Portable Bar Company FLASH BAR WHEEL BASE User manual

FLASH BAR WHEEL BASE SETUP GUIDE

• Read all the instructions before installing.
• Remove all packing materials before you start.
• This installation requires basic mechanical skills.
• Proper installation is the responsibility of the installer.
• Product failure due to improper installation is not covered under
the warranty.
• Keep this instruction manual.
2BEFORE YOU BEGIN THE INSTALLATION
Required tools
Philips Screwdriver Crescent Wrench
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED WITHIN THIS DOCUMENT IS THE SOLE PROPERTY OF THE PORTABLE BAR COMPANY
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF THE PORTABLE BAR COMPANY IS PROHIBITED.
CAUTION: DO NOT ATTACH AND MOVE MORE THAN 4 WHEELED SEGMENTS

PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED WITHIN THIS DOCUMENT IS THE SOLE PROPERTY OF THE PORTABLE BAR COMPANY
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF THE PORTABLE BAR COMPANY IS PROHIBITED.
Preassembled FB Straight Base
QTY: 1
FB Leg Support
QTY: 1
PART LIST 3
Anchor Bracket
QTY: 2
Gusset
Pre-installed
Side Frame
QTY: 2
Footrail
QTY: 1
Part included with
Flash Bar Straight Segment
Part included with
Flash Bar Straight Segment
Part included with
End Cap Kit

PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED WITHIN THIS DOCUMENT IS THE SOLE PROPERTY OF THE PORTABLE BAR COMPANY
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF THE PORTABLE BAR COMPANY IS PROHIBITED.
STEP 1: Place preassembled straight segment wheel base on a
level surface and lock the casters to prevent movement
and remove traingular gusset using a Phillips screwdriver.
Note: The triangular gussets point to the
back (bartender side) of the base.
STEP 2: Lift stainless steel access panel on top of the base.
STEP 3: Attach side frame support to preassembled base using
the provided hex head bolts.
STEP 4: Place access panel back on and install triangular gusset
using provided phillips head bolts.
STEP 5: Remove feet from side frames and then with two
people connect footrail to two FB side frames.
STEP 6: Lift the two frames and footrail assembly in unison and
insert the side frame posts to the corresponding frame
support locations on the base.
Note: There is no hardware so this must be done with two people for balance
and tension to hold the footrail in place
FLASH BAR WHEEL BASE BAR ASSEMBLY SETUP STEPS
4
Note: The triangular gussets point to the
back (bartender side) of the base.
Note: Finish tighten the bolts using a crescent wrench.

FLASH BAR WHEEL BASE BAR ASSEMBLY SETUP STEPSFLASH BAR WHEEL BASE BAR ASSEMBLY SETUP STEPS 5
Use provided anchor bracket to secure your assembly,
as shown below.

Adding a 90 Corner Segment

PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED WITHIN THIS DOCUMENT IS THE SOLE PROPERTY OF THE PORTABLE BAR COMPANY
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF THE PORTABLE BAR COMPANY IS PROHIBITED.
Preassembled FB 90 Corner Base
QTY: 1
FB 90 Corner Center Bracket
QTY: 1
PART LIST
“T” bracket.
QTY: 1
Anchor Bracket
QTY: 1
Curved footrail
QTY: 1
Side Frame
QTY: 1
7
Part included with
Flash Bar 90 Corner Segment
Part included with
Flash Bar 90 Corner Segment
Allen key and screw
QTY: 1 QTY: 4

PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED WITHIN THIS DOCUMENT IS THE SOLE PROPERTY OF THE PORTABLE BAR COMPANY
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF THE PORTABLE BAR COMPANY IS PROHIBITED.
STEP 1: Move the preassembled corner 90 base into position next to the assembled straight segment and align it with the side
support of the straight segment base.
STEP 2: Remove access panel on the corner 90 to access the
hardware locations and tighten provided 10mm
hex head bolts.
STEP 3: Place access panel back on and install the curved
footrail T bracket to the corner 90 base using provided
allen head screws. Make sure to not tighten the screws
all the way, leave the T bracket somewhat loose.
FLASH BAR WHEEL BASE BAR ASSEMBLY SETUP STEPS
8

PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED WITHIN THIS DOCUMENT IS THE SOLE PROPERTY OF THE PORTABLE BAR COMPANY
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF THE PORTABLE BAR COMPANY IS PROHIBITED.
STEP 4: With two people: connect curved corner 90 footrail to one FB side frame. There is no wardware so this must be done with two
people for ease of balance and tension to hold the pieces together. You might need to move the adjacent side frame up and
down to allow for the curved footrail to fit in.
STEP 6: Tighten T bracket and install another two allen head
screws to fix curved footrail in place.
FLASH BAR WHEEL BASE BAR ASSEMBLY SETUP STEPS
STEP 5: Align the side frame and curved footrail with the rest of
the assembly. While setting the side frame in place
lift up the straight segment side frame to allow the
footrail to fit in.
9

PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED WITHIN THIS DOCUMENT IS THE SOLE PROPERTY OF THE PORTABLE BAR COMPANY
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF THE PORTABLE BAR COMPANY IS PROHIBITED.
STEP 7: Install center bracket on the 90 corner using 5 provided phillips head bolts.
FLASH BAR WHEEL BASE BAR ASSEMBLY SETUP STEPS
Complete installation by following the
regular Flash Bar guide.
10

FLASH BAR WHEEL BASE BAR ASSEMBLY SETUP STEPSFLASH BAR WHEEL BASE BAR ASSEMBLY SETUP STEPS 11
Use provided anchor bracket to secure your assembly,
as shown below.

Adding a Straight Segment

PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED WITHIN THIS DOCUMENT IS THE SOLE PROPERTY OF THE PORTABLE BAR COMPANY
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF THE PORTABLE BAR COMPANY IS PROHIBITED.
PART LIST 13
Preassembled FB Straight Base
QTY: 1
FB Leg Support
QTY: 1
Anchor Bracket
QTY: 2
Gusset
Side Frame
QTY: 2
Footrail
QTY: 1
Part included with
Flash Bar Straight Segment
Part included with
Flash Bar Straight Segment
Pre-installed
Part included with
End Cap Kit

PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED WITHIN THIS DOCUMENT IS THE SOLE PROPERTY OF THE PORTABLE BAR COMPANY
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF THE PORTABLE BAR COMPANY IS PROHIBITED.
STEP 1: Move the preassembled straight segment into position next to the assembled straight segment or 90 corner and align it with
the side support of the straight segment base.
STEP 2: Lift stainless steel access panel on top of the base.
STEP 3: Attach side frame support to preassembled base using
the provided 10mm hex head bolts.
FLASH BAR WHEEL BASE BAR ASSEMBLY SETUP STEPS
14

PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED WITHIN THIS DOCUMENT IS THE SOLE PROPERTY OF THE PORTABLE BAR COMPANY
ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF THE PORTABLE BAR COMPANY IS PROHIBITED.
STEP 4: Install triangular gusset using provided 10mm hex
head bolts.
STEP 6: Lift the frames and footrail assembly in unison and insert the side frame posts to the corresponding frame support locations
on the base.
Note: There is no hardware so this must be done with two people for balance
and tension to hold the footrail in place
FLASH BAR WHEEL BASE BAR ASSEMBLY SETUP STEPS
STEP 5: Remove feet from side frame and with two people
connect side frame to footrail.
15
Complete installation by following the
regular Flash Bar guide.

Use provided anchor bracket to secure your assembly,
as shown below.
FLASH BAR WHEEL BASE BAR ASSEMBLY SETUP STEPSFLASH BAR WHEEL BASE BAR ASSEMBLY SETUP STEPS
16

Contact us
Tel # [phone]
Fax # [phone]
E-mail: [e-mail]
Visit us at
www.theportablebarcompany.com
FLASH BAR WHEEL BASE SETUP GUIDE - 10/2019
