Powerleap PL-K6-III/98 User manual

POWERLEAPPL-K6-III/98
Pentium

CPU Upgrade Kit
!"
Intel Pentium (P54C) and Pentium w/MMX Technology (P55C)
!"
AMD K6, K6-2, and K6-III
!"
Cyrix/IBM 6X86, 6X86L, 6X86MX, and MII
!"
IDT C6 and WinChip2
Version 1.xx

Copyright 1999 PowerLeap Products, Inc.
All Rights Reserved.
March 1999
The information in this document is subject to change without prior notice in order to improve
reliability, design and function and does not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential
damages arising out of the use or inability to use the product or documentation, even if advised of the
possibility of such damages.
Product names mentioned herein are used for identification purposes only and may be trademarks
and/or registered trademarks of their respective companies.
This product employs patented technology (Japanese Registered Utility Model No. 3042946).
Visit our web site at:
http://www.powerleap.com
Some Commonly Used Abbreviations
This manual uses the following abbreviations and acronyms.
MMX: Multimedia Extension
P54C: Intel Pentium CPU
P55C: Intel Pentium with MMX CPU

Table of Contents i
PowerLeap™Installation Guide
Table of Contents
Introduction 1
About the MMX

Technology__________________________ 1
About the 3DNow!

Technology _______________________ 1
Special Features_____________________________________ 2
What You Have ______________________________________ 2
The PowerLeap™PL-K6-III/98 3
Quick Start: CPU Settings _____________________________ 3
SW1 Settings: Clock Multiplier, CPU Voltage, and CPU
Overheating Protection____________________________ 8
SW1: Pins 1, 2, & 3 (Clock Multiplier) 8
SW1: Pins 4, 5, 6, 7, & 8 (Core Voltage) 9
SW1: Pin 10 (CPU Overheating Protection) 10
Installing the CPU Upgrade Board 11
Before Installation __________________________________ 11
Installation_________________________________________ 12
Technical Reference 21
SW1: Core Voltage Settings __________________________ 25
Downloading PowerLeap Software 27

ii Table of Figures
PowerLeap™Installation Guide
Table of Figures
Figure 1. The PL-K6-III/98__________________________________11
Figure 2. Removing the existing CPU and CPU cooling fan _________13
Figure 3. Sliding the CPU onto the CPU plate ____________________14
Figure 4. Tightening the hex nuts______________________________15
Figure 5. Inserting the CPU into the upgrade board________________16
Figure 6. Checking the DIP switch settings ______________________17
Figure 7. Installing the CPU upgrade board into the ZIF socket ______18
Figure 8. Locking the CPU upgrade board into the ZIF socket _______19
Figure 9. Connecting the power cable __________________________20

Introduction 1
PowerLeap™Installation Guide
Introduction
Your PowerLeap™ PL-K6-III/98 CPU upgrade board allows Pentium Socket 5
and Socket 7 systems to take advantage of the latest 3DNOW! & MMX CPU
technology from AMD, Intel, Cyrix, and IDT.
The CPU upgrade board employs patented technology to adapt Socket 5 and Socket
7 systems to the voltage and pinout requirements of this new generation of
processors. It provides an upgrade solution that would otherwise require the
replacement of the motherboard.
About the MMXTechnology
Intel’s MMX technology extends the performance of Pentium processors with 57
new instructions, a 32K L1 cache, four new 64-bit data types, and more. For
multimedia and communications applications, MMX can significantly enhance
audio/video playback and image processing. MMX technology is compatible with
a wide range of existing operating systems (including MS-DOS, Windows, OS/2,
and UNIX) and 16/32-bit applications.
About the 3DNow!Technology
AMD’s 3DNow! technology is an innovative group of 21 new instructions for the
x86 architecture that brings powerful performance enhancements for multimedia
and floating-point-intensive applications. With 3DNow! technology, applications
can achieve more detailed 3D imaging, faster frame rates for video playback, and
dramatic improvements in audio. 3DNow! technology appears in the AMD K6-III
& K6-2 processor and works with all existing operating systems and x86
applications.

