Portwell RUBY-D812-Q470E User manual

RUBY-D812-Q470E
Copyright © Portwell 2021 RUBY-D812-Q470E User's Guide
1
Industrial ATX Board
Version 1.0
RUBY-D812-Q470E

RUBY-D812-Q470E
Copyright © Portwell 2021 RUBY-D812-Q470E User's Guide
2
Revision History
R1.0
Preliminary

RUBY-D812-Q470E
Copyright © Portwell 2021 RUBY-D812-Q470E User's Guide
3
Contents
1 Introduction .............................................................................................................................................................................................................................. 7
2 Specifications........................................................................................................................................................................................................................... 8
2.1 Supported Operating Systems................................................................................................................................................................................ 9
2.2 Mechanical Dimensions........................................................................................................................................................................................ 10
2.3 Power Consumption ..............................................................................................................................................................................................11
2.4 Environmental Specifications................................................................................................................................................................................ 12
3 Block Diagram........................................................................................................................................................................................................................ 13
4 Hardware Configuration ......................................................................................................................................................................................................... 14
4.1 Jumpers and Connectors...................................................................................................................................................................................... 14
4.2 Jumpers Settings.................................................................................................................................................................................................. 15
5 Signal Descriptions ................................................................................................................................................................................................................ 29
5.1 Watch Dog Signal................................................................................................................................................................................................. 29
5.2 GPIO Signal.......................................................................................................................................................................................................... 32
6 System Resources................................................................................................................................................................................................................. 37
6.1 Intel® Comet Lake -S PCH................................................................................................................................................................................... 37
6.2 Main Memory........................................................................................................................................................................................................ 37
6.3 Installing the Single Board Computer ................................................................................................................................................................... 37
6.3.1 Chipset Component Driver.................................................................................................................................................................................... 38
6.3.2 Intel® UHD Graphics 630 ..................................................................................................................................................................................... 39
6.3.3 Intel LAN I2225V / I219LM Gigabit Ethernet Controller......................................................................................................................................... 39

RUBY-D812-Q470E
Copyright © Portwell 2021 RUBY-D812-Q470E User's Guide
4
7 BIOS Setup Items .................................................................................................................................................................................................................. 40
7.1 Introduction........................................................................................................................................................................................................... 40
7.2 BIOS Setup........................................................................................................................................................................................................... 40
7.2.1 Main ....................................................................................................................................................................................................................... 42
7.2.2 Advanced ............................................................................................................................................................................................................... 43
7.2.3 H/W Monitor ............................................................................................................................................................................................................. 85
7.2.4 Security .................................................................................................................................................................................................................... 88
Secure Boot........................................................................................................................................................................................................................... 89
Key Management .................................................................................................................................................................................................................. 90
7.2.5 Boot.......................................................................................................................................................................................................................... 91
7.2.6 Exit ......................................................................................................................................................................................................................... 93
8 Troubleshooting ..................................................................................................................................................................................................................... 94
8.1 Hardware Quick Installation.................................................................................................................................................................................. 94
8.2 BIOS Setting......................................................................................................................................................................................................... 95
8.3 FAQ ...................................................................................................................................................................................................................... 96
9 Portwell Software Service .................................................................................................................................................................................................... 102
10 Industry Specifications ......................................................................................................................................................................................................... 103
10.1 Industry Specifications........................................................................................................................................................................................ 103

