Power Craft PC2800LR Technical manual

PC2800LR
After Sales Support
Now you have purchased a Power Craft
product you can rest assured in the
knowledge that as well as your 3 year
parts and labour warranty you have
the added peace of mind of dedicated
helplines and email support.
2,800W DUAL VOLTAGE
LONG RUN GENERATOR
User Guide & Warranty
3
YEAR
MANUFACTURER’S
WARRANTY
CUSTOMER
HELPLINE
In order to deal with your enquiry as quickly and efficiently as possible, we ask you to send your
enquiry by email. Do not forget to include your name, address and a daytime telephone number.
Alternatively, you can contact our freephone service hot-line on the number given below.
Office hours are as follows:
Mon - Fri: 8.00am - 6.00pm, Saturday 8.00am - 2.00pm & Sunday 10.00am - 4.00pm
Omega Wolf Ltd
Prospect Close, Lowmoor Business Park,
Kirkby-In-Ashfield, Nottinghamshire NG17 7LF, UK.
UK / NORTHERN IRELAND 08707 323023
REPUBLIC OF IRELAND 1800 481 005
www.omegawolf.com/powercraft
Name:
Address:
Contact Telephone No.:
Email:
Location of purchase:
Fault Description:
2,800W DUAL VOLTAGE
LONG RUN GENERATOR
PC2800LR
If you are requested by the manufacturer to return the item for
repair please complete the enclosed section and send it together
with your product and your receipt (proof of purchase) to the
service address shown below.
AFTER SALES SUPPORT
MODEL NUMBER: PC2800LR
UK / N. IRELAND HELPLINE NO 08707 323023
WEB SUPPORT: www.omegawolf.com/powercraft
REP. IRELAND HELPLINE NO 1800 481 005

02 27
Contents
03 INTRODUCTION
04 SAFETY
06 COMPONENT IDENTIFICATION
07 OPERATION
07 Engine switch
07 Recoil starter
07 Fuel valve
08 Choke rod
08 Circuit breaker
08 Ground terminal
09 Oil alert system
09 Pilot lamp
09 DC Terminals
09 DC Circuit Protector
10 GENERATOR USE
10 Connections to a Building’s Electrical System
10 Generator Ground Circuit
11 AC Applications
11 AC Operation
12 DC Operation
13 Disconnecting the battery cables
14 PRE-OPERATION CHECK
14 Engine Oil
15 Fuel Recommendation
17 STARTING THE ENGINE
18 STOPPING THE ENGINE
19 MAINTENANCE
19 Maintenance Schedule
20 Engine Oil Change
20 Air Cleaner Service
21 Fuel Sediment Cup Cleaning
22 Spark Plug Service
23 TRANSPORTING/STORAGE
25 TROUBLESHOOTING
26 SPECIFICATIONS
27 WARRANTY CERTIFICATE
27 DECLARATION OF CONFORMITY
Warranty
EC DECLARATION OF CONFORMITY
Congratulations! You have made an excellent choice with the purchase of this
Quality product. Our commitment to quality also includes our service. Should you,
contrary to expectations, experience defects due to material or manufacturing faults during private
use within 36 months of the date of purchase we shall be liable for warranty in accordance with
statutory warranty regulations, provided that: - The device was not put to any use other than the
intended.- Was not overloaded. - Was not used with the wrong accessories. - Repairs were not
carried out by any other than the authorised workshop. The warranty certificate is only valid in
connection with the receipt. Please keep both in a safe place. The warranty does not affect your
statutory rights.
The product is guaranteed for a period of three years beginning on the day of purchase. Keep your
purchase receipt safe as proof of the date of purchase. The guarantee period can only be extended
for the duration of any repair required.
During the warranty period, defective devices can be sent FREIGHT PREPAID to the service address
stated at the end of this booklet. We will, at our discretion either repair or exchange the device in
accordance with warranty legislation.
Please include the following when sending in your product for repair:
1. The receipt (proof of purchase)
2. This warranty certificate with your name, address, contact details and a fault description
completed overleaf.
If the original receipt is not enclosed the repair will be charged for in all cases. After the warranty
has expired you can still send defective devices for repairs FREIGHT PREPAID to the address at the
end of this booklet. Quotes as well as repairs after warranty period are to be paid for in all cases.
Ensure the product is sent well packed as no responsibility can be accepted for items lost or
damaged in transit. This warranty does not affect your statutory rights.
WARRANTY CERTIFICATE
W
A
R
R
A
N
T
Y
M
O
N
T
H
S
36
Year of Manufacture 09/2007 2,800W DUAL VOLTAGE LONG RUN GENERATOR
declare that the design and construction of the following machine, in the form
supplied by us, comply with the requirements of the appropriate EC directives.
Product Description: 2,800W DUAL VOLTAGE LONG RUN GENERATOR
Model: PC2800LR
Appropriate EC directives: 89/336/EEC, 2000/14/EC, 98/37/EC, 73/23/EEC
In accordance with the standards:
EN 55012 : 2002, EN ISO 3744:1995, ISO 8528-10:1998,
EN 12601:2001, EN 60204-1:1997
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR
We OMEGA WOLF LTD, Kirkby-In-Ashfield, Nottinghamshire, UK
M D Irwin
Quality Department 09/2007

