POVISON TS104WS User manual

TS104WS Installation
The number of people needed for installation：2
①Please read the manual carefully before
installing this product. And strictly
follow the installation process
② Please take good care of this manual
for your next installation
③ Note: Before installation, screw all
the screws to 1/2 of the length of
the installation. After all screws
are half screwed in, tighten them all
together.
TotaL 1 page; page 1
Serial
number Shape Name Spare
quantity
Parts list
Assembly instructions
A
B
On a red ribbon are furniture
installation accessories
Quantity
required for
installation
C
D
E
F
G
2
wall entry expansion
screw (M8*80mm)
wall entry expansion
screw (M6*60mm)
self -attack screw
(M4*12mm)
TV cabinet support frame
0
4 0
2 0
2 0
3.Installation completed
punching by electric rotation
（Drill to a depth of 80mm using a
12mm diameter drill bit）
Wall entry expansion
(M8*80)
(2) Use a hammer to drive the expansion screw
into the wall hole
(1) After marking the position with a marking
pen, use an electric drill to drill holes in
the wall
(3) Align the cabinet with the expansion
screw, put in the nut and tighten it
hole position in cabinet
1. Place the cabinet at the required height, and mark the holes and walls
in the cabinet with a marker pen.
2.Place the support frame at the corresponding position at
the bottom of the cabinet, and mark the location of the hole
punched into the wall with a marker pen, and then punch the
hole
(1)After drilling the hole,
drive the expansion screw
into the wall with a hammer
(2)Put in the nut
and tighten it
(3)Tighten the self -attack
screw with a screwdriver
self -attack
screw (M4*12mm)
Wall entry expansion
(M6*60)
（Drill to a depth of 60mm using a 10mm diameter drill bit）
Wall

TS104WL Installation
The number of people needed for installation：2
①Please read the manual carefully before
installing this product. And strictly
follow the installation process
② Please take good care of this manual
for your next installation
③ Note: Before installation, screw all
the screws to 1/2 of the length of
the installation. After all screws
are half screwed in, tighten them all
together.
TotaL 1 page; page 1
Serial
number Shape Name Spare
quantity
Parts list
Assembly instructions
A
B
On a red ribbon are furniture
installation accessories
Quantity
required for
installation
C
D
E
F
G
4
wall entry expansion
screw (M8*80mm)
wall entry expansion
screw (M6*60mm)
self -attack screw
(M4*12mm)
TV cabinet support frame
0
8 0
4 0
4 0
3.Installation completed
Wall punching by electric rotation
（Drill to a depth of 80mm using a
12mm diameter drill bit）
Wall entry expansion
(M8*80)
(2) Use a hammer to drive the expansion screw
into the wall hole
(1) After marking the position with a marking
pen, use an electric drill to drill holes in
the wall
(3) Align the cabinet with the expansion
screw, put in the nut and tighten it
hole position in cabinet
1. Place the cabinet at the required height, and mark the holes and walls
in the cabinet with a marker pen.
2.Place the support frame at the corresponding position at
the bottom of the cabinet, and mark the location of the hole
punched into the wall with a marker pen, and then punch the
hole
(1)After drilling the hole,
drive the expansion screw
into the wall with a hammer
(2)Put in the nut
and tighten it
(3)Tighten the self -attack
screw with a screwdriver
self -attack
screw (M4*12mm)
Wall entry expansion
(M6*60)
（Drill to a depth of 60mm using a 10mm diameter drill bit）
