POS-X EVO-RP1 User manual

1
1-866-468-5767 or 201-928-0222 International Point of Sale
POS-X EVO-RP1 Receipt Printer Installation instruction
Corner Store POS supports the POS-X EVO-RP1 Receipt printer. This detailed guide will instruct you how
to install the drivers needed for the Printer to work with Corner Store POS.

2
1-866-468-5767 or 201-928-0222 International Point of Sale
Installation Instruction for POSx Printer
Download the driver for the POS-X EVO-RP1printer:
http://cornerstorepos.com/downloads/hardware/POSX_EVO_RP1_OPOSDriver.exe
Step 1: Open the setup by double clicking on it, click Run.
Step 2: Click Next

3
1-866-468-5767 or 201-928-0222 International Point of Sale
Step 3: Click Next
Step 4: Click Next.

4
1-866-468-5767 or 201-928-0222 International Point of Sale
Step 5: Click Finish.
If the next window does not open automatically, please go to Start -> All Programs -> OLE OPOS 2.81->
Setup POS and open it.

5
1-866-468-5767 or 201-928-0222 International Point of Sale
Step 6: Select POSPrinter, then select Add New Device. For name select Thermal. For Device Type
select ThermalU. Click OK.
Step 7: Select Add New LDN and type printer, click OK.

6
1-866-468-5767 or 201-928-0222 International Point of Sale
Step 8: Select Device Details, click Printer Test and Setting.
Step 9: Click Printer Test, you should get a success message. Click OK then close.

7
1-866-468-5767 or 201-928-0222 International Point of Sale
Step 10: Click on CashDrawer and click Add New Device. Under New Device select Standard. Under
Device Type select StandardU. Click OK.
Step 11: Click Add New LDN, type drawer, click OK.

8
1-866-468-5767 or 201-928-0222 International Point of Sale
Step 12: Click Device Details, then click Printer Test and Setting.
Step 13: Under Pin No: please select 5. Then select printer test. There should be a success message, click
close then OK.

9
1-866-468-5767 or 201-928-0222 International Point of Sale
Open Up CornerStore POS and go to the Setup Menu. Click on Hardware Setup.
Select Receipt under type then the ThermalU printer. Select the rest of the fields depending on your
store’s needs.

10
1-866-468-5767 or 201-928-0222 International Point of Sale
Go to the Cash Drawers tab, and select the StandardU cash drawer. Select Save & Exit.
You can now use your POSX printer and Cash Drawer with Corner Store POS!
