POVISON TS2001B User manual

TS2001B/BWD/WWD/WD Installation
The number of people needed for installation：2
①Please read the manual carefully before
installing this product. And strictly
follow the installation process
② Please take good care of this manual
for your next installation
③ Note: Before installation, screw all
the screws to 1/2 of the length of
the installation. After all screws
are half screwed in, tighten them all
together.
TotaL 1 page; page 1
Serial
number Shape Name Spare
quantity
Parts list
Installation instruction
A
B
2
1.Place the wall-mounted backboard at a suitable position
on the wall, mark the holes to be installed on the wall and
the backboard with a marker, and then drill holes on the
wall with an electric drill.
2.After the drilling is completed, insert the expansion plug
into the wall hole, place the wall-mounted backboard, and
insert the self-tapping screw into the position where the
wall hole connects to the backboard hole. Tighten the screws
with a screwdriver.
4.Installation complete3.Put the TV cabinet on the wall-mounted backboard, open
the downward door, insert the self-tapping screws into the
holes of the cabinet body, and tighten them with a
screwdriver or electric drill. On a red ribbon are furniture
installation accessories
Quantity
required for
installation
8
8 2
C
D
E
F
G
Wall
Wall mount backplate
Wall
Expansion screw
plug for wall
installation
Wall mount backplate
Self-tapping
screw（M4*50mm）
(1) (2)
4 2
Wall hole
Expansion screw
plug for wall
installation
Hole in the
wall mount
backplate
Self-tapping screw
Expansion screw
plugfor wall
installation
Self-tapping
screw（M4*30mm）
Self-tapping
screw（M4*50mm）
Self-tapping
screw（M4*30mm）

TS2001B24/BWD24/WWD24/WD24 Installation
The number of people needed for installation：2
①Please read the manual carefully before
installing this product. And strictly
follow the installation process
② Please take good care of this manual
for your next installation
③ Note: Before installation, screw all
the screws to 1/2 of the length of
the installation. After all screws
are half screwed in, tighten them all
together.
TotaL 1 page; page 1
Serial
number Shape Name Spare
quantity
Parts list
Installation instruction
A
B
2
Expansion screw
plugfor wall
installation
1.Place the wall-mounted backboard at a suitable position
on the wall, mark the holes to be installed on the wall and
the backboard with a marker, and then drill holes on the
wall with an electric drill.
2.After the drilling is completed, insert the expansion plug
into the wall hole, place the wall-mounted backboard, and
insert the self-tapping screw into the position where the
wall hole connects to the backboard hole. Tighten the screws
with a screwdriver.
4.Installation complete3.Put the TV cabinet on the wall-mounted backboard, open
the downward door, insert the self-tapping screws into the
holes of the cabinet body, and tighten them with a
screwdriver or electric drill. On a red ribbon are furniture
installation accessories
Quantity
required for
installation
8
8 2
C
D
E
F
G
Wall
Wall mount backplate
Wall
Expansion screw
plug for wall
installation
Wall mount backplate
Self-tapping
screw（M4*50mm）
Wall hole
Expansion screw
plug for wall
installation
(1) (2)
Hole in the
wall mount
backplate
Self-tapping screw
Self-tapping
screw（M4*30mm）
4 2
Self-tapping
screw（M4*30mm）
Self-tapping
screw（M4*50mm）
