Porta-Dock PORTA-LIFT 1155 User manual

10/07/08
Page 1 of 4
U:\Judy\INSTRUCTIONS CURRENT\INSTR LIFT ACCESSORIES\A22 INSTR CANOPY UNDER 1200 AND 36114.doc
PORTA-LIFT CANOPY TOP
1155, 1265, 1284, AND 36114
Thank you for purchasing our product!
*Please read these instructions and follow them step by step.*
Caution-- If installing or adjusting a canopy mounting bracket on a lift with an existing winch the bed must be lowered
with the load removed from the bed before the winch is taken off.
Step 1. Set the four canopy mounting brackets (REF. # 6) into the top of each vertical upright of the side member so that the
weld on the side of the channel is to the outside of the lift. Set to desired height using bolts, washers, & nuts (REF. # 10, 13, &
7).
Step 2. Set the four canopy sections together with the two stubbed sections (1265 canopy sections do not have stubs) (REF. #
1) in opposite corners. Slide the stubbed ends into the open-end tube sections (REF. # 2) and bolt with 3/8" X 2 1/2" bolts,
washers, & nuts (REF. # 3, 13, & 7). NOTE: 1265 models will have four fewer bolting locations than the larger canopy
shown in the instruction.
6 - 53

10/07/08
Page 2 of 4
U:\Judy\INSTRUCTIONS CURRENT\INSTR LIFT ACCESSORIES\A22 INSTR CANOPY UNDER 1200 AND 36114.doc
Step 3. Set the canopy into the four mounting brackets and adjust to desired location. Place a 3/8” X 2 1/2" bolt (REF. # 5)
through the holes in the canopy mounting bracket and secure with 3/8” washers and nut (REF. # 13 & 7). Note:
1265 models use 5/16” X 2 1/4” bolts, washers, and nuts. 1155 models use 5/16 X 2 1/2" bolts, washers, and
nuts.
6 - 54

01/28/09
Page 3 of 4
U:\Judy\INSTRUCTIONS CURRENT\INSTR LIFT ACCESSORIES\A22 INSTR CANOPY UNDER 1200 AND 36114.doc
CANOPY FRAME PARTS LISTS
CF06 CANOPY FRAME 65” X 12' W/O VINYL
REF. NO. PART NO. DESCRIPTION QTY
1 71A CANOPY FRAME RIGHT 6' X 65” 2
2 70A CANOPY FRAME LEFT 6' X 65” 2
CF08 CANOPY FRAME 113” X 14' W/O VINYL
REF. NO. PART NO. DESCRIPTION QTY
1 89A CANOPY FRAME STUBBED 6' X 114” 1
90A CANOPY FRAME STUBBED 8' X 114” 1
2 89C CANOPY FRAME PLAIN 6' X 114” 1
100C CANOPY FRAME PLAIN 8' X 114 1
CF10 CANOPY FRAME 84” X 20' W/O VINYL
REF. NO. PART NO. DESCRIPTION QTY
1 32U CANOPY FRAME STUBBED 84” 2
2 31U CANOPY FRAME PLAIN 84” 2
CANOPY UPRIGHT AND HARDWARE PARTS LISTS
PB206 CANOPY UPRIGHTS & ASSEMBLY HARDWARE 1265
REF. NO. PART NO. DESCRIPTION QTY
3 5083 3/8” X 2 1/2” BOLT 20
5147 5/16” X 2 1/2" BOLT 4
6 08E CANOPY MOUNTING BRACKET 1265 4
7 5056 3/8” NUT 20
5054 5/16” NUT 4
13 5070 3/8” WASHER 40
5068 5/16” WASHER 8
59D CANOPY UPRIGHTS & ASSEMBLY HARDWARE 1155 & 1284 MODELS
REF. NO. PART NO. DESCRIPTION QTY
3 5083 3/8” X 2 1/2” BOLT 20
6 12U CANOPY MOUNTING BRACKET 1155 & 1284 4
7 5056 3/8” NUT 20
13 5070 3/8” WASHER 40
6 - 55

10/07/08
Page 4 of 4
U:\Judy\INSTRUCTIONS CURRENT\INSTR LIFT ACCESSORIES\A22 INSTR CANOPY UNDER 1200 AND 36114.doc
52U CANOPY UPRIGHTS & ASSEMBLY HARDWARE OLD 2000C MODELS
REF. NO. PART NO. DESCRIPTION QTY
3 5083 3/8” X 2 1/2” BOLT 20
6 28U CANOPY MOUNTING BRACKET (2000C) 4
7 5056 3/8” NUT 23
10 5084 3/8” X 3” BOLT 3
13 5070 3/8” WASHER 46
41U CANOPY UPRIGHTS & ASSEMBLY HARDWARE 36114 MODELS
REF. NO. PART NO. DESCRIPTION QTY
3 5083 3/8” X 2 1/2” BOLT 20
6 28U CANOPY MOUNTING BRACKET (SMALL) 2
29U CANOPY MOUNTING BRACKET (LARGE) 2
7 5056 3/8” NUT 23
10 5084 3/8” X 3” BOLT 2
5090 3/8” X 5” BOLT 1
13 5070 3/8” WASHER 46
6 - 56
