POSBank A10plus Installation manual

A10plus Receipt Printer
Command Reference Manual
Rev. 1.50

- 2 -
Rev. 1.50
A10plus MiniPrinter
CONFIDENTIAL
1. Control Commands List
Command
Hex. codes
Function
Function
type
Classfication
Executing
Cmds
Setting
Cmds
<HT>
09
Horizontal tab
Print position
○
<LF>
0A
Print and line feed
Print
○
<FF>
0C
Print and return to standard mode (in page mode)
Print
○
<CR>
0D
Print and carriage return
Print
○
<CAN>
18
Cancel print data in page mode
Character
○
<DLE> <EOT>
10 04 n
Transmit real-time status
Status
○
<SYN>
16 n
Turn melody on/off
Miscellaneous function
○
<ESC> <FF>
1B 0C
Print data in page mode
Print
○
<ESC> <SP>
1B 20 n
Set right-side character spacing
Character
○
<ESC> !
1B 21 n
Select print mode(s)
Character
○
<ESC> $
1B 24 nL nH
Set absolute print position
Print position
○
<ESC> %
1B 25 n
Select/cancel user-defined character set
Character
○
<ESC> &
1B 26 y c1 c2
Define user-defined characters
Character
○
<ESC> *
1B 2A m nL nH
Select bit-image mode
Bit image
○
<ESC> -
1B 2D n
Turn underline mode on/off
Character
○
<ESC> 2
1B 32
Select default line spacing
Line spacing
○
<ESC> 3
1B 33 n
Set line spacing
Line spacing
○
<ESC> =
1B 3D n
Select peripheral device
Miscellaneous function
○
<ESC> ?
1B 3F n
Cancel user-defined characters
Character
○
<ESC> @
1B 40
Initialize printer
Miscellaneous function
○
○
<ESC> D
1B 44 … 00
Set horizontal tab positions
Print position
○
<ESC> E
1B 45 n
Turn emphasized mode on/off
Character
○
<ESC> G
1B 47 n
Turn double-strike mode on/off
Character
○

- 3 -
Rev. 1.50
A10plus MiniPrinter
CONFIDENTIAL
<ESC> J
1B 4A n
Print and feed paper
Print
○
<ESC> L
1B 4C
Select page mode
Miscellaneous function
○
<ESC> M
1B 4D n
Select character fonts
Character
○
<ESC> R
1B 52 n
Select an international character set
Character
○
<ESC> S
1B 53
Select standard mode
Miscellaneous function
○
<ESC> T
1B 54 n
Select print direction in page mode
Print position
○
<ESC> V
1B 56 n
Turn 90°clockwise rotation mode on/off
Character
○
<ESC> W
1B 57
Set print area in page mode
Print position
○
<ESC>＼
1B 5C n
Set relative print position
Print position
○
<ESC> a
1B 61 n
Select justification
Print position
○
<ESC> d
1B 64 n
Print and feed n lines
Print
○
<ESC> i
1B 69
Partial cut (one point left uncut)
Mechanism control
○
<ESC> m
1B 6D
Partial cut (three points left uncut)
Mechanism control
○
<ESC> p
1B 70 m t1 t2
Generate pulse
Miscellaneous function
○
<ESC> t
1B 74
Select character code table
Character
○
<ESC> {
1B 7B n
Turn upside-down print mode on/off
Character
○
<FS> p
1C 70 n m
Print NV bit image
Bit image
○
<FS> q
1C 71 n …
Define NV bit image
Bit image
○
<GS> !
1D 21 n
Select character size
Character
○
<GS> $
1D 24 nL nH
Set absolute vertical print position in page mode
Print position
○
<GS> ( k
1D 28 6B …
QR Code printing control
Miscellaneous Commands
○
<GS> *
1D 2A x y …..
Define downloaded bit image
Bit image
○
<GS> /
1D 2F n
Print downloaded bit image
Bit image
○
<GS> B
1D 42 n
Turn white/black reverse print mode on/off
Character
○
<GS> H
1D 48 n
Select print position of HRI characters
Bar code
○
<GS> I
1D 49 n
Transmit printer ID.
Status
○
<GS> L
1D 4C nL nH
Set left margin
Print position
○

- 4 -
Rev. 1.50
A10plus MiniPrinter
CONFIDENTIAL
<GS> P
1D 50 x y
Set horizontal and vertical motion units
Miscellaneous function
○
<GS> V
1D 56 m
1D 56 m n
Select cut mode and cut paper
Mechanism control
○
<GS> W
1D 57 nL nH
Set print area width
Print position
○
<GS> \
1D 5C nL nH
Set relative vertical print position in page
mode
Print position
○
<GS> a
1D 61 n
Enable/Disable Automatic status back(ASB)
Status
○
<GS> f
1D 66 n
Select font for HRI characters
Bar code
○
<GS> h
1D 68 n
Set bar code height
Bar code
○
<GS> k
1D 6B m … NUL
1D 6B m n …
Print bar code
Bar code
○
<GS> r
1D 72 n
Transmit status
Status
○
<GS> v
1D 76 30
Print raster bit image
Bit image
○
<GS> w
1D 77 n
Set bar code width
Bar code
○
Black Mark Function Command
<FF>
0C
Print and recover to page mode
Black Mark
○
<GS> <FF>
1D 0C
Top of form of mark paper
Black Mark
○
<GS> V
1D 56 m
1D 56 m n
Paper Cut Position Feed
Black Mark
○
<GS> <
1D 3C
Mechanically initialize printer
Black Mark
○
<GS> A
1D 41 m n
Marked Paper Form Feed Position Correct
Black Mark
○
<GS> ( F
1D 28 46 pL pH
a m nL nH
Set black mark adjustment value
Black Mark
○
<GS> ( M
1D 28 4D pL pH
n m
Save black mark adjustment value.
Load black mark adjustment value.
Set black mark adjustment value auto-load when
powering on.
Black Mark
○