RUBY-D812-Q470E
Copyright © Portwell 2021 RUBY-D812-Q470E User's Guide
5
Preface
This user’s guide provides information about the components, features, connectors and BIOS Setup menus available on the RUBY-D812. This document should
be referred to when designing ATX IMB application. The other reference documents that should be used include the following:
Intel Comet Lake Design Guide
Intel Comet Lake Specification
Please contact Portwell Sales Representative for above documents.
Disclaimer
The information contained within this user’s guide, including but not limited to any product specification, is subject to change without notice.
Portwell provides no warranty with regard to this user’s guide or any other information contained herein and hereby expressly disclaims any implied warranties
of merchantability or fitness for any particular purpose with regard to any of the foregoing. Portwell assumes no liability for any damages incurred directly or
indirectly from any technical or typographical errors or omissions contained herein or for discrepancies between the product and the user’s guide. In no event
shall Portwell be liable for any incidental, consequential, special, or exemplary damages, whether based on tort, contract or otherwise, arising out of or in
connection with this user’s guide or any other information contained herein or the use thereof.
Trademarks
Product names, logos, brands, and other trademarks featured or referred to within this User’s guide or the Portwell website, are the property of their respective
trademark holders. These trademark holders are not affiliated with Portwell, our products, or our website.

RUBY-D812-Q470E
Copyright © Portwell 2021 RUBY-D812-Q470E User's Guide
6
Warranty
Portwell makes no representation, warranty or guaranty, express or implied regarding the products except its standard form of limited warranty (“Limited
Warranty”). Portwell may in its sole discretion modify its Limited Warranty at any time and from time to time.
Beginning on the date of shipment to its direct customer and continuing for the published warranty period, Portwell represents that the products are new and
warrants that each product failing to function properly under normal use, due to a defect in materials or workmanship or due to non conformance to the agreed
upon specifications, will be repaired or exchanged, at Portwell’s option and expense.
Certification
Portwell is certified to DIN EN ISO 9001:2000 standard.
Technical Support
Portwell technicians and engineers are committed to providing the best possible technical support for our customers so that our products can be easily used and
implemented.
We request that you first visit our website at http://www.portwell.com.tw/support/ for the latest documentation, utilities and drivers, which have been made
available to assist you. If you still require assistance after visiting our website then contact our technical support department by email at
[email protected]for further assistance. Thank you!

RUBY-D812-Q470E
Copyright © Portwell 2021 RUBY-D812-Q470E User's Guide
7
1Introduction
RUBY-D812-Q470E based on the Intel® Core™Processor which offers 14nm Hi-K process technology with energy efficient architecture. RUBY-D812 support
dual channels DDR4 Long - DIMM up to 128GB.
Desktop solution is still popular in the market of DVR and Factory Automation which can fulfill most of these applications; therefore, with high performance and
high-end specifications, RUBY-D812 is our first generation Comet -S chip architecture on ATX IMB line.

RUBY-D812-Q470E
Copyright © Portwell 2021 RUBY-D812-Q470E User's Guide
8
2Specifications
Main Processor
◆Intel® Comet -S Core™i Processors
System Chipset
◆Intel®Q470E Express chipset
System BIOS
◆AMI UEFI BIOS
Main Memory
◆Up to 128GB in 4 slots DDR4 Long-DIMM sockets. Supports dual channel DDR4 2400/2666/2933 MHz
SDRAM
Graphics
◆Controller: Intel® Gfx Gen 9, UHD 630 graphics
◆VGA: Supports VGA up to resolution 1920 x 1200
◆Dual DP: Supports DP up to resolution 4096 x 2160
◆HDMI: Supports HDMI up to resolution 4096 x 2160
Expansion Interface
◆One SIM slot
◆One M.2 (Key E_2230) for Wireless(PCIe x1 / USD2.0)
◆One M.2 (Key M_2242/2260/2280) for SSD(PCIe x4 / SATA)
◆One M.2 (Key B_3042/3052, 2260/2280) for Wireless(PCIe x1 / USB3.2 Gen1 / USD2.0)
◆Two PCIe x16 slot(1 x16 mode / 2 x8 mode)
◆Three PCIe x4 slot
◆Two PCI slot
SATA Interface
◆Six SATA ports(SATA 6Gb/s)
*If install M.2 PCIe x4/ SATA SSD on M.2 M key slot, 2/ 1 SATA port will be disabled
Input/Output
◆COM Ports: 2x RS-232/422/485 (one on REAR I/O, one on board header)，4x RS-232 on board header
◆USB Port: 4x USB 3.2 Gen2(3 x type A, 1 x Type C), 1 x Header support additional 2 x USB3.2 Gen1
connectors & 1 x Header support additional 2 x USB2.0 connectors & 2 x Vertical connector
◆Audio Interface: Line-in / Line-Out / Mic-In