26 03
Introduction
Congratulations on choosing to buy a
Power Craft product.
By doing so you now have the assurance and peace of mind that comes with purchasing a
product made by one of Europe’s leading manufacturers.
All products brought to you by Power Craft are manufactured to the highest standards of
performance and safety, and, as part of our philosophy for customer service and satisfaction,
are backed by our comprehensive 3 Year Warranty.
We hope you will enjoy using your purchase for many years to come.
This user’s manual describes the operation and maintenance of the Generator. All information
in this publication is based on the latest product information available at the time of printing.
We reserve the right to make changes at any time without notice and without incurring any
obligation. No part of this publication may be reproduced without written permission.
Safety Message
Your safety and the safety of others are very important. We have provided important safety
messages in this manual and on the generator. Please read these messages carefully.
Specification
MODEL PC2800LR
Max.Output (Watts) 2800
Cont. Output (Watts) 2500
Phase Single
Rated Voltage 230V/110V
Rated Frequency 50Hz
DC Output 12V 8.3A
Power Factor 1.0
Engine Single cylinder 4-stroke air-cooled
Horsepower 6.7
Rated Speed 3000rpm
Displacement 200cc
Ignition System TCI
Oil Alert System Yes
Starting System Recoil
Oil Capacity (Litres) 0.6
Fuel tank Capacity (Litres) 15
Net Weight (kg) 47kg
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR

04 25
Safety
Do not connect to a building’s electrical system unless an isolation switch has been
installed by a qualified electrician.
Using a generator or an electrical appliance in wet conditions such as rain or snow
or near a pool or sprinkler system, or when your hands are wet, could result in
electrocution. Keep the generator dry.
Operator Responsibility
• Know how to stop the generator quickly in case of emergency. (See Page 18)
• Understand the use of all generator controls, output receptacles and connections.
• Be sure that anyone who operates the generator receives proper instruction.
Do not let children operate the generator.
SAFETY INFORMATION
Generators are designed to give safe and dependable service if operated according to instructions.
Read and understand this user’s manual before operating your generator. You can help prevent
accidents by being familiar with your generator’s controls and by observing safe operating
procedures.
Troubleshooting
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR

