PowerAcoustik PMD-121CMX User manual

OWNER S MANUAL
12.1 TFT-LCD DVD/SD/USB
COMBO MONITOR
M
PLAY AV MENU
POWER
PMD-121CMX

Contents
3
Caution
Features and Controls
Power and Mode Selection
Releasing The Monitor
Mute Function
Picture Control
Contrast/Brightness/Color/FM
DVD Setup
Setup Menu
General Setup
TVAspect Ratio
Angle Viewing
OSD Language
Screen Saver
Audio Setup
Dolby Digital Setup
Equalizer Settings
Video Setup
Quality
Preferences Setup
TVType
PBC
Audio
Subtitle
Disc Menu
Parental
Default
Password Setup
Password Mode
Password Change
4
6
8
10
12
13
14
16
21
22
23
6
12
18
21
21
21
21
22
22
23
23
DVD Functions
Eject
Vol+/Vol-
Mute
Play or Pause
Audio
Stop
Arrows
Setup
Menu
Display
Number Buttons
Subtitle
Title
Slow
Fast Reverse Searching
Fast Forward Searching
Previous
Next
RepeatA-B
Repeat
NTSC/PAL
Angle
PBC
Zoom
GOTO
Connection Diagram
Installation
Disc Information
Troubleshooting
Specifications
24
24
24
24
25
26
27
27
28
29
30
31
24
24
25
25
25
26
27
28
29
29
30
30
31
31
34
35
36
37
10
10
10
Turning onThe Monitor
11
AV mode
13
14
14
15
15
16
18
Remote Control
Monitor/DVD Player
14
33
SD/USB Functions
32

Caution
Please read and observe all warnings and instructions in this manual
and those marked on the unit. Retain this booklet for future reference.
There are two kinds of alarm symbols as follows:
WARNING
WARNING
CAUTION
The lightning bolt with arrowhead inside in an equilateral
triangle is intended to alert the user to the presence of
dangerous voltage within the product s enclosure that may be
of sufficient magnitude to constitute a risk of electric shock to
people.
The exclamation point inside an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompanying
the product.
Installation of all TV monitors
must be out of the driver s
field of vision.
Do not try and service these
products yourself, a
qualified service center or
factory service center for all
repairs.
locale
Be careful not to drop or
apply under pressure to the
front panel of your video
monitor. If the screen cracks
due to misuse, your warranty
will be void!
Do not mount the product where
it will obstruct the deployment of
the airbag or in an area where it
would affect the driver s ability
to control the vehicle.Also be
careful to avoid mounting the
product where it can become
hazardous during sudden stops
or in the event of an accident.
Use extra caution with any liquids
in your car. If you or your child
spills any liquid on these products,
pull your vehicle to the roadside
and turn the key off to disconnect
or wipe the products with a towel. Do not
operate the equipment until all liquids have
either evaporated or you have had the monitor
inspected at a service center by a qualified
technician. Severe harm or danger can result.
Use only a damp cloth to clean
the screen and use only purified
water on the cloth. wring out all
excess water prior to wiping the
screen. Do not use any cleaners
or chemicals to clean the screen.
In most cases a dry cloth will do!
P
OWER
A
V
MEN U
,
4
,
37
DC 12V
4:3
2400x600
NTSC/PALAuto Select
DVD-AV1-AV2
1EA
With shroud:15.1(L)X13.9(W)X3.5(H)inches
Power
Screen Format
Resolution Pixel
Color System
A/V Input
A/V Output
Dimension
Note: This equipment has been tested and has been found to comply
with the limits for a ClassA digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference
to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference. In some cases, the user will
be required to correct the interference at his own expense.
SPECIFICATIONS
Without shroud:14.8(L)X13.6(W)X2.5(H)inches
Dimension

