eng ehä use)/ ol _Pump eng ehä use cc w dr eh en un d en tfer nen ( Baj onet tver schl uss) @ 11 4\mod_1535112934344_121.docx@ 516556@ @ 1
4. Unscrew the pump housing by turning counter-clockwise and remove (bayonet closing mechanism).
Pos: 284 /A ll e Pr od ukt e/R ei ni g ung/ W ar tu ng /R+ W M i t tel/ v l T eil e m it Wass er und Buer st e r ei nig e n, besc h ädig t e T ei le erset z e n @ 32\mod_1345557239441_121.docx@ 181443@ @1
– Clean all components under running water using a soft brush, replace damage parts.
Pos: 28 5 /Alle Pr odukt e/Rei nig ung/W artung /ol_ Gerae ti n umgekehrterReihenfolgezusammenbauen@ 32\mod_1345557416891_121.docx @ 181469@ @ 1
5. Reassemble the unit in the reverse order.
Pos: 286 /Alle Prod ukt e/R eini gung/ War tung /Pum pe n (i nkl. Pump eng ehä use)/- L ei t ung Pump e i n O eff n ung Filt er u nt ers c hal e l eg en @ 32\mod_1345557788129_121.docx@ 181521@ @ 1
– Place the pump cable into the cable opening of the bottom strainer casing such that the cable will not be crushed
when closing the filter housing.
Pos: 28 7 /Alle Pr odukt e/Dum my_m odul e/==== = Abst and 6 pt === == @ 7\mod_1196627997106_0.docx@ 41651@ @ 1
Pos: 28 8 /Alle Pr odukt e/Ue bersc hrift en/H ead 2/H 2 PondoM ax Ec o 5000/8 000/1 1000/ 14000 /17 000 @ 114\mod_1535122762289_0.docx@ 516646@ @ 1
PondoMax Eco 5000/8000/11000/14000/17000
Pos: 289 /A lle Prod ukt e/R ei ni gung /W art ung /Pum pe n (i nkl. Pump eng ehä use)/ ad_ Lau feinh eit r eini gen/ ers etz en @ 114\mod_1535122968011_121.docx@ 516673@ @ 1
Cleaning/replacing the impeller unit
Pos: 29 0 /Alle Pr odukt e/Dum my_m odul e/==== = Abst and 3 pt === == @ 11\m od_1251901846864_0.docx@ 72826 @ @ 1
Pos: 291 /A lle Pr oduk te/ U eber sc hr ift e n/< So g eh en Si e v or :> >> >> >> >> >> >> > @ 4 4\mod_1399394612025_121.docx@ 240393@ @ 1
How to proceed:
Pos: 292 /Alle Prod ukt e/Bi ldv ervw eise (spr ach neu tral!) /E @ 26 \mod_1320397120645_0.docx@ 14 6421 @ @ 1
E
Pos: 29 3 /Alle Pr odukt e/Mo ntag e und Dem ontage /Schr aube n/ol _Schra uben en tfern en @ 32\mod_1345550761227_121.docx@ 181153@ @ 1
1. Remove screws.
Pos: 294 /A lle Prod ukt e/M o ntag e un d D em on tage /S chr aube n/- Sc hr au be n di en en als T ra nsp orts ic h erung@ 32\mod_1345550985267_121.docx@ 181179@ @ 1
– The screws are used as transport protection and not required for operation.
Pos: 295 /P um p e n/S chl am m sa ug er/ Al l e P um p en/ Sc hl am ms aug er /ol _Ras t hak en b et a eti g en und F il t er ob er sc hal e a uf kl app e n @ 32\mod_1345551055217_121.docx@ 181205@ @ 1
2. Actuate the engagement hook and fold up the strainer top casing.
Pos: 296 /P um p e n/S c hl am ms a ug er/ A ll e P um p e n/ Sc hl am ms aug er /ol _P um p e h er a usn e hm en @ 32 \mod_1345551169165_121.docx@ 181231@ @ 1
3. Remove pump.
Pos: 29 7 /Alle Pr odukt e/Mo ntag e und Dem ontage /Schr aube n/ol _Schra uben en tfern en @ 32\mod_1345550761227_121.docx@ 181153@ @ 1
4. Remove screws.
Pos: 298 /Alle Prod ukt e/R eini gung/ War tung /Pum pe n (i nkl. Pump eng ehä use)/ ol _Pump eng eha euse : a) mit H alter ing , Dic ht ung un d L aufei nh eit a bnehm en @ 32\mod_1345557559505_121.docx@ 181495@ @ 1
5. Remove the pump housing including its holding ring, sealing and impeller unit.
Pos: 299 /A ll e Pr od ukt e/R ei ni g ung/ W ar tu ng /R+ W M i t tel/ v l T eil e m it Wass er und Buer st e r ei nig e n, besc h ädig t e T ei le erset z e n @ 32\mod_1345557239441_121.docx@ 181443@ @1
– Clean all components under running water using a soft brush, replace damage parts.
Pos: 30 0 /Alle Pr odukt e/Rei nig ung/W artung /ol_ Gerae ti n umgek ehrt er Reih enfolg e zusam menb auen @ 3 2\mod_1345557416891_121.docx @ 18 1469 @ @ 1
6. Reassemble the unit in the reverse order.
Pos: 301 /Alle Prod ukt e/R eini gung/ War tung /Pum pe n (i nkl. Pump eng ehä use)/- L ei t ung Pump e i n O eff n ung Filt er u nt ers c hal e l eg en @ 32\mod_1345557788129_121.docx@ 181521@ @ 1
– Place the pump cable into the cable opening of the bottom strainer casing such that the cable will not be crushed
when closing the filter housing.
Pos: 302 /A lle Pr oduk te/ D umm y _mo d ule/> == == Seit e nwe chs el ==== < @ 0\mod_1125648978015_0.docx@ 1631 @ @ 1
Downloaded from www.watergardeningdirect.com

