Portwell RUBY-D811-Q370 User manual

RUBY-D811-Q370
Copyright © Portwell 2019 RUBY-D811-Q370
User's Guide
1
Industrial ATX Board
Version 1.6
RUBY-D811-Q370

RUBY-D811-Q370
Copyright © Portwell 2019 RUBY-D811-Q370
User's Guide
2
Revision History
R1.0
Preliminary
R1.1
Update Mechanical Dimensions
R1.2
Update board size information
R1.3
Update jumper information
R1.4
Update USB3.0 information
R1.5
Update RAID Item of SATA Mode Selection & Super IO
Configuration & TPM information
R1.6
Update memory support information

RUBY-D811-Q370
Copyright © Portwell 2019 RUBY-D811-Q370
User's Guide
3
Contents
1Introduction .............................................................................................................................................................................................................................. 7
2Specifications........................................................................................................................................................................................................................... 8
2.1 Supported Operating Systems..................................................................................................................................................................9
2.2 Mechanical Dimensions.........................................................................................................................................................................10
2.3 Power Consumption..............................................................................................................................................................................11
2.4 Environmental Specifications .................................................................................................................................................................12
3Block Diagram........................................................................................................................................................................................................................ 13
4Hardware Configuration ......................................................................................................................................................................................................... 14
4.1 Jumpers and Connectors.......................................................................................................................................................................14
4.2 Jumpers Settings ..................................................................................................................................................................................15
5Signal Descriptions ................................................................................................................................................................................................................ 30
5.1 Watch Dog Signal .................................................................................................................................................................................30
5.2 GPIO Signal .........................................................................................................................................................................................33
6System Resources................................................................................................................................................................................................................. 76
6.1 Intel® Coffee Lake -S PCH ....................................................................................................................................................................76
6.2 Main Memory........................................................................................................................................................................................76
6.3 Installing the Single Board Computer ......................................................................................................................................................76
6.3.1 Chipset Component Driver .....................................................................................................................................................................77
6.3.2 Intel® UHD Graphics 630.......................................................................................................................................................................78
6.3.3 Intel LAN I210AT/I219LM Gigabit Ethernet Controller................................................................................................................................78

RUBY-D811-Q370
Copyright © Portwell 2019 RUBY-D811-Q370
User's Guide
4
7BIOS Setup Items .................................................................................................................................................................................................................. 79
7.1 Introduction ..........................................................................................................................................................................................79
7.2 BIOS Setup ..........................................................................................................................................................................................79
7.2.1 Main ......................................................................................................................................................................................................81
7.2.2 Advanced...............................................................................................................................................................................................82
7.2.3 H/W Monitor...........................................................................................................................................................................................104
7.2.4 Security .................................................................................................................................................................................................106
Secure Boot ........................................................................................................................................................................................................107
Key Management.................................................................................................................................................................................................108
7.2.5 Boot ......................................................................................................................................................................................................110
CSM(Compatibility Support Module) ...................................................................................................................................................................... 111
7.2.6 Exit........................................................................................................................................................................................................113
8Troubleshooting ....................................................................................................................................................................................................................115
8.1 Hardware Quick Installation .................................................................................................................................................................115
8.2 BIOS Setting.......................................................................................................................................................................................116
8.3 FAQ...................................................................................................................................................................................................117
9Portwell Software Service .................................................................................................................................................................................................... 122
10 Industry Specifications ......................................................................................................................................................................................................... 123
10.1 Industry Specifications.........................................................................................................................................................................123