5
Troubleshooting
Symptom Items to Check Actions to be Taken
Remote control does
not work properly.
Is the power turned on?
Is the audio which is connected with
the audio cable set to receive
the DVD signal output?
Is audio cable connected securely?
Is the monitor which is connected
with the audio cable turned on?
Is the audio output set
in the correct position?
Is the remote control facing
the remote sensor?
Is the distance too far?
Is there any obstacle in the middle?
Is the battery weak?
Check the car battery capacity.
Select the correct input mode for the audio receiver.
Connect the audio cable into the jacks securely.
Turn on the monitor connected with the audio cable.
Set the Audio Output to the correct position,
and then turn on the DVD player again by pressing
the POWER button.
Point the remote control toward the remote sensor of
the product.
Use the remote control within 15 feet.
Remove the obstacle.
Replace with new battery.
Buttons do not work.
No sound
When a disc is brought from a cold environment to a warm one, there may be moisture
on the the disc, or condensation on the pickup lens. It will affect disc playback.
1. Remove the disc from the DVD player.
2. Turn on the power and leave it on for an hour to vaporize the condensation.
36
Moisture or condensation on lens
Quality installations are best
performed by qualified and
certified installers.
Don t touch the unit if there is
a flash of lightning. You may
receive an electric shock.
Do not cover or stop up heater
ducts or vents. It may cause a
fire or receive an electric shock.
Watching the monitor for an
extended period of time
without the engine running
may deplete the vehicle s
battery charge.
This product is designed for
operation with a 12 Volt DC,
negative ground vehicle. It
is not suitable for operation
under other conditions or
voltages.
CAUTION
Operating Notes
Do not bring magnetic devices
such as credit card or magnetic
card near the magnets.
1. The operating temperature of this product is limited to 14 ~+140 F.
2. If your vehicle is extremely hot or cold you must allow time for your air
conditioner or heater to cool or heat the vehicle until operating temperatures
have returned to normal operating ranges.
3. Optimal picture quality is achieved when viewed from directly front of the
monitor (+/-30degrees).
4. Do not open the housing and attempt to make any repairs yourself. Refer
servicing to qualified personnel.
5. DVD Players use an invisible laser beam which can cause hazardous radiation
exposure. Be sure to operate the unit correctly as instructed.
6. Do not cut the car power supply off while a disc is playing. It can cause
damage to the DVD Player.
7. If the buttons get stuck, please try to press the up of buttons, it will get back.
It won't impact using normal.
8. If you cann't find the files name in list when playing, please reset units or
turn off/on over again.
9. If the unit cann't be change mode when playing some special files which the unit
didn't support, please reset units or turn off/on over again.
Caution

M
PLAY AV MENU
POWER
Features and Controls
6
Disc Information
DVD features
DVD discs provide high-resolution images with high-quality sound. This DVD player
can play not only DVD discs of various versions, but also S-VCD, VCD, audio CD and
MP3 discs.
Discs that cannot be played
DVD-RW, DVD-REM, CD-ROM, CD-EXTRA discs cannot be played on this unit. In
addition, a CD or a CD-RW which was recorded on special software cannot be played.
Region code
Your DVD player is designed and manufactured to region management information
that is recorded on a DVD disc. Please check the region code.
1: NorthAmerica 2: Japan 3: Korea and SoutheastAsia
4:Australia, Mid & South America 5: Russia 6: China
How to handle the disc
Don t touch the shiny side of the disc (the side with the embedded information).
Don t stick a label or a glue-based note on either side of the disc.
Don t use discs that have glue or a damaged label with exposed adhesive residue.
It might result in damage to your DVD player.
Don t put discs in the sunshine.
Park your car in the shade.
How to handle the discs
Only use round discs. Discs with other shapes like a star, a heart, etc. may cause
damage to the player. If a disc is dirty, wipe softly with a wet cloth and then with a dry
one. Before playback, wipe the disc outward from the center with a clean cloth. Do not
use any type of solvent such as thinner, benzene, commercially available cleaners or
antistatic spray. To avoid damaging your DVD player, don t use a scratched disc.
35
Remote Control
Wireless Headphones
(Not Included)
Monitor/DVD Player
MONITOR
Vol+
Vol-
Monitor/DVD Player

Features and Controls
7
Installation
34
M
PLAY AV MENU
POWER
Caution
Do not bring magnetic devices
such as credit cards or magnetic
cards near the monitor.
..
..
X
Dome Light Button
POWER Button
AV Select Button
MENU Button
+/- Buttons
PLAY/PAUSE Button
1. Open the package and check that these items are presents.
INSTALLATION PLATE UNIT SCREWA SCREW B
2. Connect the external compoments to the RCAcable or AV output.
(Refer to the connection diagram on page 33)
3. Match the position of installation bracket and
installation plate with screwA.
4. Tighten the unit with the supplied
screw B.
EJECT Button Disc loading slot
SD Input USB Input
M
PLAY AV MENU
POWER
Dome Light Button
FAST Forward/Reverse Button
RESET
R L
AUDIO VIDEO
AV2INPUTS
SD USB

