Power Probe PPTEMPKIT User manual
PPTEMPKIT
DUAL-ZONE DIGITAL
THERMOMETER
WITH WIRELESS REMOTE TEMPERATURE SENSOR SPECIFICATIONS
OPERATION
Power Probe TeK, LLC. 890 Mariner St. Brea, CA 92821
FEATURES
oDual Zone Readings
oWireless Remote Sensor
oOpt. 2nd Remote Sensor
oBright Backlit LCD
o°F and °C -Selectable
oOperating Environment:
oMeasuring Range:
oAccuracy:
oWireless Range:
oResolution:
oBattery Type:
oBattery Life:
-4°F to 158°F
(-20°C to 70°C)
-4°F to 158°F
(-20°C to 70°C)
±2.0°F (±2.0°C)
60m (195ft.) max.
0.1°
2 x AA and 2 x AAA
400 hours
1. Remove battery cover from rear of Base Unit.
2. Install two (2) AA batteries into battery cavity and
replace battery cover.
3. Press Base Unit Power button for one sec. to turn
ON/OFF.
4. LCD display will show current temperature of Base
Unit Temp Sensor above the display.
5. Remove battery cover from rear of Remote Unit
6. Install two (2) AAA batteries into battery cavity and
replace battery cover.
7. Slide Remote Unit Power switch to the ON
position. Indicator Light should flash.
8. When paired, Remote Unit temperature will
display on Base Unit second line.
9. Press Backlight button to turn LCD backlight
ON/OFF.
10. Press °C/°F button to change the Base Unit
display reading from Fahrenheit to Celsius.
11. Press the Cycle/Select button to select optional
second Remote Unit.
-4°F to 158°F
(-20°C to 70°C)
1-800-655-3585 info@powerprobe.com
Remote Temp Unit -
Detachable Remote
Temperature Sensor &
Wireless Transmitter
Remote Unit
ON/OFF Switch
Backlight
ON/OFF
Remote Unit
ON/OFF/BATT
Indicator
Temp Sensor
Connected
Base Unit
Temperature
Remote Unit
Temperature
°C/°F Select
Base Unit
ON/OFF
Remote
Select
Base Unit
Temperature
Sensor
Remote Unit
Temperature
Sensor
Movable
Vent Clip
Base Unit -
Temperature Sensor &
2ch Wireless Receiver
www.powerprobe.com
INTRODUCTION
oThank you for purchasing the Power Probe
PPTEMPKIT Dual Zone Thermometer with
Wireless Remote Temperature Sensor.
oPlease read through this manual in it’s entirety to
fully enjoy the benefits and features of this product.
oPlease keep this manual for future reference.
oThe PPTEMPKIT has a built in temp sensor in the
Base Unit, plus a 2nd Remote Unit temp sensor that
transmits the Remote Unit temperature reading
back to the Base Unit.
oThe Remote temp sensor can transmit temperature
readings up to 60m (195ft.) away from Base Unit.
oMonitor temperature differences –Ambient vs. AC
outlet, Inside vs. Outside Temps, and more.
oUse moveable clip to attach Remote to air vents or
grilles to monitor outlet temps.
WARRANTY
Power Probe Warranty
oPower Probe products undergo a strict quality control inspection for workmanship,
function, and safety before leaving the factory.From the date of purchase, we will
warranty/repair Power Probe products for one (1) year against defects in parts and
workmanship.All repairs due to misuse will be charged afee not to exceed the cost
of the tool.All warranty units must be accompanied by acopy of the original sales
receipt.In the event of amalfunction or defective unit, please call or email your
Power Probe dealer.
PPTEMPKIT
DUAL-ZONE DIGITAL
THERMOMETER
WITH WIRELESS REMOTE TEMPERATURE SENSOR SPECIFICATIONS
OPERATION
Power Probe TeK, LLC. 890 Mariner St. Brea, CA 92821
FEATURES
oDual Zone Readings
oWireless Remote Sensor
oOpt. 2nd Remote Sensor
oBright Backlit LCD
o°F and °C -Selectable
oOperating Environment:
oMeasuring Range:
oAccuracy:
oWireless Range:
oResolution:
oBattery Type:
oBattery Life:
-4°F to 158°F
(-20°C to 70°C)
-4°F to 158°F
(-20°C to 70°C)
±2.0°F (±2.0°C)
60m (195ft.) max.
0.1°
2 x AA and 2 x AAA
400 hours
1. Remove battery cover from rear of Base Unit.
2. Install two (2) AA batteries into battery cavity and
replace battery cover.
3. Press Base Unit Power button for one sec. to turn
ON/OFF.
4. LCD display will show current temperature of Base
Unit Temp Sensor above the display.
5. Remove battery cover from rear of Remote Unit
6. Install two (2) AAA batteries into battery cavity and
replace battery cover.
7. Slide Remote Unit Power switch to the ON
position. Indicator Light should flash.
8. When paired, Remote Unit temperature will
display on Base Unit second line.
9. Press Backlight button to turn LCD backlight
ON/OFF.
10. Press °C/°F button to change the Base Unit
display reading from Fahrenheit to Celsius.
11. Press the Cycle/Select button to select optional
second Remote Unit.
-4°F to 158°F
(-20°C to 70°C)
1-800-655-3585 info@powerprobe.com
Remote Temp Unit -
Detachable Remote
Temperature Sensor &
Wireless Transmitter
Remote Unit
ON/OFF Switch
Backlight
ON/OFF
Remote Unit
ON/OFF/BATT
Indicator
Temp Sensor
Connected
Base Unit
Temperature
Remote Unit
Temperature
°C/°F Select
Base Unit
ON/OFF
Remote
Select
Base Unit
Temperature
Sensor
Remote Unit
Temperature
Sensor
Movable
Vent Clip
Base Unit -
Temperature Sensor &
2ch Wireless Receiver
www.powerprobe.com
INTRODUCTION
oThank you for purchasing the Power Probe
PPTEMPKIT Dual Zone Thermometer with
Wireless Remote Temperature Sensor.
oPlease read through this manual in it’s entirety to
fully enjoy the benefits and features of this product.
oPlease keep this manual for future reference.
oThe PPTEMPKIT has a built in temp sensor in the
Base Unit, plus a 2nd Remote Unit temp sensor that
transmits the Remote Unit temperature reading
back to the Base Unit.
oThe Remote temp sensor can transmit temperature
readings up to 60m (195ft.) away from Base Unit.
oMonitor temperature differences –Ambient vs. AC
outlet, Inside vs. Outside Temps, and more.
oUse moveable clip to attach Remote to air vents or
grilles to monitor outlet temps.
WARRANTY
Power Probe Warranty
oPower Probe products undergo a strict quality control inspection for workmanship,
function, and safety before leaving the factory.From the date of purchase, we will
warranty/repair Power Probe products for one (1) year against defects in parts and
workmanship.All repairs due to misuse will be charged afee not to exceed the cost
of the tool.All warranty units must be accompanied by acopy of the original sales
receipt.In the event of amalfunction or defective unit, please call or email your
Power Probe dealer.