2 Introduction
PowerLeap™Installation Guide
Special Features
PowerLeap PL-K6-III/98 offers the following advanced features:
#" Supports both Socket 5 and Socket 7 Pentium systems’ MMX-Enabled CPU
upgrade
#" Supports Intel Pentium, Pentium w/MMX, AMD K6, K6-2, K6-III,
Cyrix/IBM 6x86L, 6x86MX, MII, IDT C6 and WinChip2 CPUs
#" Provides chip-for-chip replacement, with no software drivers to install
#" Employs the patented IPS (Independent Power Source) technology, which
provides pure, abundant, and durable power to the V/Core of split-voltage
type CPUs
#" Supports AMD K6-III w/Internal 1:1, 256-KByte L2 cache
#" Includes switching VRM (Voltage Regulating Module) circuitry
#" Provides large on-chip 64KB L1 cache (AMD K6, K6-2, K6-III, Cyrix/IBM
6x86MX, MII, IDT-C6, and WinChip2) or 32KB L1 cache (Intel Pentium
w/MMX) for high-performance implementation
#" Offers a unique CPU overheating protection function
#" Delivers the most cost-effective MMX CPU upgrade solution
What You Have
Your PowerLeap™ PL-K6-III/98 CPU upgrade kit includes the following items:
#" The PowerLeap™ PL-K6-III/98 upgrade board
#" Power connector cord
#" PowerLeap™ Utility Diskette (CPU Control Panel software)
#" CPU cooling fan & heatsink

The PowerLeap™PL-K6-III/98 3
PowerLeap™Installation Guide
The PowerLeap™ PL-K6-III/98
This chapter describes setting the clock multiplier and voltages for your
PowerLeap PL-K6-III/98 CPU upgrade board.
Quick Start: CPU Settings
This section shows how to use the SW1 DIP switch to choose the correct clock
multiplier and voltages for your new Intel, AMD, IDT, or Cyrix/IBM processor.
Intel CPU SW1 Settings
Pentium-166 (66/2.5x) ON
12345678910
Pentium-200 (66/3.0x) ON
12345678910
Pentium w/MMX-166 (66/2.5x) ON
12345678910
Pentium w/MMX-200 (66/3.0x) ON
12345678910
Pentium w/MMX-233 (66/3.5x) ON
12345678910

4 The PowerLeap™PL-K6-III/98
PowerLeap™Installation Guide
AMD K6 CPU SW1 Settings
K6-166 (66/2.5x) ON
12345678910
K6-200 (66/3.0x) ON
12345678910
K6-233 (66/3.5x) ON
12345678910
K6-266 (66/4.0x) ON
12345678910
K6-300 (66/4.5x) ON
12345678910
AMD K6-2 CPU SW1 Settings
K6-2 /266 (66/4.0x) ON
12345678910
#K6-2 /266 (75/3.5x)
ON
12345678910
K6-2 /300 (66/4.5x) ON
12345678910
#K6-2 /300 (75/4.0x)
ON
12345678910
K6-2 /333 (66/5.0x) ON
12345678910
#K6-2 /333 (75/4.5x)
ON
12345678910
K6-2 /366 (66/5.5x) ON
12345678910
# For systems with an external clock speed faster than 66MHz.

The PowerLeap™PL-K6-III/98 5
PowerLeap™Installation Guide
AMD K6-2 CPU SW1 Settings
#K6-2 380 (75/5.0x)
ON
12345678910
K6-2 400 (66/6.0x) ON
12345678910
#K6-2 450 (75/6.0x)
ON
12345678910
# For systems with an external clock speed faster than 66MHz.
AMD K6-III CPU SW1 Settings
K6-III 400 (66/6.0x) ON
12345678910
#K6-III 450 (75/6.0x)
ON
12345678910
# For systems with an external clock speed faster than 66MHz.
IDT CPU SW1 Settings
C6 MMX-180 (60/3.0x) ON
12345678910
C6 MMX-200 (66/3.0x) ON
12345678910
#C6 MMX-225 (75/3.0x)
ON
12345678910
C6 MMX-240 (60/4.0x) ON
12345678910
# For systems with an external clock speed faster than 66MHz.