MONITOR
Vol +
Vol -
Remote Control
Turns the DVD Player/Monitor on or off.
(not function in this unit)
DVD AV1 AV2
AV SELECT
P/N
This button permits you to choose
among Multi, PALand NTSC.
Use to move to the desired menu.
DISPLAY
Press to show elapsed or remaining
time of a chapter or a title.
NUMERIC button
Use when making a selection on the
menu screen.
MODE
DVDSDUSB
POWER
1
2
MUTE
Press this button to switch off the
audio during playback. Press again
to restore the audio.
3
VOL-/VOL+ (not function in this unit)
MENU (OSD on monitor)
Press this button to open the on-
screen menu system to setup and
control various parameters of the
monitor and DVD player.
UP/DOWN
MENU (DVD menu)
This button permits you to view the
menu on the DVD.
SUBTITLE
Use this button to select the menu
for choosing a subtitle language.
TITLE (Title menu)
When a DVD is playing, press this
button to view the Title Menu.
PBC (Video CD only)
Press this button to access the special
Playback Control functions for VCD
2.0 format Video CD S.
Use this button to switch between
three modes
To start playback of iPOD, press
this button. Press again to pause
the playback. If playback is paused,
press this button to resume
playback.
RIGHT( )/LEFT( )ARROWS
(not function in this unit)
Use to incease or decrease
volume level.
Use these buttons(press once)
to skip to the next or last track,
chapter or file on the iPOD in
the player. But if you use these
buttons (press continuous) to
select either fast forward or fast
reverse playback.
833
Connection Diagram
Features and Controls
CAMCORDER
GAME
White AUDIO(L)
Red AUDIO(R)
Yellow VIDEO CAMCORDER
GAME
White AUDIO(L)
Red AUDIO(R)
Yellow VIDEO
AV Input
(AV 2) (AV 1)
White AUDIO(L)
Red AUDIO(R)
Yellow VIDEO
AV
Output
AMP
MENU
POWER VOL- VOL+
AV
MONITOR
AV Input
YELLOW
ACC
BLACK
RED
+ 12 V DC Battery
Chassis Ground
Door Trigger
WHITE
FM ANTENNA
+ Door Trigger -

9
Features And Controls
SD/USB Functions
32
Features and Controls
SD/USB Functions
A-B (repeat fromAto B)
VOL-/+ button
AUDIO
ENTER
ZOOM
UP/DOWN/RIGHT/LEFTARROWS
PLAY/PAUSE
GOTO
STOP
SKIPFORWARD/BACK
FAST FORWARD/REVERSE PLAY
Use these buttons to select either fast
forward or fast reverse playback.
Use this button to select the beginning
and end of a track which you wish to have
repeat in playback.
Use to incease or decrease volume level.
Use this button to select one of the
audio soundtracks programmed on a
DVD disc. It is alse used to select the
audio output mode for the DVD
playback.
Press this button to confirm the item
you have found and highlighted using
the arrow buttons. Usually this is done
to confirm a selection or item to be
played on the DVD.
If your DVD disc supports zooming in
to see the program differently, pressing
this button will enable you to change
the amount of zoom.
Use thes buttons to navigate the
various menus and screens for the
monitor and DVD systems.
To start playback of a disc, press this
button. Press again to pause the
playback. If playback is paused, press
this button to resume playback.
Use to search for a title or a chapter on
your DVD disc.
Press this button to stop the playback
of the current disc.
Use these buttons to skip to the next
or last track, chapter or file on the
disc in the player.
RETURN
SETUP
Press this button to display the Setup
menu. The Setup menu enables you
to enter the settings required for the
unit to work properly.
REPEAT
Press this button to change the playback
mode to repeat.
Press this button to return to the root menu
1. When USB or SD is inputed, the monitor will be displayed as shown below. But when
you input USB that the function can not change into SD state (only the SD is
moving).And you can select the desired menu by
2.
pressing the MODE button on the
remote control of monitor.
Use the (arrow and ENTER) buttons to select and set desired settings.
00:00
000/003
00:00 kbps
S
\
..
..

Power and Mode Selection
10
DVD Functions
PBC
[DVD]/[AUDIO]/[MP3]
[VCD]
You can turn the PBC (Play Back Control) function on or off by pressing this button.
When PBC is loaded, the PBC function is enabled automatically. This function is
similar to selection of DVD title. Please note that this function does not work with
MP3 dics.
Zoom
[DVD]
Some DVDs are programmed to allow you to zoom into
the image, magnifying it. Pressing the ZOOM button
does this in steps, according to the chart to the right.
[VCD]/[AUDIO]/[MP3]
GO TO
The GO TO function allows you to begin playback at a specific location on the disc.To
do this, press GO TO and navigate the screen which follows to select this playback
location.
Title
Move to the desired title.
Chapter
Move to the desired chapter.
Audio
Selects the desired audio output.
Subtitle
Select the desired subtitle.
Angle
Watch the different view angle.
TT Time
Total time.
CH Time
Chapter time.
Repeat
Sets the repeat play.
Time Display
Watch play time.
31
OSD
2X
3X
4X
1/2
1/3
1/4
ZOOM X 2
CONDITION
ZOOM X 3
ZOOM X 4
ZOOM X 1 / 2
ZOOM X 1 / 3
ZOOM X 1 / 4
Off
Menu
Title
Chapter
Audio
Subtitle
01/0201 /02
06/6106 /61
5.1CH Chinese5.1CH Chinese
OFF
Bitrate 31Bitrate 31 Title Elapsed 0:20:02Title Elapsed 0:20:02
This button does not function in PBC mode.
This button does not function in this mode.
Mute Function
1. Press the button on the remote control to mute the audio.MUTE
2. Press the button again on the remote control to return to theMUTE
previous volume level.
Releasing The Monitor
Push the release button (located on the front edge of the screen housing) and
lower the monitor. You can also adjust the swivel angle.
Turning on The Monitor
Make this arrow in DOWN
direction only.
1. Connect the monitor to external devices.
2. Press the POWER button on either the remote control or the unit once to turn
the power on.
Press the same POWER button to turn the power off.
3. Power on the external devices and play.
PULLBUTTON
POWER
POWER
UNIT
REMOTE CONTROLLER