RUBY-D811-Q370
Copyright © Portwell 2019 RUBY-D811-Q370
User's Guide
5
Preface
This user’s guide provides information about the components, features, connectors and BIOS Setup menus available on the RUBY-D811. This document should
be referred to when designing ATX IMB application. The other reference documents that should be used include the following:
Intel Coffee Lake Design Guide
Intel Coffee Lake Specification
Please contact Portwell Sales Representative for above documents.
Disclaimer
The information contained within this user’s guide, including but not limited to any product specification, is subject to change without notice.
Portwell provides no warranty with regard to this user’s guide or any other information contained herein and hereby expressly disclaims any implied warranties
of merchantability or fitness for any particular purpose with regard to any of the foregoing. Portwell assumes no liability for any damages incurred directly or
indirectly from any technical or typographical errors or omissions contained herein or for discrepancies between the product and the user’s guide. In no event
shall Portwell be liable for any incidental, consequential, special, or exemplary damages, whether based on tort, contract or otherwise, arising out of or in
connection with this user’s guide or any other information contained herein or the use thereof.
Trademarks
Product names, logos, brands, and other trademarks featured or referred to within this User’s guide or the Portwell website, are the property of their respective
trademark holders. These trademark holders are not affiliated with Portwell, our products, or our website.

RUBY-D811-Q370
Copyright © Portwell 2019 RUBY-D811-Q370
User's Guide
6
Warranty
Portwell makes no representation, warranty or guaranty, express or implied regarding the products except its standard form of limited warranty (“Limited
Warranty”). Portwell may in its sole discretion modify its Limited Warranty at any time and from time to time.
Beginning on the date of shipment to its direct customer and continuing for the published warranty period, Portwell represents that the products are new and
warrants that each product failing to function properly under normal use, due to a defect in materials or workmanship or due to non conformance to the agreed
upon specifications, will be repaired or exchanged, at Portwell’s option and expense.
Certification
Portwell is certified to DIN EN ISO 9001:2000 standard.
Technical Support
Portwell technicians and engineers are committed to providing the best possible technical support for our customers so that our products can be easily used and
implemented.
We request that you first visit our website at http://www.portwell.com.tw/support/ for the latest documentation, utilities and drivers, which have been made
available to assist you. If you still require assistance after visiting our website then contact our technical support department by email at
[email protected]for further assistance. Thank you!

RUBY-D811-Q370
Copyright © Portwell 2019 RUBY-D811-Q370
User's Guide
7
1Introduction
RUBY-D811-Q370 based on the Intel® Core™Processor which offers 14nm Hi-K process technology with energy efficient architecture. RUBY-D811 support
dual channels DDR4 Long - DIMM up to 64GB.
Desktop solution is still popular in the market of DVR and Factory Automation which can fulfill most of these applications; therefore, with high performance and
high-end specifications, RUBY-D811 is our first generation Coffee -S chip architecture on ATX IMB line.

RUBY-D811-Q370
Copyright © Portwell 2019 RUBY-D811-Q370
User's Guide
8
2Specifications
Main Processor
◆Intel® Coffee -S Core™i Processors
System Chipset
◆Intel®Q370 Express chipset
System BIOS
◆AMI UEFI BIOS
Main Memory
◆Up to 128GB in 4 slots DDR4 Long-DIMM sockets. Supports dual channel DDR4 2400/2666 MHz
SDRAM
Graphics
◆Controller: Intel® Gfx Gen 9, UHD 630 graphics
◆VGA: Supports VGA up to resolution 1920 x 1200
◆Dual DP: Supports DP up to resolution 4096 x 2304
◆HDMI: Supports HDMI up to resolution 4096 x 2160
Expansion Interface
◆One mini-PCIe socket
◆One M.2 (Key E ) for Wireless
◆One M.2 (Key M) for SSD
◆Two PCIe x16 slot
◆Three PCIe x4 slot
◆Two PCIe x1 slot
SATA Interface
◆Six SATA ports(SATA 6Gb/s)
Input/Output
◆COM Ports: 2x RS-232/422/485 on REAR I/O & 8x RS-232 on board header
◆USB Port: 4x USB 3.0 on REAR I/O, 2x USB 3.0 on board header, 6x USB 2.0 on board header
◆Audio Interface: Line-in / Line-Out / Mic-In
Ethernet
◆Supports dual 10/100/1000 Mbps Ethernet port (s) via PCI Express x1 bus which provides 500 MB/s
data transmission rate
High Drive GPIO
◆One pin-header for GPIO(8bit GPIO )