6 The PowerLeap™PL-K6-III/98
PowerLeap™Installation Guide
IDT CPU SW1 Settings
#WinChip2-225 (75/3.0x)
ON
12345678910
WinChip2-240 (60/4.0x) ON
12345678910
#WinChip2-250 (83/3.0x)
ON
12345678910
WinChip2-266 (66/4.0x) ON
12345678910
#WinChip2-300 (75/4.0x)
ON
12345678910
# For systems with an external clock speed faster than 66MHz.
Cyrix/IBM 6x86L CPU SW1 Settings
6x86L-P150+ (60/2.0x) ON
12345678910
6x86L-P166+ (66/2.0x) ON
12345678910
#6x86L-P200+ (75/2.0x)
ON
12345678910
# For systems with an external clock speed faster than 66MHz.

The PowerLeap™PL-K6-III/98 7
PowerLeap™Installation Guide
Cyrix/IBM 6x86MX CPU SW1 Settings
6x86MX-PR166GP (60/2.5x) ON
12345678910
6x86MX-PR200GP (66/2.5x) ON
12345678910
#6x86MX-PR200GP (75/2.0x)
ON
12345678910
6x86MX-PR233GP (66/3.0x) ON
12345678910
#6x86MX-PR233GP (75/2.5x)
ON
12345678910
#6x86MX-PR266GP (83/2.5x)
ON
12345678910
# For systems with an external clock speed faster than 66MHz.
Cyrix/IBM MII CPU SW1 Settings
MII-300GP (66/3.5x) ON
12345678910
#MII-300GP (75/3.0x)
ON
12345678910
#MII-333GP (75/3.5x)
ON
12345678910
# For systems with an external clock speed faster than 66MHz.

8 The PowerLeap™PL-K6-III/98
PowerLeap™Installation Guide
SW1 Settings: Clock Multiplier, CPU Voltage, and
CPU Overheating Protection
This section shows the SW1 clock multiplier and voltage settings for Intel, AMD,
Cyrix/IBM, and IDT CPUs. To reduce power consumption, dual-voltage CPUs
use two separate supply voltages: an I/O interface voltage and a lower core voltage
for the processor.
SW1: Pins 1, 2, & 3 (Clock Multiplier)
Pins 1, 2, & 3: Clock Multiplier for P55C, K6, K6-2, K6-III, 6X86MX, MII
(Dual-Voltage), C6, WinChip2, and P54C (Single-Voltage)
CLKMUL 6x 5.5x 5x 4.5x 4x 3.5x 3x 2.5x
SW1: Pin 1 ON OFF OFF ON ON OFF OFF ON
SW1: Pin 2 OFF OFF ON ON OFF OFF ON ON
SW1: Pin 3 OFF ON ON ON ON OFF OFF OFF
Pins 1 & 2 : Clock Multiplier for 6X86 (Single-Voltage) and 6X86L (Dual-Voltage)
CLKMUL 2x
SW1: Pin 1 ON
SW1: Pin 2 OFF
SW1: Pin 3 OFF

The PowerLeap™PL-K6-III/98 9
PowerLeap™Installation Guide
SW1: Pins 4, 5, 6, 7, & 8 (Core Voltage)
Pins 4, 5, 6, 7, & 8: Core Voltage for Pentium P54C/P55C, AMD K6/K6-2 /K6-III,
IDT C6/WinChip2, and Cyrix/IBM 6X86/6X86L/6X86MX/MII
Core
Voltage 3.5V 3.3V 3.2V 2.9V 2.8V 2.4V 2.2V
CPU
TYPE
C6
WinChip-2
P54C
6X86
K6-233 K6-200
6x86MX
MII
P55C
6X86L
K6-2/450
K6-III
K6-266
K6-300
K6-2
SW1: Pin 4 ON ON OFF ON OFF OFF OFF
SW1: Pin 5 ON OFF OFF OFF OFF OFF ON
SW1: Pin 6 ON ON ON OFF OFF ON OFF
SW1: Pin 7 ON ON ON ON ON OFF OFF
SW1: Pin 8 OFF OFF OFF OFF OFF OFF OFF
* Note the actual voltage printed on the CPU label.
For systems with an external clock speed of less than 66MHz
(50MHz or 60MHz), there may be a slight performance
sacrifice for your new CPU. For example, changing to a
K6-166 from a Pentium-75 will result in a system upgrade
speed of 150MHz (not 166MHz). In this case, you can get
improved performance by adjusting the external clock speed
to 66MHz.