Power and Mode Selection
11
DVD Functions
Repeat
Pressing REPEAT button changes
the play mode as follows:
[DVD]
OSD CONDITION
Chapter
Title
All
Repeat chapter
Repeat title
All
Repeat off
[VCD]
The REPEAT button does not function
when a VCD disc is being played.
Pressing REPEAT button changes
the play mode as follows:
[AUDIO]
OSD CONDITION
Track
All
Repeat single
All
Repeat off
[MP3]
Pressing REPEAT button changes
the play mode as follows:
OSD CONDITION
Repeat One
Repeat Folder
Folder
Single
Repeat folder
All
Random play
Shuffle
Random
Single
Repeat folder one time
Single play
NTSC/PAL
This button is used to select the video standard for the DVD mode between NTSC
and PAL formats.
Angle
Some DVD s are recorded with additional footage which allows you to view a scene
from a different camera angle. If theANGLE feature is enabled in the Setup Menu
(see page 14) and the disc has this option,an angle mark will be displayed on
the screen. When that occurs, press theANGLE button to see these alternate viewing
angles.
30
Selecting an AV mode
1. Turn the power ON on the unit and on the external devices.
2. Select the DVD,AV1 orAV2 mode by pressing theAV Select button on
the unit or on the remote control.
3. Play the external device.

Picture Control
12
DVD Functions
Prev( )
Press this button to advance the player from the current chapter
.to the previous chapter
[DVD]/[VCD]
[AUDIO]/[MP3]
Press this button to move to the previous track.
Next( )
Press this button to advance the player from the current chapter .to the next chapter
[DVD]/[VCD]
[AUDIO]/[MP3]
Press this button to move from the current track .to the next track
Repeat(A-B)
You can set the player to repeat a segment over and over until you cancel it. To do
this, you mark the beginning of the desired segment (A) and the end of segment (B).
The selected segment will be
repeated automatically until canceled.
[DVD]/[VCD]/[AUDIO]
29
OSD CONDITION
A
AB
Start point of repeat
Ending point repeat function
To adjust CONTRAST, BRIGHTNESS, COLOR or FM press the MENU button until
you arrive at the screen for that item. Use the arrow buttons to adjust the value.
Press the MENU button to make another adjustment or leave the MENU system.
Contrast/Brightness/Color/FM
CONTRAST
BRIGHTNESS
COLOR
50
50
50
1. Bring up the on-screen function menu by pressing the MENU button on the unit
or the remote control.
2. Press the MENU button on the unit or the remote control of monitor until you see
the item you wish to adjust.
3. Use the arrow buttons to adjust the value.
4. Press the MENU button to make another adjustment or leave the MENU system.
FM
87.7
(FM function added 87.7 87.9 88.1 88.3 88.5
88.7 88.9 89.1MHz)

DVD Setup
Setup Menu-Main Page
When the button is pressed, the setup menu will be displayed as shown
below. Select the menu category and make changes according to your preferences.
SETUP
1. Press the button if the disc is playing.STOP
2. Press the button to display setup menu.SETUP
3. Use the (arrow and ENTER) buttons to select and set desired settings.
4. Press the button again to turn off the setup menu.SETUP
13
TV DisplayTV Display
Angle MarkAngle Mark
OSD LangOSD Lang
Screen SaverScreen Saver
PS
On
ENG
On
Go To General Setup PageGo To General Setup Page
General Setup PageGeneral Setup Page
DVD Functions
Fast Reverse Searching( )
Pressing FR button repeatedly changes
the play mode as follow:
[DVD]
OSD CONDITION
FR 2X
FR 4X
FR 8X
2X rewind search
4X rewind search
Pressing FR button
changes the play mode as follow:
repeatedly
[AUDIO]
[MP3]
Pressing FR button
changes the play mode as follows:
repeatedly
FR 16X
FR 32X
PLAY
8X rewind search
16X rewind search
32X rewind search
Play
OSD CONDITION
FR 2X
FR 4X
FR 8X
2X rewind search
4X rewind search
FR 16X
FR 32X
PLAY
8X rewind search
16X rewind search
32X rewind search
Play
OSD CONDITION
FR 2X
FR 4X
FR 8X
2X rewind search
4X rewind search
FR 16X
FR 32X
PLAY
8X rewind search
16X rewind search
32X rewind search
Play
Fast Forward Searching( )
Pressing FF button changes
the play mode as follow:
repeatedly
[DVD]
OSD CONDITION
FF 2X
FF 4X
FF 8X
2X forward search
4X searchforward
Pressing FF button
changes the play mode as follow:
repeatedly
[AUDIO]/[VCD]
[MP3]
Pressing FF button
changes the play mode as follows:
repeatedly
FF 16X
FF 32X
PLAY
8X searchforward
16X searchforward
32X searchforward
Play
OSD CONDITION
FF 2X
FF 4X
FF 8X
2X forward search
4X searchforward
FF 16X
FF 32X
PLAY
8X searchforward
16X searchforward
32X searchforward
Play
OSD CONDITION
FF 2X
FF 4X
FF 8X
2X forward search
4X searchforward
FF 16X
8X searchforward
16X searchforward
28
FF 32X
PLAY
32X searchforward
Play

