Powerdiverter 3 User manual

Quick Install Guide
UK

Model 3

Inputs & Outputs
Mains Power
Input
Power Out
Heating Element
Power Sensor
Smart Switching

Hard Wire CT Input
•New Onboard CT Input
•New and Improved CT
Clamps with 5M Cable
•CT Extender Cables
Available - 5M
•Jumper should be on
Pins 1 & 2 As Shown
New CT Clamp Input

Wireless Sensor Option
•Turn Power Off
•Put Jumper on to Pins 2 & 3 As Shown
•Make Sure Your CT Is Correctly Fitted
Into The Wireless Sensor
•Power Up Wireless Sensor
•Power Up Powerdiverter
•Press and Hold EasyBoost Button Until
the Green Light Flashes Rapidly

The Clock
•Unlock Clock By
Pressing The C/R Button
4 Times
•The D+ Button Sets the
Day
•The H+ Button Sets the
Hour
•The M+ Button Sets the
Minutes
•P Button Sets Boosting
Schedule
•The C Button Resets
the Clock
•Use The Manual Boost
Button to Either Always
On, Auto (Powerdiverter will
boost during the Scheduled
Periods Selected) or Off
which means the
Clock Will Not Boost.

Easy Boost
