PWR-100154 –User Guide
The following information is to be included in the PWR-100154 User Guide to accompany the
product on a printed insert. For readability, the product is described as the PEEX tX
Transmitter and PEEX tX in this guide.
N.B. The PEEX tX is a professional part of the PEEX system which is only available for
installation and use by trained operators. Operators must confirm that the radio channels
selected for use are allowed by the country specific regulations before enabling transmission.
There will be five main elements covered, Radio Specifications; Installation; Use; Status and
Care.
Radio Specifications:
Approved for Use Country List
Austria
Hungary
Portugal
Belgium
Iceland
Romania
Bulgaria
Ireland
Slovakia
Croatia
Italy
Slovenia
Cyprus
Latvia
Spain
Czech Republic
Liechtenstein
Sweden
Denmark
Lithuania
Switzerland
Estonia
Luxembourg
Turkey
Finland
Malta
United Kingdom
France
Netherlands
United States of
America
Germany
Norway
Canada
Greece
Poland
Australia & New
Zealand
DFS
Dynamic Frequency Selection
TPC
Transmit Power Control
e.i.r.p
effective (or equivalent) isotropic radiated power
PSD
Power Spectral Density
COP
Conducted Output Power
LSB
Listen before talk

PowerChord Group Limited
Registered in England & Wales No. 9303518
Registered Office: 1 Blythe Road, London W14 0HG
US Regulatory Requirements
Frequency [MHz]
20 MHz channels
Applicable standard
5150-5350
36,40,44,48,52,56,60,64
FCC Part 15 Subpart
E (U-NII)
5470-5725
100,104,108,112,116,120,124,128,132,136,140,144
FCC Part 15 Subpart
E (U-NII)
5725-5850
149,153,157,161,165
FCC Part 15 Subpart
E (U-NII)
5150-5250 MHz
Available 20 MHz channels: 36,40,44,48
Section in standard
Maximum PSD
17 dBm in any 1 MHz band
FCC §15.407.a.1.i/ii
Maximum COP
1W with antenna gain < 6dBi
FCC §15.407.a.1.i/ii
Radar detection
No
FCC §15.407.h.2
TPC
No
FCC §15.407.h.1
LSB
No
N/A
5250-5350 MHz
Available 20 MHz channels: 52,56,60,64
Section in standard
Maximum PSD
11 dBm in any 1 MHz band
FCC §15.407.a.2
Maximum COP
Whichever is lower 250 mW
(24 dBm) or 11 dBm + 10 log B,
where B is the 26 dB emission
bandwidth in MHz,
with antenna gain < 6dBi
FCC §15.407.a.2
Radar detection
Yes
FCC §15.407.h.2
TPC
No
FCC §15.407.h.1
LSB
No
N/A
5470-5725 MHz
Available 20 MHz channels: 100,104,108,112,116,120,124,128,132,136,140,144
Section in standard
Maximum PSD
30 dBm in any 500-kHz band
FCC §15.407.a.3
Maximum COP
1W, with antenna gain < 6dBi
FCC §15.407.a.3
Radar detection
Yes
FCC §15.407.h.2
TPC
No
FCC §15.407.h.1
LSB
No
N/A

PowerChord Group Limited
Registered in England & Wales No. 9303518
Registered Office: 1 Blythe Road, London W14 0HG
5725-5850 MHz
Available 20 MHz channels 149,153,157,161,165
Section in standard
Transmit power (including
antenna gain) e.i.r.p
14 dBm
EN 300 440 7.1.3
Radar detection
No
N/A
TPC
No
N/A
LSB
Yes
EN 300 440 9
EU Regulatory Requirements
Frequency
[MHz]
20 MHz channels
Applicable standard
5150-5350
36,40,44,48,52,56,60,64
ETSI EN 301 893 V2.1.1
5470-5725
100,104,108,112,116,120,124,128,132,136,140,144
ETSI EN 301 893 V2.1.1
5725-5850
149,153,157,161,165,169
ETSI EN 300 440
5150-5250 MHz
Available 20 MHz channels: 36,40,44,48
Section in standard
Transmit power (including
antenna gain) e.i.r.p
23 dBm (no TPC)
ETSI EN 301 893 Table 2
Radar detection
No
ETSI EN 301 893 4.2.6.1.2
TPC
No
ETSI EN 301 893 4.2.3.1.2
LSB
Yes
ETSI EN 301 893 4.2.7
CAUTION: The 5150 to 5250 MHz band is restricted to indoor use only.
5250-5350 MHz
Available 20 MHz channels: 52,56,60,64
Section in standard
Transmit power (including
antenna gain) e.i.r.p
20 dBm (no TPC)
ETSI EN 301 893 Table 2
Radar detection
Yes
ETSI EN 301 893 4.2.6.1.2
TPC
No
ETSI EN 301 893 4.2.3.1.2
LSB
Yes
ETSI EN 301 893 4.2.7
CAUTION: The 5250 to 5350 MHz band is restricted to indoor use only.
5470-5725 MHz
Available 20 MHz channels: 100,104,108,112,116,120,124,128,132,136,140,144
Section in standard
Transmit power (including
antenna gain) e.i.r.p
27 dBm (no TPC)
ETSI EN 301 893 Table 2
Radar detection
Yes
ETSI EN 301 893 4.2.6.1.2
TPC
No
ETSI EN 301 893 4.2.3.1.2
LSB
Yes
ETSI EN 301 893 4.2.7