10 The PowerLeap™PL-K6-III/98
PowerLeap™Installation Guide
SW1: Pin 10 (CPU Overheating Protection)
The CPU upgrade board offers a unique CPU overheating protection function that can
prevent damage to your CPU if the temperature increases. When this function is
enabled, the CPU speed will automatically drop 60% if the CPU temperature
reaches 70°C or higher. This prevents the CPU from overheating.
CPU Overheating Protection
SW1: Pin 10 CPU Overheating Protection
ON Enabled
OFF Disabled

Installing the CPU Upgrade Board 11
PowerLeap™Installation Guide
Installing the CPU Upgrade Board
This chapter describes installing your CPU upgrade board.
Before Installation
Prior to starting installation, take your CPU upgrade board from its packing and
remove the protective foam pad, taking care not to damage the pins. If the package
includes a CPU cooling fan & heatsink, remove it too.
Figure 1. The PL-K6-III/98

12 Installing the CPU Upgrade Board
PowerLeap™Installation Guide
To compare the performance increase provided by the PL-K6-III/98 CPU
upgrade board, we suggest running the PowerLeap CPU Control Panel®both
before and after installation. If you are uncertain about the speed of your existing
CPU, you can determine the speed by running the PowerLeap CPU Control
Panel®.
Installation
If your package came with a CPU cooling fan & heatsink, install the CPU upgrade
board as follows.
$To install the CPU upgrade board:
1. Place your computer where you will have plenty of space to work.
2. Turn the computer off and disconnect all power cords and cables from
the rear of the computer.
3. Remove the cover from the computer (as described in the computer
documentation).
4. Locate your existing CPU on the computer’s motherboard. The CPU will be
clearly labeled with the manufacturer’s name (such as “Intel”), and markings
identifying the CPU model and speed (such as Pentium-75).
5. Remove the existing CPU cooling fan.

Installing the CPU Upgrade Board 13
PowerLeap™Installation Guide
6. Remove the existing CPU from the ZIF socket.
Figure 2. Removing the existing CPU and CPU cooling fan
7. Hold the provided CPU cooling fan & heatsink so that the CPU plate faces
upward.
8. Loosen the hex nuts at each corner of the CPU cooling fan. You should be able
to freely move the CPU plate up and down.

14 Installing the CPU Upgrade Board
PowerLeap™Installation Guide
9. Turn your new CPU over (so that the pins are facing upward) and slide it under
the grooves at the sides of the CPU plate.
Pin 1
Pin 1
Power
Power
Cable
Cable
Figure 3. Sliding the CPU onto the CPU plate
Pin 1 of the CPU must occupy the corner diagonally opposite
the fan’s power cable. If necessary, remove the CPU from the
CPU plate and insert it again, with pin 1 in the correct
position.

Installing the CPU Upgrade Board 15
PowerLeap™Installation Guide
10. Tighten the hex nuts. The CPU should be firmly attached to the CPU plate.
Figure 4. Tightening the hex nuts

16 Installing the CPU Upgrade Board
PowerLeap™Installation Guide
11. Turn the CPU cooling fan & heatsink over and insert the CPU into the upgrade
board, making sure that pin 1 of the CPU corresponds to pin 1 of the
upgrade board. Be sure the CPU is firmly seated in the board.
Pin 1
Pin 1
Figure 5. Inserting the CPU into the upgrade board
