POVISON TS1028 User manual

TS1028 Installation
The number of people needed for
installation：2
TotaL 1 page; page 1
Serial
number Shape Name Quantity
①Please read the manual carefully
before installing this product. And
strictly follow the installation
process
② Please take good care of this
manual for your next installation
Installation instruction
Parts list
3.installation is complete
A8
Inner hexagonal machine
(M8*55mm)
B
Table foot
4
C
Anti -tilt device
4
Self-tapping screws
（M3.5*19mm）
Self-tapping screws
（M3.5*30mm）
4
4
Entering the wall
expansion screw rubber
plug
4
Tie
2
D
E
F
G
1.Put the table foot and wire in the cabinet upside down and tighten
it.
2.Installation of anti -tilt device
Self-tapping screws
（M3.5*19mm）
marker pen
wall
（1）Place the anti -tilt device on
the back of the side plate of the
cabinet.
（2）Use a marked pen label the
location of the level of the cabinet
anti -tilt device on the wall.
（3）After the marking is
completed, use an electric
drill to open the hole in
the wall.
（4）After the opening is
completed, place entering the
wall expansion screw rubber plug
into the hole of the wall.
Entering the
wall expansion
screw rubber
plug
（5）Place the anti-tilt device on
the wall, put a self tapping screw
and use a screwdriver to tighten.
（6）Bind the two anti -dumping
devices of the wall and the
cabinet to fix it together.
Anti -tilt device
Tie
Self-tapping screws
（M3.5*30mm）
Inner hexagonal
machine(M8*55mm)
Table foot

TS1028WD24 Installation
The number of people needed for
installation：2
TotaL 1 page; page 1
Serial
number Shape Name Quantity
①Please read the manual carefully
before installing this product. And
strictly follow the installation
process
② Please take good care of this
manual for your next installation
Installation instruction
Parts list
3.installation is complete
A8
Inner hexagonal machine
(M8*55mm)
B
Table foot
4
C
Anti -tilt device
4
Self-tapping screws
（M3.5*19mm）
Self-tapping screws
（M3.5*30mm）
4
4
Entering the wall
expansion screw rubber
plug
4
Tie
2
D
E
F
G
1.Put the table foot and wire in the cabinet upside down and tighten
it.
2.Installation of anti -tilt device
Self-tapping screws
（M3.5*19mm）
marker pen
wall
（1）Place the anti -tilt device on
the back of the side plate of the
cabinet.
（2）Use a marked pen label the
location of the level of the cabinet
anti -tilt device on the wall.
（3）After the marking is
completed, use an electric
drill to open the hole in
the wall.
（4）After the opening is
completed, place entering the
wall expansion screw rubber plug
into the hole of the wall.
Entering the
wall expansion
screw rubber
plug
（5）Place the anti-tilt device on
the wall, put a self tapping screw
and use a screwdriver to tighten.
（6）Bind the two anti -dumping
devices of the wall and the
cabinet to fix it together.
Anti -tilt device
Tie
Self-tapping screws
（M3.5*30mm）
Inner hexagonal
machine(M8*55mm)
Table foot
middle foot