24 05
Safety
Carbon Monoxide Hazards
Exhaust contains poisonous carbon monoxide, a colourless and odourless gas. Breathing
exhaust can cause loss of consciousness and may lead to death.
If you run the generator in an area that is confined, or even partially enclosed, the air you
breathe could contain a dangerous amounts of exhaust gas. To keep exhaust gas from building
up, provide adequate ventilation.
Electric Shock Hazards
The generator produces enough electric power to cause a serious shock or electrocution if
misused.
Using a generator or electrical appliance in wet conditions, such as rain or snow, or near a
pool or sprinkler system, or when your hands are wet, could result in electrocution. Keep the
generator dry. Do not operate the generator in rain or snow.
If the generator is stored outdoors, unprotected from the weather, check all electrical
components on the control panel, before each use. Moisture or ice can cause a malfunction
or short circuit in electrical components, which could result in electrocution.
Do not connect to a building’s electrical system unless an isolation switch that has been
installed by a qualified electrician.
Fire and Burn Hazards
The exhaust system gets hot enough to ignite some materials.
Keep the generator at least 1 meter (3 feet) away from buildings and other equipment during
operation.
Do not enclose the generator in any structure.
Keep flammable materials away from the generator.
The silencer becomes very hot during operation and remains hot for a while after stopping
the engine. Be careful not to touch the silencer while it is hot. Let the engine cool before
storing the generator indoors.
Petrol is extremely flammable and is explosive under certain conditions. Do not smoke or
allow flames or sparks where the generator is refueled or where petrol is stored. Refuel in a
well-ventilated area with the engine stopped.
Fuel vapours are extremely flammable and may ignite after the engine has started. Make sure
that any spilled fuel has been wiped up before starting the generator.
Transporting / storage
1. Drain the carburetor by loosening the drain screw. Drain the petrol into a suitable container.
Petrol is extremely flammable and is explosive under certain conditions. Perform
this task in a well ventilated area with the engine stopped. Do not smoke or allow
flames or sparks in the area during this procedure.
2. Change the engine oil.
3. Remove the spark plug, and pour about a tablespoon of clean engine oil into the cylinder.
Crank the engine several revolutions to distribute the oil, then reinstall the spark plug.
4. Slowly pull the starter grip until resistance is felt. At this point, the piston is coming up
on its compression stroke and both the intake and exhaust valves are closed. Storing the
engine in this position will help to protect it from internal corrosion.
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR

06 23
Component Identification Transporting / storage
When transporting the generator, turn the engine switch and the fuel valve OFF. Keep the
generator level to prevent fuel spillage. Fuel vapour or spilled fuel may ignite.
Contact with a hot engine or exhaust system can cause serious burns or fires. Let
the engine cool before transporting or storing the generator.
Take care not to drop or strike the generator when transporting. Do not place heavy objects
on the generator.
Before storing the unit for an extended period:
1. Be sure the storage area is free of excessive humidity and dust.
2. Service according to the table below:
STORAGE TIME RECOMMENDED SERVICE PROCEDURE TO PREVENT HARD STARTING
Less than 1 month Fill with fresh petrol and add petrol conditioner*.
2 months to 1 year
Fill with fresh petrol and add some petrol conditioner*.
Drain the carburetor float bowl.
Drain the fuel sediment bowl.
1 year or more
Fill with fresh petrol and add some petrol conditioner*.
Drain the carburetor float bowl.
Drain the fuel sediment bowl.
Remove the spark plug. Put a tablespoon of engine oil into the cylinder. Turn the
engine slowly with the pull rope to distribute the oil. Reinstall the spark plug.
Change the engine oil.
After removal from storage, drain the stored petrol into a suitable container, and fill
with fresh petrol before starting.
* Use petrol conditioners that are formulated to extend storage life.
Contact your authorised generator dealer for conditioner recommendations.
VOLTMETER
110V
OUTLETS
EARTH
TERMINAL
FUEL METER
FUEL TANK CAP
Record the engine number for your future reference.
Engine serial number:
CIRCUIT
BREAKER
OIL DRAIN
PLUG
ENGINE
ON/OFF
SWITCH
230V
OUTLETS
CHANGE OVER SWITCH
110V/230V
SILENCER
RECOIL
STARTER
AIR
FILTER
FUEL ON /
OFF VALVE
CHOKE LEVER
CHARGING LEADS
AND CLIPS
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR

22 07
Operation
Engine Switch
To start and stop the engine.
Switch position:
OFF: To Stop the engine.
ON: To run the engine after starting.
Recoil Starter
To start the engine. Pull the starter grip lightly until resistance is felt, then pull briskly.
NOTE: Do not allow the starter to snap back against the engine. Return it gently to prevent
damage to the starter.
Fuel Valve
The fuel valve is located between the fuel tank and carburetor. When the valve lever is in the
ON position, fuel is allowed to flow from the fuel tank to the carburetor. Be sure to return
the lever to OFF after stopping the engine.
Maintenance
Spark Plug Service
Recommended spark plugs:
MP160; BPR6ES (NGK)
MP240, MP340, MP390; BPR5ES (NGK)
MP270; BP6ES (NGK)
To ensure proper engine operation, the spark
plug must be properly gapped and free of deposits.
If the engine has been running, the exhaust will
be very hot.
Be careful
Do not to touch the silencer.
1. Remove the spark plug cap.
2. Clean any dirt from around the spark plug base.
3. Use the wrench supplied in the tool kit to remove the spark plug.
4. Visually inspect the spark plug. Discard it if the insulator is cracked or chipped. Clean the
spark plug with a wire brush if it is to be reused.
5. Measure the plug gap with a feeler gauge.
Correct as necessary by carefully bending the side electrode.
The gap should be: 0.70-0.80 mm (0.028-0.031 in)
6. Check that the spark plug washer is in good condition, and thread the spark plug in by
hand to prevent cross-threading.
8. After the spark plug is seated, tighten with a spark plug wrench to compress the washer.
- If installing a new spark plug, tighten 1/2 turn after the spark plug seats to compress the
washer. If reinstalling a used spark plug, tighten 1/8-1/4 turn after the spark plug seats to
compress the washer.
NOTICE
The spark plug must be securely tightened. An improperly tightened spark plug can
become very hot and could damage the engine. Never use spark plugs that have an
improper heat range. Use only the recommended-spark plugs or equivalent.
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR

08 21
Operation Maintenance
Choke Lever
The choke is used to provide an enriched fuel mixture when cold starting. The choke can be
opened by moving the choke rod to the ON position and closed by moving the choke rod to
the OFF position.
Circuit Breaker
The circuit breaker will automatically switch OFF if there is a short circuit or a significant
overload of the generator at the socket. lf the circuit breaker is switched OFF automatically,
check that the appliance is working properly and does not exceed the rated load capacity of
the circuit before switching the circuit breaker ON again.
Earth Terminal
The generator earth terminal is connected to
the frame of the generator, on a metal
non-current carrying parts of the generator,
and the earth terminals of each socket.
DC Circuit Protector
Earth
Terminal
DC 12
Circuit
Breaker
1. Unsnap the air filter cover clips, remove the air filter
cover, and remove the element.
2. Wash the element in a solution of household detergent
and warm water, then rinse thoroughly; or wash in
nonflammable or high flash point solvent, Allow the
element to dry thoroughly.
3. Soak the element in clean engine oil and squeeze out
the excess oil. The engine will smoke during initial
start-up if too much oil is left in the element.
4. Reinstall the air filter element and the cover.
Fuel Sediment Bowl Cleaning
The sediment bowl prevents dirt or water, which may be in
the fuel tank, from entering the carburetor. If the engine
has not been run for a long time, the sediment bowl should
be cleaned.
1. Turn the fuel valve to the OFF position. Remove the
sediment bowl, O-ring, and filter.
2. Clean the sediment bowl, O-ring, and filter in
nonflammable or high flash point solvent.
3. Reinstall the filter, O-ring, and sediment bowl.
4. Turn the fuel valve ON and check for leaks.
Fuel Valve Sediment Bowl
Fuel
Filter
O-Ring
Sediment
Bowl
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR
AIR FILTER COVER
AIR FILTER ELEMENT
ELEMENT
CLIP
CLIP

