INSTALLATION AND USER MANUAL
for your heat pump
www.poolstar.fr
Models 70 / 90 / 120 / 150 / 200
SILVERLINE FI

2
This heat pump contains a ammable refrigerant R32.
Any intervention on the refrigerant circuit is prohibited without a valid authorization.
Before working on the refrigerant circuit, the following precautions are necessary for safe work.
1. Work procedure
The work must be carried out according to a controlled procedure, in order to minimize the risk of
presence of ammable gases or vapors during the execution of the works.
2. General work area
All persons in the area must be informed of the nature of the work in progress. Avoid working in a conned area. The
area around the work area should be divided, secured and special attention should be paid to nearby sources of ame
or heat.
3. Verication of the presence of refrigerant
The area should be checked with a suitable refrigerant detector before and during work to ensure that there is no
potentially ammable gas. Make sure that the leak detection equipment used is suitable for ammable refrigerants, ie
it does not produce sparks, is properly sealed or has internal safety.
4. Presence of re extinguisher
If hot work is to be performed on the refrigeration equipment or any associated part, appropriate re extinguishing
equipment must be available. Install a dry powder or CO2 re extinguisher near the work area.
5. No source of ame, heat or spark
It is totally forbidden to use a source of heat, ame or spark in the direct vicinity of one or more parts or pipes contai-
ning or having contained a ammable refrigerant. All sources of ignition, including smoking, must be suciently far
from the place of installation, repair, removal and disposal, during which time a ammable refrigerant may be released
into the surrounding area. Before starting work, the environment of the equipment should be checked to ensure that
there is no risk of ammability. «No smoking» signs must be posted.
6. Ventilated area
Make sure the area is in the open air or is properly ventilated before working on the system or performing hot work.
Some ventilation must be maintained during the duration of the work.
7. Controls of refrigeration equipment
When electrical components are replaced, they must be suitable for the intended purpose and the appropriate speci-
cations. Only the parts of the manufacturer can be used. If in doubt, consult the technical service of the manufacturer.
The following controls should be applied to installations using ammable refrigerants:
- The size of the load is in accordance with the size of the room in which the rooms containing the refrigerant are
installed;
- Ventilation and air vents work properly and are not obstructed;
- If an indirect refrigeration circuit is used, the secondary circuit must also be checked.
- The marking on the equipment remains visible and legible. Illegible marks and signs must be corrected;
- Refrigeration pipes or components are installed in a position where they are unlikely to be exposed to a substance
that could corrode components containing refrigerant
8. Verication of electrical appliances
Repair and maintenance of electrical components must include initial safety checks and component inspection proce-
dures. If there is a defect that could compromise safety, no power supply should be connected to the circuit until the
problem is resolved.
Initial security checks must include:
• That the capacitors are discharged: this must be done in a safe way to avoid the possibility of sparks;
• No electrical components or wiring are exposed during loading, recovery or purging of the refrigerant gas system;
• There is continuity of grounding.
Warning

3
Dear Customer,
Thank you for your purchase and for your condence in our products.
These are the result of many years of research in the eld of design and production
of heat pumps for swimming pools. Our aim is to provide you with an exceptional high
performance quality product.
We have produced this manual with the utmost care so that you get maximum benet
from your Poolex heat pump.
Thank you

4
PLEASE READ CAREFULLY.
These installation instructions are an integral part of the product.
They must be given to the installer and retained by the user.
If the manual is lost, please consult the website:
www.poolex.fr
The instructions and recommendations contained in this manual should be read carefully and understood
since they provide valuable information concerning the heat pump’s safe handling and operation. Keep this
manual in an accessible place for easy future reference.
Installation must be carried out by a qualied professional person in accordance with current regu-
lations and the manufacturer’s instructions. An installation error may cause physical injury to persons or
animals as well as mechanical damage for which the manufacturer can under no circumstances be held
responsible.
After unpacking the heat pump, please check the contents in order to
report any damage.
Prior to connecting the heat pump, ensure that the information provided in this manual is compatible with
the actual installation conditions and does not exceed the maximum limits authorised for this particular
product.
In the event of a defect and/or malfunction of the heat pump, the electricity supply must be discon-
nected and no attempt made to repair the fault.
Repairs must be undertaken only by an authorised technical service organisation using original replace-
ment parts. Failure to comply with the above-mentioned clauses may have an adverse e󰀨ect on the heat
pump’s safe operation.
To guarantee the heat pump’s e󰀩ciency and satisfactory operation, it is important to ensure its regular
maintenance in accordance with the instructions provided.
If the heat pump is sold or transferred, always make sure that all technical documentation is transmitted
with the equipment to the new owner.
This heat pump is designed solely for heating a swimming pool. Any other use must be considered as being
inappropriate, incorrect or even hazardous.
! !
Any contractual or non-contractual liability of the manufacturer/distributor shall be deemed null and void for
damage caused by installation or operational errors, or due to non-compliance with the instructions provid-
ed in this manual or with current installation norms applicable to the equipment covered by this document.

