COM Express™ PCOM-C60B ZR4 User Manual
Copyright © PORTWELL PCOM-C60B
1
COM Express™
PCOM-C60B ZR4
User manual Revision 1.0
COM Express™ PCOM-C60B ZR4 User Manual
Copyright © PORTWELL PCOM-C60B
2
Revision History
R 1.0
Preliminary for PCOM-C60B ZR4
COM Express™ PCOM-C60B ZR4 User Manual
Copyright © PORTWELL PCOM-C60B
3
Contents
1 Introduction ..............................................................................................................................................................................................................9
2 Block Diagram .........................................................................................................................................................................................................10
3 Specifications ..........................................................................................................................................................................................................11
4 Carrier I/O Location.................................................................................................................................................................................................12
5 Mechanical drawing................................................................................................................................................................................................13
6 Rear I/O...................................................................................................................................................................................................................17
7 On board Connectors..............................................................................................................................................................................................21
8 Jumper.....................................................................................................................................................................................................................35
9 Miscellaneous .........................................................................................................................................................................................................42
10 Ordering Guide......................................................................................................................................................................................................44
11 Pin out Tables........................................................................................................................................................................................................45
12 Industry Specifications..........................................................................................................................................................................................50
COM Express™ PCOM-C60B ZR4 User Manual
Copyright © PORTWELL PCOM-C60B
4
List of Tables
Table 1 Specifications.................................................................................................................................................................................................................................. 11
Table 2 Rear IO list ...................................................................................................................................................................................................................................... 17
Table 3 Display Port .................................................................................................................................................................................................................................... 18
Table 4 4*USB2.0 ........................................................................................................................................................................................................................................ 19
Table 5 RJ45 + 2* USB3.2............................................................................................................................................................................................................................. 19
Table 6 2*USB3.2 ........................................................................................................................................................................................................................................ 20
Table 7 Audio Jack....................................................................................................................................................................................................................................... 20
Table 8 Headers & Connectors list............................................................................................................................................................................................................... 21
Table 9 Front Panel ..................................................................................................................................................................................................................................... 22
Table 10 PCIE x4 Slot Port 0-3/4-7............................................................................................................................................................................................................... 23
Table 11 PCIE x1 Slot Port 2/1/3/5/6/7 ....................................................................................................................................................................................................... 24
Table 12 PCIE x16 Slot Port.......................................................................................................................................................................................................................... 26
Table 13 SATA Port 1/2/3/0......................................................................................................................................................................................................................... 26
Table 14 TPM Connector ............................................................................................................................................................................................................................. 27
Table 15 COM0/1 D-SUB ............................................................................................................................................................................................................................. 28
Table 16 GPIO Header ................................................................................................................................................................................................................................. 29
Table 17 I2C & SMbus Header ..................................................................................................................................................................................................................... 29
Table 18 LVDS Backlight Control & Connector ............................................................................................................................................................................................. 30
Table 19 VGA D-SUB.................................................................................................................................................................................................................................... 31
Table 20 eDP Backlight Control & Connector............................................................................................................................................................................................... 32
Table 21 CPU Fan ........................................................................................................................................................................................................................................ 33
Table 22 ATX 8 Pin Connector...................................................................................................................................................................................................................... 33
Table 23 ATX 24 Pin Connector.................................................................................................................................................................................................................... 34
Table 24 Jumper List.................................................................................................................................................................................................................................... 35