- 5 -
Rev. 1.50
A10plus MiniPrinter
CONFIDENTIAL
2. Control Command Details
Command
Description
HT
[Name] Horizontal tab
[Format] ASCII HT
Hex 09
Decimal 9
[Range] None
[Default] None
[Printers not featuring this command]
None
[Description]
Moves the print position to the next horizontal tab position.
[Notes]
■ This command is ignored unless the next horizontal tab position has been set.
■ Horizontal tab positions are set by ESC D.
■ If the next horizontal tab position exceeds the print area, the printer sets the print position
to [Print area width + 1].
■ If this command is processed when the print position is at [Print area width + 1],
the printer executes print
buffer-full printing of the current line and horizontal tab processing from the beginning of the
next line.
In this case, in page mode, the printer does not execute printing, but the print position is moved.
■ When underline mode is turned on, the underline will not be printed under the tab space
skipped by this command.

- 6 -
Rev. 1.50
A10plus MiniPrinter
CONFIDENTIAL
LF
[Name] Print and line feed
[Format] ASCII LF
Hex 0A
Decimal 10
[Range] None
[Default] None
[Printers not featuring this command]
None
[Description]
Prints the data in the print buffer and feeds one line, based on the current line spacing.
[Notes]
■ The amount of paper fed per line is based on the value set using the line spacing
command (ESC 2 or ESC 3).
■ After printing, the print position moves to the beginning of the line. When a left margin
is set in standard mode, the position of the left margin is the beginning of the line.
■ When this command is processed in page mode, only the print position moves,
and the printer does not perform actual printing.

- 7 -
Rev. 1.50
A10plus MiniPrinter
CONFIDENTIAL
FF(page)
[Name] Print and return to standard mode (in page mode)
[Format] ASCII FF
Hex 0C
Decimal 12
[Default] None
[Range] None
[Description] In page mode, prints all the data in the print buffer collectively and switches from
page mode to standard mode.
[Notes]
■ This command is enabled only in page mode. See FF (in standard mode) to use this
command in standard mode. Page mode can be selected by ESC L or FS L.
■ The data is deleted in the print area after being printed.
■ This command returns the values set by ESC W to the default values.
■ The value set by ESC T is maintained.
■ After printing, the print position moves to the beginning of the line.
When a left margin is set, the position of the left margin is the beginning of the line.

- 8 -
Rev. 1.50
A10plus MiniPrinter
CONFIDENTIAL
CR
[Name] Print and carriage return
[Format] ASCII CR
Hex 0D
Decimal 13
[Description] Executes one of the following operations.
Print head
When auto line feed is enabled
When auto line feed is disabled
Line
thermal
Executes printing and one line
feed as LF
This command is ignored
Serial dot
head
Executes printing and one line
feed as LF
In standard mode, prints the data in the
print buffer and moves the print position
to the beginning of the print line.
In page mode, moves the print position
to the beginning of the print line.
[Notes] ■ With a serial interface, the command performs as if auto line feed is disabled.
■ After printing, the print position moves to the beginning of the line.
When a left margin is set in standard mode, the position of the left margin is the beginning of the
line.
■ When this command is processed in page mode, only the print position moves,
and the printer does not perform actual printing.

- 9 -
Rev. 1.50
A10plus MiniPrinter
CONFIDENTIAL
CAN
[Name] Cancel print data in page mode
[Format] ASCII CAN
Hex 18
Decimal 24
[Range] None
[Default] None
[Description] In page mode, deletes all the print data in the current print area.
[Notes] ■ This command is enabled only in page mode. Page mode is selected by ESC L.
■ If data set in the previously specified print area is set in the currently specified print area,
it is deleted.

- 10 -
Rev. 1.50
A10plus MiniPrinter
CONFIDENTIAL
DLE EOT n
[Name] Transmit real-time status
[Format] ASCII DLE EOT n
Hex 10 04 n
Decimal 16 4 n
[Range] 1 ≤ n ≤ 4
[Description] Transmits the real-time status, using n as follows:
n
Function
1
Transmit printer status
2
Transmit offline status
3
Transmit error status
4
Transmit roll paper sensor status
[Notes]
■ This is a real-time command that the printer executes upon receiving it.
Take the following into consideration:
• If this command interrupts the code string of another command, this command is
processed as a parameter of the other command; therefore, the print result will not be
correct.
• If a command such as graphics data or defined data has a code string that is
the same as a code string in a parameter, the printer processes and then continues with
the bit-image or other command.
■ With a serial interface model, this command is executed even when the printer is offline, the
receive buffer is full, or an error occurs.
■ With a parallel interface model, this command is not executed in the following conditions,
because the printer is busy and unable to receive data from the host computer.
■ This command can be used when the printer is disabled by ESC =.
■ This command is ignored when transmitting block data (Header ~ NUL).
■ Each status equals 1 byte.