20 09
Operation
Maintenance
Used motor oil may cause skin cancer if repeatedly left in contact with the skin for
prolonged periods. Although this is unlikely unless you handle used oil on a daily
basis, it is still advisable to thoroughly wash your hands with soap and water as
soon as possible after handling used oil.
Please dispose of used motor oil in a manner that is compatible with the environment.
We suggest you take it in a sealed container to your local service station or recycling
centre for reclamation. Do not throw it in the dustbin or pour it on the ground.
Air filter service
A dirty air filter will restrict airflow to the carburetor. To prevent carburetor
malfunction, service the air filter regularly. Service more frequently when
operating the generator in extremely dusty areas.
Using petrol or flammable solvent to clean the filter element can cause a fire or
explosion. Use only soapy water or nonflammable solvent.
NOTICE
Never run the generator without the air filter. Rapid engine wear will result.
Engine oil change
Drain the oil while the engine is warm to assure rapid and complete draining.
1. Remove the drain plug and sealing washer, oil filler cap, and drain the oil.
2. Reinstall the drain plug and sealing washer. Tighten the plug securely.
3. Refill with the recommended oil and check the level.
Oil capacity: 0.6 Litres
Oil Alert System
The Oil Alert system is designed to prevent engine damage caused by an insufficient amount
of oil in the crankcase. Before the oil level in the crankcase can fall below a safe limit, the Oil
Alert system will automatically shut down the engine (the engine switch will remain in the
ON position).
Pilot Lamp
The pilot lamp is illuminated when the generator is operating normally.
DC Terminals
The DC terminals may ONLY be used for charging 12 volt automotive type batteries.
The terminals are coloured red to identify the positive (+) terminal and black to identify the
negative (-) terminal. The battery must be connected to the generator DC terminals with the
proper polarity (battery positive to generator red terminal and battery negative to the
generator black terminal.)
DC Circuit Protector
The DC circuit protector automatically shuts off the DC battery charging circuit when the
generator is overloaded, when there is a problem with the battery or the connections between
the battery and the generator are incorrectly connected.
DC Circuit Protector
Earth
Terminal
DC 12
Circuit
Breaker
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR

10 19
Generator Use
Connections to a Building’s Electrical System
Connections for standby power to a building’s electrical system must be made by a qualified
electrician. The connection must isolate the generator power from utility power, and must
comply with all applicable laws and electrical codes.
Improper connections to a building’s electrical system can allow electrical current from the
generator to back feed into the utility lines. Such back feed may electrocute utility company
workers or others who contact the lines during a power cut. Consult the utility company or a
qualified electrician.
Improper connections to a building’s electrical system can allow electrical current from the
utility company to back feed into the generator. When utility power is restored, the generator
may explode, burn, or cause fires in the building’s electrical system.
Generator Earth Circuits
Portable generators have a system earth that connects the generator frame components to
the ground terminals in the AC output receptacles.
The system earth is not connected to the AC neutral wire.
The earth terminal can be used to earth the generator or bond the frame of the generator
to the frame of a vehicle, but only if it is required by local law or electrical code. Before using
the earth terminal consult a qualified electrician or electrical inspector for regulations.
Maintenance
Periodic maintenance and adjustment is necessary to keep the generator in good operating
condition. Perform the service and inspection at the intervals shown in the Maintenance
Schedule below.
Exhaust gas contains poisonous carbon monoxide. Shut off the engine before performing any
maintenance. If the engine must be run, make sure the area is well ventilated.
MAINTENANCE SCHEDULE
(1) Service more frequently when used in dusty areas.
(2) These items should be serviced by an authorised agent. Contact the helpline.
(3) For frequent use, log hours of operation to determine proper maintenance
intervals.
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR

18 11
Generator Use
Stopping the engine
In an emergency:
1. To stop the engine in an emergency, turn the engine switch to the OFF position. See step 3.
In normal use:
1. Turn the AC circuit breaker to the OFF position.
2. Disconnect all electrical loads from panel receptacles.
Disconnect DC battery charging cables.
3. Turn the engine switch to the OFF position.
4. Turn the fuel valve to the OFF position.
STOPPING THE ENGINE
DC Circuit Protector
Earth
Terminal
DC 12
Circuit
Breaker
AC Applications
Before connecting an appliance or power cord to the generator;
Make sure that it is in good working order. Faulty appliances or power cords can create a
potential for electrical shock.
If an appliance begins to operate abnormally, becomes sluggish or stops suddenly, turn it off
immediately. Disconnect the appliance, and determine whether the problem is the appliance,
or if the rated load capacity of the generator has been exceeded.
Make sure that the electrical rating of the tool or appliance does not exceed that of the
generator, Never exceed the maximum power rating of the generator. Power levels between
rated and maximum may be used for no more than 5 minutes.
NOTICE
Substantial overloading will trip the circuit breaker. Exceeding the time limit for
maximum power operation or slightly overloading the generator may not switch
the circuit breaker OFF, but will shorten the service life of the generator.
Limit operation requiring maximum power to 5 minutes.
Maximum power is: See specifications.
For continuous operation, do not exceed the rated power.
Rated power is: See specifications.
In either case, the total power requirements (watts) of all appliances connected must be
considered. Appliance and power tool manufactures usually list rating information near the
model number or serial number.
AC Operation
1. Start the engine.
2. Switch ON the AC circuit breaker.
3. Plug in the appliance.
Most motorised appliances
require more than their rated
wattage for startup.
Do not exceed the current limit specified for any one socket. If an overloaded circuit causes
the AC circuit breaker to switch OFF, reduce the electrical load on the circuit, wait a few minutes
and then reset the circuit-breaker.
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR

DC operation
The DC terminals may ONLY be used for charging 12 volt automotive-type batteries.
NOTE: To operate the battery charging facility, it is necessary to switch the Circuit breakers
to the off position. Charging will not occur unless this is done.
Connecting the battery cables:
1. Before connecting charging cables to a battery that is installed in a vehicle, disconnect the
vehicle’s earthed battery cable.
The battery gives off explosive gases; keep sparks, flames and cigarettes away. Provide
adequate ventilation when charging or using batteries.
2. Connect the positive (+) battery cable to the battery positive (+) terminal.
3. Connect the other end of the positive (+) battery cable to the generator positive (+) terminal.
4. Connect the negative (-) battery cable to the battery negative (-) terminal.
5. Connect the other end of the negative (-) battery cable to the generator negative (-)
terminal.
6. Start the generator.
NOTICE
Do not start the vehicle while the battery charging cables are connected and the
generator is running. The vehicle or the generator may be damaged.
An overloaded DC circuit, excessive current draw by the battery, or wiring problem will trip
the DC circuit protector (PUSH button extends out). If this happens, wait a few minutes before
pushing in the circuit protector to resume operation. If the circuit protector continues to go
OFF, discontinue charging and contact the helpline.
Generator Use Starting the engine
STARTING THE ENGINE
1. Make sure to disconnect all electrical loads from panel receptacles. The generator may be
difficult to start if a load is connected.
2. Turn the fuel valve to the ON position.
3. The automatic choke will be closed if the engine is cold. If you want to operate the choke
manually, move the choke lever out of the OFF position.
4. Start the engine, with recoil starter:
Turn the engine switch to the ON position.
Pull the starter grip lightly until resistance is felt, then pull briskly.
NOTICE
Do not allow the starter grip to snap back against the engine.
Return it gently to prevent damage to the starter or housing.
5. If you have manually closed the choke, move it to the OPEN position as the engine
warms up.
12 17
DC Circuit Protector
Earth
Terminal
DC 12
Circuit
Breaker
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR

Generator Use
Pre-operation check
Running the engine with persistent pinking is misuse, and the Manufacturer’s Warranty does
not cover parts damaged by misuse.
Oxygenated Fuels
Some petrols are being blended with alcohol or an ether compound to increase the octane.
These petrols are collectively referred to as oxygenated fuels. If you use an oxygenated fuel,
be sure its pump octane rating is 86 or higher.
Ethanol (ethyl or grain alcohol)
Petrol containing more than 10% ethanol by volume may cause starting and/or performance
problems.
Methanol (methyl or wood alcohol)
Petrol containing methanol must contain solvents and corrosion inhibitors to protect the fuel
system. Petrol containing more than 5% methanol by volume may cause starting and/or
performance problems and may damage metal, rubber and plastic parts of your fuel system.
MTBE (methyl tertiary butyl ether)
You may use petrol containing up to 15% MTBE by volume.
Before using an oxygenated fuel, try to confirm the fuel’s contents. Some states require this
information to be posted on the pump. If you notice any undesirable operating symptoms,
switch to a conventional unleaded petrol. Fuel system damage or performance problems
resulting from the use of an oxygenated fuel are not the responsibility of the manufacturer
and are not covered under warranty.
NOTICE
Oxygenated fuels can damage paint and plastic. Be careful not to spill fuel when
filling your fuel tank. Damage caused by spilled fuel is not covered under warranty.
16 13
Disconnecting the battery cables:
1. Stop the engine.
2. Disconnect the negative (-) battery cable from the generator negative (-) terminal.
3. Disconnect the other end of the negative (-) battery cable from the battery negative (-)
terminal.
4. Disconnect the positive (+) battery cable from the generator positive (+) terminal.
5. Disconnect the other end of the positive (+) battery cable to the battery positive (+) terminal.
6. Connect the vehicle earth cable to the battery negative (-) terminal.
7. Reconnect the vehicle earth battery cable.
DC Circuit Protector
Earth
Terminal
DC 12
Circuit
Breaker
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR

Pre-operation check
Engine oil
NOTICE
Engine oil is a major factor affecting engine performance and service life. Non-
detergent and 2-stroke engine oils will damage the engine and are not recommended.
Check the oil level BEFORE EACH USE with the generator on a level
surface with the engine stopped.
SAE 10W-30 is recommended for general, all-temperature use.
Other viscosities shown in the chart may be used when the average
temperature in your area is within the indicated range.
1. Remove the oil filler cap and wipe the dipstick clean.
2. Check the oil level by inserting the dipstick into the filler neck without screwing it in.
3. If the level is low, fill to the top of the oil filler neck with the recommended oil.
Pre-operation check
14 15
Fuel Recommendation
1. Check the fuel level gauge.
2. Refill the tank if the fuel level is low. Do not fill above the shoulder of the fuel strainer.
Petrol is extremely flammable and is explosive under certain conditions.
Refuel in a well-ventilated area with the engine stopped. Do not smoke or allow flames
or sparks in the area where the engine is refueled or where petrol is stored.
Do not overfill the fuel tank (there should be no fuel in the filler neck). After refueling,
make sure the tank cap is closed properly and securely. Be careful not to spill fuel when
refueling. Spilled fuel or fuel vapour may ignite. If any fuel is spilled, make sure the area
is dry before starting the engine.
Avoid repeated or prolonged contact with skin or breathing of vapour.
KEEP OUT OF REACH OF CHILDREN.
Fuel tank capacity: 15 Litres
Use petrol with a pump octane rating of 86 or higher.
We recommend unleaded petrol because it produces fewer engine and spark plug deposit
and extends exhaust system life.
Never use stale or contaminated petrol or oil/petrol mixture. Avoid getting dirt or water in
the fuel tank.
Occasionally you may hear light sparks knocks or springing, (metallic rapping noise) while
operating under heavy loads. This is no cause for concern.
Pinking is a metallic tapping noise that can occur if poor or incorrect fuel is used or if the
ignition timing is not set correctly.
If pinking occurs at a steady engine speed, under normal load, change brands of petrol.
lf pinking persists, contact the helpline.
NOTICE
Running the engine with persistent pinking can cause engine damage.
FUEL TANK CAP FUEL STRAINER SHOULDER
FUEL LEVEL GAUGE
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR
Helpline No. UK / Northern Ireland 08707 323023 Rep. Ireland 1800 481 005
Web Support: www.omegawolf.com/powercraft
Model Number: PC2800LR