RUBY-D811-Q370
Copyright © Portwell 2019 RUBY-D811-Q370
User's Guide
9
Mechanical and
environmental specifications
◆Operating temperature: 0 ~ 60° C
◆Storage temperature:-20 ~ 80° C
◆Humidity: 5 ~ 90% non-condensing
◆Power supply voltage: ATX
◆Board size: 304.8mm x 243.8 mm
2.1 Supported Operating Systems
The RUBY-D811 supports the following operating systems.
Windows 10 Enterprise & IOT Enterprise (64b) RS3
Ubuntu, SuSe, Redhat Enterprise 1,2 (Kernel 4.14)
Yocto 2.4 Tool-based Embedded Linux Distribution
Wind River VxWorks 7

RUBY-D811-Q370
Copyright © Portwell 2019 RUBY-D811-Q370
User's Guide
10
2.2 Mechanical Dimensions

RUBY-D811-Q370
Copyright © Portwell 2019 RUBY-D811-Q370
User's Guide
11
2.3 Power Consumption
Test Configuration
CPU Type
Intel® Core™ i7-8700TE CPU @ 3.2GHz
SBC BIOS
Portwell, Inc. RUBY-D811 TEST BIOS (90418T00)
Memory
WARIS UB-DIMM DDR4 2133 16GB
VGA Card
Onboard Intel® UHD Graphics 630
VGA Driver
Intel® UHD Graphics 630 Version: 24.20.100.6286
LAN Card
Onboard Intel® Ethernet Connection(2) I219-LM
LAN Driver
Intel® Ethernet Connection(2) I219-LM Version: 12.13.17.7
LAN Card #2
Onboard Intel® I210AT Gigabit Network Connection
LAN Driver #2
Intel® I210AT Gigabit Network Connection Version: 12.14.7.0
Audio Card
Onboard Realtek ALC887 High Definition Audio
Audio Driver
Realtek ALC887 High Definition Audio Version: 6.0.1.8186
Chipset Driver
Intel® Coffee lake-S Chipset Device Software Version: 10.1.17541
USB 3.0 Driver
Intel® USB 3.0 eXtensible Host Controller Adaptation Driver Version: 6.3.9600.17393
SATA HDD
Intel SSD 256G
Power Supply
FSP460-60PFB 460W / GADIWA 5V/12V DC POWER

RUBY-D811-Q370
Copyright © Portwell 2019 RUBY-D811-Q370
User's Guide
12
Power consumption
ATX:
Item
Power ON
Full Loading 10Min
Full Loading 30Min
CPU +12V
0.98A
2.05A
1.98A
System +12V
0.83A
1.48A
1.26A
System +3.3V
0.55A
0.65A
0.69A
System +5V
1.11A
1.37A
1.34A
System+ Device +12V
0.97A
1.81A
1.56A
System+ Device +5V
1.87A
USB2.0 Loading Test
4.98 V/ 570 mA
2.4 Environmental Specifications
Storage Temperature : -20~80°C
Operation Temperature : 0~60°C
Storage Humidity : 5~90%
Operation Humidity: 10~90%

RUBY-D811-Q370
Copyright © Portwell 2019 RUBY-D811-Q370
User's Guide
13
3Block Diagram

RUBY-D811-Q370
Copyright © Portwell 2019 RUBY-D811-Q370
User's Guide
14
4Hardware Configuration
4.1 Jumpers and Connectors
This chapter indicates jumpers’, headers’ and connectors’ locations. Users may find useful information related to hardware settings in this chapter.

