protech prox PA-J510 User manual

X 1
X 1
X 1
X 1
If you discover any of the items below are damaged or lost,
please contact your vendor immediately.
X 1
PA-J510
This Quick Reference Guide
AC Power Cord
Driver DVD
Power Adaptor
All Right Reserved Copyright 2016
PA-6322
3
Specifications
322 PA-63
All Right Reserved Copyright 2015
Ver. Q2
All Rights Reserved. Copyright 2023
Packing Checklist
PA-J510
PA-J510 PA-J510
System View
Unit: mm
PA-J510
Quick
Reference
Guide
Front View Side View
REAR I/O
SIDE I/O
USB7 Power
Button
Open up the cover from the right side of PA-J510 Box as shown
and find the Side I/O USB7 and Power Button.
System
Storage
I/O Ports
Add-ons
Display
Environment
Audio
Primary Display
CPU Support Intel®Core®i5-1145G7E / i3-1115G4E / Celeron®6305E /
Pentium®7505
Memory 1 x DDR4 SO-DIMM slot (up to 16GB)
Power Supply
Network 1 x RJ45, Gigabit 10/100/1000 Mbps / 1 x M.2 (E Key, 2230)
System Weight
Dimensions (WxHxD)
1 x 60/90 watt power adapter
O.S. Support Windows®11 IoT Enterprise / Windows®10 IoT Enterprise
15”, 1024 x 768
2nd Display 10.1” Monitor with Touch
1 x 2W Speaker
Wall Mount Type VESA 75 x 75mm standard
POS+2nd Display: 5.3 kg w/o power adapter / POS: 4.3 kg
1 x M.2 2280, SATA interface
Rear I/O: 2 x USB 2.0/ 2 x USB 3.1 / 1 x USB Type-C
1 x RJ45 (support +5V/12V selectable)
1 x Giga LAN
1 x 4-pin DC power jack
20 columns x2 lines STN LCD display
ISO I,II,III;JIS II and support information key (USB interface)
Silicon Fingerprint Module
15” IPS LCD (Max. Resolution: 1024 x 768)
Brightness: 400 cd/m²
0~50 degree
1 x RJ11 (+12V or +24V selectable) (Default at +24V)
Side I/O: 1 x USB 2.0
Bezel-free projected capacitive
USB
SATA
Serial Port
LAN
DC In
Customer Display
MSR & i-Button
Fingerprint
Primary Display
CE / FCC
0°C ~ 35°C (32°F ~ 95°F)
-20°C ~ 60°C (-4°F ~ 140°F)
20% ~ 90%
EMC & Safety
Operating Temp.
Storage Temp.
Humidity
Cash Drawer
Barcode Scanner
Tilt Angle
Touchscreen
POS: 342 x 270 x 195 mm (with 45 degree)
POS + 2nd Display: 342 x 291 x 237 mm (with 45 degree)
1D: EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar,
Code 128, Code 93, ITF-6, ITF-14, Interleaved 2 of 5,
Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5,
GS1 Databar, Code 39, Code 11
2D: PDF417, QR Code, Micro QR, Data Matrix,
Chinese sensible code
1 x USB 2.0 or 1 x 24V Power USB (1A) or 1 x DC Out (1A)Option
2 x Mini DP for Primary/ 2nd display
1 x HDMI 1.4
Display
270
342
322.4
24.4
USB
Type C
USB USB
COM2 COM1 DRW 2nd Dis.
1st Dis. DC In LAN HDMI
LAN COM1
COM2
HDMI
DC In
2nd Display
Port
1st Display
Port
Power USBDC OUT USB
(optional)
USB
Type C
USB 3.0 DRW
USB 2.0

PA-J510
High Performance 15” POS Terminal
All Right Reserved Copyright 2012
The following messages are reminders for safety on how to protect your system from damages and extend a long life for the system.
1. Check the Cable Voltage
• Make sure the range of operating voltage between AC 100V ~ 240V. Otherwise, the system could be damaged.
2. Environmental Conditions
• Place your PA-J510 on a sturdy, level surface. Be sure to allow enough space to have easy access around the system.
• Avoid extremely hot or cold place to install the system.
• Avoid exposure to sunlight for a long period of time or in an airtight space.
• Avoid the system from any heating device or using it outdoors in a cold winter day.
• Bear in mind that the operating ambient temperature is from 0 ~ 35°C (32°F ~ 95°F).
• Avoid moving the system rapidly from a hot place to a cold place and vice versa as condensation may come from inside of system.
• Place PA-J510 in strong vibration(s) may cause hard disk failure.
• Don’t place the system close to any radio active device in case of signal interference.