5
1. General ............................................................................................................................................................................................ 6
1.1 General Terms of Delivery ......................................................................................................................................................... 6
1.2 Safety instructions....................................................................................................................................................................... 6
1.3 Water treatment .......................................................................................................................................................................... 7
2. Description...................................................................................................................................................................................... 8
2.1 Package contents ...................................................................................................................................................................... 8
2.2 General characteristics .............................................................................................................................................................. 8
2.3 Technical specications .............................................................................................................................................................. 9
2.4 Unit dimensions ....................................................................................................................................................................... 10
2.5 Exploded view............................................................................................................................................................................11
3. Installation..................................................................................................................................................................................... 12
3.1 Pre-requirements ..................................................................................................................................................................... 12
3.2 Location ................................................................................................................................................................................... 12
3.3 Installation layout ..................................................................................................................................................................... 13
3.4 Connecting the condensation draining kit ................................................................................................................................ 13
3.5 Installing the unit on noise-damping supports .......................................................................................................................... 13
3.6 Hydraulic connection ................................................................................................................................................................ 14
3.7 Electrical installation ................................................................................................................................................................. 16
3.8 Electrical connection ................................................................................................................................................................ 17
4. Use ................................................................................................................................................................................................ 18
4.1 Wired remote control ................................................................................................................................................................ 18
4.2 Remote control display ............................................................................................................................................................ 19
4.3 Mode setting ............................................................................................................................................................................ 19
4.4 Temperature setting ................................................................................................................................................................. 19
4.5 Parameter checking and setting ............................................................................................................................................... 19
4.6 Current time setting................................................................................................................................................................... 20
4.7 Timer on/o󰀨 setting ................................................................................................................................................................... 21
4.8 Key lock and unlock.................................................................................................................................................................. 21
4.9 Status values ........................................................................................................................................................................... 22
5. Operation ...................................................................................................................................................................................... 24
5.1 Operation .................................................................................................................................................................................. 24
5.2 Servo-control of circulating pump ............................................................................................................................................. 24
5.3 Using the pressure gauge ........................................................................................................................................................ 25
5.4 Antifreeze protection ................................................................................................................................................................ 25
6. Maintenance and servicing ......................................................................................................................................................... 26
6.1 Maintenance and servicing ....................................................................................................................................................... 26
6.2 Winter storage .......................................................................................................................................................................... 26
7. Repairs .......................................................................................................................................................................................... 27
7.1 Faults and anomalies ............................................................................................................................................................... 27
7.2 List of faults............................................................................................................................................................................... 28
7.3 Errors ....................................................................................................................................................................................... 29
7.4 Wiring diagrams........................................................................................................................................................................ 29
8. Recycling ...................................................................................................................................................................................... 30
8.1 Recycling the heat pump .......................................................................................................................................................... 30
9. Warranty ........................................................................................................................................................................................ 31
9.1 General warranty conditions ..................................................................................................................................................... 31
Contents