DVD Setup
General Setup
1. TV Aspect Ratio
In the Setup function called TV Display, you set the player to output the video signal at the
same aspect ratio as your monitor. If the monitor is widescreen format, select WIDE.
If it is as normal screen (4:3), choose NORMAL/PS (Pan and Scan) or NORMAL L/B
(Letterbox). Normal/PS4:3PANSCAN
Choose this setting if you want the movie to fill the entire screen.
(This might mean that the left and right edges won t be seen)
Normal/LB4:3
Choose this setting if you want to see the movie in its original aspect ratio.
(The movie might appear with black bars at the top and bottom of the screen.)
Wide 16:9 WIDE SCREEN
Choose this setting if your DVD Player is connected to a widescreen TV.
(This opition is available only if the disc has a 16:9 display aspect ratio.)
2. Angle Viewing
Some DVD discs contain programming which allows you
to view a scene from a few different camera angles. You
can tell when a scene is so recorded when an Angle Mark
is displayed on the screen. This mark will only appear if you
have enabled theAngle Mark feature
in the DVD Setup menu.
On: When selected, the screen will be shown with
angle mark.
Off: When selected, no angle mark is shown on
the screen.
3. OSD Language
Use this option to set the OSD language.
When selected, change to set the on-screen display
language.
14
Angle MarkAngle Mark
OSD LangOSD Lang
Screen SaverScreen Saver
On
ENG
On
Set TV Display ModeSet TV Display Mode
General Setup PageGeneral Setup Page
Normal/LB
Wide
TV DisplayTV Display PS Normal/PS
OSD LangOSD Lang
Screen SaverScreen Saver
ENG
On
Set Angle MarkSet Angle Mark
General Setup PageGeneral Setup Page
Off
TV DisplayTV Display PS
Angle MarkAngle Mark On On
Screen SaverScreen Saver On
Set OSD LanguageSet OSD Language
General Setup PageGeneral Setup Page
TV DisplayTV Display PS
Angle MarkAngle Mark On
OSD LangOSD Lang ENG
English
Korean
French
German
Italian
Spanish
Portuguese
Dutch
English
Korean
French
German
Italian
Spanish
Portuguese
Dutch
DVD Functions
Subtitle(SUB-T)
This button is used to select the language for the on-screen display system.
(This title menu may vary, depending on the particular DVD.)
[DVD]
OSD
1/2
Title
Slow( )
27
Used to display the title menu of the loaded DVD disc.
This function is only present on discs which support it.
[DVD]
[DVD]/[VCD]
CONDITION
1/4
1/8
2X slow forward
4X slow forward
8X slow forward
Use this button to play a disc in slow-forward or
slow-reverse. Slow playback can be done at five
different speeds. Pressing this button repeatedly
decreases the speed in steps. Pressing a sixth
time returns playback to the normal speed.
1/16
1/2
1/4
1/8
1/16
Play
16X slow forward
2X slow rewind
4X slow rewind
8X slow rewind
16X slow rewind
Play
1/32 32X slow forward
1/32 32X slow rewind

DVD Setup
Audio Setup
4. Screen Saver
The screen saver is useful to prevent your display
from becoming damaged. The screen saver picture
appears when you leave the DVD player in stop mode
for about two minutes.
15
Angle MarkAngle Mark
OSD LangOSD Lang
On
ENG
Screen SaverScreen Saver
General Setup PageGeneral Setup Page
TV DisplayTV Display PS
Go To Speaker Setup PageGo To Speaker Setup Page
Audio Setup PageAudio Setup Page
Speaker Setup
SPDIF Setup
Dolby Digital Setup
Channel Delay
Equalizer
3D Processing
Speaker Setup
SPDIF Setup
Dolby Digital Setup
Channel Delay
Equalizer
3D Processing
Off
Screen SaverScreen Saver On On
DVD Functions
Display
Pressing the DISPLAY on the
remote control changes the play mode as
follows:
button
[DVD]
OSD CONDITION
Title Elapsed
Title Remain
Chapter Elapsed
Display the Title Elapsed
Display the Title Remain
Display the Chapter Elapsed
[VCD]
Whenever press the button,title chapter
will be displayed as follows:
Pressing the display button displays
information about the current CD on the
screen as follows:
[AUDIO]
OSD CONDITION
Single Elapsed
Single Remain
Display the single elapsed
Display the single remain
Display the total elapsed
[MP3]
Your DVD player will display the counter
automatically when you play the MP3 disc.
Number Buttons
The 0 through 9 number buttons are used to enter the number of the track, the number
of the DVD chapter, the time, the date, etc.
26
OSD CONDITION
Single Elapsed
Single Remain
Display time
Left display time
No sign
Chapter Remain
Display Off
Display the Chapter Remaining
No sign
Display Off
Total Elapsed
Total Remain Display the total remaining
[DVD]
Select a track by pressing the
corresponding number button.
[AUDIO]
You can select a track in the folder by
pressing the corresponding number button.
[DVD]
OSD CONDITION
Select Track:__ Select track no
OSD CONDITION
__:__ Select track no