RUBY-D812-Q470E
Copyright © Portwell 2021 RUBY-D812-Q470E User's Guide
9
Ethernet
◆Supports one 10/100/1000 Mbps Ethernet port (s) via PCI Express x1 bus
◆Supports one 10/100/1000/2500 Mbps Ethernet port (s) via PCI Express x1 bus
High Drive GPIO
◆One pin-header for GPIO(8bit GPIO )
Mechanical and
environmental specifications
◆Operating temperature: 0 ~ 60° C
◆Storage temperature:-20 ~ 80° C
◆Humidity: 15 ~ 95% non-condensing
◆Power supply voltage: ATX
◆Board size: 304.8mm x 243.8 mm
2.1 Supported Operating Systems
The RUBY-D812 supports the following operating systems.
Windows* 10 IOT Enterprise RS51(64-bit)
Ubuntu, SuSe, Redhat Enterprise 1,2 (Kernel 4.14)
Yocto Project* BSP tool-based embedded Linux distribution1 (64-bit)
Wind River VxWorks 7.0

RUBY-D812-Q470E
Copyright © Portwell 2021 RUBY-D812-Q470E User's Guide
10
2.2 Mechanical Dimensions

RUBY-D812-Q470E
Copyright © Portwell 2021 RUBY-D812-Q470E User's Guide
11
2.3 Power Consumption
Test Configuration
CPU Type
Intel® Core™ i9-10900TE CPU @ 1.8GHz
SBC BIOS
Portwell, Inc. RUBY-D812 TEST BIOS (0.04.00)
Memory
WARIS UB-DIMM DDR4 2133 16GB
VGA Card
Onboard Intel® UHD Graphics 630
VGA Driver
Intel® UHD Graphics 630 ver:26.20.100.7926_Q0
LAN Card
Onboard Intel® Ethernet Connection I219-LM
LAN Driver
Intel® Ethernet Connection I219-LM Version: 12.18.9.23
LAN Card #2
Onboard Intel® I225V Gigabit Network Connection
LAN Driver #2
Intel® I225V Gigabit Network Connection Version: 26.4
Audio Card
Onboard Realtek ALC897 High Definition Audio
Audio Driver
Realtek ALC897 High Definition Audio Version: 6.0.9222.1
Chipset Driver
Intel® Comet lake-S Chipset Device Software Version:3.1.7.142
USB 3.0 Driver
Intel® USB 3.0 eXtensible Host Controller Adaptation Driver
SATA HDD
Intel SSD 256G
Power Supply
FSP460-60PFB 460W / GADIWA 5V/12V DC POWER

RUBY-D812-Q470E
Copyright © Portwell 2021 RUBY-D812-Q470E User's Guide
12
Power consumption
ATX:
Item
Power ON
Full Loading 10Min
Full Loading 30Min
CPU +12V
0.98A
2.05A
1.98A
System +12V
0.83A
1.48A
1.26A
System +3.3V
0.55A
0.65A
0.69A
System +5V
1.11A
1.37A
1.34A
System+ Device +12V
0.97A
1.81A
1.56A
System+ Device +5V
1.87A
USB2.0 Loading Test
4.98 V/ 570 mA
2.4 Environmental Specifications
Storage Temperature : -20~80°C
Operation Temperature : 0~60°C
Storage Humidity : 15~95%
Operation Humidity: 10~90%

RUBY-D812-Q470E
Copyright © Portwell 2021 RUBY-D812-Q470E User's Guide
13
3Block Diagram

RUBY-D812-Q470E
Copyright © Portwell 2021 RUBY-D812-Q470E User's Guide
14
4Hardware Configuration
4.1 Jumpers and Connectors
This chapter indicates jumpers’, headers’ and connectors’ locations. Users may find useful information related to hardware settings in this chapter.