Table 25 TPM Present on Carrier................................................................................................................................................................................................................. 36
COM Express™ PCOM-C60B ZR4 User Manual
Copyright © PORTWELL PCOM-C60B
5
Table 26 5VSB Select for Module................................................................................................................................................................................................................. 36
Table 27 1*PCIe x4 / 4*PCIe x1 Select ......................................................................................................................................................................................................... 37
Table 28 1*PCIe x4 / 4*PCIe x1 Select ......................................................................................................................................................................................................... 37
Table 29 LVDS Panel Power Select............................................................................................................................................................................................................... 38
Table 30 LVDS Backlight Enable................................................................................................................................................................................................................... 38
Table 31 BIOS EEROM Boot from Module or Carrier Select ......................................................................................................................................................................... 39
Table 32 SMA RF (COMe 3.0 SDP use) ......................................................................................................................................................................................................... 39
Table 33 USB Host Present .......................................................................................................................................................................................................................... 40
Table 34 AT/ATX Mode Select...................................................................................................................................................................................................................... 40
Table 35 LVDS Color Depth Select................................................................................................................................................................................................................ 40
Table 36 eSPI / LPC Clock Select .................................................................................................................................................................................................................. 41
Table 37 eSPI / LPC Reset Select.................................................................................................................................................................................................................. 41
Table 38 eDP / LVDS Signal Select................................................................................................................................................................................................................ 41
Table 39 Miscellaneous List......................................................................................................................................................................................................................... 42
Table 40 Other Test (BATLOW#/LID#/CB_WAKE#/THRM#).......................................................................................................................................................................... 43
Table 41 F85281 Mode Select...................................................................................................................................................................................................................... 43
Table 42 Ordering Guide ............................................................................................................................................................................................................................. 44
Table 43 AB & CD Row Connector Signals.................................................................................................................................................................................................... 49
Table 44 Portwell Product Matrix...............................................................................................................................................................................錯誤! 尚未定義書籤。
COM Express™ PCOM-C60B ZR4 User Manual
Copyright © PORTWELL PCOM-C60B
6
List of Figures
Figure 1 Block Diagram ............................................................................................................................................................................................................................... 10
Figure 2 I/O & Connectors location............................................................................................................................................................................................................. 12
Figure 3 Mechnical Isometric View ............................................................................................................................................................................................................. 13
Figure 3 Mechnical dimension - Top............................................................................................................................................................................................................ 14
Figure 4 Mechnical dimension - Bottom...................................................................................................................................................................................................... 15
Figure 5 Mechanical dimension - Side view................................................................................................................................................................................................. 16
Figure 6 Rear I/O......................................................................................................................................................................................................................................... 17
COM Express™ PCOM-C60B ZR4 User Manual
Copyright © PORTWELL PCOM-C60B
7
Disclaimer
Warranty
PORTWELL tries to procure that this user manual and our product features are correct and reliable, but in any condition, PORTWELL provides
no express or implied warranty and guaranty regard to this user manual or any other product information.
PORTWELL shall not be liable for loss of revenues or profits, inconveniences, expense for substitute equipment or service, storage charges, loss
or corruption of data, or any other special, incidental or consequential damages caused by the use or misuse of or inability to use the
PORTWELL products, regardless of the legal theory on which the claim is based, and even if PORTWELL as been advised of the possibility of
such damages.
The information contained within this user manual, including but not limited to any other product specification, PORTWELL reserves its right to
modify them at any time without notice.
Trademarks
All product names, logos, brands, trademarks and registered trademarks in this user’s manual or the PORTWELL website are the property of
their respective owners.
Certification
PORTWELL is certified to ISO 9001:2008 standard.
COM Express™ PCOM-C60B ZR4 User Manual
Copyright © PORTWELL PCOM-C60B
8
Technical Support
PORTWELL technicians and engineers are committed to providing the best possible technical support for our customers so that our products
can be easily used and implemented.
We request that you first visit our website at http://www.PORTWELL.com.tw/support/ for the latest documentation, utilities and drivers, which
have been made available to assist you. If you still require assistance after visiting our website, you can contact our technical support
COM Express™ PCOM-C60B ZR4 User Manual
Copyright © PORTWELL PCOM-C60B
9
1 Introduction
PCOM-C60B user manual contains all information of the product specification, mechanical dimensions, and multiple I/O expansion with ATX
mother board form factor. This carrier is planned to fulfill the most of COM-Express 2.1/3.0 Type 6 module, included basic, and compact size.
COM Express™ PCOM-C60B ZR4 User Manual
Copyright © PORTWELL PCOM-C60B
10
2 Block Diagram
Figure 1 Block Diagram
COM Express™ PCOM-C60B ZR4 User Manual
Copyright © PORTWELL PCOM-C60B
11
3 Specifications
Product
➢PCOM-C60B
Form Factor
➢COM Express™ standard pin out Type 6 Rev. 3.0 (ATX 244 x 244mm).