Dual Mono
Use this function to set the input audio
signal to match your speaker setup.
Dynamic
Use this function to change the setting
from the factory.
Set DRC OffSet DRC Off
Dual MonoDual Mono STR
Dynamic
Dolby Digital SetupDolby Digital Setup
L-Mono
R-Mono
Dual MonoDual Mono Stereo
Mix-Mono
Dolby Digital SetupDolby Digital Setup
Dynamic
FULL
3/4
1/2
1/4
OFF
1. Dolby Digital Setup
Dynamic
Dual Mono (1 + 1) SetupDual Mono (1 +1) Setup
Dolby Digital SetupDolby Digital Setup
L-Mono
R-Mono
Dual MonoDual Mono STR Stereo
Mix-Mono
DVD Setup
Show below are two examples of Audio Setups.
Go To Dolby Digital SetupGo To Dolby Digital Setup
Audio Setup PageAudio Setup Page
Speaker Setup
SPDIF Setup
Dolby Digital Setup
Channel Delay
Equalizer
3D Processing
Speaker Setup
SPDIF Setup
Dolby Digital Setup
Channel Delay
Equalizer
3D Processing
Set Stereo SetupSet Stereo Setup
STR
16
Go To Equalizer PageGo To Equalizer Page
Audio Setup PageAudio Setup Page
Speaker Setup
Spdif Setup
Dolby Digital Setup
Channel Delay
Equalizer
3D Processing
Speaker Setup
Spdif Setup
Dolby Digital Setup
Channel Delay
Equalizer
3D Processing
2. Equalizer Settings
Bass BoostBass Boost
Super BassSuper Bass
Treble BoostTreble Boost
Off
Off
Off
Select Equalizer TypeSelect Equalizer Type
Equalizer PageEqualizer Page
Rock
Pop
Live
Dance
Techno
Classic
Soft
EQ TypeEQ Type None None
DVD Functions
Stop( )
In DVD mode, Press STOP to stop playback.
To resume playback, press PLAY/PAUSE. If
you press STOP and then PLAY/PAUSE twice,
the player will begin playback at the first
scene of the movie.
[DVD]/[AUDIO]
In MP3 mode, Pressing STOP will stop
audio playback. Press PLAY/PAUSE to begin
playback of the first title on the disc.
the
[MP3]
Menu
Pressing the SETUP brings up the DVD disc menu. The content of this menu varies,
depending on the programming of the disc.
25
[DVD]
OSD CONDITION
1 Time Press Play KeyTo Continue Stop
OSD CONDITION
1Time Stop Stop
Arrows( / / / )
In addition to navigating the various menus, you can use the arrow buttons to define the area
of the screen you want to enlarge in ZOOM mode.
[DVD]
After pressing STOP button, select the desired folder and set the condition by pressing
ENTER button.
Disc Stop
2Time
Setup
Pressing the SETUP button opens the Setup Menu, where you can make and adjust DVD
settings to suit your equipment and preferences.
[MP3]

