POSIFLEX SA-304 User manual

1
Package Contents
Magnetic Stripe Reader
(SA-304 for XT-3114)
(SA-305 for XT-3015/4015)
(SL-305 for TM/LM-3X15 series)
2 Fixing Screws
Printed Quick Installation Guide
Peripheral Information CD
(shipped with SL-305 only)
RFID Mifare Card (Optional)
RFID Ring Tag (Optional)
Views of the Magnetic Stripe Reader
Front View Right Side View
SA-304/305_SL-305
Fanfree LCD Touch Terminal
Quick Installation Guide
USB I/O Cable
3-track Magnetic Stripe Reader
RFID Mifare Card Reader
(Optional)
Fingerprint Sensor
with Status LED Indicator
(Optional)
18600901020 Ver. A0
http://www.posiflex.com

2
Hardware Installation
During Installation of the SA-304/305 and SL-305, do NOT power ON your
terminal and monitor.
Installation of SA-304 onto the 14” XT Series Terminals
(except XT-2614E)
Start to install SA-304 onto according to the following steps.
1. Loosen and remove the two fixing screws
from the side mount cover on the back of
the right side of the terminal.
2. Remove the side mount cover from the back
of the right side of the terminal.
3. Insert the USB IO cable of the SA-304 into
the cable connector of the main board.
4. Determine whether the cable is well
connected to the cable connector. Then,
push the cable into a space between the rear
cover and the mainboard.

3
5. Align the two screw holes of the SA-304
MSR cover with the two fixing holes of the
terminal.
6. Fix the SA-304 MSR onto the terminal by
locking two long screws shipped with the
package.
7. The installation of SA-304 onto the terminal
is completed, as shown in the right figure.
Installation of SA-305 onto the 15”/17” XT Series Terminals
Start to install SA-305 onto the terminal according to the following steps.
1. Loosen and remove the two fixing screws
from the side mount cover on the back of
the right side of the terminal.

4
2. Remove the side mount cover A from the
back of the right side of the terminal.
3. Remove the side mount cover B from the
terminal.
4. Insert the USB IO cable of the SA-305 into
the cable connector of the main board.
If the SA-305 is provided with two USB IO
cables for two types of readers, you can
connect the IO cables to the two cable
connector of the main board.
5. Determine that the USB IO cable is securely
connected to the cable connector of the
main board.
Cover A
Cover B

5
6. Put the large side mount cover back in
place.
7. Move the USB IO cable to the middle, as
shown in the right figure.
8. Align the two screw holes of the SA-305
MSR cover with the two screw holes on the
terminal.
9. Fix the SA-305 MSR onto the terminal by
locking the two long screws shipped with
the package.
10. The installation of SA-305 onto the terminal
is completed, as shown in the right figure.

6
Installation of SL-305 onto TM/LM-3X15 Series Monitor
1. Loosen and remove the two fixing screws
from the side mount cover on the back of
the right side of the TM/LM-3X15 series
monitor.
2. Remove the side mount cover from the back
of the right side of the TM/LM-3X15 series
monitor.
3. Insert the USB IO cable of the SL-305 into
the cable connector of the main board.
4. Determine whether the USB IO cable of
SL-305 is well connected to the cable
connector of the main board. Then, push the
connected cable into a space between the
rear cover and the mainboard.
5. Align the two screw holes of the SL-305
MSR cover with the two fixing holes of the
LM/TM-3X15, and then fix the SL-305
MSR onto the TM/LM-3X15 series monitor
by locking two long screws shipped with
the package.

7
6. The installation of SL-305 onto the
TM/LM-3X15 series monitor is completed,
as shown in the right figure.
7. Connect the B-type USB port and VGA port
of the TM/LM-3X15 through a USB cable
and a VGA cable to the A-type USB port
and VGA port of a Posiflex terminal,
respectively.
Driver Installation and Utility Outline
Before installing the drivers of the SA-304/305 and SL-305, after installing the
SA-304/305 and SL-305, power on your terminal and monitor. If your terminal
is a Posiflex XT series terminal of which the OS is pre-loaded, you can find
the drivers and utilities for SA-304/305 from the “Drivers” folder in the Local
Disk (C:) and then double click the executing file to install or directly open.
For SL-305 working with the TM/LM-3X15 series monitor, insert the
Peripheral Information CD, shipped with the SL-305 package, into your CD-
ROM for driver and utility installation.
Installing the Posiflex USB MSR Manager
1. If your MSR is SL-305, please insert the
information CD, you will see the menu
as shown in the right figure, and left
click “Peripheral Drivers & Utilities”.
2. Left click “SD/SA Series” at the left
side of the menu.
3. Left click the Setup logo at the row
of USB MSR Manager to install the
reader driver.

8
4. Then, follow the step-by-step instructive messages to complete the
driver installation.
5. After completion of the driver installation, restart your terminal.
6. Left click Start Programs Posiflex Tools Posiflex USB
MSR Manager.
7. Then, the Posiflex USB MSR Manager appears .
Installing the USB MSR Virtual COM Driver for Posiflex USB MSR
You can install the virtual COM port (VCP) driver when you would like the
USB device to appear as an additional COM port available to the PC.
(Application software can access the USB device in the same way as it
would access a standard COM port.)
1. Left click Start Programs Posiflex Tools Posiflex USB
MSR Manager.
2. The Posiflex USB MSR Manager
appears, as shown in the right
figure. Then, tick off on virtual
COM port interface.
3. Left click the Setup logo at the row of USB MSR Virtual COM
Driver to install the virtual COM driver.
4. Then, follow the step-by-step instructive messages to complete the
driver installation.
5. After completion of the driver installation, restart your terminal.

9
Installing the Fingerprint Driver
(for Optional Fingerprint Model Only)
1. Left click the Setup logo at the row of FP-200 Device Driver to
install the fingerprint driver.
2. Then, follow the step-by-step instructive messages to complete the
driver installation.
3. After completion of the driver installation, restart your terminal.
Installing the RFID Setup Tool
(for Optional RFID Model Only)
1. Left click the Setup logo at the row of RF-3X0 Setup Tools to
install the RFID setup tools.
2. Then, follow the step-by-step instructive messages to complete the
tool installation.
3. After completion of the tool installation, restart your terminal.
4. Left click the RFID setup tools icon and then the tool appears.
Operation of the Magnetic Stripe Reader
After installing the drivers and tools, you can start to operate the SA-304/305
and SL-305 models.
MSR
1. Keep the magnetic stripe of the card facing the arrow
head circled in the picture above.
2. Move the magnetic stripe card along the track of the
reader from top to bottom or from bottom to top in the
direction of the arrow.
or

10
RFID Reader (Optional)
Set the Mifare card against the proximity area for making the RFID reader to
read the card.
Fingerprinter (Optional)
Keep your thumb close to the fingerprinter reading area to
allow the fingerprinter sensor to read your thumb
fingerprint.
Checking the LED status:
Standby status: solid blue
Reading Status: solid blue and solid red
(The red LED will be off after around 2 seconds.)
To get the detailed information on SA ※
※※
※ -304/305 and SL-305, please
download the technical manual of this model from Posiflex Global
Website (http://www.posiflex.com/en-global/Download/download).
Reading
Area