PowerChord Group Limited
Registered in England & Wales No. 9303518
Registered Office: 1 Blythe Road, London W14 0HG
5725-5850 MHz
Available 20 MHz channels 149,153,157,161,165,169
Section in standard
Transmit power (including
antenna gain) e.i.r.p
14 dBm
EN 300 440 7.1.3
Radar detection
No
N/A
TPC
No
N/A
LSB
Yes
EN 300 440 9
Regulatory Notices:
FCC ID: 2AO3Y-PWR100154
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution:
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
20cm between the radiator & your body.

PowerChord Group Limited
Registered in England & Wales No. 9303518
Registered Office: 1 Blythe Road, London W14 0HG
IC: 23657-PWR100154
This device complies with Industry Canada license-exempt RSS standard(s). Operation is
subject to the following two conditions:
1) this device may not cause interference, and
2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:
1) l'appareil ne doit pas produire de brouillage, et
2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même
si le brouillage est susceptible d'en compromettre le fonctionnement.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
This device complies with RSS-310 of Industry Canada. Operation is subject to the
condition that this device does not cause harmful interference.
Cet appareil est conforme à la norme RSS-310 d'Industrie Canada. L'opération est
soumise à la condition que cet appareil ne provoque aucune interférence nuisi-
ble.
This device and its antenna(s) must not be co-located or operating in conjunction with
any other antenna or transmitter, except tested built-in radios.
Cet appareil et son antenne ne doivent pas être situés ou fonctionner en conjonction
avec une autre antenne ou un autre émetteur, exception faites des radios intégrées qui
ont été testées.
The County Code Selection feature is disabled for products marketed in the US/
Canada.
La fonction de sélection de l'indicatif du pays est désactivée pour les produits
commercialisés aux États-Unis et au Canada.
Caution:
(i.) the device for operation in the band 5150-5250 MHz is only for indoor use to
reduce the potential for harmful interference to co-channel mobile satellite systems;
(ii.) for devices with detachable antenna(s), the maximum antenna gain permitted
for devices in the bands 5250-5350 MHz and 5470-5725 MHz shall be such that the
equipment still complies with the e.i.r.p. limit;

PowerChord Group Limited
Registered in England & Wales No. 9303518
Registered Office: 1 Blythe Road, London W14 0HG
(iii.) for devices with detachable antenna(s), the maximum antenna gain permitted for de-
vices in the band 5725-5850 MHz shall be such that the equipment still complies with the
e.i.r.p. limits as appropriate;
(iv.) where applicable, antenna type(s), antenna models(s), and worst-case tilt angle(s)
necessary to remain compliant with the e.i.r.p. elevation mask requirement set forth in
section 6.2.2.3 shall be clearly indicated.
Avertissement:
Le guide d’utilisation des dispositifs pour réseaux locaux doit inclure des instructions précises
sur les restrictions susmentionnées, notamment :
(i.) les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement
pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux
systèmes de satellites mobiles utilisant les mêmes canaux;
(ii.) le gain maximal d’antenne permis pour les dispositifs utilisant les bandes de 5250 à 5 350
MHz et de 5470 à 5725 MHz doit être conforme à la limite de la p.i.r.e;
(iii.) le gain maximal d’antenne permis (pour les dispositifs utilisant la bande de 5 725 à 5 850
MHz) doit être conforme à la limite de la p.i.r.e. spécifiée pour l’exploitation point à point et
l’exploitation non point à point, selon le cas;
(iv.) De plus, les utilisateurs devraient aussi être avisés que les utilisateurs de radars de
haute puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les
bandes 5250-5350 MHz et 5650-5850 MHz et que ces radars pourraient causer du brouillage
et/ou des dommages aux dispositifs LAN-EL.
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled en-
vironment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
Declaration d'exposition aux radiations:
Cet équipement est conforme aux limites d’exposition aux rayonnements IC établies pour
un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un min-
imum de 20 cm de distance entre la source de rayonnement et votre corps.
47 CFR § 2.1077 Compliance Information (SDoC)
Responsible Party -
RML Labs
2550 E Desert Inn Rd. #438
Las Vegas NV 89121
[phone]