6
All equipment, even if shipped ‘free of carriage and packing’, is dispatched at the consignee’s own risk
The person responsible for receiving the equipment must carry out a visual inspection to identify any dam-
age to the heat pump during transport (refrigerant system, body panels, electrical control box, frame). He/
she must note down on the carrier’s delivery note any remarks concerning damage caused during transport
and conrm them to the carrier by registered letter within 48 hours.
The equipment must always be stored and transported vertically on a pallet and in its original packaging. If
it is stored or transported horizontally, wait at least 24 hours before switching it on.
During installation and servicing
Only a qualied person may undertake installation, start-up, servicing and repairs, in compliance with
current standards.
Before operating or undertaking any work on the equipment (installation, commissioning, usage, servicing),
the person responsible must be aware of all the instructions in the heat pump’s installation manual as well
as the technical specications.
Under no circumstances install the equipment close to a source of heat, combustible materials or a build-
ing’s air intake.
If installation is not in a location with restricted access, a heat pump protective grille must be tted.
To avoid severe burns, do not walk on pipework during installation, repairs or maintenance.
To avoid severe burns, prior to any work on the refrigerant system, turn o󰀨 the heat pump and wait several
minutes before placing temperature and pressure sensors.
Check the refrigerant level when servicing the heat pump.
Check that the high and low pressure switches are correctly connected to the refrigerant system and that
they turn o󰀨 the electrical circuit if tripped during the equipment’s annual leakage inspection.
Check that there is no trace of corrosion or oil stains around the refrigerant components.
1.2 Safety instructions
1.1 General Terms of Delivery
WARNING: Please read carefully the safety instructions before using the equipment.
The following instructions are essential for safety so please strictly comply with them.
1. General

7
1.3 Water treatment
Poolex heat pumps for swimming pools can be used with all types of water treatment systems.
Nevertheless, it is essential that the treatment system (chlorine, pH, bromine and/or salt chlorinator meter-
ing pumps) is installed after the heat pump in the hydraulic circuit.
To avoid any deterioration to the heat pump, the water’s pH must be maintained between 6.9 and
8.0.
During use
To avoid serious injuries, never touch the fan when it is operating.
Keep the heat pump out of the reach of children to avoid serious injuries caused by the heat exchanger’s
blades.
Never start the equipment if there is no water in the pool or if the circulating pump is stopped.
Check the water ow rate every month and clean the lter if necessary.
During cleaning
Switch o󰀨 the equipment’s electricity supply.
Close the water inlet and outlet valves.
Do not insert anything into the air or water intakes or outlets.
Do not rinse the equipment with water.
During repairs
Carry out work on the refrigerant system in accordance with current safety regulations.
Brazing should be performed by a qualied welder.
When replacing a defective refrigerant component, use only parts certied by our technical department.
When replacing pipework, only copper pipes conforming to Standard NF EN12735-1 may be used for
repairs.
When pressure-testing to detect leaks:
To avoid the risks of re or explosion, never use oxygen or dry air.
Use dehydrated nitrogen or a mixture of nitrogen and refrigerant.
The low and high side test pressure must not exceed 42 bar.
1. General

8
2.1 Package contents
2.2 General characteristics
Heat pump Poolex Silverline FI
2 hydraulic inlet/outlet connectors (50mm diameter)
Extension cable for remote control panel
This installation and user manual
Condensation draining kit
Winter storage cover
4 anti-vibration pads (fastenings not supplied)
A Poolex heat pump has the following features:
CE certication and complies with the RoHS European directive.
High performance with up to 80% energy savings compared to a conventional heating system.
Clean, e󰀩cient and environmentally friendly R32 refrigerant.
Reliable high output leading brand compressor.
Wide hydrophilic aluminium evaporator for use at low temperatures.
User-friendly intuitive remote control.
Heavy duty ABS shell, anti-UV treated and easy to maintain.
Designed to be silent.
Dual antifreeze system to avoid frost damage:
Revolutionary exchanger with patented antifreeze system.
A smart monitoring system to preserve the pipework and liner without emptying the pool in winter.
2. Description