-EN -
13
Pos: 30 3 /Alle Pr odukt e/Ue bersc hrift en/H ead 1/H 1 Lager n /Ü berwi nter n @ 71\mod_1462832479137_121.docx@ 368104@ @ 1
Storage/overwintering
Pos: 304 /A ll e Pr od ukt e/ L ag ern /Ü b erw in ter n/ LA G - N icht fros tsich er, dei nstalli eren . So lager n Sie das Ger ät: @ 49\mod_1419949586401_121.docx@ 273296@ @1
The unit is not frost-proof and has to be removed and put into storage if minus temperatures are expected.
How to correctly store the unit:
Pos: 305 /A ll e Pr od ukt e/ L ag ern /Ü b erw in ter n/ LA G - ul _Ger ät r ei nig e n, b esc hä dig t e T ei le erse tz en @ 48\mod_1418899793966_121.docx @ 272197@ @ 1
•Thoroughly clean the unit, check it for damage and replace any damaged parts.
Pos: 306 /A ll e Pr od ukt e/ L ag ern /Ü b erw in ter n/ LA G - ul _Ans c hl üss e v or Feuc hti gk ei t/ Ver s chm utz ung sch üt ze n @ 50\mod_1423237508065_121.docx@ 27 8394 @ @ 1
•Protect electrical connections from moisture and dirt.
Pos: 307 /A ll e Pr od ukt e/ L ag ern /Ü b erw in ter n/ LA G - ul _Pum p e g et auc ht und f ros tfr ei l ag er n @ 45\mod_1411630567729_121.docx@ 251073@ @ 1
•Store the pump submerged and in a frost-free environment.
Pos: 308 /A ll e Pr od ukt e/ L ag ern /Ü b erw in ter n/ LA G - ul _Of fe ne Steckv er bi ndu ng en sc h ütz en @ 7 1\mod_1462465773253_121.docx@ 366403@ @ 1
•Protect open plug connections from moisture and dirt.
Pos: 309 /A lle Pr oduk te/ D umm y _mo d ule/= == == Abs ta nd 12pt = ==== @ 27\mod_1325898123757_0.docx@ 155185@ @ 1
Pos: 310 /A lle Prod ukt e/U e bersc hr ift e n/H ead 1/H1 Versc hl eiß teil e @ 8\mod_1223247075102_121.docx@ 53883@ @ 1
Wear parts
Pos: 311 /A ll e Pr od ukt e/ V er schl eiß t eil e/ ul _L au fei nh eit @ 3 4\mod_1354722941270_121.docx @ 19 1893 @ @ 1
•Impeller unit
Pos: 312 /A lle Pr oduk te/ D umm y _mo d ule/= == == Abs ta nd 12pt = == == @ 27\mod_1325898123757_0.docx@ 155185@ @ 1
Pos: 313 /A ll e Pr od ukt e/R e par at ur /1 1. Rep arat ur nich t m ög li ch - Ger ät ents or gen @ 2 0\mod_1282309239229_121.docx@ 121147@ @ 1
Repair
A damaged unit cannot be repaired and must be put out of operation. Dispose of the unit in accordance with the
regulations.
Pos: 314 /A lle Pr oduk te/ D umm y _mo d ule/= == == Abs ta nd 12pt = == == @ 27\mod_1325898123757_0.docx@ 155185@ @ 1
Pos: 31 5 /Alle Pr odukt e/Ue bersc hrift en/H ead 1/H 1 Entsorg ung @ 7 \mod_1196625583904_121.docx@ 41547@ @ 1
Disposal
Pos: 316 /A ll e Pr od ukt e/ W ar n hi nw ei s e/N eu /HI NW E IS /H IN W E IS -K ein Hausmüll, mit W EEE @ 71\mod_1462830921981_121.docx@ 368076@ @ 1
NOTE
Do not dispose of this unit with domestic waste.
•Render the unit unusable beforehand by cutting the cables and dispose of the unit via the return system
provided for this purpose.
Pos: 317 /A lle Pr oduk te/ D umm y _mo d ule/= == == Abs ta nd 12pt ===== @ 27\mod_1325898123757_0.docx@ 155185@ @ 1
Pos: 318 /A ll e Pr od ukt e/ G ar a ntie /G ar a nti e 3J ahr e Plus V er sc hlei ßt ei l @ 11 7\mod_1541672965101_121.docx@ 525879@ @ 1
Guarantee conditions
PfG grants a 3 year guarantee from the date of sale on proven material and manufacturing faults. Wear parts such as
bulbs etc. are exempted from the guarantee. Prerequisite for our guarantee is the presentation of the purchase receipt.
Our guarantee will become null and void if the unit is misused, electrically or mechanically damaged by inappropriate
use and improper repair by non-authorised workshops. Repairs are reserved for workshops authorised by PfG or by
PfG itself. In the case of warranty claims, please return the defective unit or part freight paid to PfG together with a
description of the fault and the purchase receipt. PfG reserves the right to invoice repair costs. PfG is not liable for
transport damage. Any damage must be claimed against the carrier. Further claims of whatever type, especially con-
sequential damage, are excluded. This guarantee does not affect the final customer’s claims against the dealer.
Pos: 319 /A lle Pr oduk te/ D umm y _mo d ule/> == == Seit e nwe chs el ==== < @ 0\mod_1125648978015_0.docx@ 1630 @ @ 1
Downloaded from www.watergardeningdirect.com