RUBY-D812-Q470E
Copyright © Portwell 2021 RUBY-D812-Q470E User's Guide
15
4.2 Jumpers Settings
For users to customize RUBY-D812’s features. In the following sections, Short means covering a jumper cap over jumper pins; Open or N/C (Not Connected)
means removing a jumper cap from jumper pins. Users can refer to Figure 1 for the Jumper allocations.
Jumper Table
The jumper settings are schematically depicted in this manual as follows:
Jumper Function List
1
COM RING/+5V/+12V selection jumper (6-pin COM1_SEL)
2
EATX Power connectors (24-pin EATXPWR, 8-pin EATX12V)
3
CPU and Chassis Fan headers (4-pin CPU_FAN, 4-pin CHA_FAN1/2/3)
4
Intel® LGA1200 CPU socket
5
M.2 socket 3 (M.2_PCH_(SKT3))
6
DDR4 DIMM slots
7
USB 2.0 connectors / header (USB_INTERNAL_12, USB_INTERNAL_13,
USB1011)
8
USB 3.2 Gen 1 header (20-1 pin U32G1_67)
9
M.2 socket 2 (M.2_PCH_(SKT2))
10
TPM header (14-1 pin TPM)
11
SATA 6.0Gb/s ports (7-pin SATA6G_1-6)

RUBY-D812-Q470E
Copyright © Portwell 2021 RUBY-D812-Q470E User's Guide
16
12
M.2 Wi-Fi
13
I2C header (6-pin I2C)
14
General Purpose Input/Output header (10-pin GPIO_CON)
15
System Panel header (10-1 pin F_PANEL)
16
Chassis Intrusion header (4-1 pin CHASSIS)
17
Speaker header (4-pin SPEAKER)
18
Disable ME jumper (3-pin DIS_ME)
19
LPC Debug header (10-1 pin LPC_DEBUG)
20
COM Port headers (10-1 pin COM2, COM3, COM4, COM5, COM6)
21
AT/ATX Mode selection jumper (3-pin AT_ATX_SEL)
22
WDT Enable jumper (2-pin WDT_EN)
23
LPT header (26-1 pin LPT)
24
Front Panel Audio header (10-1 pin AAFP)
25
Clear CMOS header (2-pin CLRTC)
26
PCI slots
27
Digital Audio header (4-1 pin SPDIF_OUT)
28
PCI Express 3.0/2.0 x4 slots
29
PCI Express 3.0/2.0 x16 slots

RUBY-D812-Q470E
Copyright © Portwell 2021 RUBY-D812-Q470E User's Guide
17
1: COM RING/+5V/+12V selection jumper (6-pin COM1_SEL)
PIN No.
Description
1-2(Short)
+12V
2-3(Short)
+5V
5-6(Short)
★RI (Default)

RUBY-D812-Q470E
Copyright © Portwell 2021 RUBY-D812-Q470E User's Guide
18
2: EATX Power connectors (24-pin EATXPWR, 8-pin EATX12V)

RUBY-D812-Q470E
Copyright © Portwell 2021 RUBY-D812-Q470E User's Guide
19
3: CPU and Chassis Fan headers (4-pin CPU_FAN, 4-pin CHA_FAN1/2/3)
5: M.2 socket 3 (M.2_PCH_(SKT3))
•The M.2 SSD module is purchased separately.
•This socket supports M Key and 2242/2260/2280 storage devices

RUBY-D812-Q470E
Copyright © Portwell 2021 RUBY-D812-Q470E User's Guide
20
7: USB 2.0 connectors / header (USB_INTERNAL_12, USB_INTERNAL_13, USB1011)
NOTE: These Universal Serial Bus (USB) ports / header are for USB 2.0 devices
8: USB 3.2 Gen 1 header (20-1 pin U32G1_67)