9
2.3 Technical specications
The technical specications of our heat pumps are provided for information purposes only. We reserve the right to make changes without prior notice.
1 Ambient air temperature
2 Initial water temperature
3Noise at 1 m, at 4 m and at 10 m in accordance with Directives EN ISO 3741 and EN ISO 354
4Calculated for an in-ground private swimming pool covered with a bubble cover.
Poolex Silverline FI
Test conditions 70 90 120 150 200
Air (1) 26°C
Water (2) 26°C
Heating power (kW) 6.8~1.94 9.2~2.23 11.3~2.28 14.5~2.25 19.2~2.59
Power in mode Silence (kW) 3.31~1.54 4.75~2.23 5.77~2.08 7.31~2.25 10.47~2.59
Consumption (kW) 1.05~0.15 1.46~0.16 1.86~0.13 2.43~0.14 3.14~0.16
Consumption in Silence (kW) 0.36~0.12 0.47~0.16 0.61~0.13 0.72~0.14 1.06~0.16
COP (Coe. of performance) 12.9~6.47 13.9~6.3 16.1~6.07 16.1~5.96 16.2~6.1
Air (1) 15°C
Water (2) 26°C
Heating power (kW) 5.2~1.35 6.4~1.4 8.4~1.6 10.5~1.8 14.1~2.08
Power in mode Silence (kW) 2.7~1.35 3.54~1.45 4.39~1.6 5.28~1.8 7.17~2.08
Consumption (kW) 1.11~0.21 1.44~0.22 1.83~0.21 2.29~0.24 3.07~0.26
Consumption in Silence (kW) 0.42~0.21 0.55~0.22 0.67~0.21 0.81~0.24 1.08~0.26
COP (Coe. of performance) 6.4~4.6 6.3~4.4 7.6~4.5 7.5~4.5 8.0~4.5
Air (1) 35°C
Water (2) 27°C
Cooling capacity (kW) 3.24 4.0 5.20 6.52 8.73
Consumption (kW) 0.81 1.04 1.27 1.59 2.15
EER (Coe. of performance) 3.88 3.8 4.1 4.1 4.06
Air (1) 15°C
Water (2) 26°C
MODE FIX
Heating power (kW) 5.2 6.4 8.4 10.5 14.16
Consommation (kW) 1.10 1.44 1.83 2.29 3.07
COP (Coe. of performance) 4.95 4.4 4.5 4.5 4.6
Maximum power (kW) 1.38 1.83 2.62 2.9 4.2
Maximum current (A) 8 10 13 15 21
Electricity supply 220~240V / 50Hz
Protection IPX4
Heating temperature range 15°C~40°C
Cooling temperature range 8°C~28°C
Operating temperature range -7°C~43°C
Unit dimensions L x W x H (mm) 824*334*643 907*334*643 1104*354*743
Unit weight (kg) 38.5 38.5 39.5 44.5 51
Sound pressure level at 1 m (dBA) (3) 37~50 37~51 38~52 40~54 40~54
Sound pressure level at 10 m (dBA) (3) 19~29 19~30 21~31 23~34 23~34
Hydraulic connection (mm) PVC 50mm
Heat exchanger Cuve PVC et Serpentin Titane torsadé
Min. / Max. water ow rate (m³/h) 2~4 3~4 4~6 5~7 7~9
Compressor GMCC GMCC GMCC MITSUBISHI GMCC
Compressor type Hermetic Rotary DC Inverter Compressor
Refrigerant R32
Réfrigérant mass (kg) 0.45 0.45 0.6 0.65 1
Fan motor DC Fan Motor
Load loss (mCE) 1.1 1.1 1.1 1.1 1.1
Max. pool volume (m3) (4) 30-45 40-50 45-65 65-80 80-110
Remote control Écran de contrôle LCD rétroéclairé laire
Mode Chau󰀨age / Refroidissement
2. Description

10
2.4 Unit dimensions
2. Description
Dimensions en mm
D
A
B
G
E
C
F
Silverline FI 70 / 90 / 120 150 200
A 865 945 1143
B 656 656 756
C 103 93 71
D 260 330 350
E 27 27 27
F 829 909 1107
G 343 343 363

11
2.5 Exploded view
2. Description
12
11
13
15
16 8
1
2
3
4
5
6
9
10
7
17
18
19
20
21
22
14
1. Top panel
2. Logic board box
3. Back panel
4. Pressure gauge
5. Water Flow Switch
6. Heat exchanger
7. Right side panel
8. gas pipe
9. Electrical control box
10. Electrical box cover
11. pressure switch hp/bp
12. Compressor
13. Front panel
14. Fan blade
15. Fan motor
16. Fan support
17. Electrical terminal block
18. Middle support
19. Electric transformer
20. Electrical control box
21. Base frame
22. Right hand grip