110
EN
Type
Mains voltage
Power consumption
Max. flow rate
Max. head height
Immersion depth
Water temperature
PondoMax
Eco
1500
AC 220 … 240 V, 50 Hz
25 W ≤1500 l/h ≤1.9 m ≤2 m
+4 … +35 ºC
2500 40 W ≤2500 l/h ≤2.2 m ≤4 m
3500 40 W ≤3500 l/h ≤2.4 m ≤4 m
5000 60 W ≤5000 l/h ≤2.6 m ≤4 m
8000 70 W ≤8000 l/h ≤2.8 m ≤4 m
11000 95 W ≤10000 l/h ≤3.0 m ≤4 m
14000 140 W ≤13400 l/h ≤3.2 m ≤4 m
17000 180 W ≤17000 l/h ≤3.5 m ≤4 m
EN Type Weight Connection to the pump inlet Connection to the pump outlet Cable length
PondoMax
Eco
1500 1.9 kg 25 mm G1 10 m
2500 2.2 kg 25 mm G1½ 10 m
3500 3.1 kg G1 G1½ 10 m
5000 3.4 kg G1½ G1½ 10 m
8000 4.4 kg G1½ G1½ 10 m
11000 4.4 kg G1½ G1½ 10 m
14000 5.4 kg G1½ G1½ 10 m
17000 5.4 kg G1½ G1½ 10 m
Pos: 3229 / Al le Pro duk t e/D um m y_m o dul e/> == == Seit enw ec hsel ====< @ 0\mod_1125648978015_0.docx@ 1630 @ @ 1
Pos: 3230 / Pum p en /Sc hl amm s a ug er/ Po n doM ax / Po n doM ax Eco/t b _Sy m b ol e a uf dem G er ät @ 11 3\mod_1534776151423_0.docx@ 515907@ @ 1
PondoMax Eco 1500/2500
PondoMax Eco
3500/5000/8000/
11000/14000/17000
EN Dust tight. Submersible to 2 m
depth.
Dust tight. Submersible to 4 m
depth.
Remove the unit at tempera-
tures below zero (centigrade).
Possible hazard for persons
wearing pace makers!
Protect from direct sun radiation. Do not dispose of together with
household waste!
Read the operating
instructions
Downloaded from www.watergardeningdirect.com

113
Pos: 3232 / Pum p en /Sc hl amm s a ug er/ Po n doM ax / Po n doM ax Eco/ AB B Ersat zt ei le Pon doM ax Eco 150 0 @ 11 4\mod_1535125597134_0.docx@ 516742@ @ 1
PMX0006
Pos: 3233 / Pum p en /Sc hlam ms a uger / Po n doM ax / Po ndoM ax Eco/ AB B Ersat zt ei le Pon doM ax Eco 2500/ 35 00 @ 1 14\mod_1535125722372_0.docx @ 516769@ @ 1
Downloaded from www.watergardeningdirect.com

114
PMX0014
Pos: 3234 / Pum p en /Sc hl amm s a ug er/ Po n doM ax / Po n doM ax Eco/ AB B Ersat zt ei le Pon doM ax Eco 500 0-17000@ 114\mod_1535125047309_0.docx @ 516715@ @ 1
Downloaded from www.watergardeningdirect.com

115
PMX0005
=== Ende der Liste für Textmarke Inhalt2 ===
Downloaded from www.watergardeningdirect.com

71302/11-19
Downloaded from www.watergardeningdirect.com
