Seuic AutoID 6L-W User manual

6 1 2
JIANGSU SEUIC TECHNOLOGY CO.,LTD Install battery and battery cover
Take out the device and battery from the package. Install the battery
and battery cover according to Picture 2.
First use
For the first time, please make sure the battery, has enough power
supply for the system to boost.
Power on
Long press power key until PDA vibrates to power on the device.
Charging
The device could be charged through USB cable with power adapter.
USB cable: Connect the PDA to the power socket using an USB data
cable and a power adapter, or connect the PDA to the computer via
the USB data cable. Red indicator of PDA means under charging, green
one means full charged.
Note：If the device will not used for a long time, please charge the
device at least once every two months to ensure the battery and backup
battery won't over discharge.
Install SIM card and SD card
Remove the battery, and insert SIM card into the right card slot
(Note：The terminal does not support small card), the lower-left side is
PSAM slot, insert it according to the direction of the slot. The top-left
side is a memory card slot, insert it according to the direction of the slot.
(Note：The terminal does not support SIM card hot plug, need to restart
terminal after accident hot plug).
Power off
Long press the power button for more than 5 seconds, when the
indicator light on the top right of the terminal is extinguished, terminal
shuts down.
Power on/off
Scan indicator Power indicator
Flash light
Camera
Loud speaker
Scan engine
Memery card
slot
SIM card slot
PSAM card slot
USB port
ESC key Scan button
Rest key
Hard keyboard
Battery cover lock
Hard keyboard
switch
Microphone
Custom key
（Picture 1） （Picture 2）
（Picture 3）
Apply series： 6L W
Technical Support
Please visit SEUIC’ s official website www.chinaautoid.net to
download User Manual, SDK, different Apps or software in order
to help you better use the device.
2017 SEUIC Company. All rights reserved.
It is strictly prohibited to copy, transfer, distribute and store any
content in the document in any form without the SEUIC's
permission.
JIANGSU SEUIC TECHNOLOGY CO.,LTD
Company address: NO.15 Xinghuo Road,Nanjing New High
Technology Industry Zone,Nanjing City,Jiangsu Province, China
Hotline: [phone]
Company official website:www.seuic.com
Products official website: www.chinaautoid.net
Mailbox: [email protected]
Post code: 210061
Do not throw away : Apply to some electronic components,
such as battery, etc., some components may cause an explosion,
pollution or other adverse consequences to the environment,
and should be used for recycling.
Environmental protection life span mark: The number in this
logo means that the normal environmental protection life span
is 10 years, harmful substances or elements contained in the
product during this period will not be disclosed, will not cause
serious pollution to the environment or its personal, property
damage. Some parts may also have environmental protection
use period logo, its environmental protection service life is
identified by the number.
®
QUICK START GUIDE

Common functions
Connect with PC
Barcode scanning
Wi-Fi connection
Charge the Battery
34 5
Bettery
Indicator light
Micro USB connect
（Picture 4:sigle slot bettery charger）
Place the battery on the charging dock and connect to the power supply.
Red indicator of the charging dock means under charging; green one
means full charged.
Connect your PDA with PC via USB cable.
SEUIC’s scan tool or customers’ scan tool applications are optional
to scan the barcodes.
Frequently Asked Questions：
1.There is no light when scanning.
Problem shooting: please make sure whether the scan engine is closed,
if closed, please go to the settings of scan tool to open it.
2. One scanning results in two barcodes.
Problem shooting: please confirm whether the built-in scan tool and
client’s application are opened simultaneously first. If yes, close the
built-in scan tool and set “not automatically open when power on”
.
2. Enable it to open WLAN connection.
3. Under the taskbar, click WIFI manager icon, select Wireless Information,
PDA will search and list available WLAN.
4. Select the WLAN you want to connect to, and then click Connect.
If you select an encrypted network, you need to enter a password to
connect.
Note：If you open the WLAN connection and the mobile network
data connection at the same time, the priority connection is WLAN. If the
mobile network data connection is available after the WLAN connection is
interrupted, the system will prompt you to use the mobile network to
provide data services.
Attention
1. Do not soak USB port of PDA into water.
2. Do not use full ROM, otherwise it will cause system exception.
3. Please close 2D scan engine when you don’t use it, not to keep it
open for a long time.
4. Please do not directly look into the light beam of scan engine during
scanning in order to avoid injury.
5. Please first connect the USB cable to device, and then connect to the
USB port in PC.
6. When replacing SIM card, need to restart the device.
Trouble Shooting
the corresponding network model.
2. PDA and PC cannot be connected, please check whether the USB
cable and the PDA are well connected.
3. If the device can't go to sleep status, please check whether network
data exchange is working, or whether Flash and NAND is in the
operating processes of reading and writing data.
WCDMA/GSM connection
When you insert SIM card, start the PDA and open Wireless Manager,
it will pop up notification of SIM card insertion, the operator will
automatically select the SIM card.
Note：Open Connect Manager to use mobile data, select Dialup
Connect.
SAR
Maximum SAR≤2.0W/kg,meet the requirements of national
standards:GB 21288-2007.
Declaration of hazardous substances in product
Toxic or hazardous substances or elements
Pb Hg Cd Cr6+ PBB PBDE
Host ×○○○○○
Charger ×○○○○○
Battery ○○ ○ ○○○
Accessories ○○○○○○
Component
name
○：It indicates that the content of the toxic and hazardous
substances in all homogeneous materials in the parts is below
the requirements set by GB/T26572.
×：The content of the harmful substance in a homogeneous
material at least in the part exceeds the limit set by the
GB/T26572, and there is no mature alternative in the industry,
meeting EU RoHS environmental protection requirements.
Environmental protection related signs
Mainly used for materials and Technology Standard
Specification for electrical and electronic products, to make it
more conducive to human health and environmental protection.
The purpose of this standard is to eliminate the Pb, Hg, Cd,
Cr6+, PBB, PBDE, and a total of 6 substances in the electronic
products, and focus on the content of Pb cannot be more than
0.1%.
1. Click“Wireless Manager”in main screen.
1. Unable to dial up the Internet after inserting SIM card, please check
whether the SIM card is out of service, then check whether PDA supports