DVD Setup
EQ Equalizer Type
In this menu you can choose the desired preset
equalizer mode.
(Choose from Rock, Pop, Live, Dance, Techno,
Classic or Soft)
Bass Boost
The Bass Boost function increases the volume
level of the bass frequencies.
Super Bass
Super Bass Boost further increases the volume
level of the bass frequencies.
Treble Boost
Treble Boost increases the volume level of the upper
frequencies.
17
Bass BoostBass Boost
Super BassSuper Bass
Treble BoostTreble Boost
Off
Off
Off
Select Equalizer TypeSelect Equalizer Type
Equalizer PageEqualizer Page
Rock
Pop
Live
Dance
Techno
Classic
Soft
EQ TypeEQ Type None None
Super BassSuper Bass
Treble BoostTreble Boost
Off
Off
Boss BoostBoss Boost
Equalizer PageEqualizer Page
EQ TypeEQ Type None
Off
Bass BoostBass Boost Off On
Treble BoostTreble Boost Off
Super BassSuper Bass
Equalizer PageEqualizer Page
EQ TypeEQ Type None
Off
Bass BoostBass Boost Off
On
Super BassSuper Bass Off
Treble BoostTreble Boost
Equalizer PageEqualizer Page
EQ TypeEQ Type None
Off
Bass BoostBass Boost Off
On
Super BassSuper Bass Off
Treble BoostTreble Boost Off
DVD Functions
Eject
Audio
Change the audio output format.
(A the disc supports available audio
type.)
vailable only if
24
[DVD]
Changes the audio output format.
(Available only of the disc supports available audio
type.)
[VCD]/[AUDIO]
OSD CONDITION
Mute Mute
Mute off
Mute off
Vol+/Vol-
Use these buttons to adjust the audio output level of the speaker from 0 to 100.
Mute
Press MUTE to turn off the audio part of the
currently playing program. Press it again to
return the audio volume to the level at which
you were last listening.
OSD CONDITION
Play Disc
Pause
Play or Pause( )
When this button is pressed, the disc is ejected. When this button is pressed for more
than 3 seconds, the disc is unconditionally ejected. Use this function if you encounter
difficultly ejecting a disc.
An invalid button press.
[MP3]
OSD CONDITION
2 Channel
5.1 Channel
1/2:Ac32CHEnglish
2/2:Ac35.1CHEnglish
OSD CONDITION
Stereo
Mono Left
Stereo
Mono Left
Mono Right
Mix Mono
Mono Right
Mix Mono
Whenever this button is pressed, the mode
switches from pause to play or play to pause.

DVD Setup
Video Setup
Sharpness can be adjusted by highlighting it in the menu and then using the
UP/DOWN arrow buttons to increase or decrease the sharpness.
In the Video Setup, you can make adjustments to various elements of the picture quality.
18
Brightness
Contrast
Gamma
00
00
None
Color
Video Quality SetupVideo Quality Setup
Medium
Low
Color MID High
Hue
Saturation
Luma DelayLuma Delay
00
00
1T1 T
Picture Quality
Video Setup PageVideo Setup Page
Component YUV
Quality
Divx VOD
Component YUV
Quality
Divx VOD
Go TO Video Quality Setup PageGo TO Video Quality Setup Page
DVD Setup
Password Setup
1. Password Mode
In the Password setup, you must first enter the current 6-digit passcode, and
then you have the opportunity to change it. The factory default passcode is .
Once you have changed and confirmed the password, press the ENTER button.
136900
2. Password Change
23
Password
Password ModePassword Mode
Password Setup PagePassword Setup Page
Off
Password Mode OnPassword Mode On On
Change PasswordChange Password
Password Setup PagePassword Setup Page
Password Mode OnPassword Mode On On
Password Change Old Password
New Password
Confirm PWD
OK
Password Setup, which is required for using the Parental Controls settings,
is divided into two modules: Turning on the Password function, and setting
a Password. The first step is to turn it on in the Password Mode setting.
Brightness
Contrast
Gamma
00
00
None
Color
Video Quality SetupVideo Quality Setup
Medium
Low
Color MID High
Hue
Saturation
Luma DelayLuma Delay
00
00
1T1 T
Brightness
Use this option to adjust the display brightness. When you reach desired
brightness level, use the / buttons and press the ENTER button.
Video Quality SetupVideo Quality Setup
Hue
Saturation
Luma DelayLuma Delay
00
00
1T1 T
Brightness
Brightness 0
Brightness
Contrast
Gamma
00
00
None
Color MID
Brightness
Please Enter Old PasswordPlease Enter Old Password