RUBY-D811-Q370
Copyright © Portwell 2019 RUBY-D811-Q370
User's Guide
15
4.2 Jumpers Settings
For users to customize RUBY-D811’s features. In the following sections, Short means covering a jumper cap over jumper pins; Open or N/C (Not Connected)
means removing a jumper cap from jumper pins. Users can refer to Figure 1 for the Jumper allocations.
Jumper Table
The jumper settings are schematically depicted in this manual as follows:
Jumper Function List
1
ATX 12V Power Connector
2
CPU FAN Connector (+12V)
3
24-pin ATX Power Input Connector
4
PWR LOSS Header (PWR_LOSS1)
5
SATA3 Connectors (SATA3_1 ~ SATA3_6)
6
USB3_PWR3 (For USB3_5_6)
7
USB 3.0 Header (USB3_11_12)
8
M.2 Key-M Socket (M2_1)
9
M.2 Key-E Socket (M2_2)
10
System Panel Header
11
COM Port Pin9 PWR Setting Jumpers (For COM Port7~10)
12
COM7, 8, 9, 10 _COM Port Headers

RUBY-D811-Q370
Copyright © Portwell 2019 RUBY-D811-Q370
User's Guide
16
13
ATX/AT Mode Jumper (PWR_JP1)
14
USB 2.0 Headers_ USB2_9_10
15
Clear CMOS Headers_ CLRMOS1
16
USB2_PWR3 (For USB2_9_10)
17
Clear CMOS Headers_ CLRMOS2
18
USB 2.0 Headers_ USB2_7_8
19
USB2_PWR2 (For USB2_7_8)
20
USB 2.0 Headers_ USB2_5_6
21
USB2_PWR1 (For USB2_5_6)
22
COM Port Headers _COM3, 4, 5, 6
23
COM Port Pin9 PWR Setting Jumpers (For COM Port3~6)
24
Printer Port / GPIO Header (LPT_GPIO1)
25
Digital Input / Output Power Select
26
LPC Header
27
Digital Input / Output Default Value Setting (JGPIO_SET1)
28
Front Panel Audio Header
29
SPDIF Header
30
Chassis Intrusion Headers (CI1, CI2)
31
ATX/AT Mode Jumper (SIO_AT1)
32
USB3_PWR1 (For USB3_1_2)
USB3_PWR2 (For USB3_3_4)
33
Audio Jacks

RUBY-D811-Q370
Copyright © Portwell 2019 RUBY-D811-Q370
User's Guide
17
34
Chassis FAN Connector (+12V)
35
Top : RJ45 LAN Port (LAN2)
Bottom : USB 3.0 Ports (USB3_1_2)
36
LAN LED Headers
37
Top : RJ45 LAN Port (LAN1)
Bottom : USB 3.0 Ports (USB3_3_4)
38
COM Port Pin9 PWR Setting Jumpers (For COM Port1~2)
39
Top : COM Port (COM2) (RS232/422/485)*
Bottom : D-Sub Port (VGA1)
40
Top : COM Port (COM1) (RS232/422/485)*
Bottom Right : PS/2 Keyboard/Mouse Port
Bottom Left: HDMI Port (HDMI2)
41
Top : DisplayPort 1
Bottom : DisplayPort 2

RUBY-D811-Q370
Copyright © Portwell 2019 RUBY-D811-Q370
User's Guide
18
1: ATX 12V Power Connector
2: CPU FAN Connector (+12V)
3: 24-pin ATX Power Input Connector
4: PWR LOSS Header (PWR_LOSS1)
Short：Power Loss
Open：no Power Loss

RUBY-D811-Q370
Copyright © Portwell 2019 RUBY-D811-Q370
User's Guide
19
5: SATA3 Connectors (SATA3_1 ~ SATA3_6)
USB Power Setting Jumpers
6 : USB3_PWR3 (For USB3_5_6)
16 : USB2_PWR3 (For USB2_9_10)
19 : USB2_PWR2 (For USB2_7_8)
21 : USB2_PWR1 (For USB2_5_6)
32 : USB3_PWR1 (For USB3_1_2)
1-2：+5V
2-3：+5VSB
7: USB 3.0 Header (USB3_11_12)

RUBY-D811-Q370
Copyright © Portwell 2019 RUBY-D811-Q370
User's Guide
20
8: M.2 Key-M Socket (M2_1) 9: M.2 Key-E Socket (M2_2)