Display Interface
➢Display Port (Rear I/O)
➢VGA (Header)
➢LVDS 24bit / Dual channel (Connector)
Ethernet
➢GbE (1G/2.5G)
Serial IO
➢8x GPIO (4 GPI / 4 GPO)
➢I2C / SMBus
➢2x RS-232 COM Ports
PCI Express
➢1x PCIe x16 Slot
➢2x PCIe x 4 Slot
➢6x PCIe x 1 Slot
USB
➢4 x USB 3.0 (10 Gbps) (Port 0~3)
➢8 x USB 2.0 (480 Mbps )(Port 0~7)
➢1 x USB 2.0 OTG
SATA
➢4 x SATA3.0 (6 Gbps) (Port 1~3)
Miscellaneous
➢FAN 4 Pin,
➢HDA
Power DC IN
➢+12V ATX Power ; AT/ATX Mode
Environment
➢Operating Temperature -40 ﾟC ~ +85 ﾟC
➢Storage Temperature -40 ﾟC ~ +85 ﾟC
➢Relative Humidity 5%~95%
Table 1 Specifications
COM Express™ PCOM-C60B ZR4 User Manual
Copyright © PORTWELL PCOM-C60B
12
4 Carrier I/O Location
Figure 2 I/O & Connectors location
COM Express™ PCOM-C60B ZR4 User Manual
Copyright © PORTWELL PCOM-C60B
13
5 Mechanical drawing
Figure 3 Mechnical Isometric View
COM Express™ PCOM-C60B ZR4 User Manual
Copyright © PORTWELL PCOM-C60B
14
Figure 4 Mechnical dimension - Top
COM Express™ PCOM-C60B ZR4 User Manual
Copyright © PORTWELL PCOM-C60B
15
Figure 5 Mechnical dimension - Bottom
COM Express™ PCOM-C60B ZR4 User Manual
Copyright © PORTWELL PCOM-C60B
16
Figure 6 Mechanical dimension - Side view
COM Express™ PCOM-C60B ZR4 User Manual
Copyright © PORTWELL PCOM-C60B
17
6 Rear I/O
This section introduces the Rear I/O connector layout on PCOM-C60B
Figure 7 Rear I/O
Table 2 Rear IO list
Rear I/O
Function
J1
Display Port Connector
J48 A/B
Display Port 1/2 Connector
J8
4*USB2.0
J4
RJ45 + 2*USB3.2
J9
2*USB3.2
J13
Audio Jack
COM Express™ PCOM-C60B ZR4 User Manual
Copyright © PORTWELL PCOM-C60B
18
Table 3 Display Port
J1, J48 A/B: Display Port Connector
PIN
Signal Name
PIN
Signal Name
1
DP_LANE0_P
2
GND
3
DP_LANE0_N
4
DP_LANE1_P
5
GND
6
DP_LANE1_N
7
DP_LANE2_P
8
GND
9
DP_LANE2_N
10
DP_LANE3_P
11
GND
12
DP_LANE3_N
13
DP_AUX_SEL
14
GND
15
DP_AUX_P
16
GND
17
DP_AUX_N
18
DP_HPD
19
GND
20
VCC3
J1
J48 A/B
COM Express™ PCOM-C60B ZR4 User Manual
Copyright © PORTWELL PCOM-C60B
19
Table 4 4*USB2.0
Table 5 RJ45 + 2* USB3.2
J8 : 4*USB2.0
PIN
Signal Name
A1
VBUS4
A2
USB_DN4
A3
USB_DP4
A4
GND
B1
VBUS5
B2
USB_DN5
B3
USB_DP5
B4
GND
J4: RJ45 + 2*USB3.2
PIN
Signal Name
PIN
Signal Name
PIN
Signal Name
A1
VBUSOTG
B1
VBUS1
C1
VCT_LAN
A2
USB_DN0
B2
USB_DN1
C2
LAN_MDI0P
A3
USB_DP0
B3
USB_DP1
C3
LAN_MDI0N
A4
GND
B4
GND
C4
LAN_MDI1P
A5
USB_RXN0
B5
USB_RXN1
C5
LAN_MDI1N
A6
USB_RXP0
B6
USB_RXP1
C6
LAN_MDI2P
A7
GND
B7
GND
C7
LAN_MDI2N
A8
USB_TXN0
B8
USB_TXN1
C8
LAN_MDI3P
A9
USB_TXP0
B9
USB_TXP1
C9
LAN_MDI3N
J8
J4
COM Express™ PCOM-C60B ZR4 User Manual
Copyright © PORTWELL PCOM-C60B
20
Table 6 2*USB3.2
Table 7 Audio Jack
J9: 2*USB3.2
PIN
Signal Name
PIN
Signal Name
A1
VBU2
B1
VBUS3
A2
USB_DN2
B2
USB_DN3
A3
USB_DP2
B3
USB_DP3
A4
GND
B4
GND
A5
USB_RXN2
B5
USB_RXN3
A6
USB_RXP2
B6
USB_RXP3
A7
GND
B7
GND
A8
USB_TXN2
B8
USB_TXN3
A9
USB_TXP2
B9
USB_TXP3
J13: Audio Jack
PIN
Signal Name
PIN
Signal Name
A1
GND
B2
LINE_IN_L
A2
LINE_OUT_L
B3
GND
A3
GND
B4
LINE_IN_JD
A4
LINE_OUT_JD
B5
LINE_IN_L
A5
LINE_OUT_L
J9
J13