Contrast
Use this option to adjust the contrast level.
Use the / buttons and press the ENTER button, when you reach the
desired contrast level. The contrast control increases or decreases the ratio of
bright and dark screen sections.
Brightness
Gamma
00
None
Contrast
Video Quality SetupVideo Quality Setup
Color MID
Hue
Saturation
Luma DelayLuma Delay
00
00
1T1 T
Contrast 00
Contrast
Contrast 0
DVD Setup
19
DVD Setup
Use the Disc Menu option to select the display
language for a DVD s disc menu display language.
(not the same as the players menu)
1. Press the SETUP button during stop mode.
2. Press the / buttons to move to Preference.
3. Press the / buttons to move to Disc Menu.
4. Press the ENTER button.
5. Press the / buttons to select Disc Menu.
5. Disc Menu
The Parental Control settings limit the player to only play content at or below a certain
movie rating. The ratings systems in different countries vary. In the USA, the Motion
PictureAssociation of America(MPAA) rates movies as G, PG, PG-13, etc.
In this menu item, you can set what is the highest level of rating you wish to allow the
unit to play.
1. Press the SETUP button when stop mode.
2. Press the / buttons to move to Preference.
3. Press the / buttons to move to Parental.
4. Press the ENTER button.
5. Press the / buttons to select desired
parental level.
6. Parental
If you select RESET when in the DEFAULT settings
mode, all the settings of the Setup Menu will be
returned to the factory defaut settings, except for
Parental Level, Region and Password values.
1. Press the SETUP button when stop mode.
2. Press the / buttons to move to Preference.
3. Press the / buttons to move to Default.
4. Press the ENTER button to select Reset.
7. Default
22
PBC
Audio
Subtitle
On
ENG
Preferred Menu LanguagePreferred Menu Language
Preference PagePreference Page
French
Spanish
TV TypeTV Type Ntsc English
Parental
Default
Japanese
Korean
Chinese
Thai
Russian
Disc MenuDisc Menu ENG
PBC
Audio
Subtitle
On
ENG
Load Factory SettingLoad Factory Setting
Preference PagePreference Page
TV TypeTV Type Ntsc
Disc MenuDisc Menu ENG
Parental
Reset
Default
PBC
Audio
Subtitle
On
ENG
Set Parental ControlSet Parental Control
Preference PagePreference Page
TV TypeTV Type Ntsc 1KIDSAF
2G
3P
G
4PG13
5PGR
6R
7 NC17
8ADULT
1KID SAF
2G
3PG
4PG 13
5PGR
6R
7NC17
8ADULT
Parental
Default
Disc MenuDisc Menu ENG
Gamma
Hue
Select screen hue level using the direction / buttons and press the ENTER button.
Brightness
Contrast
00
00
Gamma
Video Quality SetupVideo Quality Setup
Medium
Low
Color MID
Hue
Saturation
Luma DelayLuma Delay
00
00
1T1 T None
Gamma None High
Brightness
Contrast
00
00
Hue
Video Quality SetupVideo Quality Setup
Color MID
Saturation
Luma DelayLuma Delay
00
1T1 T
Gamma None
Hue 00
Hue
Hue 0
In some systems, you might experience a loss in the strength of the dark sections of
the displayed picture. This can be helped by changing the Gamma setting, which
boosts the dark level but leaves the other levels unchanged.

DVD Setup
Saturation
Select screen saturation level using the direction / buttons and press the
ENTER button.
Luma Delay
Select the Luma Delay menu and select the preferred video image quality.
20
Brightness
Contrast
00
00
Saturation
Video Quality SetupVideo Quality Setup
Color MID
Luma DelayLuma Delay 1T1 T
Gamma None
Hue 00
Saturation 00
Saturation
Saturation 0
Brightness
Contrast
00
00
Luma DelayLuma Delay
Video Quality SetupVideo Quality Setup
Color MID
Gamma None
Hue 00
Saturation 00
Luma DelayLuma Delay 1T1 T
DVD Setup
Preference
1. TV Type
Choose the proper TV format appropriate to the
monitor you have connected to the player from
the following: NTSC, PAL or Multi type.
1. Press the SETUP button during stop mode.
2. Press the / buttons to move to Preference.
3. Press the / buttons to move to TV Type.
4. Press the ENTER button.
5. Press the / buttons to select TV Type.
2. PBC (Play Back Control)
This feature is only available when a SVCD disc
is loaded. It allows you to disable or enable the
PBC (Play Back Control) menu of VCD discs.
1. Press the SETUP button during stop mode.
2. Press the / buttons to move to Preference.
3. Press the / buttons to move to PBC.
4. Press the ENTER button.
5. Press the / buttons to select TV TypeOn/Off.
3. Audio
Use the audio language menu to select the subtitle
language that you prefer. If the disc you are playing
has that language available, it will display subtitles
in that language.
1. Press the SETUP button during stop mode.
2. Press the / buttons to move to Preference.
3. Press the / buttons to move toAudio.
4. Press the ENTER button.
5. Press the / buttons to select desired
audio language.
4. Subtitle
In the Subtitle menu, you can select a subtitle
language. Please note that subtitle will only
appear in this language if the disc programming
has included it.
1. Press the SETUP button during stop mode.
2. Press the / buttons to move to Preference.
3. Press the / buttons to move to Subtitle.
4. Press the ENTER button.
5. Press the / buttons to select desired
subtitle.
21
PBC
Subtitle
On
Preferred Audio LanguagePreferred Audio Language
Preference PagePreference Page
French
Spanish
TV TypeTV Type Ntsc English
Parental
Default
Japanese
Korean
Chinese
Thai
Russian
Disc MenuDisc Menu ENG
Audio ENG
PBC
Audio
On
ENG
Preferred Subtitle LanguagePreferred Subtitle Language
Preference PagePreference Page
French
Spanish
TV TypeTV Type Ntsc
Parental
Default
Japanese
Korean
Chinese
Russian
Disc MenuDisc Menu ENG
Subtitle
Thai
Others
Thai
Others
Audio
Subtitle
ENG
Set PBC StateSet PBC State
Preference PagePreference Page
TV TypeTV Type Ntsc
On
Parental
Default
Disc MenuDisc Menu ENG
Off
PBC On
PBC
Audio
Subtitle
On
ENG
Set TV StandardSet TV Standard
Preference PagePreference Page
Parental
Default
Disc MenuDisc Menu ENG
PAL
Multi
NTSC
TV TypeTV Type Ntsc
0T
1T1T