PowerChord Group Limited
Registered in England & Wales No. 9303518
Registered Office: 1 Blythe Road, London W14 0HG
Installation:
1) The PEEX tX Transmitter is a sealed device with no assembly required.
2) The device can be mounted using a number of attachment points suitable for cable
ties. If mounted at height, the PEEX tX should have a certified safety harness
connected between permanent infrastructure and the safety loop point at the top of
the PEEX tX.
Figure 1. The PEEX PWR-100154 Transmitter Attachment Points and Mounting Plate
3) Mounting to typical 50mm tubing and other fixed infrastructure can be achieved by
attachment of a suitable clamp to the mounting plate at the rear of the PEEX tX. The
clamp should use countersunk M12 Hex socket bolts to ensure secure connection
and avoid obstructing with the connection of the clamp to tubing. Please make sure
that the M12 Hex socket bolts cannot enter further than 25mm into the mounting
plate.
4) The PEEX tX is water resistant to the level of IP54.
5) To maintain the water resistance rating, the unit should only be mounted vertically
with the cables entering from below. Indoor use allows the device to be mounted in
any orientation.
Use:
6) The PEEX tX is powered from a mains electricity input supply of 100-240 VAC, 50-
60Hz and draws 0.25amps RMS.
7) To connect the PEEX tX to the power supply a powerCon True 1 NAC3FX-W
connector must be fitted to a suitable mains cable capable of easily supporting a
Multiple attachment
points around the
PEEX tX allow for
secure mounting
using cable ties.
Safety harness
attachment point.
Mounting plate suitable
for the attachment of a
range of tube clamps to
fix PEEX tX to lighting
trusses and other typical
infrastructure. M12 Hex
socket countersunk bolts
needed.

PowerChord Group Limited
Registered in England & Wales No. 9303518
Registered Office: 1 Blythe Road, London W14 0HG
maximum amperage of 6 amps. This can then be inserted into the left-side (viewed
from the front) of the powerCon NAC3PX socket located on the underside of the
PEEX tX.
8) If power is to be looped through the PEEX tX to another device, then a powerCon
True 1 NAC3MX-W connector must be fitted to a suitable mains cable capable of
easily supporting a maximum amperage of 6 amps. This can then be inserted into
the right-side of the powerCon NAC3PX socket located on the underside of the PEEX
tX.
Figure 2. The PEEX PWR-100154 Transmitter Cable Sockets
9) The PEEX tX is designed to be connected to the PEEXNet network via Ethernet and
will not function as a radio transmitter without connection to the PEEX muX
Multiplexer. Please see ‘PowerChord –PWR 100101 User Guide’ for further details.
10) To connect the PEEX tX to the PEEXNet network, RJ45 sockets are located adjacent
to the powerCon socket. Suitable Ethernet cable, capable of supporting 100base-T
networking, can be inserted into either one of these sockets.
11) If the Ethernet is to be looped through the PEEX tX to another device, then suitable
Ethernet cable, capable of supporting 100base-T networking, can be inserted into
the free socket.
12) The front panel of the PEEX tX Transmitter has a 4-segment LED display with four
buttons below it. The display shows either the value being entered for the device ID
or the distance value being entered. This is achieved by using the four buttons
below the display:
i) Mode / Esc –used to toggle between the two tX setup modes and escape the
manual setup mode.
ii) Up / Down –used to enter values for either device ID or distance.
iii) Enter –used to confirm a value entered for either device ID or distance.
iv) ID entry –used to manually enter a device ID for the PEEX tX. This is also
automatically assigned on connection with the PEEX muX.
v) Distance entry –used to enter a distance in meters that the device is located with
respect to the nearest stage speaker. This is used to create the early estimate of
audio delays required to properly synchronise the acoustic and digital sound sources.
powerCon NACPX
socket. Power input
and loop through.
Shows sealing covers
in place.
RJ45 Network
sockets. Used to
connect Ethernet and
loop through
Ethernet.

PowerChord Group Limited
Registered in England & Wales No. 9303518
Registered Office: 1 Blythe Road, London W14 0HG
Figure 3 The PEEX PWR-100154 Transmitter Front Panel Controls and Screen
Status:
13) The PEEX tX provides status information via the LEDs and the 4-segment LED display.
14) Green LED lights, adjacent to the two RJ45 Ethernet connectors, are visible from the
front side view of the PEEX tX and show network connection status and flash in
sympathy with data flow.
15) A green LED is located just above and to the right of the 4-segment display and
indicates that power is available to the device.
16) Two other LEDs are mounted above the display, but are not currently used.
17) All other statuses are only available via the PEEX muX Multiplexer –see separate
document.
Care:
18) To keep your PEEX tX clean, use a damp cloth to remove any marks and then dry
thoroughly. Do not immerse in water.
19) Regularly check the cable sockets to ensure that no debris has entered the sockets.
Use the attached rubber seals for each socket whenever they are not in use.
Green LED indicates
power on status.
Red and Green LEDs.
Not used currently
and not illuminated in
normal operation.
2 x Green LEDs flash
in sympathy with
network traffic on the
two Ethernet ports.
Enter button used to
verify data entry for
device ID and distance.
Up and Down buttons to
increment and
decrement device ID and
distance numbers.
Mode / Esc button to
toggle between ID
and distance modes
and to escape manual
setup mode.
4-Segment LED
display.