12
Equipment necessary for the installation of your heat pump:
Power supply cable suitable for the unit’s power requirements.
A By-Pass kit and an assembly of PVC tubing suitable for your installation as well as stripper, PVC
adhesive and sandpaper.
A set of wall plugs and expansion screws suitable to attach the unit to your support.
We recommend that you connect the unit to your installation by means of exible PVC pipes in order to
reduce the transmission of vibrations.
Suitable fastening studs may be used to raise the unit.
3.1 Pre-requirements
3.2 Location
Please comply with the following rules concerning the choice of heat pump location.
1. The unit’s future location must be easily accessible for convenient operation and maintenance.
2. It must be installed on the ground, xed ideally on a level concrete oor. Ensure that the oor is su󰀩ciently
stable and can support the weight of the unit.
3. A water drainage device must be provided close to the unit in order to protect the area where it is installed.
4. If necessary, the unit may be raised by using suitable mounting pads designed to support its weight.
5. Check that the unit is properly ventilated, that the air outlet is not facing the windows of neighbouring
buildings and that the exhaust air cannot return. In addition, provide su󰀩cient space around the unit for
servicing and maintenance operations.
6. The unit must not be installed in an area exposed to oil, ammable gases, corrosive products, sulphurous
compounds or close to high frequency equipment.
7. To prevent mud splashes, do not install the unit near a road or track.
8. To avoid causing nuisance to neighbours, make sure the unit is installed so that it is positioned towards
the area that is least sensitive to noise.
9. Keep the unit as much as possible out of the reach of children.
3. Installation
WARNING: Installation must be carried out by a qualied engineer.
This section is provided for information purposes only and must be checked and adapted if
necessary according to the actual installation conditions.
Place nothing less than one metre in front of the heat pump.
Leave 50 cm of empty space around the sides and rear of the heat pump.
Do not leave any obstacle above or in front of the unit!
2500
Dimensions en mm

13
3.3 Installation layout
3.4 Connecting the condensation draining kit
3.5 Installing the unit on noise-damping supports
While operating, the heat pump is subject to condensation. This will result in a more or less large run-o󰀨
of water, depending on the degree of humidity. To channel this ow, we recommend that you install the
condensation drainage kit.
How do you install the condensation drainage kit|?
Install the heat pump, raising it at least 10 cm with solid water-resistant pads, then connect the drainage
pipe to the opening located under the pump.
In order to minimise the noise pollution associated with heat pump vibrations, it can be positioned on
vibration absorbing pads.
To do this, you simply have to position a pad between each of the unit’s feet and its support, and then x
the heat pump to the support with suitable screws.
3. Installation
Valves 1, 2 and 3: Bypass valves
Valves 4 and 5: Regulating valves
(Recommended for facilitating adjustments close to the machine)
Heat pump
Water outlet
Water intake
Elevating
studs Condensation
draining
Valve 4
Valve 5
Valve 2
Circulating
pump
Filtration
Valve 1
Automated treatment system
(salt chlorinator, metering pump)
TOWARDS THE POOL
FROM THE POOL
4-way valve
Half-open valve Open valve
Key

14
Making a hydraulic connection with the By-Pass kit
Step 1: Take the necessary steps to cut your pipes.
Step 2: Make a straight perpendicular cut through the PVC pipes with a saw.
Step 3: Assemble your hydraulic circuit without connecting it in order to check that it perfectly ts your
installation, then dismantle the pipes to be connected.
Step 4: Chamfer the ends of the cut pipes with sandpaper.
Step 5: Apply stripper to the ends of the pipes to be connected.
Step 6: Apply the adhesive in the same place.
Step 7: Assemble the pipes.
Step 7: Clean o󰀨 any adhesive remaining on the PVC.
Step 8: Leave to dry for at least 2 hours before putting the hydraulic circuit into water.
3.6 Hydraulic connection
WARNING: Installation must be carried out by a qualied engineer.
This section is provided for information purposes only and must be checked and adapted if
necessary according to the actual installation conditions.
WARNING: Do not run water through the hydraulic circuit for 2 hours after applying the adhesive.
By-Pass assembly
The heat pump must be connected to the pool by
means of a By-Pass assembly.
A By-Pass is an assembly consisting of 3 valves that
regulate the ow circulating in the heat pump.
During maintenance operations, the By-Pass permits
the heat pump to be isolated from the system without
interrupting your installation.
3. Installation
TOWARDS THE POOL
Open valve
Half-open valve
FROM THE POOL

15
By-Pass assembly for more than one heat pump
By-Pass assembly for one heat pump
The lter located upstream of the heat pump must be regularly cleared so that the water in
the system is clean, thus avoiding the operational problems associated with dirt or clog-
ging in the lter.
3. Installation
Half-open valve Open valve
Key
TOWARDS THE POOL
Filtration + Pump
Automated treatment
system
FROM THE POOL
POOL
Half-open valve Open valve
Key
Filtration + Pump
Automated treatment
system
TOWARDS THE POOL
POOL
FROM THE POOL