3. Handling
• If the system isn’t fully in DOS mode, adjust BIOS setting as the instruction: Advanced Chipset Feature => Boot display => choose “LFP”.
• Avoid putting heavy objects on top of the system.
• Don’t turn the system upside down. This may cause the hard drive to malfunction.
• Don’t allow foreign objects to fall into this product.
• If water or other liquid spills into this product, unplug the power cord immediately.
4. Good Care
• When the outside of the case is stained, remove the stain with a neutral washing agent with a cloth.
• Never use strong agents such as benzene and thinner to clean the system.
• If heavy stains are present, moisten a cloth with diluted neutral washing agent or with alcohol and then wipe thoroughly
with a dry cloth.
• If dust has been accumulated on the outside, remove it by using a special made vacuum cleaner for computers.
• Don’t contact the surface of capacitive touch before entering operation system, or capacitive touch may have problems for electrostatics interface.
CAUTION! Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent ype recommended by
the manufacturer. Dispose of used batteries according to the manufacturer’s instructions.
WARNING! Some internal parts of the system may have high electrical voltage. And therefore we strongly recommend that
qualified engineers can open and disassemble the system. The LCD and Touchscreen are easily breakable, please handle them
with extra care.
All Rights Reserved. Copyright 2021
Easy Maintenance
Jumper Setting Safety Precatuion
Step 1: Follow the arrow to turn the system
touchscreen leftwards.
Follow the arrow to turn
the system touchscreen leftwards.
Step 2: Unscrew M.2 2280 and follow the direction of red arrow
(as shown) to release the cover.
Unscrew M.2 2280
and follow the red arrow
to open the cover.
Step 3: Slide a new M.2 2280 into the M2. slot and
fasten up the screw to secure the cover
and complete.
M.2 2280 Maintenance
Memory Maintenance
Step 1: Unplug the 2 Display Port
cables from I/O Ports
(1st Dis. and 2nd Dis. ports).
2nd Dis. Port
1st Dis. Port Step 2: Unfasten the 5
screws as shown.
Step 4: Open the cover and unplug all the connected
cables. (Remove the LED cable and Wi-Fi
antenna if Wi-Fi function is available.)
Step 5: Change the memory and heating pad.
Step 6: Re-connect all the unplugged cables and
replace all removed screws in the order you
dismantled and complete.
Step 3: Move the PCB box outwards slightly as
shown (red arrow) and lay the PCB box
down on a flat surface.
Warning: If you force to move the PCB Box too far away
from the POS system, the connected cables inside the
system could be damaged.
How To Turn System Touchscreen
Please refer to the “How To Turn System Touchscreen”
section below on how to turn the primary touchscreen properly.
Slide a new M.2 2280 into
the M2. slot and fasten up the
screw to secure the cover.
Warning: If you force to turn not in
the direction you previously turned,
the internal structure of the POS
system could be damaged.
Important: Please turn the primary
touchscreen only in the direction
you previously turned.
You can turn the POS touchscreen either way. Heed that after you turn the
primary touchscreen to the rear side, you must turn the primary touchscreen
only in the direction you previously turned.
PA-J510 System Top View
In this example, the primary
touchscreen is to be turned
leftwards.
The primary touchscreen
has been turned as illustrated.
CAUTION! Danger of explosion may occur if the battery is replaced
incorrectly. Replace batteries only with the same or equivalent type
recommended by the manufacturer. Dispose the used batteries
according to the manufacturer’s instructions.
DIMM1
CPU
M2_M1
JPWRBTN1
1
JUSB7
1
USB7
M2_M2
M2_E1
13
13
JUSB1
15
JBAT1
1
JRST1
1
MDP2
DRW1
COM1COM2
31
JP3
USB1
USB2
USB-C
HDMI1
LAN1
DC_IN1
MDP1
M.2 M Key
M.2 M Key
M.2 E Key
M4
M3
M1M2
1
JPCMOS1
1
2
74 75
1
2
74
75
12
7475
JP1
JP2
JP1 USB Signal Selection
(for M2_E1) (default)
1
M2_E1-USB2.0 D+
1
JUSB1-USB2.0 D+
(for JUSB1)
1
(default)
1
Normal Clear CMOS
Data
JPCMOS1 Clear CMOS Data
Selection
JP3 Cash Drawer Voltage
Selection
1
24V
(default)
1
12V
JP2 USB Signal Selection
11
M2_E1-USB2.0 D- JUSB1-USB2.0 D-
(for M2_E1) (default) (for JUSB1)
CPU_FAN1
1
JSPK1
1
JMIC1 J24V_OUT1
1
JUSB9
11
JSYS_LED1
5
4
13
All Rights Reserved. Copyright 2023