16
3. Installation
To function safely and maintain the integrity of your electrical system, the unit must be connected to a
general electricity supply in accordance with the following regulations:
Upstream, the general electricity supply must be protected by a 30 mA di󰀨erential switch.
The heat pump must be connected to a suitable D-curve circuit breaker (see table below) in accordance
with current standards and regulations in the country where the system is installed.
The electricity supply cable must be adapted to match the unit’s rated power and the length of wiring
required by the installation (see table below). The cable must be suitable for outdoor use.
For a three-phase system, it is essential to connect the phases in the correct sequence.
If the phases are inverted, the heat pump’s compressor will not work.
In places open to the public, it is mandatory to install an emergency stop button close to the heat pump.
Models Electricity supply Max. current Cable diameter Protection Thermal-magnetic (D
curve) protection
Silverline FI 70
1-phase
220-240V/1N~50Hz
8 RO2V 3x2.5 mm² 16 A
Silverline FI 90 10 RO2V 3x2.5 mm² 16 A
Silverline FI 120 13 RO2V 3x2.5 mm² 16 A
Silverline FI 150 15 RO2V 3x4 mm² 20 A
Silverline FI 200 21 RO2V 3x4 mm² 25 A
1Cable cross-section suitable for max. length 10 metres. For longer than 10 metres, consult an electrician.
3.7 Electrical installation
WARNING: Installation must be carried out by a qualied engineer.
This section is provided for information purposes only and must be checked and adapted if
necessary according to the actual installation conditions.

17
VPlease comply with the following instructions to electrically connect the heat pump.
Step 1: Detach the electrical side panel with a screwdriver to access the electrical terminal block.
Step 2: Insert the cable into the heat pump unit by passing it through the opening provided for that purpose.
Step 3: Connect the power supply cable to the terminal block in accordance with the diagram below.
Step 4: Carefully close the heat pump panel.
Servo-control of circulating pump
Depending on the type of installation, you can also connect a circulating pump to terminals P1and P2so
that this operates in tandem with the heat pump.
3. Installation
3.8 Electrical connection
WARNING: The heat pump’s power supply MUST be disconnected before any operation.
WARNING: Servo-control of a pump whose power exceeds 5A (1000W) requires the use of a
power relay.
L N P1P2
Connecter à l’alimentation
230V / 50Hz
Connecter à la
pompe à filtration
ou un relais de puissance
PHASE NEUTRE TERRE PHASE NEUTRE
Single phase model
Connect to power supply
230V / 50Hz
PHASE NEUTRE NEUTRETERRE PHASE
Connect to a ltration
pump or a power
relay

18
4. Use
4.2 Control box displays
Prior to setting your required temperature, you must rst select an operating mode for your heat pump:
Cooling mode
Full Inverter
+nE
+nE
+H1
+H1
+l0
+l0
Speed compressor
Fan speed
inlet water temperature
Parameters menu
Temperature unit
Clock
Clock programming
Keypad lock
Programming On O󰀨
Heating Mode
Full Inverter
Automatic mode
Full Inverter
Heating Mode boost
Cooling boost
Heating Mode Eco Silence
Cooling Eco Silence
Defrost
Temperature setting
Setpoint and water inlet temperature
4.1 Wired remote control
Before starting, ensure that the ltration pump is working and that water is circulating through
the heat pump.
SET IN NO ROOM VALUE OUT
1
2
ON
OFF
TEMP
HUM
h
MIN
%
F
AUTO
FAN
h
MIN
%
F
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN

19
WARNING:
4. Use
Once the control panel is unlocked, press to
SET IN NO ROOM VALUE OUT
1
2
ON
OFF
TEMP
HUM
h
MI N
%
F
AUTOFAN
h
MI N
%
F
and
SET IN NO ROOM VALUE OUT
1
2
ON
OFF
TEMP
HUM
h
MI N
%
F
AUTOFAN
h
MI N
%
F
to set and modify the value, press SET to conrm
the value.
Press to
SET IN NO ROOM VALUE OUT
1
2
ON
OFF
TEMP
HUM
h
MI N
%
F
AUTOFAN
h
MI N
%
F
to conrm the parameters.
Step 1 : To enter the verication parameters, Keep pressing
SET IN NO ROOM VALUE OUT
1
2
ON
OFF
TEMP
HUM
h
MI N
%
F
AUTOFAN
h
MI N
%
F
press for 3 seconds, then scroll through the
parameters with the buttons
SET IN NO ROOM VALUE OUT
1
2
ON
OFF
TEMP
HUM
h
MI N
%
F
AUTOFAN
h
MI N
%
F
and
SET IN NO ROOM VALUE OUT
1
2
ON
OFF
TEMP
HUM
h
MI N
%
F
AUTOFAN
h
MI N
%
F
Step 2 : Once on the desired parameter, press to
SET IN NO ROOM VALUE OUT
1
2
ON
OFF
TEMP
HUM
h
MI N
%
F
AUTOFAN
h
MI N
%
F
to access the parameter setting. You can change the
value of the parameter with the buttons.
SET IN NO ROOM VALUE OUT
1
2
ON
OFF
TEMP
HUM
h
MI N
%
F
AUTOFAN
h
MI N
%
F
and
SET IN NO ROOM VALUE OUT
1
2
ON
OFF
TEMP
HUM
h
MI N
%
F
AUTOFAN
h
MI N
%
F
, then
SET IN NO ROOM VALUE OUT
1
2
ON
OFF
TEMP
HUM
h
MI N
%
F
AUTOFAN
h
MI N
%
F
to conrm.
Push on
SET IN NO ROOM VALUE OUT
1
2
ON
OFF
TEMP
HUM
h
MIN
%
F
AUTOFAN
h
MIN
%
F
to change the operating mode. The di󰀨erent modes appear in the following order:
Cooling mode
Eco silence
Cooling mode
Boost
Cooling Mode
Full Inverter
+LO
+H1
+nE
+nE
+H1
+L0
Heating mode
Full Inverter
Heating mode
Boost
Heating mode
Eco silence
Automatic mode
4.3 Operating mode selector
4.4 Temperature setting
4.5 Parameter checking and setting
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
SET
IN
1
2
ON
OFF
C
FAN
When the cooling mode switches to heating mode or vice-versa, the heat pump will restart after 10
minutes.
When the incoming water temperature is less than or equal to the required temperature (setpoint
temperature - 1°C), the heat pump will switch to heating mode. The compressor will stop when the
temperature of the incoming water is greater than or equal to the required temperature (setpoint
temperature + 1°C).

20
Step 1 : press 5s to
SET IN NO ROOM VALUE OUT
1
2
ON
OFF
TEMP
HUM
h
MI N
%
F
AUTOFAN
h
MI N
%
F
to enter current time setting.
Step 2 : Press to
SET IN NO ROOM VALUE OUT
1
2
ON
OFF
TEMP
HUM
h
MI N
%
F
AUTOFAN
h
MI N
%
F
, the hours are blinking, push to
SET IN NO ROOM VALUE OUT
1
2
ON
OFF
TEMP
HUM
h
MI N
%
F
AUTOFAN
h
MI N
%
F
and
SET IN NO ROOM VALUE OUT
1
2
ON
OFF
TEMP
HUM
h
MI N
%
F
AUTOFAN
h
MI N
%
F
to adjust the hours.
Step 3 : Press to
SET IN NO ROOM VALUE OUT
1
2
ON
OFF
TEMP
HUM
h
MI N
%
F
AUTOFAN
h
MI N
%
F
, the minutes are blinking, push to
SET IN NO ROOM VALUE OUT
1
2
ON
OFF
TEMP
HUM
h
MI N
%
F
AUTOFAN
h
MI N
%
F
and
SET IN NO ROOM VALUE OUT
1
2
ON
OFF
TEMP
HUM
h
MI N
%
F
AUTOFAN
h
MI N
%
F
to adjust the minutes.
Step 4 : Press to
SET IN NO ROOM VALUE OUT
1
2
ON
OFF
TEMP
HUM
h
MI N
%
F
AUTOFAN
h
MI N
%
F
to validate and return to the main screen.
4. Use
When the incoming water temperature is higher or equal to the required temperature (setpoint temperature
+ 1°C), the heat pump will switch to cooling mode. The compressor will stop when the temperature of the
incoming water is less than or equal to the required temperature (setpoint temperature - 1°C).
WARNING: When the cooling mode switches to heating mode or vice-versa, the heat pump will restart
after 10 minutes.
Bon à savoir
AUTO
FAN
°C
AUTO
FAN
°C
AUTO
FAN
°C
AUTO
FAN
°C
AUTO
FAN
°C
4.6 Setting the clock
Step 1
Step 4
Step 2 Step 3
Step 3
